Dynamix 530 User manual

DYNAMIX IP PHONE 530
Quick Start Guide

DYNAMIX IP PHONE 530. Quick Start Guide
--------------------------------------------------------------
2
Installation and access.....................................................................................3
Configure DYNAMIX IP PHONE 530 to make VoIP calls.................................4
WAN Config.....................................................................................................4
SIP Config........................................................................................................5

DYNAMIX IP PHONE 530. Quick Start Guide
--------------------------------------------------------------
3
Installation and access
Installation:
Set up DYNAMIX IP PHONE 530 as below:
When the DYNAMIX IP PHONE 530 is connecting to your network.
You can use the “Sysinfo” button to obtain DYNAMIX IP PHONE 530 WAN port IP.
Modify your computer’s IP address to the same network as DYNAMIX IP PHONE 530
Key in DYNAMIX IP PHONE 530’s IP address in the web browser and press enter, then
you can access DYNAMIX IP PHONE 530’s web manage interface. Remember the
account is admin/admin for administrator and guest/guest for user.

DYNAMIX IP PHONE 530. Quick Start Guide
--------------------------------------------------------------
4
Configure DYNAMIX IP PHONE 530 to make VoIP calls
WAN Config
Enter Network Æ WAN Config to set the WAN setting:
DYNAMIX IP PHONE 530 supports three different IP types: Static IP, Dynamic obtain IP
(DHCP) and PPPoE. You can use either of these IP types to connect the internet.
Use Static IP:
----Select “Static”;
----Enter the DYNAMIX IP PHONE 530’s IP address in the “IP address” field.
----Set the “Netmask”, default 255.255.255.0
----Enter the DYNAMIX IP PHONE 530’s upper gateway IP address (for example:Router)
in the “Gateway” field
----Key in the DNS information in the “Primary DNS” and “Alter DNS” fields.
Use DHCP:
----Select DHCP
If you have a DHCP server in your network, DYNAMIX IP PHONE 530 will automatically
obtain the network information from your DHCP server.
Use PPPoE:
----Select PPPoE
----Type your PPPoE dialup information in the PPPoE setting fields:PPPoE server(option),

DYNAMIX IP PHONE 530. Quick Start Guide
--------------------------------------------------------------
5
Username and password.
Then the DYNAMIX IP PHONE 530 will connect to the internet through PPPoE , and
automatically obtain the IP address , Netmask, Gateway, Primary DNS and Alter DNS
information.
SIP Config
Enter VoIP Æ SIP Config setting page and set the sip information
----Register Server Addr : sip server address;
----Register Server Port : sip server register port;
----Register Username : username of your sip account;
----Register Password : password of your sip account;
----Register Number : Phone number of your sip account; the same as username if none
----check Enable Register；
Then you can make VoIP calls if the WAN and SIP config is correct.
Notice: Please go to the “Config Manage” and save the config, otherwise you will lose the
setting after device reboot.
