Durr Dental VistaScan Mini Easy User manual

EN
1802V004
9000-618-210/02

Installation and operating instructions
VistaScan Mini Easy

9000-618-210/02 1802V004 1
Installation
6 Requirements . . . . . . . . . . . . . . . . . . . . 14
6.1 Installation/setup room . . . . . . . . . 14
6.2 System requirements . . . . . . . . . . 14
6.3 Monitor . . . . . . . . . . . . . . . . . . . . . 14
7 Installation . . . . . . . . . . . . . . . . . . . . . . 14
7.1 Carrying the unit . . . . . . . . . . . . . . 14
7.2 Setting up the unit. . . . . . . . . . . . . 14
7.3 Electrical connections . . . . . . . . . . 15
7.4 Connecting the unit. . . . . . . . . . . . 16
8 Commissioning. . . . . . . . . . . . . . . . . . . 18
8.1 Set up the network (only with
network connection) . . . . . . . . . . . 18
8.2 Driver installation (USB port only). . 18
8.3 Configuring the unit in VistaSoft. . . 19
8.4 Configuring the appliance in
DBSWIN . . . . . . . . . . . . . . . . . . . . 19
8.5 X-ray unit settings . . . . . . . . . . . . . 21
8.6 Acceptance tests . . . . . . . . . . . . . 22
Usage
9 Correct use of image plates . . . . . . . . . 23
10 Operation . . . . . . . . . . . . . . . . . . . . . . . 24
10.1 Changing the input unit cover . . . . 24
10.2 X-ray. . . . . . . . . . . . . . . . . . . . . . . 25
10.3 Scanning the image data. . . . . . . . 27
10.4 Erasing the image plate. . . . . . . . . 28
10.5 Switch off the unit. . . . . . . . . . . . . 28
11 Cleaning and disinfection. . . . . . . . . . . 29
11.1 Image plate scanner . . . . . . . . . . . 29
11.2 Light protection cover . . . . . . . . . . 30
11.3 Image plate. . . . . . . . . . . . . . . . . . 30
11.4 Protection cover . . . . . . . . . . . . . . 30
11.5 Storage box with image plate
storage tray . . . . . . . . . . . . . . . . . 30
12 Maintenance. . . . . . . . . . . . . . . . . . . . . 31
12.1 Recommended maintenance
schedule. . . . . . . . . . . . . . . . . . . . 31
EN
Contents
Important information
1 About this document . . . . . . . . . . . . . . . 3
1.1 Warnings and symbols . . . . . . . . . . 3
1.2 Copyright information . . . . . . . . . . . 3
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Intended purpose . . . . . . . . . . . . . . 4
2.2 Intended use. . . . . . . . . . . . . . . . . . 4
2.3 Improper usage. . . . . . . . . . . . . . . . 4
2.4 General safety notes . . . . . . . . . . . . 4
2.5 Specialist personnel . . . . . . . . . . . . 4
2.6 Protection from electric shock. . . . . 4
2.7 Only use original parts. . . . . . . . . . . 5
2.8 Transport . . . . . . . . . . . . . . . . . . . . 5
2.9 Disposal . . . . . . . . . . . . . . . . . . . . . 5
Product description
3 Overview. . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Scope of delivery . . . . . . . . . . . . . . 7
3.2 Accessories . . . . . . . . . . . . . . . . . . 7
3.3 Optional accessories. . . . . . . . . . . . 7
3.4 Consumables . . . . . . . . . . . . . . . . . 8
3.5 Wear parts and replacement
parts. . . . . . . . . . . . . . . . . . . . . . . . 8
4 Technical data . . . . . . . . . . . . . . . . . . . . 9
4.1 Image plate scanner . . . . . . . . . . . . 9
4.2 Image plate. . . . . . . . . . . . . . . . . . 10
4.3 Light protection cover . . . . . . . . . . 10
4.4 Type plate . . . . . . . . . . . . . . . . . . . 11
4.5 Evaluation of conformity . . . . . . . . 11
5 Operation . . . . . . . . . . . . . . . . . . . . . . . 11
5.1 Image plate scanner . . . . . . . . . . . 11
5.2 Image plate. . . . . . . . . . . . . . . . . . 12
5.3 Light protection cover . . . . . . . . . . 13
5.4 Protection cover . . . . . . . . . . . . . . 13
5.5 Storage box . . . . . . . . . . . . . . . . . 13

