Dyson DC22 User manual

OPERATING MANUAL
clik
clik
clik
clik
1
2
3
REGISTER
YOUR 2 YEAR
GUARANTEE
TODAY
ASSEMBLY
WASH FILTERS
Wash filters with cold water
regularly or as required.
A
B

2
3 EASY WAYS TO REGISTER YOUR 2 YEAR GUARANTEE
Your Dyson vacuum cleaner will be covered for parts and
labour for 2 years from the date of purchase, subject to
the terms of the guarantee.
If you have a query about your Dyson vacuum cleaner,
call the Dyson Customer Care Helpline quoting the
serial number and details of where/when you bought the
vacuum cleaner. The serial number can be found on the
main body of the vacuum cleaner behind the clear bin.
Most queries can be solved over the phone by one of our
Dyson Customer Care Helpline staff.
Visit our website to register your full parts and labour
guarantee online (Australia only).
www.dyson.com.au/register
Note your serial number for future reference
This illustration is for example purposes only.
REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline.
REGISTER
ONLINE
Visit our website to register your
full parts and labour guarantee
online (Australia only).
www.dyson.com.au/register
AU 1800 239 766
NZ 0800 397 667
SG 7000 435 7546
ID 021 707 39766

IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
When using an electrical appliance, basic precautions should always be followed, including the following:
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:
1. Do not leave the Dyson vacuum when plugged in. Unplug from socket when not in use and before servicing.
2. Do not use outdoors or on wet surfaces. Suitable for dry locations only. Do not use to pick up water.
3. Do not allow to be used as a toy. Close attention is necessary when used by or near children. Children should be supervised to
ensure that they do not play with the Dyson vacuum.
4. This Dyson vacuum is not intended for use by young children or infirm persons with reduced physical, sensory or reasoning
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction by a responsible person
concerning use of the Dyson vacuum to ensure that they can use the Dyson vacuum safely.
5. Use only as described in this manual. Use only Dyson recommended accessories and replacement parts. Do not carry out
any maintenance other than that shown in this manual, or advised by the Dyson Customer Care Helpline. Contact the Dyson
Customer Care Helpline when service or repair is required. Do not disassemble the Dyson vacuum as incorrect reassembly may
result in an electric shock or fire.
6. Do not use with a damaged cable or plug. If the Dyson vacuum is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, do not use and contact the Dyson Customer Care Helpline. If the supply cable is damaged it
must be replaced by Dyson, its service agent or similarly qualified person in order to avoid a hazard.
7. Do not pull or carry by cable, use cable as a handle, close a door on cable, or pull cable around sharp edges or corners. Do not
run the Dyson vacuum over cable. Keep cable away from heated surfaces. To avoid a tripping hazard rewind the cable when not
in use.
8. Always extend the cable to the red line but do not stretch or tug the cable.
9. Do not unplug by pulling on the cable. To unplug, grasp the plug, not the cable.
10. Do not handle the plug or Dyson vacuum with wet hands.
11. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may
reduce airflow.
12. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts, such as the brush bar. Do not
point the hose, wand or tools at your eyes or ears or put them in your mouth.
13. Turn off all controls before unplugging.
14. Use extra care when cleaning on stairs. Do not work with the Dyson vacuum above you on the stairs.
15. Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they or their vapors may be
present.
16. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
17. Do not use without the clear bin and filters in place.
18. Hold the plug when rewinding onto cable reel. Do not allow the plug to whip when rewinding.
19. The use of an extension cable is not recommended.
READ AND SAVE THESE INSTRUCTIONS
THIS DYSON VACUUM IS INTENDED FOR HOUSEHOLD USE ONLY
3
Do not pull on
the cable.
Do not store
near heat
sources.
Do not use near
naked flame.
Do not run over
the cable.
Do not pick up
water or liquids.
Do not pick up
burning objects.
Do not use
above you on
the stairs.
Do not put
hands near the
brush bar when
the vacuum
cleaner is in use.

