Durabrand CD-208 User manual

IB-CD208(LC)-WM-E-060403
PLAYS REGULAR MUSIC CD DISCS & MP3 ENCODED DISCS
FULLY PROGRAMMABLE PLAYBACK
45 SECOND (CD) & 120 SECOND (MP3) ANTI-SKIP PROTECTION
RECEIVES AM/FM STEREO BROADCASTS
REPEAT ONE AND REPEAT ALL PLAY
FM STEREO AND POWER LED INDICATORS
2 WAY POWER - AC/DC
USES 6 SIZE D BATTERIES (not included)
PORTABLE CD/MP3 PLAYER
WITH AM/FM STEREO RECEIVER
MODEL CD-208
OPERATING INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE USE

IB-CD208(LC)-WM-E-060403
1
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings, install in accordance with the manufacturers
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding-type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12.Unplug this apparatus during lightning storms or when unused for long periods
of time.
13.Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally or has been dropped.
14.This appliance shall not be exposed to dripping or splashing water and that no
object filled with liquid such as vases shall be placed on the apparatus.
IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is
intended to alert the user to
the presence of uninsulated
dangerous voltage within
the products enclosure that
may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER
SERVICEABLE PARTS
INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in
the literature accompanying
the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SEE BOTTOM OF THE SET.
WARNING

IB-CD208(LC)-WM-E-060403
1.Power Sources - The appliance should be connected to a power supply
only of the type described in the operating instructions or as marked on the
appliance.
2.Wall or Ceiling Mounting - The appliance should not be mounted to a wall
or ceiling.
3.Object and Liquid Entry - Care should be taken so that objects do not fall
and liquids are not spilled into the enclosure through openings.
4.Servicing - The user should not attempt to service the appliance beyond
that described in the operating instructions. All other servicing should be
referred to qualified service personnel.
2
ADDITIONAL SAFETY INSTRUCTIONS
Do not apply oil or petroleum products or solvents to any part of this set.
CAUTION
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
This compact disc player is classified as CLASS 1 LASER PRODUCT as
stated on the bottom of the set.

IB-CD208(LC)-WM-E-060403
CAUTION: TO REDUCE THE RISK OF FIRE OR PERSONAL INJURY OR
DAMAGE TO YOUR SET, READ AND FOLLOW THESE INSTRUCTIONS.
1. Use only the type and size of batteries mentioned in the operating instructions
booklet (batteries are not included with this set, please buy the proper batteries).
2. Do not dispose the batteries into a fire. The cells may explode. Check with
local codes for possible special disposal instructions.
3. Do not open or mutilate the batteries. Released electrolyte is corrosive and
may cause damage to the eyes or skin. It may be toxic if swallowed.
4. Be careful when handling batteries in order not to short the battery with conducting
materials such as rings, bracelets and keys. The battery or conductor may
over heat and cause burns.
5. Do not attempt to recharge non-rechargeable batteries. The batteries may
leak corrosive electrolyte or explode.
6. Do not attempt to rejuvenate the batteries identified for use with this product by
heating them. Sudden release of the battery electrolyte may cause burns or
irritation to eyes or skin.
7. All batteries should be replaced at the same time. Mixing fresh and dis-
charged batteries could increase internal cell pressure and rupture the batteries.
8. When inserting batteries into this product, the proper polarity ( and ) or
direction must be observed. Reverse insertion of some or all of the batteries
may result in battery electrolyte leakage or explosion.
9. Remove the batteries from this product if the product will not be used for a long
period of time (several months or more) since during the period the batteries
could leak, damaging the product.
10. Discard weak or dead batteries as soon as possible since they are more likely
to leak in the product. Batteries should be replaced (depending on the product)
when the display gets dim or if the Low Battery Indicator shows or if the sound
gets distorted.
11. Do not store this product in high temperature areas. Batteries that are stored
in a freezer or refrigerator for the purpose of extending shelf life should
be protected from condensation during storage and defrosting. Batteries should
be stabilized at room temperature prior to use after cold storage.
12. If this product does not operate normally, see TROUBLE SHOOTING in this
instruction manual. If you cant resolve the problem, or if the product is damaged,
refer to the LENOXX WARRANTY INFORMATION. Opening or removing
covers may expose you to dangerous voltages or other risks. Incorrect
reassembly can cause electric shock when the appliance is subsequently used.
13. If liquid leaks from the batteries, carefully wipe this liquid. Do not allow it to
touch your skin, and discard the leaking batteries.
14. Do not mix batteries (OLD and NEW or CARBON and ALKALINE, etc.).
15. The use of rechargeable batteries is not recommended for this set because
their voltage and life is lower than standard batteries.
16. Installation of batteries should be done by an adult only.
SAVE THESE INSTRUCTIONS
3
BATTERY SAFETY INSTRUCTIONS