2 9000-618-210/02 1802V004
Contents
Troubleshooting
13 Tips for operators and service
technicians . . . . . . . . . . . . . . . . . . . . . . 32
13.1 Poor X-ray image . . . . . . . . . . . . . 32
13.2 Software error. . . . . . . . . . . . . . . . 36
13.3 Fault on the unit . . . . . . . . . . . . . . 37
Appendix
14 Scanning times. . . . . . . . . . . . . . . . . . . 39
15 File sizes (uncompressed) . . . . . . . . . . 40
16 Information about EMC in
accordance with EN 60601-1-2 . . . . . . 41
16.1 General notes . . . . . . . . . . . . . . . . 41
16.2 Abbreviations . . . . . . . . . . . . . . . . 41
16.3 Guidelines and manufacturer's
information . . . . . . . . . . . . . . . . . . 41
EN

9000-618-210/02 1802V004 3
Other symbols
These symbols are used in the document and
on or in the unit:
Note, e.g. specific instructions regarding
efficient and cost-effective use of the unit.
Please read all of the accompanying doc-
uments.
Wear protective gloves.
Switch off and de-energise the device
(e.g. unplug from mains).
CE labelling
Manufacturer
Dispose of correctly in accordance with
EU Directive 2012/19/EU (WEEE).
Do not reuse
Order number
Serial number
1.2 Copyright information
All circuits, processes, names, software pro-
grams and units mentioned in this document are
protected by copyright.
The Installation and Operating Instructions must
not be copied or reprinted, neither in full nor in
part, without written authorisation from Dürr
Dental.
1 About this document
These installation and operating instructions
represent part of the unit.
If the instructions and information in
these installation and operating instruc-
tions are not followed, Dürr Dental will
not be able to offer any warranty or as-
sume any liability for the safe operation
and the safe functioning of the unit.
1.1 Warnings and symbols
Warnings
The warnings in this document are intended to
draw your attention to possible injury to persons
or damage to machinery.
The following warning symbols are used:
General warning symbol
Warning – risk of dangerous electric volt-
ages
Warning - laser beam
The warnings are structured as follows:
SIGNAL WORD
Description of the type and source of
danger
Here you will find the possible conse-
quences of ignoring the warning
iFollow these measures to avoid the
danger.
The signal word differentiates between four
levels of danger:
– DANGER
Immediate danger of severe injury or death
– WARNING
Possible danger of severe injury or death
– CAUTION
Risk of minor injuries
– NOTICE
Risk of extensive material/property damage
Important information
EN

4 9000-618-210/02 1802V004
Important information
2.4 General safety notes
iAlways comply with the specifications of all
guidelines, laws, and other rules and regula-
tions applicable at the site of operation for the
operation of this unit.
iCheck the function and condition of the unit
prior to every use.
iDo not convert or modify the unit.
iComply with the specifications of the Installa-
tion and Operating Instructions.
iThe Installation and Operating Instructions
must be accessible to all operators of the unit
at all times.
2.5 Specialist personnel
Operation
Unit operating personnel must ensure safe and
correct handling based on their training and
knowledge.
iInstruct or have every user instructed in han-
dling the unit.
Installation and repairs
iInstallation, readjustments, alterations, up-
grades and repairs must be carried out by
Dürr Dental or by qualified personnel specifi-
cally approved and authorized by Dürr Dental.
2.6 Protection from electric shock
iComply with all the relevant electrical safety
regulations when working on the unit.
iNever touch the patient and unshielded plug
connections on the device at the same time.
iReplace any damaged cables or plugs imme-
diately.
Observe the EMC rules concerning medical
devices
iObserve specific precautionary measures re-
lating to electromagnetic compatibility (EMC)
for medical devices, see "16 Information
about EMC in accordance with EN 60601-1-
2".
2 Safety
Dürr Dental has designed and constructed this
unit so that when used properly and for the in-
tended purpose it does not pose any danger to
people or property. Nevertheless, residual risks
can remain. You should therefore observe the
following notes.
2.1 Intended purpose
VistaScan Mini Easy
The unit is intended exclusively for use in dental
applications for the scanning and processing of
image data on an image plate.
Light protection cover
The light protection cover protects the image
plate against light.
2.2 Intended use
VistaScan Mini Easy
The unit may only be operated using accesso-
ries and optional accessories specifically ap-
proved by Dürr Dental.
The unit may only be cleaned using the disin-
fectants and cleaning agents specified or ap-
proved by Dürr Dental.
Light protection cover
The light protection cover is a disposable item.
The light protection cover is designed exclusive-
ly for use with Dürr Dental image plate scanners
and Dürr Dental image plates in dental applica-
tions.
2.3 Improper usage
Any other usage or usage beyond this scope is
deemed to be improper. The manufacturer ac-
cepts no liability for damages resulting from im-
proper usage. In these cases the user/operator
will bear the sole risk.
This unit is not suitable for monitoring patients
over longer periods of time.
This unit must not be operated in operating the-
atres or similar rooms, in which dangers may
arise from the combustion of flammable materi-
als.
EN

