DynaLock 3101C User manual

Page 1
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
The 3101C Delay Egress System is a 1500 pound
holding force (holding force not evaluated by UL)
electromagnetic lock electronically controlled to
provide a 15 or 30 second delay in unlocking.
The 3101C requires both mechanical and electrical
installation procedures as described herein.
When completed, a simple adjustment procedure to
set door movement will nalize the installation.
INSTALLATION DESCRIPTION
ELECTRICAL INSTALLATION
After mechanical installation is complete the 3101C needs to be wired and adjusted. A continuous power source, 12
or 24 VDC or VAC is required. Once low voltage power is supplied the unit is fully operational. Delay egress systems
also normally require re panel tie-in. All other wiring is for selected options.
NOTE: Please see Egress Sensor Adjustment (page 8) before applying power.
Familiarize yourself with the door and frame conditions. The lock must mount rigidly to the underside of the door
frame header and against the vertical strike jamb. The door mounted armature is supplied with hardware that allows
it to pivot slightly and pull away from the door as part of the delayed egress function.
NOTE: This lock does not change hands to match the hand of the door. Do not remove the coil assembly
from the lock housing.
NOTE: For locks ordered with the DSM option, please verify that two magnets are installed inside the
armature housing.
MECHANICAL INSTALLATION
The electromagnetic lock and armature are ruggedly constructed and designed to provide years of trouble-free
service. Care must be taken during installation and use, so that the lock face and armature face are kept free of dirt,
rust, paint, or any other obstruction which may interfere with the lock and armature making good contact.
HANDLING

Page 2
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
MODEL #3101C BILL OF MATERIALS
(1) 3101C LOCK ASSEMBLY
(1) ARMATURE
(1) ARMATURE HOUSING
(1) ARMATURE MOUNTING PLATE ASSEMBLY
(1) HARDWARE KIT
(1) DOOR SIGN - “15 SECONDS” *
(1) TEMPLATE
(1) INSTALLATION MANUAL
(1) Electric Drill
(1) #2 Phillips Screwdriver
(1) Soft Faced Mallet
(1) Hammer
(1) Center Punch
(1) Pencil & Tape
Drill Bits: 1/8”, 5/16”, 3/8”, 9/16”
REQUIRED TOOLS
(5) Fas-Trak Mounting Screws #10 x 1” phillips pan head tek screw
(5) Fas-Trak Mounting Screws 10-24 x 1/2” phillips pan head machine screw
(1) Armature Mounting Screw 5/16-18 x 1” hex at head machine screw, turned
(1) Armature Spacer 3/8”D x 0.360”L
(1) Armature Spring Compression spring
(4) Armature Mounting Plate Screws #10 x 1” phillips at head sheet metal screw
(4) Armature Housing Mounting Screws 8-32 x 3/8” phillips machine screw
(1) Anti-Tamper Cover Screw Driver Bit T10 Pin Torx Driver Bit
(1) Fas-Trak Set Screw Wrench 1/8” ball head hex wrench
(1) Armature Bolt Wrench 3/16” hex wrench
(1) Thread Locking Compound Liquid
(2) Bypass/Reset Key
(1) Mini Screwdriver
NOTE: For further parts clarication refer to the Exploded Parts View on page 14 or consult factory.
HARDWARE KIT CONTENTS (PN 301556)
QTY. ITEM DESCRIPTION
General Information........................................... 1
Bill Of Materials................................................. 2
Using The Template........................................... 3
Mounting The Armature Assembly...................... 4
Mounting The Lock............................................. 5
Basic Set-Up...................................................... 6
Basic Wiring...................................................... 7
Egress Sensor Adjustment................................. 8
Indicator Descriptions......................................... 9
Optional Set-Up................................................. 10
Option Wiring..................................................... 11-12
Factory Wiring................................................... 13
Exploded Parts View.......................................... 14-15
TABLE OF CONTENTS
* “30 SECONDS” SIGN AVAILABLE

