Duran Electronica DURTOX-X Instruction Manual

DURTOX-X
ELECTROCHEMICAL DETECTORS FOR TOXIC GASES AND O2
Installation &User Manual
© 2010 DURAN ELECTRONICA S.L. - All rights reserved · www.duranelectronica.com
I-manDURTOX-v01
Certificate nº FS82426

3
I-manDURTOX-v01
page
1. DURTOX-X. Electrochemical technology detectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. RELAYOUTPUTMODULE(optional) .......................................4
3. CONNECTIONS........................................................5
4. ADDRESSINGRS485CDETECTORS ......................................7
5. OPTICAL INDICATORS (internal LEDs): signals and functioning . . . . . . . . . . . . . . . . . . 7
6 TEST ................................................................8
7 TECHNICALCHARACTERISTICS .........................................8
8 INFORMATION ABOUT ATEX MARKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
9GUARANTEE. .........................................................9
10 EC DECLARATION OF CONFORMITY.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TABLE OF CONTENTS

4© 2010 DURAN ELECTRONICA S.L.
All rights reserved · www.duranelectronica.com
1. DURTOX-X. Electrochemical technology detectors
DURTOX-X is an exproof detector using electrochemical technology for the detection of toxic gases and O2.
Communication formats
• RS485C addressable, 4 wire connection, compatible with EUROSONDELCO and SIEMENS
CC62P control panels. Up to 16 detectors can be connected in parallel on the same loop.
•4-20mA, 3 wire connection, compatible with any standard system provided with this type of input.
Applications
DURTOX-X exproofdetectorshavebeendesignedforenvironmentsinwhichtheformationofexplosiveatmospheres
due to gases or vapours is probable, and assure a high level of protection.
(Group of apparatus II – ATEX Directive Category 2)
Special features
• Provided with a 12bit microprocessor allowing total control over the sensor status..
• Thermal compensation that allows a correct response from each of the electrochemical sensors
when faced with temperature variations, except for DURTOX-X O2, which due to its systems does
not require such a feature.
• Self testing hardware.
• Digital filter based on variable samplings of the sensor average values
• Auto-Zero automatic adjustment This special feature monitors zero value in relation to sensor
response and electronics. The following protocol is used for this: Every 30 minutes an automatic
test is performed, if drift is +/- than 2% of the full scale, it will readjust itself to zero, otherwise it
will be shown as a readout.
• Other features accessiblewithfactorybasedmethodologyallowustocheckonthesensorremaining
useful life, date of manufacture, date of last calibration and serial number.
2. RELAY OUTPUT MODULE (optional)
The optional relay output for the RS485 models of DURTOX-X is programmed with the following default values:
Activated, instantaneous –no delay-
Alarm: 50ppm for CO, 10ppm for H2S, 25ppm for NH3, 5ppm for NO2, <18% for O2
Available gases Standard range* Installation height Area covered
Carbon monoxide CO 0-300ppm* 1,50 to 2m from floor 300 m2
Hydrogen sulfide H2S 0-100ppm / 0-200ppm* 1m from floor 150 m2
Ammonia NH30-100ppm*/0-1000ppm/0-5000ppm 30cm from ceiling 75 m2
Nitrogen dioxide NO20-20ppm* 1m from floor 200 m2
Oxygen O20-25% vol* 1,70 to 2m from floor 200 m2
* Ranges available with RS485C detectors compatible with EUROSONDELCO / SIEMENS CC62P

5
I-manDURTOX-v01
3. CONNECTIONS
IMPORTANT – Instructions regarding cable glands for ATEX detectors:
The user must ensure the cable is well anchored. The minimum torque setting applicable to the cap is 20 Nm.. Check
cable entry tightness after any maintenance operation: If cable has moved, tighten up the cap again. If tightening
isn’t possible, send the detector back to factory for cable gland replacement.
DURTOX-X with RS485C communication:

6© 2010 DURAN ELECTRONICA S.L.
All rights reserved · www.duranelectronica.com
DURTOX-X with 4-20mA communication :
IMPORTANT: If the system where detectors are to be connected does not have 4-20mA inputs, but 0-5 or
0-10V DC tension inputs, a resistance must be connected between negative (-) and signal (s), on the receptor devi-
ce. Resistance value will depend on the detector power tension in accordance to the following table:

7
I-manDURTOX-v01
4. ADDRESSING RS485 DETECTORS
Before connecting DURTOX-X detectors to EUROSONDELCO or SIEMENS CC62P, they must be addressed. If
more than one detector is connected to the same loop, assign a number to each of them according to table 1.
Table 1- NUMBERING DETECTORS USING SW1 (addressing)
5. OPTICAL INDICATORS (internal LEDs): signals and functioning
RS485C models – installed in vertical module -
• Fast intermittent: during initialization and recognition of the loop by the module line.
• Periodic intermittent: normal functioning. Time between blinking, in seconds, will correspond with
the assigned number of the detector (1 to 16).
• 6-blink burst: Line failure. A-B communication cable is cut.
• 1 second cadence: failure or short circuit in the A-B communication lines. More than 5 minutes
have passed without the detector being able to communicate with the module line.
4-20mA models –installed in main module-
• LD1: indicates the detector operational status.
• LD2: this LED will turn on in case of any internal failure in the detector as well as to indicate a
positive or negative scale overflow.
Detector Tension Load Resistance Tension Range (4-20mA)
Between 10V and 18V DC 250 Ω1% From 1V to 5V DC
Between 18V and 30V DC 500 Ω1% From 2V to 10V DC
Detector nr. 1 2 3 4
01 On On On On
02 Off On On On
03 On Off On On
04 Off Off On On
05 On On Off On
06 Off On Off On
07 On Off Off On
08 Off Off Off On
09 On On On Off
10 Off On On Off
11 On Off On Off
12 Off Off On Off
13 On On Off Off
14 Off On Off Off
15 On Off Off Off
16 Off Off Off Off