9000-618-210/02 1802V004 5
Important information
2.9 Disposal
Unit
The unit must be disposed of properly.
Within the European Union, the unit must
be disposed of in accordance with EU
Directive 2012/19/EU (WEEE).
iIf you have any questions about the correct
disposal of parts, please contact your dental
trade supplier.
Image plate
The image plate contains barium compounds.
iDispose of the image plate properly in accord-
ance with the locally applicable regulations.
iIn Europe, dispose of the image plate in ac-
cordance with waste code 090199 "Wastes
not otherwise specified". Disposal as domes-
tic waste is possible.
2.7 Only use original parts
iOnly use Dürr Dental parts or accessories and
special accessories specifically approved by
Dürr Dental.
iOnly use only original wear parts and replace-
ment parts.
DÜRR MEDICAL accepts no liability for
damages or injury resulting from the use
of non-approved accessories or optional
accessories, or from the use of non-origi-
nal wear parts or replacement parts.
The use of non-approved accessories,
optional accessories or non-genuine
wear parts / replacement parts
(e.g.mains cable) can have a negative
effect in terms of electrical safety and
EMC.
2.8 Transport
The original packaging provides optimum pro-
tection for the unit during transport.
If required, original packaging for the unit can be
ordered from Dürr Dental.
Dürr Dental will not accept any responsi-
bility or liability for damage occurring dur-
ing transport due to the use of incorrect
packaging, even where the unit is still un-
der guarantee.
iOnly transport the unit in its original packag-
ing.
iKeep the packing materials out of the reach of
children.
iDo not expose the unit to any strong vibra-
tions or shocks.
EN

6 9000-618-210/02 1802V004
3 Overview
1
3
4
5
8
2
6
7
9
1 VistaScan Mini Easy image plate scanner
2 Input unit cover
3 Plus intraoral image plate
4 Light protection cover intraoral
5 Storage box
6 DBSWIN imaging software DVD
7 USB cable
8 Network cable
9 Power supply unit with country-specific adapter
Product description
EN

