Dualtron MAN User manual

60V Max 2700W BLDC HUBLESS Foot Scooter
User manual
DualtronMan

Checklist before use
Contents
This manual includes everything the users need to care.
Please read the manual carefully before use.
Please contact the seller for technical support.(www.dual-tron.com)
- Contents of the box : DUALTRONMAN, Charger, Manual and warranty card
01
Open the box and remove the protection styrofoam on the product first.
DUALTRONMAN(Electric WHEELMAN) is 33kg and it is enough to lift for the adult. However,
it is recommendable to prepare before lift to prevent damage on the muscle and put your
hands to the hole of the DUALTRONMAN(Or hold thick rubber parts of the align bar) and lift.
Please keep the product box to use when you send product for the repairing service.
02
03Introduction
04Cautions
05Preparations before use
07Product description
08Driving parts of the system
09Control parts description
10 How to use remote control assembly
11 Dashboard setting
12 Battery charging
13 Product specifications
14 Safety tips for riding
15 Start riding
16 General safety guidelines and restrictions
17 Use and care tips: Lithium-ion battery
18 Important information before riding
19 Warranty

DUALTRONMAN(Electric WHEELMAN) user manual | 3
Product
introduction
Thank you for your purchasing our product.
DUALTRONMAN(Electric WHEELMAN)is for leisure activity and it is an extreme electric foot scooter
which provide environmentally friendly product as it uses lithium battery.
DUALTRONMAN(Electric WHEELMAN) has maximum 2700W of motor output power and it provides
powerful torque with a silent and stable power which the users who enjoy trick also can be satised. As
it can be different according to the user’s weight or driving condition, you can ride with maximum speed
65km/h and cover 100km of distance. In addition, it has high torque and can climb around 50% of degree.
Enjoy your riding with the high efciency electric brake system and cruise control mode.
DUALTRONMAN(Electric WHEELMAN) will give you a new experience as if you are snowboarding.

4| DUALTRONMAN(Electric WHEELMAN) user manual
!
Warning
Danger of death or serious injury
When you ride the product, there is danger of death or serious injury from losing control, collision, falling down. For a safety
riding, the user should read manual carefully and follow.
While riding, rider should always wear protective equipments such as a safety helmet, kneepads, elbow pads, and gloves before
riding. For safety riding, it is recommended to avoid a rainy day, a wet road, a slippery or rough road, a steep slope, a highway, a
broken road, a track or a road if there is obstacles can make falling down on the road. And don’t ride in the poor visibility or narrow
area as an indoor or a parking lot.
Warning : Every DUALTRONMAN(Electric WHEELMAN) is manufactured with a strict quality checking but it is a
essential to do check a hook rubber, bolt & nut, tire pressure, brake and if there is any strange noise
when it is idling by itself before riding for safety riding.
Be careful water!
DUALTRONMAN(Electric WHEELMAN) is not waterproof. Electric system, motor, bearing and the other parts can get
damage and it can be the cause of malfunction or fire. The warranty does not cover if DUALTRONMAN is damaged by
water.
Be careful the point can be caught in!
Be careful the rolling parts as a tire and wheel disk as a finger or a hair can be caught in. A cloth or shoes string also
can be caught in.
Be careful electric shock!
Don’t open or adjust electric system(controller, battery, motor). Malfunction or fire can be occurred and the warranty
does not cover in this case.

DUALTRONMAN(Electric WHEELMAN) user manual | 5
Preparations
before use
- Always wear a full face helmet, gloves and knee, elbow, back born, shoulder pad when riding.
- For the first riding, learn the function at the open, flat and clean space.
- Before riding, read carefully about warning and maintenance in this manual.
- Don’t wear shoes as a slipper, a high hill, sports shoes that have long string during riding for
safety riding.
- For safety riding, DUALTRONMAN(Electric WHEELMAN) is designed for both stance regular(Left
foot is front) and goofy(Right foot is front). The default factory setting is for regular as there are
regular riders are much more than goofy riders. The goofy riders need to change hook connector
as it can be difficult to balance for goofy riders with default setting. If you want to check your
riding stance, try to stand on the long board naturally. If your left foot is front, set the hook
connector on the right side, if your right foot is front, set the hook connector on the left side.
Regular Style : Left foot is front Goofy Style : Right foot is front
01
02
Prepare safety
gear
Stance of user

