DYNAMIX UM-A4W
ADSL Router
4 Port 10/100 Mbps
Fast Ethernet Switch
Quick Setup Guide

Contents
I. Panel Description………………………………….………….………………..P2
II. Connecting IEEE 802.11b Wireless ADSL Router…………P4
III. Set Up TCP/IP In Windows………………….….…………..….…….…P5
Option-A : Windows ME/98…………………………...………….….….….P5
Option-B : Windows 2000……………………………….…….…….…….P6
Option-C : Windows XP…………………………………………………..…P7
IV. Set Up IEEE 802.11b Wireless ADSL Router…………………....P8
IEEE 802.11b Wireless ADSL Router P1

I. Panel Description
1. Front Panel
POWER Lights up when the IEEE 802.11b Wireless ADSL Router is powered on.
Lit when the IEEE 802.11b Wireless ADSL Router is ready for services.
WLAN READY Blinking when Wireless communication is active.
ADSL Lit when a successful ADSL connection is established.
RXD Blinking when data communication is active.
Port 1 : LINK/ACT Port 1. Blinking when the IEEE 802.11b Wireless ADSL Router is actively
sending/receiving data.
Port 2 : LINK/ACT Port 2. Blinking when the IEEE 802.11b Wireless ADSL Router is actively
sending/receiving data.
Port 3 : LINK/ACT Port 3. Blinking when the IEEE 802.11b Wireless ADSL Router is actively
sending/receiving data.
Port 4 : LINK/ACT Port 4. Blinking when the IEEE 802.11b Wireless ADSL Router is actively
sending/receiving data.
RESET Restore the IEEE 802.11b Wireless ADSL Router’s factory default setting.
IEEE 802.11b Wireless ADSL Router P2

2. Back Panel
LINE Connect to ADSL Line.
PORT 1 Connect to network device 1. Support auto crossover functionality.
PORT 2 Connect to network device 2. Support auto crossover functionality.
PORT 3 Connect to network device 3. Support auto crossover functionality.
PORT 4 Connect to network device 4. Support auto crossover functionality.
USB USB Rev. 1.1 specification compliant for host computer connection.
AC JACK Connect to AC Power Adaptor.
POWER SWITCH Power ON/OFF Switch.
IEEE 802.11b Wireless ADSL Router P3

II. Connecting IEEE 802.11b Wireless ADSL Router
1. Wired and wireless devices connection mechanism :
2. Wired Connection:
A. Make sure all your network hardware and PCs are powered off.
B. Connect one end of your Ethernet network cable (RJ45) to one of the LAN ports
( Labeled 1~4 ) on the Wireless Router, and plug in the other end to an Ethernet
port on your PC.
C. Connect your ADSL Line from the Splitter or Microfilter to the ADSL port of the
IEEE 802.11b Wireless ADSL Router.
D. Connect the AC Power Adaptor to the IEEE 802.11b Wireless ADSL Router and
the other end of the adaptor to the wallet.
E. Power on your Notebook/PCs and IEEE 802.11b Wireless ADSL Router.
3. Wireless Connection:
 Requirements: Your Notebook/PC must have IEEE802.11g PCMCIA or USB or PCI
Wireless Adaptor properly installed.
A. Make sure all your network hardware and PCs are powered off.
B. Power on your Notebooks/PCs and IEEE 802.11b WirelessADSL Router.
C. For initial access to the Wireless Router through a wireless connection, make
sure your Notebook/PCs Wireless Adaptors has its “SSID” set to “AP_Router” and
with its “WEP” encryption set to “Disable”.
IEEE 802.11b Wireless ADSL Router P4

III. Set Up TCP/IP In Windows
Option-A Windows ME / 98
Step 3: Select the network adapter installed
and click on Properties.
2
Step 2: Double-click the Network icon.
Step 1: Click Start →Setting
→Control Panel.
1
Step 4: Select Obtain an IPaddress
automatically.
2
1
Step 5: Erase all the gateway setting. Step 6: Select Disable DNS then click OK.
IEEE 802.11b Wireless ADSL Router P5

Option-B Windows 2000
3
2
1
Step5: Select Obtain an IPaddress
automatically and Obtain DNS
server address automatically.
Then Click OK.
Step 2: Double-click the Network and Dial-up
Connections icon.
Step 3: Right Click on the Local Area
Connection and select Properties.
Step 4: Select Internet Protocol(TCP/IP)
and click Properties.
Step 1: Click Start →Setting
→Control Panel.
IEEE 802.11b Wireless ADSL Router P6

Option-C Windows XP
IEEE 802.11b Wireless ADSL Router P7
3
Click Switch to Classic View.
Step 1: Click Start →Click Control Panel.
Step 2: Double-click the Network
Connections icon.
Step 3: Right Click on the Local Area
Connection and select Properties.
Step 4: Select Internet Protocol(TCP/IP)
and click Properties.
Step5: Select Obtain an IPaddress
automatically and Obtain DNS server
address automatically. Then click OK.
2
1

IEEE 802.11b Wireless ADSL Router P8
IV. Set Up IEEE 802.11b WirelessADSL Router
1. Launch your web browser, and enter the IEEE 802.11b Wireless ADSL
Router’s IP Address : “10.0.0.2” in the address field then press the Enter key to
login.
2. Enter the default User Name “admin” and Password “epicrouter”. Then press
“OK” to login.
3. Click “Automatic Setup” and follow the following steps to help you install the
IEEE 802.11b WirelessADSL Router quickly and easily.

STEP 1. Select the presetting country form the list.
 IP Mode : Click “Dynamic IP” or “Static IP” for the connection
mode. Check your ISP for the connection/setting details.
 If “Static IP” mode is chosen, more terms need to be filled before
any Internet access is available. Check your ISP for the
setting/configuration details.
 For some specific Encapsulation, you might need to fill in your “User
Name” and “Password”. Check your ISP for the
setting/configuration details.
 Click and select “Manual Setup” if you can’t find any available
parameters from the country list. Check your ISP immediately for the
setting/configuration details.
STEP 2. Click “Save Setting” after your choice.
The IEEE 802.11b Wireless ADSL Router system will reboot and activate your
setting. Click “Back To Home” after the reboot process. Connection to the
Internet is available after the above process.