9000-618-210/02 1802V004 7
Product description
3.2 Accessories
The following items are required for operation of
the device, depending on the application:
Image plates
Plus image plate, size 0
2 x 3 cm (2 pcs.). . . . . . . . . . . . . . 2130-040-50
Plus ID image plate, size 0
2 x 3 cm (2 pcs.). . . . . . . . . . . . . . 2130-040-60
Plus image plate, size 2
3 x 4 cm (4 pcs.). . . . . . . . . . . . . . 2130-042-50
Plus image plate, size 2
3 x 4 cm (12 pcs.). . . . . . . . . . . . . 2130-042-55
Plus ID image plate, size 2
3 x 4 cm (4 pcs.). . . . . . . . . . . . . . 2130-042-60
Light protection covers
Light Protection Cover Plus size 0
2 x 3 cm (100 pcs.). . . . . . . . . . . . 2130-080-00
Light Protection Cover Plus size 2
3 x 4 cm (300 pcs.). . . . . . . . . . . . 2130-082-00
Light Protection Cover Plus size 2
3 x 4 cm (1000 pcs.) . . . . . . . . . . . 2130-082-55
Light Protection Cover Plus size 0,
white
2 x 3 cm (100 pcs.). . . . . . . . . . . . 2130-080-50
Light Protection Cover Plus size 2,
white
3 x 4 cm (300 pcs.). . . . . . . . . . . . 2130-082-50
3.3 Optional accessories
The following optional articles can be used with
the unit:
Wall bracket . . . . . . . . . . . . . . . . . 2141-001-00
Storage box . . . . . . . . . . . . . . . . . 2141-002-00
Image plate and film holder
system set . . . . . . . . . . . . . . . . . . 2130-981-50
Image plate and film holder system
conversion set for
endo-exposures . . . . . . . . . . . . . . 2130-981-51
Copper dot set, self-adhesive . . . .2130-006-00
Mobile Connect (for using apps for
mobile appliances, e.g.Dürr Dental
Imaging iPad app) . . . . . . . . . . .2100-725-12FC
Commissioning and intraoral constancy tests
Intra / extra digital test body . . . . .2121-060-54
3.1 Scope of delivery
The following items are included in the scope of
delivery (possible variations due to country-spe-
cific requirements and/or import regulations):
VistaScan Mini Easy
image plate scanner . . . . . . . . . . . . . 2143-61
VistaScan Mini Easy
image plate scanner . . . . . . . . . . . . . 2143-67
VistaScan Mini Easy
image plate scanner . . . . . . . . . . . . . 2143-52
– VistaScan Mini Easy basic unit
– Power supply unit
– USB cable
– Network cable
– DBSWIN imaging software DVD
– Input unit cover for the image plate – size 0
– Input unit cover for the image plate – size 2
– Plus image plate:
- Size 0
- Size 2
– Light protection covers Plus:
- Size 0
- Size 2
– Storage box
– Protection cover
– Image plate cleaning wipes
– Installation and operating instructions
– Quick start instructions
EN

8 9000-618-210/02 1802V004
Product description
3.4 Consumables
The following materials are consumed during
operation of the device and must be reordered
separately:
Cleaning and disinfection
Image plate cleaning wipes
(10pcs.) . . . . . . . . . . . . . . . . . . CCB351B1001
FD 350 Classic disinfection
wipes . . . . . . . . . . . . . . . . . . . . CDF35CA0140
FD 333 rapid surface
disinfectant . . . . . . . . . . . . . . . . CDF333C6150
FD 322 rapid surface
disinfectant . . . . . . . . . . . . . . . . CDF322C6150
FD 366 quick-acting disinfectant for
sensitive surfaces . . . . . . . . . . . CDF366C6150
Light protection covers
see "3.2 Accessories"
3.5 Wear parts and replacement
parts
Image plates
see "3.2 Accessories"
Information about replacement parts is
available from the portal for authorised
specialist dealers at:
www.duerrdental.net.
EN

9000-618-210/02 1802V004 9
Product description
4 Technical data
4.1 Image plate scanner
Electrical data for the device
Voltage V DC 24
Max. current consumption A 1.25
Output W < 30
Type of protection IP20
Electrical data – power supply unit
Voltage V AC 100 - 240
Frequency Hz 50/60
Protection class II
Type of protection IP20
Over-voltage category II
Output W < 40
Max. current consumption A 0.8
Classification
Medical Devices Directive (93/42/EEC) Class I
Laser class (unit)
in accordance with EN60825-1 1
Laser source
Laser class
in accordance with EN60825-1 3B
Wavelength lnm 635
Output mW 10
Noise level
Ready to scan dB(A) approx. 37
During scanning dB(A) approx. 55
General technical data
Dimensions (W x H x D) mm 226 x 234 x 243
Weight kg approx. 6.5
Heat output W < 40
Duty cycle S2 (in accordance with VDE
0530-1) min 25
Duty cycle S6 (in accordance with VDE
0530-1) % 25
Pixel size (selectable) μm 12.5 - 50
Max. theoretical resolution Line pairs/
mm (Lp/mm) approx. 40
EN