Page 3
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
Inspect the door frame and determine if an angle bracket, spacer or ller plate will be required for installation. The
lock will require a 2-9/16” wide header stop for a suitable mounting surface.
*These items are available from DynaLock.
MOUNTING CONSIDERATIONS
NORMAL
MOUNTING
*FILLER PLATE
REQUIRED
*ANGLE BRACKET
REQUIRED
USING THE TEMPLATE
Fold the template on the dotted line to form a 90 degree
angle. Scoring the template with a straight edge and a
screwdriver will make it fold easier.
With the door in the closed and latched position place
the template against the header and door with one edge
against the vertical strike jamb and tape in place.
Transfer all hole locations to both the door and header
with a center punch, then remove the template from
the door.
Referring to the template drill two 1/8” dia. lock
mounting holes and one 9/16” dia. wiring hole in the
top of the frame, at the transferred locations.
1.
2.
3.
4.
Drill the remaining transferred holes in the face of the door to accept the Armature Mounting Plate
Assembly:
a. Four 1/8” dia. mounting screw holes, 1” deep.
b. One 3/8” dia. armature screw clearance hole, 3/8” deep.
c. One 5/16” dia. adjustment wheel screw clearance hole, 1/4” deep.
5.
2-9/16” 2-9/16”
*SPACER PLATE
REQUIRED
9/16" DIA. WIRING HOLE
1/8" D IA. DRILL
PLAC E AGA INST HE AD ER
FOLD ON DOTTED LINE
1/4" D IA. ARMATURE GUID E PIN
HOLES 9/1 6" DEEP (2 REQ' D.)
1/8" D IA. DRILL
(4 PL ACES)
PLAC E AGA INST J AMB
OPPOSITE H INGES F OR
L.H.R. DOOR IN STALL ATION
PLAC E AGA INST J AMB
OPPOSITE H INGES F OR
R.H.R. DO OR INSTALLATION
#3101-B SERIES
ELE CT R OM AG NETI C LOC K
11/32" DIA. ARMATURE SCREW
CLEA RANC E HOL E 1" DEEP
CARDBOARD
TEMPLATE
HINGE SIDE
OF DOOR
C

Page 4
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
Using the four #10 x 1” at head sheet metal screws attach the armature mounting plate to the door. Firmly tighten
the screws with a #2 phillips screw driver.
MOUNTING THE ARMATURE ASSEMBLY
Attach the Armature to the Mounting Plate Assembly using the hardware supplied. Apply the supplied thread locking
compound to the threads of the Armature Mounting Screw and rmly tighten with a 3/16” hex wrench. The head of
the armature mounting screw must not project beyond the face of the armature. Failure to properly secure the
Armature to the door could result in serious injury or possible security breach.
Check the installation by pushing in on a corner of the Armature - it should move. Although the mounting screw is
tight the Armature should have approximately 1/4” of free play, under slight spring tension.
(4) 1/8” DIA. MOUNTING
SCREW HOLE - 1” DEEP
(1) 3/8” DIA. ARMATURE SCREW
CLEARANCE HOLE, 3/8” DEEP
(4) #10 X 1”
MOUNTING
SCREW
(1) 5/16” DIA. ADJUSTMENT
WHEEL SCREW CLEARANCE
HOLE - 1/4” DEEP
0.360”L ARMATURE SPACER
5/16-18x1” TURNED
ARMATURE MOUNTING
SCREW
ARMATURE
HOUSING
ARMATURE
8-32x3/8”
ARMATURE
HOUSING
SCREW
SPRING
ARMATURE MOUNTING
PLATE ASSEMBLY