1
clik
clik
clik
clik
2
3
2
1
3
clik
clik
4
Looking for blockages
Tools
Suction releasePower

1
clik
clik
clik
clik
2
3
2
1
3
clik
clik
5
Emptying
Cleaning
Storage
Tools
Cable

Filter A
Filter B
24 hrs
1
2
3
4
5
6
7
8
9
10
11 12
24 hrs
1
2
3
4
5
6
7
8
9
10
11 12
IMPORTANT!
WASH FILTERS
6

Filter A
Filter B
24 hrs
1
2
3
4
5
6
7
8
9
10
11 12
24 hrs
1
2
3
4
5
6
7
8
9
10
11 12
Wash filters with cold water regularly or as required.
7
Rinse and shake filter under tap. Turn over and tap very firmly
to remove motor emissions. Repeat until water runs clear.
Register for a filter wash reminder by email (Australia only);
[e-mail]

8
USING YOUR DYSON VACUUM CLEANER
CAUTION:
• Do not allow the vacuum cleaner to be used by anyone who may not be able to
operate it safely.
• The use of an extension cable is not recommended.
• Always switch ‘OFF’ and unplug before performing maintenance on your
vacuum cleaner.
• Ensure the cyclone is secured to the vacuum cleaner. Do not press the cyclone
release button or shake the vacuum cleaner while carrying or it could fall and
cause injury.
• Store the vacuum cleaner indoors. Put the vacuum cleaner away after use with
the cable coiled safely, to prevent tripping hazards.
• Do not use outdoors or on wet surfaces or to vacuum water or other liquids –
electric shock could occur.
• Do not lubricate any parts, or carry out any maintenance or repair work other
than that shown in this manual, or advised by the Dyson Customer Care
Helpline.
• Do not use any lubricants, cleaning agents, polishes or air fresheners on any
part of the Dyson vacuum.
• This Dyson vacuum is fitted with a thermal cut-out. If any part of the Dyson
vacuum becomes blocked the machine may overheat and automatically shut
off. If this happens, switch off and unplug the Dyson vacuum and allow to cool
before attempting to check filters or for blockages. Clear any blockages before
restarting.
• Store the vacuum cleaner indoors. Do not use or store this vacuum cleaner
below 0°C (32°F). Ensure that the vacuum cleaner is at room temperature before
operating.
PLEASE NOTE:
• This vacuum cleaner is intended for domestic use only. Fine dust such as plaster
dust or flour should only be vacuumed in very small amounts.
• Do not use the vacuum cleaner to pick up sharp hard objects, small toys, pins,
paper clips, etc. They may damage the vacuum cleaner.
• If used in a garage, care should be taken to wipe the soleplate and wheels with
a dry cloth after vacuuming to clean off any sand, dirt, or pebbles that could
damage delicate floors.
• Consult your flooring manufacturer’s recommended instructions before
vacuuming and caring for your flooring, rugs, and carpet. Some carpets will fuzz
if a rotating brush bar is used when vacuuming. If this happens, we recommend
vacuuming in hard floors mode and consulting with your flooring manufacturer.
• When vacuuming, certain carpets may generate small static charges in the clear
bin. These are entirely harmless and are not associated with the mains supply.
To minimise any effect from this, do not put your hand or insert any object into
the clear bin unless you have first emptied it and rinsed it out with cold water.
(See ‘Cleaning the clear bin’ section on page 5 and 8).
• Do not use or store this vacuum cleaner below 0°C. Ensure that the vacuum
cleaner is at room temperature before operating.
EMPTYING THE CLEAR BIN
CAUTION:
• Switch ‘OFF’ the vacuum cleaner and unplug before emptying the clear bin.
• Empty as soon as the dirt reaches the level of the MAX mark – do not overfill.
• To remove the clear bin from the vacuum cleaner, press the grey button at the
rear of cyclone carrying handle. To release the dirt, press the red bin release
button. Emptying into a bag is recommended for people with asthma and
allergies.
• To minimise dust/allergen contact when emptying, encase the clear bin tightly
in a plastic bag and empty. Remove the clear bin carefully and seal bag tightly,
dispose as normal.
• Do not use the vacuum cleaner without the clear bin in place.
CLEANING THE CLEAR BIN
CAUTION:
• To remove the cyclone unit from the clear bin press the red bin release button.
This exposes a small silver button behind the red opening mechanism. Press the
silver button and separate the cyclone unit from the clear bin.
• Clean the clear bin with cold water only (see cleaning the clear bin section on
page 5).
• Ensure the clear bin is completely dry before replacing.
PLEASE NOTE:
• Do not use detergents, polishes or air fresheners to clean the clear bin.
• Do not put clear bin in a dishwasher.
• Clean the shroud with a cloth or dry brush to remove lint and dust.
WASHING YOUR FILTERS
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before removing the filters.
• Ensure filters are completely dry before refitting to the vacuum cleaner.
PLEASE NOTE:
• This machine has two filters, located as shown. It is important to check your
filters regularly and wash with cold water regularly or as required, to maintain
performance. FilterB should be rinsed and tapped out until the water runs
clean, then tapped out again to ensure all excess water is removed.
• After washing please leave for 24 hours to dry completely.
• The filters may require more frequent washing if vacuuming fine dust.
• Do not use detergents to clean the filters.
• Do not put the filters in a dishwasher, washing machine, tumble dryer, oven,
microwave or near a naked flame.
LOOKING FOR BLOCKAGES
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before checking for blockages.
Failure to do so could result in personal injury.
• Beware of sharp objects when clearing blockages.
• Refit all parts of the vacuum cleaner securely before using.
PLEASE NOTE:
• Clearing blockages is not covered by your vacuum cleaner’s limited guarantee.
• This vacuum cleaner is fitted with an automatically resetting thermal cut-out.
If any part of the vacuum cleaner becomes blocked, it may overheat and
automatically cut-out. Switch ‘OFF’ and unplug the vacuum cleaner and leave to
cool down for 1-2 hours before checking filters or for blockages.
• Large items may block the tools or wand inlet, if this happens switch the vacuum
cleaner off and unplug the vacuum cleaner before removing the blockage.
Do not operate the wand release catch.
CLEARING BRUSH BAR OBSTRUCTIONS
CAUTION:
• Switch ‘OFF’ and unplug the vacuum cleaner before clearing brush bar
obstructions. Failure to do so could result in personal injury.
• Beware of sharp objects when clearing obstructions.
• Refit all parts of the vacuum cleaner securely before using.
PLEASE NOTE:
• Clearing brush bar obstructions is not covered by your vacuum cleaner’s limited
guarantee.
2
1
3