10 9000-618-210/02 1802V004
Product description
Network connection
LAN technology Ethernet
Standard IEEE 802.3u
Data rate Mbit/s 100
Connector RJ45
Type of connection Auto MDI-X
Cable type ≥CAT5
Ambient conditions during operation
Temperature °C +10 to +35
Relative humidity % 20 - 80
Air pressure hPa 750 - 1060
Height above sea level m < 2000
Ambient conditions during storage and transport
Temperature °C -20 to 60
Relative humidity % 10 - 95
Air pressure hPa 750 - 1060
Height above sea level m < 16000
4.2 Image plate
Classification
Medical Devices Directive (93/42/EEC) Class IIa
Ambient conditions during operation
Temperature °C 18 - 45
Relative humidity % < 80
Ambient conditions during storage and transport
Temperature °C < 33
Relative humidity % < 80
Dimensions of intraoral image plates
Size 0 mm 22 x 35
Size 2 mm 31 x 41
4.3 Light protection cover
Classification
Medical Devices Directive (93/42/EEC) Class I
EN

9000-618-210/02 1802V004 11
Product description
5 Operation
5.1 Image plate scanner
1
2
3
4
1 Intake slot
2 Operating elements
3 Release key
4 Collection tray
The image plate scanner is used to read image
data stored on an image plate and to transfer
the data to the imaging software (e.g.VistaSoft)
on a computer.
The transport mechanism guides the image
plate through the device. The image plate is
read using a laser inside the scanner unit. The
scanned data is converted into a digital image
and transferred to the imaging software.
After scanning, the image plate runs through the
erasure unit. Image data still held on the image
plate is erased with the aid of bright light.
The image plate is then ejected for re-use.
4.4 Type plate
The type plate is located on the rear of the de-
vice.
REF Order number
SN Serial number
4.5 Evaluation of conformity
This device has been subjected to conformity
acceptance testing in accordance with the cur-
rent relevant European Union guidelines. This
equipment conforms to all relevant require-
ments.
EN

12 9000-618-210/02 1802V004
Product description
Connections
The connections are located on the rear of the
unit, underneath the cover.
1
2
3
4
5
6
1 Connection for power supply unit
2 Reset button
3 AUX connection for diagnostic units
4 Network connection status LEDs
5 Network connection
6 USB port
5.2 Image plate
The image plate stores X-ray energy, which is
re-emitted in the form of light after excitation via
the laser. This light is then converted to image
information in the image plate scanner.
The image plate has an active side and an inac-
tive side. The image plate must always be ex-
posed on the active side.
When used properly, image plates can be ex-
posed, read and erased several hundred times
provided there is no mechanical damage. The
image plate must be replaced if there are any
signs of damage, e.g. if the protective layer is
damaged or there are visible scratches that
could interfere with the diagnosis.
Intraoral
2
1
1 Inactive side Black, printed with the
word "back" and the size
and manufacturer's infor-
mation
2 Active side Light blue, with position-
ing aid
Operating elements
1
2
3
4
5
6
1 Green operating LED
2 Blue communication indicator
3 On / off switch
4 Green status LED
5 Yellow status LED
6 Red status LED
The status LEDs display the following status
messages:
Ready for operation
Not ready for communication
Device currently switching off
Error
Cover missing
Image plate currently being processed
Image plate currently being processed
Light protection cover can be removed
and the next image plate can be insert-
ed
Input unit ready for operation
The next image plate can be inserted
Device starting up from standby mode
Status LED flashing
Status LED off
EN

9000-618-210/02 1802V004 13
Product description
5.3 Light protection cover
The light protection cover provides several pro-
tective functions for the intraoral image plate:
– Protection against sunlight and UV light, and
therefore protection against accidental erasure
– Protection against mechanical damage
– Protection against contamination and soiling
The light protection cover is a disposable item.
5.4 Protection cover
The protective cover protects the device against
dust and dirt, for example during extended peri-
ods inwhich it is not in use.
5.5 Storage box
Image plates packaged in light protection cov-
ers can be stored in the storage box until they
are next used. The storage box protects the im-
age plate and the light protection cover against
contamination and dirt.
The positioning aid is visible on the X-ray im-
age and makes it easier to align the image cor-
rectly during diagnosis.
Exposure from the wrong side
A marker is attached to the inactive side of the
image plate.
1
1 Marker
If the image plate has been exposed from the
wrong side, the marker is visible as a shadow in
the X-ray image.
1
1 Marker visible as a shadow
The image can be corrected by mirroring it in
the software. If a diagnosis is not possible in the
area of the marker then the image will need to
be acquired again.
With the aid of the copper dots set you
can retrospectively add a marker to im-
age plates (see "3.3 Optional accesso-
ries").
Clear assignment of image plate to image (Im-
age Plate Plus ID only)
On the Image Plate Plus ID there is also a hexa-
decimal code on the image plate in addition to
the marker. This code can be seen in the X-ray
image.
This code allows you to clearly assign the cor-
rect image plate to the X-ray image.
1
1 Hexadecimal code
EN