Page 5
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
MOUNTING THE LOCK
Before installation begins remove the rear Electronics Cover,
End Cover and Sensor Cover Assembly (see page 14 for parts
locations). Carefully unplug the sensor harness from the circuit
board connector labeled J5 then detach the Sensor Cover
Assembly from the lock. In the upper inside corners of the lock
housing are located two #1/4-28 set screws. Using the 1/8” ball
head hex wrench loosen (do not remove) the two set screws
until the Fas-Trak Baseplate is free (Fig. “C”). Remove the Fas-
Trak.
Place the Fas-Trak against the header with the slot counter bores
visible and the tabs facing the door (Fig. “A”). Attach the Fas-Trak
to the header at both slotted hole locations, with two #10 x 1” tek
screws or 10-24x1/2” machine screws. Tighten the screws just
snug enough to allow for nal adjustment.
Temporarily mount the lock to the Fas-Trak by offsetting the lock
1-1/8” from the jamb (Fig. “C”) and tipping the front of the lock
down engaging the rear ange of the Fas-Trak (Fig. “B”). Rotate
the lock up allowing one tab to pass through the corresponding
notch in the top of the lock housing. Slide the lock into position.
Close and latch the door. Check that the armature and lock
faces make full contact. If any adjustment is required gently tap
the housing with a soft mallet until full contact is achieved. Open
the door, remove the lock from the Fas-Trak and tighten both
slot screws. Drive three more screws into the header using the
Fas-Trak as a physical template. Screw heads must not project
above the Fas-Trak.
Any roughed-in wiring may be brought in at this time through the slotted wiring holes. Re-install the lock on the
Fas-Trak. Firmly tighten both housing set screws with the 1/8” ball head hex wrench. Re-install the End Cover and
Sensor Cover Assembly. Carefully plug the Sensor harness back into the J5 connector on the circuit board (see
page 13 for connector information). If the lock wiring and set-up are not being done at this time replace the
Electronics Cover and see that these instructions are left for the electrical installer.
1.
2.
3.
4.
FAS-TRAK
TABS
SET
SCREW
LOCK VERTICAL JAMB
FIG. “C”
1-1/8” OFFSET
TABS FACING DOOR
VISIBLE SLOT
COUNTER BORES
LOCK
ENGAGE
REAR
FLANGE
FAS-TRAK
FIG. “B”
FIG. “A”
SET
SCREW

Page 6
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
BASIC SET-UP
- LED Indicator Array
Multicolor high-intensity LED array. Displays Red or Green,
depending on lock mode (see page 9 for indicator modes).
Displays lock status by projecting through lens in ciricuit
board housing cover.
Remove the Electronics Cover to expose the circuit board assembly.
1.
2.
- System Selector Switches
The selector switches (S3) which control major system
functions are factory set to the OFF position for basic lock
operation. Switch 1 will be used during sensor adjustment
(page 8). Switches 2 through 7 are only used for options
described on page 10.
3.
L
C
L
C
(Factory Setting)

Page 7
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
BASIC WIRING
Terminals 1& 2 - Auto-Sensing Power Input. May be 12 or 24 Volts, AC
or DC, uninterrupted. Maximum current draw, by voltage, is as follows:
12VDC: 456 mA
12VAC: 1172 mA
24VDC: 263 mA
24VAC: 779 mA
DO NOT INTERRUPT INPUT POWER (TERMINALS 1 & 2) FOR
AUTHORIZED ACCESS/EGRESS. EXTERNAL ACCESS/EGRESS
CONTROLS (EX. KEYPAD, CARD READER, ETC.) SHOULD USE
DEDICATED BYPASS TERMINALS 7 & 8 or 9 & 10 (SEE PAGE 11).
Terminals 3 & 4 - Fire Panel Input. May be normally-open (N.O.) or
normally-closed (N.C.) dry contacts from re panel (check re alarm control
jumper “FA” - page 6). DO NOT APPLY POWER TO TERMINALS 3 & 4
OR CIRCUIT BOARD DAMAGE WILL OCCUR.
When the re panel trips, the 3101B will release, the audible will sound a
constant tone and the bi-color LED (LED1) will change to green. When the
re panel is reset, the 3101B will reset and lock.
NOTES:
Basic hook-up is shown below. For other system features hook-up see “Option Wiring” (page 11).
PROPER OPERATION OF THE 3101C REQUIRES
ADJUSTMENT OF THE EGRESS SENSOR
PROCEED TO EGRESS SENSOR ADJUSTMENT
POWER
FAC
CONTINUOUS
1 2 3 4
POWER INPUT
12/24 VAC/VDC
FIRE PANEL INPUT
N.O. OR N.C.
CONTACTS
A power limited, UL Listed power supply for security
applications is required for UL294 installations.
When the 3101C is used with a re alarm control panel, wiring
must be done for fail-safe operation.
Suitability of all wiring leads is to be determined based on end-
user product requirements.
1.
2.
3.