9
2 YEAR DYSON GUARANTEE
TERMS AND CONDITIONS
Terms and conditions of your Dyson 2 year guarantee.
• The guarantee becomes effective from the date of purchase.
• All work will be carried out by Dyson Appliances (Aust) Pty Ltd, Avery Robinson
Ltd (NZ), Singapore’s authorised agent - Service @Home Pte Ltd., Indonesia’s
authorised agent - PT Higienis Indonesia or their authorised agents.
• Any parts replaced will become the property of Dyson Appliances (Aust) Pty Ltd.,
Avery Robinson Ltd (NZ), Dyson Singapore Pte Ltd., PT Higienis Indonesia.
• The repair and replacement of your vacuum cleaner under guarantee will not
extend the period of guarantee.
• The guarantee provides benefits which are additional to and do not affect your
statutory rights as a consumer.
• You must provide proof of purchase before any work can be carried out on your
vacuum cleaner. Without this proof, any work carried out will be chargeable.
Please keep your receipt.
WHAT IS COVERED
The repair or replacement of your vacuum cleaner if your vacuum cleaner is
found to be defective due to faulty materials, workmanship or function within
2 years of purchase (if any part is no longer available or out of manufacture,
Dyson will replace it with a functional replacement part).
WHAT IS NOT COVERED
Dyson shall not be liable for costs of repair or replacement of a product incurred
as a result of:
• Normal wear and tear (e.g. fuse, belt, brush bar, batteries etc).
• Industrial use of the vacuum cleaner such as vacuuming gyprock dust or builders
dust may void your guarantee.
• Accidental damage, faults caused by negligent use or care, neglect, careless
operation or handling of the vacuum cleaner which is not in accordance with this
Dyson Operating Manual.
• Blockages – please refer to this Dyson Operating Manual for details of how to
unblock your vacuum cleaner.
• Use of the vacuum cleaner for anything other than normal domestic household
purposes in the country of purchase.
• Use of parts not assembled or installed in accordance with the instructions of
Dyson.
• Use of parts and accessories other than those produced or recommended by
Dyson.
• Damage from external sources such as transit, weather, electrical outages or
power surges.
• Failures caused by circumstances outside Dyson’s control.
• Repairs or alterations carried out by parties other than Dyson or its authorised
agents.
If you are in any doubt as to what is covered by your guarantee, please call the
Dyson Customer Care Helpline on:
Australia 1800 239 766
New Zealand 0800 397 667
Singapore 7000 435 7546
Indonesia 021 707 39766
Remember: Always disconnect plug from mains before inspecting for problems.
• If your vacuum cleaner will not operate, first check: mains socket has electricity
supply and the plug is properly inserted into the socket.
• Sucking up certain items such as stockings, clippings of cloth, sizeable pieces of
paper etc may block the hose or ducts. Should a blockage occur, first disconnect
the vacuum cleaner from the electricity supply and refer to the ‘Looking for
blockages’ section in this Dyson Operating Manual (see pages 4,5 and 8).
• Never pick up hot cinders or lit cigarette ends.
• Do not attempt to pick up water with your Dyson vacuum cleaner. It has not
been designed as a wet pick-up cleaner.
REGISTERING YOUR GUARANTEE
To help us ensure you receive prompt and efficient service, please register as a
Dyson vacuum cleaner owner. There are three ways to do this:
• Online (Australia only) at www.dyson.com.au/register
• By calling the Dyson Customer Care Helpline.
• By completing and returning the enclosed form to us by mail.
• This will confirm ownership of your Dyson vacuum cleaner in the event of an
insurance loss, and enable us to contact you if necessary.
DYSON CUSTOMER CARE
THANK YOU FOR CHOOSING TO BUY A DYSON VACUUM CLEANER
If you have a query about your Dyson vacuum cleaner, call the Dyson Customer
Care Helpline and quote your serial number, or contact us via the website.
The serial number can be found on the main body of the vacuum cleaner behind
the clear bin.
Most queries can be solved over the phone by one of our
Dyson Customer Care Helpline staff.
If your Dyson vacuum cleaner needs a service, call the Dyson Customer Care
Helpline so we can discuss the available options.
If your vacuum cleaner is under guarantee and the repair is covered, it will be
repaired at no cost.
DYSON CUSTOMER CARE DETAILS
If there are any queries, please call the Dyson Customer Care Helpline.
AU: 1800 239 766
(Mon-Fri 8:00am to 6:00pm EST, Sat-Sun 8:30am to 4:00pm EST)
www.dyson.com.au
NZ: 0800 397 667
(Mon-Fri 8:30am to 5:00pm)
www.dyson.co.nz
SG: 7000 435 7546
(Mon-Fri 9:00am to 6:00pm)
www.dyson.com.sg
ID: 021 707 39766
(Mon-Fri 9:00am to 5:00pm)
www.dyson.co.id
ABOUT YOUR PRIVACY
Dyson may use this information for future marketing and research purposes
(including sending commercial electronic messages) and may disclose it to
third parties for the purposes of providing the services you have requested or
to our business partners or professional advisers. If you wish to access your
personal information or see our full privacy policy, please contact us at
[e-mail]
DISPOSAL INFORMATION
Dyson products are made from high grade recyclable materials. Please dispose
of this product responsibly and recycle where possible.
When your Dyson vacuum cleaner reaches the end of its life, we are responsible
for it’s safe disposal. You can send your old Dyson vacuum cleaner back to us
(at our cost) and we will organise for it to be recycled.*
*Please note that not all parts are recyclable. Recycling of parts is subject to the
capabilities of 3rd party suppliers. Available in Australia only.
Simply:
1. Box up your old Dyson vacuum cleaner
2. Take your package to your local post office and send to the address below:
Dyson We Recycle
Reply Paid 83215
Dyson Service Centre
Unit 6 & 7, 7-11 Parraweena Rd
Taren Point, NSW 2229.
PRODUCT INFORMATION
Product weight 7.30kg.
Please note: Small details may vary from those shown.