6| DUALTRONMAN(Electric WHEELMAN) user manual
Preparations
before use
It is easy to learn how to ride DUALTRONMAN(Electric WHEELMAN) but you need to consider
something before riding.
- Firstly, find your preference stance between regular and goofy.
- Put the DUALTRONMAN(Electric WHEELMAN) on the ground to make its side pad which is on the
same way with the hook connector meets the ground.
- Hold rail, wall or hand of the helper and put your foot to center of each front and rear tire.
- From the front foot, make shin tight to the device and push the footpad with the heel to make the ankle
around 90 degree and stand the front wheel up.
- As same as the front foot, put the footpad with the heel and make shin tight to the device. And make
ankle around 90 degree and ride with throttle and brake during stand the rear wheel up. (Refer to the
How to use remote control assembly)
- If you put your feet too much or too little, the stance can be not correct.
- During riding, never lie down the front wheel to avoid falling down.
- To move to left or right slowly, open or close your feet slowly.
- Whether if it is a slow speed or high speed, there can be occurred ‘Speed Wobble’ in the unstable
stance. High speed riding can be dangerous before learning the stable stance.
03
04
Safety gear
Basic riding skill
and safety riding
It can be different for the riding condition and rider’s preference, however, it is recommended to wear
the all of the safety gear as full face helmet, elbow pad, knee pad, riding glove, back born pad and
shoulder pad.

DUALTRONMAN(Electric WHEELMAN) user manual | 7
Product description
Main power
Charging port(3P)
Auxiliary battery connecting
port(4P)
LED light button
Up button
Dashboard
power
Down button
Acceleration
throttle lever
Brake lever
Electric brake sensitivity
adjusting sensor
Brake cable
Remote
control grip
Connecting hose
Align bar
Front pad Rod end bearing
15” tire
Non-slip sheet
Side pad
Foot pad
Hook rubber LED headlight
LED light button
Auxiliary battery connecting port
Charging port
Main power
Battery part
Side pad
Foot pad
Non-slip sheet
Brake mount
Driving motor part
Brake caliper
LED taillight
Rear pad
LCD dashboard
Hook connector

8| DUALTRONMAN(Electric WHEELMAN) user manual
Driving parts of
the system
External auxiliary battery
Auxiliary battery
carrier
Selectable additional option
Installing external auxiliary battery
Motor
Bearing
* The specification of the external battery
and design of the carrier can be changed
without notice to improve product quality.
Internal main
battery

DUALTRONMAN(Electric WHEELMAN) user manual | 9
Control parts
description (1) Main power The ‘I’ means main battery power ON status.
The ‘O’ means main battery power OFF, however the ‘O’
is auxiliary battery ON status then it is connected. The
auxiliary battery should be removed when you don’t use
the product.
(2) Charging port The port to charge internal main battery..
(3) Auxiliary battery connecting port The port to connect
extra auxiliary battery.
(4) LED light button Turn on and off the front and rear LED light.
Variety setting can be set include motor output power and
electric brake. (Refer to the 11page for the detail)
One hand remote control which can accelerate and
decelerate with one hand.
(1) Up button
(2) Dashb o a r d
power
(3) Down button
(1) Main power
(2) Charging port(3P)
(3) Auxiliary battery
connecting port
(4) LED light button
A
A Power, Charging, LED control panel
B
Controller setting dashboard
C
Remote control set
(1)Acceleration
throttle
(2) Brake lever

10 | DUALTRONMAN(Electric WHEELMAN) user manual
How to use remote
control assembly
One hand remote control grip Hold the grip on the handle bar to control; accelerate and brake.
Use throttle Rotation times of the motor can be increased and decreased with the throttle lever
squeezing. As it is very sensitive, slow and mild acceleration is recommended.
Use Brake Hold brake lever to decelerating to decelerate and stop. A rapid decreasing is
forbidden as it is dangerous.
Use electric brake sensitivity adjusting sensor The electric brake works even though you squeeze
slightly. You can adjust its working point with electric brake sensitivity adjusting sensor nut on the
brake lever.
Throttle lever for acceleration
Brake lever for
deceleration and stop
Electric brake sensitivity
adjusting sensor
Brake cable
Hose
Remote control grip