Page 8
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
EGRESS SENSOR ADJUSTMENT
WHEEL STOP INSTALLED
(LOCKS ADJUSTMENT)
SEE PAGE 10 FOR LOCATION OF ELECTRONIC PARTS MENTIONED IN THIS SECTION
The sensor and armature assembly are designed for use on a door with existing mechanical latching hardware. If used
on a door without a latch, false alarms are possible. In these cases, we suggest using an external trigger such as our
6451 Exit Sensor Bar - connect using terminals 11&12 and disable this internal sensor (see pages 10&11).
With the door closed and latched apply input power to terminals 1 & 2. Slide
selector switch (DS1) #1 to the ON position to activate the Set-Up mode.
Rotate the on-board keyswitch counter-clockwise. The 3101C should now
be unlocked (Multicolor LED Array OFF).
Open the door. Temporarily remove the Adjustment Wheel Stop from the
Armature Mounting Plate and close the door. Set aside for re-installation
later.
With the door closed observe the multicolor LED array. It should be lit red. If
it is not lit, rotate the adjustment wheel counter-clockwise as necessary to
ensure that it will contact and fully depress the ball plunger on the lock. Rattle
the door to ensure the LED array remains lit.
With the door closed and LED array lit red, unlatch and slowly open the door.
The LED array will shut off as soon as the door opens far enough for the ball
plunger to fully project.
With adjustment completed, re-install the adjustment wheel stop to lock-in
the adjustment. Close the door, slide selector switch (DS1) #1 back to the
OFF position and return the on-board keyswitch to the center position to re-
lock the 3101C.
Unlatch and push on the door until delay egress triggers (1-3 seconds). The
audible will sound and LED array will ash red. After 15 seconds the lock will
release. Turn the on-board keyswitch clockwise to reset the lock. If delayed
egress triggers too soon, or fails to trigger, re-adjust the sensor adjustment
wheel for desired sensitivity.
WHEEL
STOP
MOUNTING
SCREW
WHEEL
STOP
EGRESS SENSOR
ADJUSTMENT WHEEL
ARMATURE
MOUNTING
PLATE
1.
2.
3.
4.
5.
6.
DOOR CLOSED AND LATCHED DOOR UNLATCHED & MOVED

Page 9
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
INDICATOR & AUDIBLE DESCRIPTIONS
BUILT-IN KEYSWITCH OPERATION
CENTER
CLOCKWISE (SPRING LOADED)
COUNTER-CLOCKWISE
NORMAL / LOCKED
RESET AFTER DELAY EGRESS ALARM
BYPASS / UNLOCKED WITHOUT ALARM
POSITION DESCRIPTION
CONDITION AUDIBLE SIGNAL LOCK COVER LED
DELAY EGRESS ALARM One second pulse rate during
delay cycle.
ON BLINK RED
DELAY EGRESS ALARM Steady tone after delay until
reset.
OFF GREEN
FIRE ALARM
RELEASE
Steady tone until re alarm
contacts are reset.
OFF GREEN
OPTIONAL REMOTE
AUTHORIZED BYPASS
(TERMINALS 7&8 / 9&10)
None, unless bypass audible
is enabled (dip switch 2). If
door is held open past relock
time, goes into delay egress
alarm & requires reset.
OFF BLINK GREEN
POOR MAGNETIC
BOND
Rapid pulse rate until problem
is corrected (only functional
with Dynastat Force Sensor
option).
N/A FAST BLINK RED

