DYNAMIX IP PHONE 530
User Manual

DYNAMIX IP PHONE 530. User Manual
2/49
1DYNAMIX IP PHONE 530 Features.......................................................................... 4
1.1 Appearance..........................................................................................................................4
1.2 Interface ..............................................................................................................................4
1.3 Electricity characteristic......................................................................................................4
1.4 Software..............................................................................................................................4
1.5 Standard and Protocols........................................................................................................5
1.6 Compliant Standard.............................................................................................................5
1.7 Operating requirement ........................................................................................................5
1.8 Package ...............................................................................................................................6
1.9 Installation...........................................................................................................................6
2Web Configuration....................................................................................................... 6
2.1 Access Web setting page.....................................................................................................6
2.2 Current state........................................................................................................................7
2.3 Network...............................................................................................................................8
2.3.1 Wan Config .....................................................................................................................8
2.3.2 LAN Config ....................................................................................................................9
2.4 VoIP SIP Config................................................................................................................10
2.5 Advance ............................................................................................................................12
2.5.1 DHCP Server......................................................................................................... 12
2.5.2 NAT.......................................................................................................................13
2.5.3 Net Service............................................................................................................ 14
2.5.4 Firewall settings.................................................................................................... 15
2.5.5 QoS settings .......................................................................................................... 16
2.5.6 Advance SIP settings............................................................................................. 17
2.5.7 Digital Map ........................................................................................................... 18
2.5.8 Call Service Settings ............................................................................................. 20
2.5.9 MMI Filter............................................................................................................. 22
2.5.10 Audio Settings....................................................................................................... 22
2.5.11 VPN....................................................................................................................... 23
2.5.12 Memory Key ......................................................................................................... 24
2.6 Dial-Peer ...........................................................................................................................24
2.7 Config Manage..................................................................................................................25
2.8 Update...............................................................................................................................25
2.8.1 Web Update:.......................................................................................................... 25
2.8.2 TFTP/FTP Update:................................................................................................ 25
2.8.3 Auto Provisioning: ................................................................................................ 25
2.9 System Manage.................................................................................................................27
2.9.1 Account Manage ................................................................................................... 27
2.9.2 Phone Book:.......................................................................................................... 27
2.9.3 Syslog Config:....................................................................................................... 27
2.9.4 Time Set:............................................................................................................... 28
2.9.5 Reboot:.................................................................................................................. 28
3Use keypad configure DYNAMIX IP PHONE 530 .................................................. 29
3.1 Keypad function................................................................................................................29
3.2 Keypad Menu....................................................................................................................30
4Telnet Console ........................................................................................................... 32
4.1 Introduce ...........................................................................................................................32
4.2 Global Command..............................................................................................................33
5Tree Structure............................................................................................................. 34
6Network Diagnosis..................................................................................................... 40
7Restore to factory default........................................................................................... 41

DYNAMIX IP PHONE 530. User Manual
3/49
8POST Mode(safe mode) ............................................................................................ 42
9FAQ............................................................................................................................ 43
9.1.1 How many servers may Dynamix IP phone 530 register simultaneously? ........... 43
9.1.2 Why the settings vanish after reboot? ................................................................... 43
9.1.3 How to use the dial rule?....................................................................................... 43
9.1.4 How to use speed dial function? ........................................................................... 44
9.1.5 How to configure digital map?.............................................................................. 44
9.1.6 How to use Call Forward, Call Transfer and 3-way Conference calls? ................ 44
9.1.7 How to use the record function? ........................................................................... 46
9.1.8 How to use set the IP type via keypad?................................................................. 47
9.1.9 VLAN implement.................................................................................................. 47

DYNAMIX IP PHONE 530. User Manual
4/49
1DYNAMIX IP PHONE 530 Features
1.1 Appearance
1.2 Interface
Power: Output Power:12VDC,500mA.
WAN: RJ45 port.
LAN: RJ45 port.
1.3 Electricity characteristic
zSpeciality of electric: output the 12V 500mA DC
zThe network connects:2 RJ45 connect, a WAN, a LAN
1.4 Software
zSupport two sip accounts at the same time.
zRedundancies server support.
zNAT, Firewall.
zDHCP client and server.
zSupport PPPoE, (used for ADSL, cable modem connecting).
zSupport major G7.xxx CODEC.
zVAD,CNG.