DUALTRONMAN(Electric WHEELMAN) user manual | 11
Dashboard setting
(1) Up button
(2 Dashboard
power
(3) Down
button
- Press the (2)On/Off while the main power switch ON(I) and can
check default screen with time, ODO, RPM and ETC.
- Speed can be adjusted with (1),(3) button when it is default screen.
- User setting can be set with pressing (1), (3) button
simultaneously. (P0~P11)
- Turn off the dashboard power with long pressing (2) button and
then turn off(O) the main switch for storage.
- Turn the main power off(O) and remove the auxiliary battery for
storage.
Status No Default setting Description Note
P
015 Tire size setting Fixed
145 Voltage setting Fixed
220 Magnetic quantity Fixed
30 Speed sensor setting
40 Kilometer : 0 / Mile : 1
50 Throttle start : 0 / Kick start : 1
60 Cruise mode set : 1 / None : 0
70 Slow start : 0 / Power start : 1
80 No function
90 No function
10 100 Max speed 1~100%
11 2
Electric brake 0:None, 1:Medium, 2:hard
* Never change the default setting of P0, P1, P2.
* As it is difficult to handle in an emergency situation, cruise mode should be used in a safety riding condition.
* You can cancel the cruise mode with squeezing brake or accelation lever a little.
* You can find detail information
from the Minimotors global
website(http://dual-tron.com)

12 | DUALTRONMAN(Electric WHEELMAN) user manual
Battery charging
- Connect charger to the charging port correctly.(If the direction is wrong or use too much power, port
can be damaged and the battery and charger can be broken due to short.
- Connect the power plug of the charger to the consent.
- It needs around 16hours if it is completely discharged on EX+ 60V 31.5A battery.
(If you use high speed charger which is additional selectable option, 3 times faster.)
- The red lamp means charging, the green lamp means charging is done.
- Disconnect the charger after charging is done.
- Don’t use and inquire to the seller if the lamp on the charger doesn’t work or if there is damage on the
cable.
- The charger should be used indoor and it is forbidden to use in the place wet or hot.
- Don’t tune the charger or use other charger not genuine.
- To use charger safely, read manual carefully before use the charger.
01
02
How to charge
How to use charger correctly
Warning : Use only DUALTRONMAN genuine charger and additional selectable option speed
charger. If you use other charger, it has danger of fire and explosion.
!
Cautions when storage
the product after riding
Is the power off?
When you store the product,
the main power switch should
be on O to off the power.
Is the auxiliary battery
disconnected?
After riding, turn off the main
power and auxiliary connected
battery should be disconnected
after charging.
Is it a suitable place to
store?
Don’t store or charge the device
or auxiliary battery in the place
wet or hot. (Avoid a direct ray of
light and car trunk in Summer)
How to do long time
storage?
If you would like to storage more
than one month, the battery
should be charged before
storage. (Refer to the General
safety guidelines and restrictions
and Use and care tips: Lithium-
ion battery)

DUALTRONMAN(Electric WHEELMAN) user manual | 13
Product
specifications
Product Name DUALTRONMAN Electric WHEELMAN
Motor MAX 2700W BLDC HUBLESS MOTOR (Silent wheel drive with big bearing drive system)
Model MX EX EX+ Li-ion battery(EX-Li-Polymer)
Capacity 60V 1,065Wh 60V 1,540Wh 60V 1,864Wh 18A / 26A / 31.5A
Weight 33kg 32.5kg 33kg Flame: 25.5kg / Battery: 7.5kg(EX+)
Charging 9hr± 13hr± 16hr±
Standard 2A charger base
/ Can be different due to battery status
(If you use optional quick charger, 3 times faster)
Range Max 100-110km
EX+ battery, 70kg loaded, 25℃ atmosphere
temperature
20km constant drive on flat road
Speed Max 65km/h 70kg loaded, 67.2V max charged
Gradability 50% (Climb ability 26˚) Gradability can be different due to riders weight,
road condition, battery status, temperature
Max load 140kg Under 120kg is recommendable
Brake Rear disk brake and electric brake
(Two brakes work simultaneously)
Auto recovery charging system applied when
brake lever works. : max charging current around
5A(World first and biggest efficiency)
Cooling control
system
Cooling heat control system
only for DUALTRONMAN
Cooling maximize system is applied for stable
working of controller
Dashboard LCD multi functional dashboard Battery remains, TRIP, ODO, Time, Speed, Voltage
and user selected function
Product size 1085 x 300 x 430mm Front width(FW) x Length(L) x Rear width(RW)
Tire Front and rear Taiwan Chungshin
Offload tube tire
Onload tire can be replaced(Will be release)
(Offload tire is default)
Material Flame-Full aluminum alloy, Aluminum forged alloy(6082-T6) / Cowl-Polycarbonate
* Parts and specification can be changed to improve products quality and safety.
* The range on the specification is checked on the following conditions. (70kg loaded, flat road 20km/h constant riding) Riding performance can
be different with the riding condition.
* Range can be affected due to the loaded weight, atmosphere temperature, wind direction(wind speed), road condition, gradient and tire condi-
tion.
1085mm
H 430mm
300mm