Page 10
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
OPTIONAL SET-UP
- System Selector Switches
Set the System Selector Switches (S3) to
address your specic system requirements.
The normal factory setting is all switches
off.
1. C
1 SYSTEM SET-UP NORMAL SET-UP MODE
2 BYPASS AUDIBLE DISABLED ENABLED
3 NUISANCE DELAY 1 SEC. 3 SEC.
4 EGRESS DELAY 15 SEC. 30 SEC.
5 MASTER AUDIBLE ENABLED DISABLED
6
7 EGRESS SENSOR ENABLED DISABLED
8 UNUSED SPARE
SWITCH FUNCTION OFF ON
MODE SETTINGS
*
*Only applies to terminals 9&10 (see next page)
FIRE ALARM
INPUT SETTING
NORMALLY
CLOSED
NORMALLY
OPEN
C

Page 11
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
OPTION WIRING
REMOTE BYPASS INPUT
Momentarily closing a normally-open dry contact
across terminals 7 & 8 will immediately release the
lock without alarm. The door will remain unlocked
until the contact is opened. Connect authorized
access/egress control(s) here (typical).
REMOTE RESET INPUT
Momentarily closing a normally-open dry contact
across terminals 5 & 6 will reset and re-lock the
3101C following delayed egress and re-closure of
door.
REMOTE TRIP INPUT
Momentarily closing a normally-open dry contact
across terminals 11 & 12 will initiate delayed egress.
This input may be used as a redundant or substitute
means of triggering delayed egress if built-in sensor
initiation is not desired (see page 10, note 3).
INPUT DESCRIPTIONS
! WARNING: Do not apply power to inputs marked “ ! ” or damage will occur.
A
C
B
D
REMOTE BYPASS INPUT TIME DELAY
Momentarily closing a normally-open dry contact across
terminals 9 & 10 will immediately release the lock without
alarm. The door will remain unlocked for a period of time
controlled by on-board adjustable timer S2. To increase the
delay rotate timer S2 clockwise. Range is 1 to 75 seconds
(~5 sec. per click). For NFPA101 applications, the remote
bypass device time delay must be set for 0 seconds.
For UL294 compliance, all equipment must not be connected with cables greater than 98.5 ft. (30 m) long

Page 12
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
OPTION WIRING
MONITORING OUTPUT DESCRIPTIONS
DELAY EGRESS OUTPUT
Delay egress alarm monitoring.
SPDT dry relay contacts rated 1A @ 24VDC/24VAC
Contacts change state upon initiation of delayed
egress, after the nuisance delay has elapsed. They
remain in that state until door is closed and reset.
DYNST OPTION OUTPUT
Dynastat bond sensor monitoring.
SPDT dry relay contacts rated 1A @ 24VDC/24VAC
Contacts change state to signal lock status as either
secure or unsecure. Armature misalignment can also
create an unsecure condition.
DSM OPTION OUTPUT
Door position sensor monitoring.
SPDT dry relay contacts rated 0.5A @ 24VDC
Contacts change state to signal physical door position
as either closed or open. DSM is an independent
circuit that does not require lock power to operate.
ATS OPTION OUTPUT
Anti-Tamper Switch monitoring.
SPDT dry relay contacts rated 0.25A @ 24VDC
Contacts change state to signal removal of the
lock electronics cover.
TYPICAL WIRING
NOTE: INDICATORS ARE NOT INCLUDED
NOTE: INDICATORS ARE NOT INCLUDED
NOTE: INDICATORS ARE NOT INCLUDED
NOTE: INDICATORS ARE NOT INCLUDED
13 14 15
ALARM
SECURE
NC C NO
TO INDICATOR
POWER SUPPLY
16 17 18
UNSECURE
SECURE
NC C NO
TO INDICATOR
POWER SUPPLY
19 20 21
OPEN
CLOSED
NC C NO
TO INDICATOR
POWER SUPPLY
22 23 24
TAMPER
NORMAL
NC C NO
TO INDICATOR
POWER SUPPLY
E
F
G
H
AAO AUXILIARY ALARM OUTPUT
Secondary delay egress alarm monitoring output.
SPDT dry relay contacts rated 1A @ 24VDC/24VAC
Contacts change state upon initiation of delayed
egress, after the nuisance delay has elapsed. They
remain in that state until door is closed and reset.
NOTE: INDICATORS ARE NOT INCLUDED
25 26 27
ALARM
SECURE
NC C NO
TO INDICATOR
POWER SUPPLY
E
J