DYNAMIX IP PHONE 530. User Manual
5/49
zG.168 compliant 32ms echo cancellation
zTone generation and Local DTMF re-generation according with ITU-T
zE.164 dial plan and customized dial rules
zHotline.
zSpeed Dial
zCall Forward, Call Transfer, 3-way conference calls
zRecord
zCaller ID display
zDND(Do Not Disturb),Black List,Limit List
zUpgrade firmware through FTP, TFTP or HTTP,.
zWeb management.
zTelnet remote management.
zadjustable user password and super password
1.5 Standard and Protocols
zIEEE 802.3 /802.3 u 10 Base T / 100Base TX
zPPPoE: PPP Protocol over Ethernet
zDHCP Client and Server: Dynamic Host Configuration Protocol
zG.711 u/a; G729, G7231 5.3/6.3 audio Codec
zSIP RFC3261, RFC 2543
zIAX2
zTCP/IP: Internet transfer and control protocol
zRTP: Real-time Transport Protocol
zRTCP: Real-time Control Protocol
zVAD/CNG save bandwidth
zTelnet: Internet's remote login protocol
zDNS: Domain Name Server
zTFTP: Trivial File Transfer Protocol
zHTTP: Hyper Text Transfer protocol
zFTP: File Transfer protocol
1.6 Compliant Standard
zCE：EN55024,EN55022
zFCC part15
zcomply with ROHS in EU
zcomply with ROHS in China
z
Explanation:
The letter “e” is the first letter of “environment: and “electronic”, The rim is a round with two arrow ,
stands for recycle. The number 20 stands for the years of environment protection. Please note the
years of environment protection is not discarding year nor usage life
1.7 Operating requirement
zOperation temperature: 0 to 40° C (32° to 104° F)
zStorage temperature: -30° to 65° C (-22° to 149° F)
zHumidity: 10 to 90% no dew

DYNAMIX IP PHONE 530. User Manual
6/49
1.8 Package
zSize: 338×220×85mm
zPacking List
9DYNAMIX IP PHONE 530
9Power adaptor (out put 12v ,500mA)
9Manual CD
1.9 Installation
Use ethernet cable to connect DYNAMIX IP PHONE 530’s LAN port and your computer. Set your
computer’s ip to the network 192.168.10.x or using dynamic obtain IP. Open your web browser and
key in 192.168.10.1. Then you will see the logon page of DYNAMIX IP PHONE 530, the default
username and password is admin/admin for administrator and guest/guest for guest.
Set up page for VoIP use only:
2Web Configuration
2.1 Access Web setting page
Enter DYNAMIX IP PHONE 530 IP address in the web browser and press ENTER to go to the log on
page, and key in the username and password to access DYNAMIX IP PHONE 530 setting page.
Default username and password is:
Administrator: Username: admin password: admin
User: Username:guest Username: guest

DYNAMIX IP PHONE 530. User Manual
7/49
2.2 Current state
This page shows DYNAMIX IP PHONE 530’s running state.
Network shows the WAN and LAN port connecting state and current settings.
VoIP part show the working state of VoIP, you can see whether DYNAMIX IP PHONE 530 has
registered the public sip server

DYNAMIX IP PHONE 530. User Manual
8/49
Phone Number public sip and private sip phone numbers.
2.3 Network
2.3.1 Wan Config
WAN port network setting page.
Support static IP, dynamic obtain IP and PPPoE.
VLAN Enable: Enable Vlan
¾Configure Static IP:
----Enable Static;
----Set DYNAMIX IP PHONE 530’s IP address in the IP Address;
----Set netmask in the Netmask field;
----Set router IP address in the Gateway;
----DNS Domain:
----Set local DNS server in the Preferred DNS and the Alternate DNS
----Auto DNS：DNS select it to get the DNS address automatically
¾Configure to dynamic obtain IP
----Enable DHCP;
If there is DHCP server in your local network, DYNAMIX IP PHONE 530 will automatically
obtain WAN port network information from your DHCP server.
¾Configure PPPoE:
----Enable PPPoE
----PPPoE server: Enter “ANY” if no specified from your ITSP.
----Enter PPPoE username and pin in the username and password.
-----Fixed IP: use the fixed IP address
DYNAMIX IP PHONE 530 will automatically obtain WAN port network information from your

DYNAMIX IP PHONE 530. User Manual
9/49
ITSP if PPPoE setting and the setup are correct.
Notice: If user accesses the IP phone through WAN port. He/She should use the new IP address to
access the IP phone when the WAN port address was changed.
2.3.2 LAN Config
Bridge Mode: Enable this option to switch to bridge mode. IP phone won’t assign IP for its LAN
port in bridge mode and its LAN and WAN port will be in the same network. (This setting won’t take
effect unless you save the config and reboot the device)
IP Netmask: Set the IP and Netmask for the LAN
DHCP Server: Enable DHCP service in LAN port
NAT: Enable NAT.

