dynarex Adjustable Full Length Bed Rail User manual

LIMITED LIFETIME WARRANTY
Your Dynarex Product is warrantied to be free of defects
in materials and workmanship for the lifetime of the
product for the original consumer purchaser. This item
was built to exacting standards and carefully inspected
prior to shipment. This Limited Lifetime Warranty is an
expression of our confidence in the materials and
workmanship of our products and our assurance to the
consumer of years of dependable service.
The Warranty shall not apply under the following
conditions:
problems arising from normal wear; problems arising
from failure to adhere to the product instructions;
problems arising from misuse, negligence, accident or
improper operation, maintenance or storage; problems
arising from modifications or unauthorized repairs, parts
or attachments; products where the serial number has
been removed or defaced; Problems with non-durable
components, such as rubber accessories, casters, and
grips, which are subject to normal wear and need
periodic replacement. Dynarex shall not be liable for any
consequential or incidental damages whatsoever.
Dynarex shall repair or replace defective products at its
option. The foregoing warranty is exclusive and in lieu of
other express warranties, if any, including the implied
warranties of merchantability and fitness of a particular
purpose. The remedy for any violation of the implied
warranty shall be limited to repair or replacement of the
defective product pursuant to the terms contained
herein.
Reorder No. 10463
Manufactured for: Dynarex Corporation
10 Glenshaw Street • Orangeburg, NY 10962
USA • www.dynarex.com
Made in China
SYMBOL GLOSSARY
For an explanation of symbols
used in Dynarex packaging, visit
dynarex.com/symbols.php
Adjustable
Full Length
Bed Rail
CROSSBRACES
Barrel
Spring Loaded Knob
Outer
Telescoping Rail
Inner
Telescoping Rail Upper
Adjustment
Hole
Rail Stop
FOOT-END
HEAD-END
R180618

INSTALLATION WARNING
OPERATING INSTRUCTIONS
lowering/raising the rail
1. Place crossbrace on the head end of the frame
between the first and second spring.
2. Turn the barrel so that the tab is facing upwards.
3. Insert the lock plate on one side of the bed so that it
is under the lip of the frame.
4 Push the crossbar together to allow for the locking
collar to enter inside the frame.
5. Slowly release the crossbar so the locking plate
inserts into the lip of the bed frame on the other side.
6. Rotate the barrel so that the tab is facing down
thereby locking the crossbar into position.
7. Place the second crossbrace on the foot end of the
frame between the first and second spring. Repeat
steps 2-6 to secure the crossbrace to the bed.
8. Insert one bed rail into the barrels on one side of
the bed ensuring that the spring loaded knob is
fully engaged.
9. Insert the other bed rail into the barrels on the
other side of the bed ensuring that the spring loaded
knob is fully engaged.
1. Hold the rail, while pulling the spring loaded knob.
2. Lower or raise the rail to the desired height.
3. Release the knob and lower or raise the rail until the
spring loaded knob “clicks” into position (unless the
rail is at the lowest position).
4. Repeat steps 1 to 3 for the opposite end of the bed
rail.
5. Make sure the head and foot end of the bed are at
the same height.
To prevent damage to the levers and motors of
articulating beds, make certain that when the head and
foot ends are raised that the telescoping length of the
bed rails is not less then 47 inches. Otherwise the bed
rails will bottom out and will bind the drive mechanism of
the bed. Either the bed rails or the bed will be damaged.
CAUTION: Beware of gap between bed rail and
mattress when bed is in semi Fowler’s position. Put rail
in “MID” position to eliminate gap.
Bed Frame
Lock Plate on
Locking Collar
Lip of Bed
Frame
Hex Screw
(DO NOT REMOVE) Barrel Spring
Loaded
Knob
Tab
SEMI FOWLER’S POSITION
Lock Plate on
Locking Collar
Barrel
Spring Loaded
Knob
Tab
TAB UP (STEP 3)
TAB DOWN (STEP 6)