14 9000-618-210/02 1802V004
7 Installation
7.1 Carrying the unit
NOTICE
Risk of damage to sensitive compo-
nents in the unit as a result of shocks
or vibrations
iDo not expose the unit to any strong
vibrations or shocks.
iDo not move the unit during opera-
tion.
7.2 Setting up the unit
Portable and mobile HF communication appli-
ances can interfere with the effectiveness of
electrical medical devices.
iDo not stack the unit next to or together with
other appliances.
iIf, however, this unit is operated next to other
units or stacked with other units, monitor the
unit carefully in the configuration selected in
order to ensure normal operation.
The unit can be set up as a tabletop unit or
mounted on a wall using the wall bracket.
The load-bearing capacity of the table or wall
must be suitable for the weight of the unit (see
"4 Technical data").
Only qualified specialists or employees
trained by Dürr Dental are permitted to
install, connect and start using the unit.
6 Requirements
6.1 Installation/setup room
The room chosen for set up must fulfil the fol-
lowing requirements:
– Closed, dry, well-ventilated room
– It should not be a room made for another
purpose (e.g.boiler room or wet cell).
– Max. light intensity 1000 Lux, no direct sun-
light at the place of installation of the unit
– There should be no large fields of interference
(e.g.strong magnetic fields) present that can
interfere with the correct operation of the unit.
– Refer to the requirements for environmental
conditions in "4 Technical data".
6.2 System requirements
The system requirements for the compu-
ter systems can be found in the down-
load area at www.duerrdental.com (doc-
ument no. 9000-618-148).
6.3 Monitor
The monitor must comply with the requirements
for digital X-ray with a high light intensity and
wide contrast range.
Strong ambient light, sunlight falling directly onto
the monitor and reflections can make it harder
or even impossible to perform a diagnosis
based on the X-ray images.
Installation
EN

9000-618-210/02 1802V004 15
Installation
Connecting the unit to the mains supply
The unit has no main power switch. For
this reason it is important that the unit is
be set up in such a way that the plug can
be easily accessed and unplugged if re-
quired.
Requirements:
– Properly installed power outlet close to the
unit (observe the max. mains cable length)
– Easily accessible power outlet
– Mains voltage must match the information
shown on the type plate of the power supply
unit
iAttach the matching country-specific adapter
to the power supply unit.
iRemove the cover from the rear of the device.
Setting the unit on a table
To prevent errors when scanning the im-
age data, install the unit so it is not ex-
posed to vibrations.
iPlace the unit on a firm, horizontal surface.
6,5
kg
Installing the unit with the wall mounting
bracket
The unit can be mounted on a wall with the wall
mounting bracket (see "3.3 Optional accesso-
ries").
For installation refer to the installation in-
structions for the wall mounting (order
number 9000-618-162)
7.3 Electrical connections
Safety when making electrical connections
iThe device must only be connected to a cor-
rectly installed power outlet.
iDo not place non-fixed multi-socket units on
the floor. Follow the requirements in sec-
tion16 of IEC60601-1 (EN60601-1).
iDo not operate any other systems using the
same multiple socket.
iMake sure that none of the electrical cables
leading to the unit are under any mechanical
tension.
iBefore initial start-up check that the mains
supply voltage and the voltage stated on the
type plate match (see also "4. Technical
data").
EN