DYNAMIX IP PHONE 530. User Manual
10/49
2.4 VoIP SIP Config
2.4.1 SIP config
Setting page of public SIP server:
Register ServerAddr: Register address of public SIP server
Register Server Port: Register port of public SIP server，default port is 5060
Register Username: Username of your SIP account (Always the same as the phone number)
Register Password: Password of your SIP account.
Proxy ServerAddr: IP address of proxy SIP server (SIP provider always use the same IP for
register server and proxy server, in this case you don’t need to configure the proxy server
information. )
Proxy Server Port: Signal port of SIP proxy
Proxy Username: proxy server username
Proxy Password: proxy server password
Domain Realm: SIP domain, enter the sip domain if any, otherwise DYNAMIX IP
PHONE 530 will use the proxy server address as sip domain.
Local SIP port: Local SIP register port, default 5060
Phone Number: Phone number of your SIP account
Display name: config the diaply name , it can be displayed at the callee's side . only letter and
number input is allowed here
Register Expire Time: register expire time, default is 600 seconds. DYNAMIX IP PHONE 530 will
auto configure this expire time to the server recommended setting if it is different from the SIP server.
Detect Interval Time: Co-work with the Auto Detect Server, if Auto Detect Server is enable,
DYNAMIX IP PHONE 530 will periodically detect if the SIP server is available according this
setting.
User Agent:
Encrypt Key: The particular service system decrypts of the key , matching with the server Type
usage, the key provide by the particular service system supplier, default is empty

DYNAMIX IP PHONE 530. User Manual
11/49
Server Type：The particular service system supplier carries out the sign and speeches to encrypt,
default is common
DTMF Mode: DTMF signal sending mode: support RFC2833, DTMF_RELAY (inband audio) and
SIP info
RFC Protocol Edition: Current DYNAMIX IP PHONE 530 SIP version. Set to RFC 2543 if the gate
need to communicate to devices (such as CISCO5300) using the SIP 1.0. Default is RFC 3261.
Enable Register: Enable/Disable SIP register. DYNAMIX IP PHONE 530 won’t sent register
info to SIP server if disable register.
Transport Protocol: config the transfer protocol, TCP or UDP.
2.4.2 Iax2 Config
Setting page of public IAX server:
IAX Server Addr: Register address of public IAX server
IAX Server Port: Register port of public IAX server，default port is 4569
Account Name: Username of your SIP account (Always the same as the phone number)
Account Password: Password of your IAX account.
Local port: Signal port of local, default port is 4569
Phone Number: Phone number of your IAX account
Voice mail number: If the IAX support voice mail, but your username of the voice mail is letters
which you can not input with the ATA , then you use the number to stand for your username
Voice mail text: if IAX support voice mail, config the domain name of your mail box here.
Echo test number: If the platform support echo test , and the number is test form , the config the test
number to replace the text format The echo test is to test the woring status of terminals and platform
Echo test text: echo test number in text format
Refresh time: IAX refresh time
Enable Register: enable or disable register
IAX(Default Protocol): Set IAX 2 as the default protocol , if not the system will choose SIP as
default

DYNAMIX IP PHONE 530. User Manual
12/49
Enable G.729: Using G.729 speech coding mandatory consultations
2.5 Advance
2.5.1 DHCP Server
DHCP server manage page.
User may trace and modify DHCP server information in this page.
DNS Relay: enable DNS relay function.
User may use below setting to add a new lease table.
Lease Table Name: Lease table name.
Lease Time: DHCP server lease time.
Start IP: Start IP of lease table.
End IP: End IP of lease table. Network device connecting to the DYNAMIX IP PHONE 530 LAN
port can dynamic obtain the IP in the range between start IP and end IP.
Netmask: Netmask of lease table.
Gateway: Default gateway of lease table
DNS: default DNS server of lease table.
Notice: This setting won’t take effect unless you save the config and reboot the device