IB-CD208(LC)-WM-E-060403
You can use the AC power or batteries as a power source.
4
To a wall outlet
Replace all the batteries
with new ones when the
POWER lamp dims or
the player stops
operating. Before you
replace all the batteries,
be sure to take out the
disc from the player and
remember to check the
Battery Safety Instructions
on Page 3.
If the discs do not play
on batteries, this means
the batteries are almost
used up. But the radio
may continue to play on
these weak batteries
because it uses less
power than the disc
player.
TIP: 1. Connecting the AC power
Insert one end of the supplied AC power cord into
the socket located at the rear of the set, and the
other end into the 120V standard household outlet.
2. Using the player on batteries
Remove the AC plug from the back of the set and
wall outlet, then insert 6 size D batteries (not
supplied) into the battery compartment as shown.
Observe (+) and (-) polarities.
BATTERY DOOR
(on the bottom of the set)
CHOOSING THE POWER SOURCES
Install Batteries
as illustrated
NOTE: The polarized
plug has two blades with
one wider than the other.

IB-CD208(LC)-WM-E-060403
1
3
2
Connect the supplied AC power cord or batteries (refer to page 4).
PLAYING A CD
POWER lamp
Slide the FUNCTION
switch to the MP3/CD
position (power on), the
POWER lamp will be on,
and the symbol  
starts a new cycle in the
display.
Lift the CD DOOR to open
it and push a CD down
onto the center spindle.
The label side of the CD
disc should face upward.
FUNCTION
switch
CD DOOR
TIP:
1.   will show in the display if there is no CD disc in the CD compartment
or if the CD disc is upside down.
2.   will show in the display when the CD DOOR is opened.
Close the CD DOOR. The
display will show the
symbol  , total tracks
and total playing time of
that CD, then the player
will begin to play
automatically.
5
Track number
currently playing

IB-CD208(LC)-WM-E-060403
To Press or Adjust
Adjust the volume VOLUME control
Stop playback
Pause playback
Go to the next track
Go back to the previous
track
Locate a point in a song
When the CD
play is paused,
the track number
currently playing
will flash and no
music will play.
Remove the CD
Turn off the power
6
If you just started
to play a disk, the
music may stop
or skip for a few
seconds. If the
music is playing
for a few minutes
and had time to
load, the music
will not skip.
Track number
USE THESE BUTTONS FOR
ADDITIONAL OPERATIONS
Press PLAY/PAUSE, the track
number currently playing will
flash during pause. Press
again to resume play after
pause.
SKIP/SEARCH
FORWARD
SKIP/SEARCH
BACKWARD
Slide the FUNCTION switch
to the OFF position, the
POWER lamp turns off.
TIP
To resume play,
press the PLAY/
PAUSE button
again, the track
number will stop
flashing and
music will play.
STOP button
or
Press and hold down while
playing till you find the point.
Press the STOP button first,
then lift the CD DOOR.
Go to the next 10th
track Press the 10+/ALBUM
button.
VOLUME
control
FUNCTION
switch
Open the CD DOOR
by lifting here
PLAY/
PAUSE
SKIP/SEARCH
FORWARD
SKIP/SEARCH
BACKWARD
STOP
10+/ALBUM
PHONES jack
To enjoy the music without
disturbing others
Insert your headphones (not
included) plug them into the
PHONES jack.