16 9000-618-210/02 1802V004
Installation
7.4 Connecting the unit
The device can be connected either via the USB
port or via the network connection. If you are
using VistaSoft/VistaConnect, the device can
only be operated via the network. The cables
are included in the scope of delivery.
Do not connect the device via the USB
port and via the network connection at
the same time.
If the device is connected via the USB
port and via the network connection at
the same time, the network connection
will take priority.
Combining devices safely
Take care when connecting units together or to
parts of other systems as there is always an ele-
ment of risk (e.g. due to leakage currents).
iOnly connect units when there can be no
question of danger to operator or to patient.
iOnly connect units when it is safe to do so
and when there is no risk of damage or harm
to the surroundings.
iIf it is not 100% clear from the unit data sheet
that such connections can be safely made or
if you are in any doubt, always get a suitably
qualified person (e.g. the manufacturer) to ver-
ify that the setup is safe.
iSafety and essential performance features are
independent of the network. The device is de-
signed for operation independent of a net-
work. However, some of the functions are not
available in this case.
iIncorrect manual configuration can lead to
significant network problems. The expert
knowledge of a network administrator is re-
quired for configuration.
iThe data connection utilizes part of the band-
width of the network. Interactions with other
medical devices cannot be completely exclud-
ed. Apply the IEC80001-1 standard for risk
assessment.
iThe device is not suitable for direct connec-
tion to the public internet.
iAlways comply with the relevant requirements
from of IEC60601-1-1 (EN60601-1-1) when
connecting the unit to other appliances, e.g.
to a computer system, both inside and out-
side of the patient environment.
iPlug in the connecting plug of the power sup-
ply unit into the socket connection of the de-
vice.
iSecure the cable with a cable clip.
2
1
iPlug the mains plug into the power outlet.
iRefit the cover.
The cover on the rear must be cor-
rectly fitted when the device is oper-
ated within the patient environment.
EN

9000-618-210/02 1802V004 17
Installation
Connecting the unit via the USB port
Only connect the USB cable to the com-
puter when the installation wizard asks
you to do so.
iRemove the cover from the rear of the device.
iConnect the USB cable to the device.
The cover on the rear must be correctly
fitted when the device is operated within
the patient environment.
iRefit the cover.
iOnly connect peripheral units (e.g. computer,
monitor, printer) that conform at least to the
requirements set out in IEC60950-1
(EN60950-1).
A copy of the system manufacturer‘s
declaration in accordance with Article 12
of Directive 93/42/EEC can be found in
our download section at www.duerrden-
tal.com (document no. 9000-461-264).
Connecting the unit via the network cable
Purpose of the network connection
The network connection is used to exchange in-
formation or control signals between the unit
and a software installed on a computer, in order
to, e.g.:
– Display parameters
– Select operating modes
– Indicate messages and error situations
– Change unit settings
– Activate test functions
– Transmit data for archiving
– Provide documents concerning the units
iRemove the cover from the rear of the device.
iConnect the supplied network cable to the
network connection of the device.
iRefit the cover.
The cover on the rear must be cor-
rectly fitted when the device is oper-
ated within the patient environment.
EN

18 9000-618-210/02 1802V004
Installation
8.2 Driver installation (USB port
only)
Only connect the USB cable to the com-
puter when the installation wizard asks
you to do so.
iClose all programs.
iInsert the supplied DBSWIN DVD (version
5.3.1 or higher) into the DVD drive.
The start window opens.
iIf the DVD does not start to play automatically,
double-click the file CD_Start.exe.
iSelect the required language.
iOpen the Drivers tab.
iClick Duerr Dental Driver Installation.
iClick OK to confirm. The Dürr Dental Driver
Setup installation wizard opens.
iFollow the instructions of the installation wiz-
ard.
8 Commissioning
NOTICE
Short circuit due to the build up of
condensation
iDo not switch on the unit until it has
warmed up to room temperature and
it is dry.
The unit supports the following imaging pro-
grams:
– VistaSoft from Dürr Dental
– VistaConnect from Dürr Dental
– DBSWIN from Dürr Dental
– VistaEasy from Dürr Dental
– Third-party software on request
8.1 Set up the network (only with
network connection)
Network configuration
Various options are available for network config-
uration:
– Automatic configuration via DHCP.
– Automatic configuration via Auto-IP for direct
connection of unit and computer.
– Manual configuration.
iConfigure the network settings of the unit us-
ing the software or, if applicable, the touch
screen.
iCheck the firewall and release the ports, if ap-
plicable.
Network protocols and ports
Port Purpose Serv-
ice
45123 UDP,
45124 UDP
Unit recognition and
configuration
2006 TCP Unit data
5141) UDP Event protocol data Syslog
2005 TCP,
23 TCP
Diagnosis Telnet,
SSH
1) The port can vary depending on the config-
uration.
When the unit is first connected to a
computer, it applies the language and
time settings of the computer.