DYNAMIX IP PHONE 530. User Manual
13/49
2.5.2 NAT
Advance NAT setting. Maximum 10 items for TCP and UDP port mapping.
IPSec ALG: Enable/Disable IPSec ALG;
FTPALG: Enable/Disable FTP ALG;
PPTPALG: Enable/Disable PPTPALG;
Transfer Type: Transfer type using port mapping.
Inside IP: LAN device IP for port mapping.
Inside Port: LAN device port for port mapping.
Outside Port: WAN port for port mapping.
Click Add to add new port mapping item and Delete to delete current port mapping item.

DYNAMIX IP PHONE 530. User Manual
14/49
2.5.3 Net Service
HTTP Port: configure HTTP transfer port, default is 80.User may change this port to enhance
system’s security. When this port is changed, please use http://xxx.xxx.xxx.xxx:xxxx/ to reconnect.
Telnet Port: configure telnet transfer port, default is 23.
RTP Initial Port: RTP initial port.
RTP Port Quantity: Maximum RTP port quantity, default is 200
Notice:
Settings in this page won’t take effect unless save and reboot the device.
If you need to change telnet port or HTTP port, please use the port greater than 1024,
because ports under 1024 is system remain ports.
HTTP service if HTTP is set to 0.

DYNAMIX IP PHONE 530. User Manual
15/49
2.5.4 Firewall settings
Firewall setting page. User may set up firewall to prevent unauthorized Internet users from accessing
private networks connected to the Internet (input rule), or prevent unauthorized private network
devices to access the internet.
Access list support two type limits: input_access limit or output_access limit. Each type support 10
items maximum.
DYNAMIX IP PHONE 530 firewall filter is base WAN port. So the source address or input
destination address should be WAN port IP address.
Configuration:
in_access enable enable in_access rule
out_access enable enable out_access rule
Input/Output: specify current adding rule is input rule or output rule.
Deny/Permit: specify current adding rule is deny rule or permit rule.
Protocol Type: protocol using in this rule: TCP/IP/ICMP/UDP.
Port Range: port range if this rule
SrcAddr: source address. Can be single IP address or network address.
Dest Addr: destination address. Can be IP address or network address.
Src Mask: source address mask. Indicate the source is dedicate IP if set to 255.255.255.255.
Otherwise is network ID
Des Mask: Destination address mask. Indicate the source is dedicate IP if set to
255.255.255.255. Otherwise is network ID

DYNAMIX IP PHONE 530. User Manual
16/49
2.5.5 QoS settings
DYNAMIX IP PHONE 530 IP phone implement QoS based on 802.1p, The QoS is used to mark the
network communication priority in the data link/MAC sub-layer. DYNAMIX IP PHONE 530 will
sorted the packets using the QoS and sends it to the destination.
1. Voice 802.1p Priority --- Configure the priority of the voice packets in 802.1p protocol.
2. VLAN Enable --- Disable/Enable VLAN function
3. Voice VLAN ID --- configure the Voice/signaling VLAN ID
4. DiffServ Enable --- Disable/Enable Diffserv service
5. DiffServ Value --- Configure Diffserv parameter. The value range : value range：
0x28,0x30,0x38,0x48,0x50,0x58,0x68,0x70,0x78,0x88,0x90,0x98,0xb8.default is 0xb8 ,oxb8 stands
for best fast transmission; 28-30 is guaThrantee for the transmission priority for the 1st rank , 48-58 is
guarantee for the transmission priority for the 2nd rank, 68-78 is guarantee for the transmission
priority for the 3rd rank, 88-98 is guarantee for the transmission priority for the 4th rank.
6. Data VLAN ID--- Assign VLAN id for data stream.
7. Data 802.1P Priority --- Configure the priority of the data packets (non-voice/signaling data) in
802.1p protocol.
8. Data/Voice DiffServ differentiated --- undifferentiated for Date and voice VLAN is not
distinction VLAN tag, Tag differentiated for Date and Voice VLAN is distinction VLAN tag,
Date untagged for Date VLAN is distinction VLAN tag
Please refer to VLAN implement for detail