IB-CD208(LC)-WM-E-060403
You may have repeat, intro and random play functions by pressing the REPEAT
button. Press the REPEAT button several times, the display will show the
followings in turn:
CD REPEAT, INTRO AND RANDOM PLAY
7
Single Track Repeat
Plays one song over and over till you press STOP .
Press the REPEAT button once,
REPEAT ONE will show
in the display. Select the song you want to repeat with
either of the SKIP/SEARCH buttons ( or ), or
10+/ALBUM button.
The song currently playing will repeat over and over
until you press the STOP button.
All Tracks Repeat (Disc Repeat)
Repeats all songs in order till you press STOP.
Press the REPEAT button twice,
REPEAT ALL will show
in the display.
All the songs will keep playing in sequence 1, 2, 3, etc.
and when finished, the player will start all over again
until you press the STOP button.
Intro Play
This plays the first 10 seconds of each song in
sequential order.
Press the REPEAT button three times,
INTRO will flash
in the display. Press the PLAY button once, the first 10
seconds of each song on the CD will play in sequential
order.
When you find a song you like, press the PLAY button
again,
INTRO will not show in the display, normal play
will be resumed, that song (and the following songs)
will play normally.
Random Play
This plays the songs on the disc in random order.
Press the REPEAT button four times,
RANDOM will flash
in the display. Press the PLAY button once, the player
begins random play.
Press the SKIP/SEARCH buttons ( or ) to skip
to the next random song.
To quit random play, press the REPEAT button once
again, the player will play normally.
REPEAT ONE REPEAT ALL INTRO RANDOM NORMAL PLAY

IB-CD208(LC)-WM-E-060403
CD PROGRAMMED PLAY
To change the current program
Just create a new program following the above programming procedure.
To cancel Programmed Play
Press the STOP button twice, the word PROGRAM will disappear from the
display.
8
You can make a program up to 20 tracks in the specified order you want them
to be played.
NOTE:
1. Programming can only be done in
STOP mode.
2. The programmed memory will be lost if the STOP button is pressed twice, or
the alkaline batteries are exhausted or removed, or AC power is shut off, or the
CD DOOR is opened.
3. The player will stop automatically after all the programmed tracks have been
played.
1. Slide the FUNCTION switch to the MP3/CD
position. Make sure the set is in the
STOP mode.
2. Press the PROGRAM button once. The letters
  will flash in the display .
3. Press the SKIP/SEARCH buttons ( or ) or
10+/ALBUM button to select the tracks to be
programmed in the order that you want.
4. Press the PROGRAM button to confirm. The
programmed number 2 (example) will now show in
the display, then ready for your next selecting of
track.
5. Repeat above steps 3 and 4. You can program up
to 20 tracks.
6. After programming is finished, press the PLAY
button to start programmed play.
Programming Example
Program Number
Track Number (song number) 2
12
5
3
8
4
1
5
2
6
4
7
1
8
1etc.
etc.
track number
programmed
number

IB-CD208(LC)-WM-E-060403
1
2
3
Connect the supplied AC power cord or batteries (refer to page 4).
MP3 PLAYBACK
CD DOOR
FUNCTION switch
Close the CD DOOR, the display will
show all the symbols as illustrated. The
player will automatically play all the
songs of the MP3 disc.
Slide the FUNCTION switch to the MP3/
CD position. The symbol   starts a
different cycle in the display, and the
POWER lamp lights up.
General Information
1. Usually, you must write your own MP3 disc on your computers CD writer.
Or, you may buy pre-recorded MP3 discs from some on line sources.
2. When saving songs (audio files) onto your CD-R (or CD-RW), you must
save them as .MP3 (DOT MP3) files. Do not save them as .DOC or
.TEXT, .PDF etc. when downloading, converting or saving files as MP3 files.
3. Do not save TEXT files as .MP3 files because they will not play and they
may interfere with the set.
4. Do not attempt to combine normal CD audio tracks and MP3 tracks onto
one CD because the set will only recognize the audio tracks and play those.
POWER lamp
9
Album
number Track number playing
time
Lift the CD DOOR to open it and push an
MP3 disc down onto the center spindle.
The label side of the MP3 disc should
face upward.