14 | DUALTRONMAN(Electric WHEELMAN) user manual
Safety tips
for riding
Precautions while
riding
DUALTRONMAN(Electric WHEELMAN) is a device for leisure sports. As every device for leisure sports
needs to be mastered with practicing and balancing, there are some special safety cautions to do.
DUALTRONMAN(Electric WHEELMAN) is a device only for one person riding and it is an extreme device
for the outdoor activity. Don’t ride at closed place as indoor or parking lot. Ride only in a good field of
vision or day time. Don’t interrupt the transit of the other people or cars.
Before and after riding, always check if there is big damage on the hook rubber which is steering part.
The user needs to check if there is any play or a crack on the align bar and if there is some loosen bolt
or nut, the air pressure of the tire is acceptable (35~40psi), the brake work well, if there is any strange
sound when motor is idling. It is essential to check to avoid accident. If there is any problem, stop using
immediately and check the device with the seller or a service center.
DUALTRONMAN(Electric WHEELMAN) need to be managed in a wet or a cold weather. 0~45 degree of
the temperature is recommendable) If it is windy or rainy too much.
01
02
03
One person riding and place for riding
Tire air pressure check and maintenance
Avoid riding on a rainy day or humid day
!
- Follow the law and
regulations of the country in
which you intend to use it.
- Be careful of pedestrian
or car. Avoid riding at the
crowded place.
- Don’t park at the place can
block the pedestrian or car.
It can be cause of the safety
issue.
- Don’t ride on the crosswalk.
For safety, carry the
product when you cross the
crosswalk.
- Keep the safety distance
when ride with other riders.
- Keep the safety distance
can discriminate obstacles
and dangerous things on the
road.
- Riders should ride at the safe
place with wearing safety
gears.

DUALTRONMAN(Electric WHEELMAN) user manual | 15
Start riding
Step1
Ready
Put the device down on the flat
surface.
Step2
Power on
Turn on the main power and set the
suitable speed at the dashboard
setting.
Step3 Stance
Hold Remote control assembly lightly
and set your stance goofy or regular.
Lay down the side pad same way to
the hook connector.
Step6
Deceleration and stop
To decelerate and stop, pull the brake
lever. Stop the operation of the motor
and lay down rear foot naturally
to side pad touch the ground to
decrease speed.
Step5
Speed up
Front wheel should be stand to the forward way and pull the acceleration throttle on the
Remote control assembly to speed up.
Step4
Balancing
Hold rail, wall or hand of the helper and put your
foot to center of each front and rear tire. From the
front foot, make shin tight to the device and push the
footpad with the heel to make the ankle around 90
degree and stand the front wheel up. As same as the
front foot, put the footpad with the heel and make
shin tight to the device. And make ankle around 90
degree and stand the rear wheel up.

16 | DUALTRONMAN(Electric WHEELMAN) user manual
General safety guidelines and restrictions
- Never carry passengers or allow more than one person at a time to ride the scooter.
- Novice riders need to practice how to operate the scooter in the safe place.
- Stop the scooter with the brakes when unexpected obstacles suddenly show up. Never use your foot to stop the scooter.
- Store the battery fully charged. Discharged battery may shorten the life of battery.
- When you store the battery for a long time more than three months, store the battery not fully charged under 80~90% at
dry and low-temperature.
- If the battery is damaged, the battery emits an unusual smell, or the battery leaks, stop us ing the product, contact the
authorized service center immediately and get technical supp ort.
- Put the battery in a safe place out of the reach of children and pets.
- Use of an unauthorized charger could cause serious damage to the battery and circuit.
- When the product is waterlogged, Never charge the battery and contact the seller for insp ection.
- Never ride the scooter in wet or icy weather and contact the seller for inspection when your scooter gets wet.
- Always wear protective equipment, such as an approved safety helmet, kneepads, elbow pads, and gloves before riding.
- Never drink and drive. Do not ride the scooter with barefoot or wearing high heels, open toed shoes and sandals.
- Check the brake for proper function before each ride. When the brakes do not function properly, inspect the brakes and
reserve brake power by adjusting the brakes.
- Always check the tires pressure and re-inflate as necessary before open.
If there is any inquiry, don’t hesitate to contact the seller. Thanks.
!

