dynarex Bari+Max 10670 User manual

WARNING
1. Before use, please read the user manual carefully.
2. Please pay attention to the positions contacting the cushion
bottom, which may produce sliding phenomenon.
3. Please don't use awls or other sharp tools to contact the cushion.
4. Fill the appropriate amount of air during use.
5. Keep away from fire and moist environments.
6. Please don't bend or fold the cushion in the gas filling state.
7. If any part of body touches the cushion base, too much air has
been released, which will reduce the therapeutic effect.
8. Please check the cushion every day to make sure the patient will
not bottom out.
9. Please preserve the product and its accessories in
a dry environment.
Reorder No. 10670
Reorder No. 10671
Bari+Max
Support Where You Need It
Bariatric Air Cushion

1. Cells
2. Hand pump
3. Valve
4. Black rope
5. Repair kit
6. User manual
7. Cover
INSTRUCTIONS
1. Cells: Made of medical rubber & PVC.
2. Hand pump: Used to inflate the cushion with air.
3. Valve: Each cushion has a valve which is used to adjust the air
inside cushion and softness of cushion.
4. Black rope: For carrying or lifting the cushion.
5. Repair kit: Includes glue and two patches of film to repair
small holes.
6. User manual: Provides instruction on adjustment, care and repair.
7. Polyester cover: Helps keep the cushion surface clean and
prevents cushion from sliding.
1. Place the air cushion on chair. Air
cells should be facing up and the
valve should be positioned in the
front. Turn valve counterclockwise
to open.
2. Slide the silicone pump nozzle
over the valve. Inflate until the
cells begin to arch upwards.

3. Turn valve clockwise
to close and remove
the hand pump.
5. Place your hand between
cushion and the patient’s
lowest penetrating bony
prominence.
4. While the cushion is in this
over-inflated condition,
place the patient on the
cushion in his/her normal
sitting position with arm and
foot rests properly placed.
6. With your hand in place, slowly
turn the valve counterclockwise
to release some air to immerse
the patient in the cushion in
order to achieve the desired
personal comfort level. The
inflation height should be no
more than 1″and no less than
½″of cushioning between the
chair and the lowest
penetrating bony prominence.

CLEANING INSTRUCTIONS
CUSHION
1. Use germicidal soap to wash the cushion.
2. Use a wash cloth to wipe the cushion dry. Do not use detergents
or other solvents.
3. Do not machine wash or tumble dry.
4. Do not heat or steam autoclave.
COVER
1. Wash at 30˚C / 86˚F
2. Do not iron.
3. For single patient use only.
REPAIRING LEAKS
1. Make sure the cushion and all four corners are inflated
completely.
2. Immerse the over-inflated cushion into water to locate the leak.
(You will see air bubbles rising from the area where the leak
is located.)
3. When the leak has been located, mark the leak.
4. Deflate the cushion.
5. Allow the cushion to dry completely.
6. Clean the area around the hole and let the surface dry.
7. Place a patch film over the hole.
8. Press the patch film down firmly to seal. Do not use the cushion
for at least 30 minutes.
9. When leak repair is complete, adjust the cushion to proper
inflation according to the user manual.
10. Repeat to test if there are any other leaks.
Patches do not change the performance of the cushion, but if your
patch is not successful in solving the problem, or there is more
serious damage, please contact your local provider.
SYMBOL GLOSSARY
For an explanation of symbols
used in Dynarex packaging, vi sit
dynarex.com/symbols.php
Manufactured for: Dynarex Corporation
10 Glenshaw Street | Orangeburg, NY 10962
USA • www.dynarex.com | Made in China R220722