Page 13
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
Observe polarity when re-connecting the J5, J7, J8 harness connectors. Orient these connectors with
respect to harness wire colors as follows:
J5 WHT GRN RED BLK **J10 WHT BLK BLU
J7 WHT BLK BLU J8 GRN WHT RED
FACTORY WIRING
DYNASTAT
HARNESS
(2 COND.) DSM OPTION
HARNESS
(3 COND.)
3101C SENSOR COVER
ASSEMBLY
SENSOR
HARNESS
(4 COND.)
COIL
HARNESS
(4 COND.)
KEYSWITCH HARNESS (3 COND.)
ON-BOARD KEYSWITCH
DSM
OPTION
SENSOR
LOCK COIL ASSEMBLY
3101C CIRCUIT BOARD
Harness connectors J3 and J6 are not polarity sensitive.
Harnesses J6 and J8 are only present if the 3101C is equipped with the DYN - Dynastat Force Sensor
and/or DSM - Door Status Switch Options.
1.
2.
3.
NOTES:
BPM BYPASS MONITOR
OPTION (2 YELLOW COND.)
MAINTAINED - N.O., 4A@125V
3101A SERIES
LEGACY SENSOR
(OPTIONAL)
**Note: J10 is normally not-used. It is specically intended to allow interfacing the 3101C Circuit Board to
a 3101A Series legacy sensor cover assembly, when necessary.

Page 14
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
EXPLODED PARTS VIEW
LEGEND ON
NEXT PAGE
1
2
3
4
5
6
11
12 13
1-1/2”
1/4”
1-31/32”
1/2”
7
8
9
10
14
15
17
16
18
19
20
21

Page 15
3101C Gen II MANUAL 11/17
INSTALLATION INSTRUCTIONS
705 Emmett Street Bristol, CT 06010
1-877-DynaLock www.dynalock.com
3101C DELAYED
EGRESS LOCK
(GENERATION II)
EXPLODED PARTS VIEW LEGEND
ITEM DESCRIPTION PART #
1Fas-Trak Baseplate 300011
2#10x1” Self-Tapping Screw *
210-24x1/2” Machine Screw *
3 Lock Housing
4 Access Cover & Sensor Assembly 301037
58-32x3/8” Machine Screw 300608
6 1/4-28x1/4” Set Screw 300604
7 Electronics Cover 300549
86-32x1/2” Pin Torx Security Screw 700174
9End Cover 300010
* Part of Hardware Kit (301556)
Refer to Page 14 for parts locations.
ITEM DESCRIPTION PART #
10 Armature Mounting Plate Assy. 301038
11 Sensor Adjustment Wheel & Stud 301383
12 Wheel Stop 301003
13 8-32x1/2” Wheel Stop Screw 301005
14 #10x1” FHS Mtg. Plate Screw *
15 Armature Housing w/ pads 301334
16 8-32x3/8” Armature Mtg. Screw *
17 Disc Magnet (DSM only) 301289
18 Armature 300373
19 Compression Spring *
20 0.360”L Armature Spacer *
21 5/16-18x1” Armature Bolt (turned) *

Page 16
3101C Gen II MANUAL 11/17
PLEASE DELIVER THIS MANUAL
AND THE KEYS TO THE END USER UPON
COMPLETION OF THE 3101C INSTALLATION
FOR PRODUCT SUPPORT AND PARTS
ORDERING INFORMATION CONTACT:
DynaLock Corp.
705 Emmett Street
Bristol, CT 06010
Bus: [phone] Toll-Free USA
[phone]
Fax: [phone]
DYNALOCK ON THE INTERNET:
E-mail: [email protected]
Website: www.dynalock.com
GWXT/GWXT7 - AUXILIARY LOCK
ALVY - ACCESS CONTROL SYSTEM UNIT
SPECIAL LOCKING ARRANGEMENTS
CATEGORY FWAX
Products tested to the
following Access Control
Performance Levels:
Line Security - I (None)
Destructive Attack - I (None)
Endurance - IV (100,000 cycles)
Standby Power - I (None)