DYNAMIX IP PHONE 530. User Manual
17/49
2.5.6 Advance SIPsettings
This page is used to set the private sip server, stun server, and back up sip server information.
STUN Server setting:
STUN ServerAddr: configure stun server address;
STUN Server Port: configure stun server port default 3478
STUN Effect Time: stun detect NAT type circle, unit: minute.
Enable SIP STUN: enable/disable stun.
Enable PRACK: Whether to make gateway or IP phone support Prack function in SIP , we suggest
you keeping default setting
Enable Keep Authentication: registering signal together with the authentication information. If
enable it, the server will confirm the registering and send back the confirmation massage directly
instead of requesting the terminals to send authentication information if needed.
Auto Detect Server: Whether to enable the function of auto detecting the server. With this function
your ATA and IP phone will send information to auto detect the server at every period of time. If find
the server is not available it will try to register the server again.
Enable Session Timer：Whether to enable te RFC4028
Signal Encode: Wherther to enable the signal encrypt
Rtp Encode: Whether to enable the voice encrypt
Enable Private Register: Whether to enable the second SIP Server to register
Please refer to SIP_Config for the setting for how to set the public alter server.
User can register two sip servers: public sip server and private sip server.these two sip servers are
independent from each other and running in the same time.
For how to configure private sip server. Please refer to SIP_Config
Enable URI Convert: transfer the # into %23 when sending URI
Enable Strict Proxy: compatible with special server ( when the message is returned , they use

DYNAMIX IP PHONE 530. User Manual
18/49
original address but not the address in via field
Enable Quote Name: To work with the server , config here to use quotation mark to include the
displayname
Enable Subscibe: subscribe the message such as other side's status or the voice mail after successful
registration
2.5.7 Digital Map
Digit map is a set of rules to determine when the user has finished dialing.
DYNAMIX IP PHONE 530 support below digital map:
Digital Map is based on some rules to judge when user end their dialing and send the number to the
server. DYNAMIX IP PHONE 530 support following digital map:
----End With “#”: Use # as the end of dialing.
----Fixed Length: When the length of the dialing match, the call will be sent.
----Timeout: Specify the timeout of the last dial digit. The call will be sent after timeout
----Prefix: User define digital map:
[ ] represents the range of digit, can be a range such as [1-4], or use comma such as [1,3,5], or
use a list such as [234]
x represents any one digit between 0~9
Tn represents the last digit timeout. n represents the time from 0~9 second, it is necessary. Tn
must be the last two digit in the entry. If Tn is not included in the entry, we use T0 as default, it means
system will sent the number immediately if the number matches the entry.
Example:
[1-8]xxx All number from 1000 to 89999 will be sent immediately.
9xxxxxxx 8 digits numbers begin with 9 will be sent immediately.
911 Number 911 will be sent will be immediately
99xT4 3 digits numbers begin with 99 with be sent after four seconds.

DYNAMIX IP PHONE 530. User Manual
19/49

DYNAMIX IP PHONE 530. User Manual
20/49
2.5.8 Call Service Settings
User configure the value add service such as hotline, call forward, call transfer, 3-way conference
call .etc in this page
Hotline: configure hotline number. DYNAMIX IP PHONE 530 immediately dials this number after
hook-off if it is set.
Call Forward: Please refer to Value_add_service for detail.
No Disturb: DND, do not disturb, enable this option to refuse any calls.
Ban Outgoing: Enable this to ban outgoing calls.
Enable Call Transfer: Please refer to Value_add_service for detail.
Enable Three Way Call: Please refer to Value_add_service for detail.
Enable Call Waiting: Enable/disable Call Waiting
Accept Any Call: If this option is disable, DYNAMIX IP PHONE 530 refuse the incoming call
when the called number is different from DYNAMIX IP PHONE 530’s phone number.
No Answer Time: no answer call forward time setting.
Auto Answer: Enable/disable auto answer function.
Enable Voice Record: Enable/disable answering machine function. Please refer to Record Function
for detail.
User-defined Voice: Use customized greeting message.
Incoming Record Playing: simultaneously play the message when recording.
P2P IP Prefix: Config the point to point calling. For example , if you want to call IP 192.168.1.119
Just defin 192.168.1. here and you can dial #119 to make the point to point call with the IP phone of
192.168.1.119
Use Record Server: Config the supporting of server recording , transfer all the recording to server.