DUALTRONMAN(Electric WHEELMAN) user manual | 17
Use and care tips : Lithium-ion batter
LI-ION
1. Only use the charger that was supplied with your product to charge lithium-ion battery. Use of an unauthorized charger could cause serious
damage to the battery and can cause fire.
2. Charge lithium-ion battery within 0-45℃and discharge within -20-60℃. Charging and discharging the battery not within the appropriate
temperature may dam age the lithium-ion battery.
3. Do not leave lithium-ion battery in any place exposed to direct sunlight or high temperature. Do not store it in wet place. Always store it in dry
place.
4. Charge lithium-ion battery in dry, open, and well-ventilated place. Do not charge the battery near inflammable goods.
5. In the winter, bring the battery from outside to inside, temperatures changed from low to high and this may cause dew condensation. In this
case, do not charge the battery immediately but charge it after reduce temperature difference.
6. If the battery protection circuit is damaged, the battery emits an unusual smell, or the battery leaks, contact the authorized service center
immediately and get technical support.
7. Put lithium-ion battery in a safe place out of the reach of children and pets.
8. Do not reverse the polarity on a battery and short-circuit. Also exposing the battery to excessive shock can result in explosion of battery.
9. Do not do stunts or jumps on the product on bumpy surface. Exposing a battery pack to excessive shock can result in fire on the battery. If
there are some crashes during riding, then you should remove it out of the product to check whether the battery is working well.
10. Connecting the charger when the product is waterlogged, the risk of electric shock and fire is very high. Do not charge the battery in this case
and the battery should be checked by expert before charging.
11. Do not disassemble or incinerate lithium-ion battery. To safely dispose of lithium-ion battery, put it as industrial waste and be careful not
short-circuit occurs in the terminals.
12. If the battery require replacement after long-term use, replace it with new one through the authorized dealer. Normally, the discharge capacity
of lithium-ion battery normally decrease more than 15% after 300 times of cycle use.
13. Do not use the battery if it leaks or gives off an odor, and short-circuit inside the battery pack. Lithium-ion is inflammable material. Avoid
charging the battery wi thout proper care. Be very alert to the time that you have charged the battery to prevent fire.
14. Use only with the authorized and recommended battery and charger. Manufacturer and distributor cannot be held responsible for any damage
of your product by using unauthentic battery and charger.
!

18 | DUALTRONMAN(Electric WHEELMAN) user manual
The important information before riding
- Check features and structure of the product before purchasing.
- Use the product after reading the user manual.
- Keep the products’ box for the repairing service.
- Most products of Minimotors Co. Ltd, are mini motor products and it is classified as an extreme leisure vehicle.
- Extreme leisure vehicle needs to be maintained frequently.
- It’s impossible to exchange or refund the products after assembly or using. Since it is as a car or bike. (However, we solve all the initial problem of the
products.)
- The products can be broken during delivery.
(1) If there is any problem when you check the product after receiving, you have to contact the seller immediately and tell them for exchange or free repairing
service.
(2) If you don’t let the seller know, we can’t recompense or exchange the product as it is impossible to proof the broken products to the logistic company.
(3) If the product is broken during delivery, you have to check with deliveryman or take picture for proof.
(4) You have to let the seller know by the day you received if the product is broken during delivery. The seller does not in charge if you tell them later.
| Delivery information |
- We are trying to sent the product in a day, however, it can be delayed 1~2days
for the late order of holiday order. It needs 1~3 days from the order.
- Some products can’t be delivery together. Please check before order.
- You can pay delivery pee in advance and the amount can be different for each
products.
- The delivery can be delayed if there are too many orders.
- If you order from island or mountain area, seller will call you as delivery cost
can be different.
| Exchange or refund |
- You have to use contracted logistic company to deliver for the initial defect, wrong
delivery, exchange, refund to save the delivery cost.
- If you want refund or exchange, don’t open the box and let us know in 7days that you
want refund or exchange. Exchanging the product is limited for 1 time. If you send the
product without any notice, we will resend it to you.
- If you exchange or refund due to change your mind, you need to pay for the delivery
cost for the going and returning.
- There is an address for return on the bottom of the product warranty card.

DUALTRONMAN(Electric WHEELMAN) user manual | 19
Warranty
1. The warranty covers only the defect occurred due to a manufacturing fault in the warranty period with normal use.
The warranty covers 3months and you need to pay for the repairing after 3months.
2. In this case, you need to pay for the repairing even if it is in warranty period.
- If the malfunction is occurred by user as carelessness, self repairing or tuning.
- If the product is used for the rental business.
- Replacing tire or expendables (ex: Tire, Tube, Brake pad, cables, Gears, Chain, etc)
3. You need to show warranty card when you request repairing.
4. For the repairing, you need to visit the service center and you need to pay delivery cost for the going and returning if you want to use logistics service.
Purchasing date 20 . . .
Store name
Contact No.

MINIMOTORS Co., Ltd.
www.dual-tron.com