8© 2010 DURAN ELECTRONICA S.L.
All rights reserved · www.duranelectronica.com
6. TEST
Once connected, DURTOX-X begins to count a 60 second sensor stabilization time. During this time the 4-20mA
model will have a tension output of only 1,9mA, later increasing to 4mA.
Do not open these detectors while powered. Adjustments or calibrations of the installation are not allowed. Due to
the technology applied, these operations can only be carried out at the factory.
Perform a check-up test at least once a year using gas tester containers with the right composition for each gas.
Using any other means could poison or destroy the sensor and, therefore, the guarantee would be invalidated.
All detectors manufactured by DURAN ELECTRONICA are factory calibrated with the appropriate target gas.
Therefore, manipulation is neither required nor advisable once installed.
7. TECHNICAL CHARACTERISTICS
Technology 12bit Microprocessor and electrochemical sensors
Power 10 to 30V DC (4-20mA)/10 to 15V (RS485C)
Maximum consumption 43mA to 12V DC
Useful life ± 2 years in air, 4 years CO
Accuracy ± 5% bottom of scale
Repeatability ± 5% bottom of scale
Initialization stabilization delay when connecting
- all versions - Approx. 5 minutes
T90 response time CO & NH3 ≤30s H2S ≤20s
O2 ≤15s
Temperature and humidity ranges -10ºC to +50ºC
20-90% Hr
Working atmospheric pressure 90-110 KPa
Air velocity <0.1-0.5m/s
Maintenance periods Annual - recommended -
Explosive atmosphere code II 2G Ex d IIC T6 Gb
Housing material Aluminium & Epoxy paint
Stopping plug material Type PLG
Cable gland material and cable diameter Natural brass & Santoprene 6-10mm2
Adaptor material & syntherized filter Stainless steel.
Cable type (RS485) 4 wire shielded (power 2 x 1,5 + A and B communications
2 x 0,25 twisted pair)
Cable type (4-20mA) 3 X 1,5mm Ø shielded, recommended minimum
Maximum installation distance 1000m (RS485C) & 350m (4-20mA)
Dimensions (mm) & weight (gr) 162 x 150 x 90 / 1.392

9
I-manDURTOX-v01
8. INFORMATION ABOUT ATEX MARKING
EC marking in conformity with Directive 94 / 9 / EC (ATEX).
0163 (the number 0163 corresponds to the Notified Body,
Laboratorio Oficial J. M. Madariaga)
Group II apparatus, Category 2G (explosive atmosphere caused by gases
and vapours) In conformity with protection mode “d” - flameproof enclosures
LOM 10ATEX2076 EC Type Examination Certificate
9. GUARANTEE
DURTOX-X detectors are guaranteed against any manufacturing defect for a 1 year period after the acquisition of
the equipment. If, during this period of time, any anomaly was detected, please inform your provider or installer.
Guaranteecovers thefull repairofthe equipmentwhich DURAN ELECTRONICA TechnicalDepartmentconsiders
to be defective, with the purpose of bringing them back to their normal use. This warranty will be valid as long
as the equipment has been installed by a competent person, and always following the specifications contained in
this manual. Negligent installation or use will exempt DURAN ELECTRONICA from any responsibility from
damagescaused toobjectsand/or people,and fromthe fulfillmentofthe termsof thiswarranty. Incase ofimproper
handling, or not respecting the conditions, characteristics and observations described in this manual, DURAN
ELECTRONICA WILLNOTHOLDITSELFRESPONSIBLEFORDAMAGESCAUSEDBYIMPROPERUSEOFTHISPRODUCT.
Guaranteedoesnot include:installations,periodic testsand maintenance,damagescaused byinadequatehandling,
inappropriate use, negligence, overload, inadequate power or equipment abandonment, tension deviations,
defective installations and all other external causes, repairs or amendments made by personnel not authorized by
DURAN ELECTRONICA and transportation costs of the equipments.
DURAN ELECTRONICA reserves the right to carry out improvements or to include modifications the equipment
without prior notice.
II 2 G Ex d IIC T6 Gb

10 © 2010 DURAN ELECTRONICA S.L.
All rights reserved · www.duranelectronica.com
II 2 G
10. DECLARATION OF CONFORMITY
Víctor Manuel Andrés González, Managing Director of:
DURAN ELECTRÓNICA, S. L.
Tomás Bretón, 50 - 28045 MADRID (Spain)
DeclarestheconformityofgasdetectormodelDURTOX-X inaccordancewiththecontainsofthefollowingEuropean
Parliament and Council directives:
2004/108/EC Electromagnetic compatibility
94/9/EC Equipment and protective systems intended for use in potentially explosive atmospheres
conformity assumed by compliance with the following standards:
EN 60079-0:2009
EN 60079-1:2007
Year of affixing the regulatory (Ex d IIC T6 Gb) marking: 2010
EC Type examination certificate number LOM 10ATEX2076
Product Quality Assurance Notification number: LOM 08ATEX9073
Issued by notified body number 0163: Laboratorio Oficial J. M. Madariaga (LOM)
C/ Alenza, 1 – 28003 MADRID (Spain), that authorizes to affix the legal marking.
0163
The LOM 10ATEX2076 certificate does not cover that indicated in the paragraph 2, Article I of the 94/9/EC directive
related to safety, controlling and regulating devices, nor the Essential Health and Safety Requeriments indicated in
the paragraphs 1.5.5, 1.5.6 and 1.5.7 of the Annex II of the Directive 94/9/EC related to devices with a measuring
function.