www.dyson.com
JN.35878 PN.14220-40-02 02.08.10
Dyson Customer Care
If you have a query about your Dyson vacuum cleaner, call the
Dyson Customer Care Helpline with your serial number and
details of where and when you bought the cleaner, or contact us
via the Dyson website. The serial number can be found on the
main body of the vacuum cleaner behind the clear bin.
AU Dyson Customer Care
[e-mail]
1800 239 766
Dyson Appliances (Aust) Pty Ltd.,
PO Box 2835,
Taren Point, NSW 2229,
Australia
www.dyson.com.au
NZ Dyson Customer Care
[e-mail]
0800 397 667
Avery Robinson Ltd.,
Unit F, 151D Marua Road,
Ellerslie, Auckland 1051,
New Zealand
www.dyson.co.nz
SG Dyson Customer Care
[e-mail]
7000 435 7546
Service @ Home Pte. Ltd.,
2 Leng Kee Road, #04-09A Thye Hong Centre,
Singapore 159086
www.dyson.com.sg
ID Dyson Customer Care
[e-mail]
021 707 39766
PT. Higienis Indonesia
Permata Plaza Top Floor, TF-04,
JI, M. H. Thamrin Kav. 57,
Jakarta 10350
Indonesia
www.dyson.co.id
IMPORTANT!
WASH FILTERS
Wash your filters with cold water regularly or as required.
Register for a filter wash reminder by email (Australia only):
[e-mail]

1 This vacuum cleaner is…
My first vacuum cleaner
A replacement vacuum cleaner
An additional vacuum cleaner
2 Which brand of cleaner are you replacing or adding to?
Dyson Electrolux
Hoover LG
Miele Panasonic
Samsung Nilfisk
Vax Kambrook
Volta
Other, please specify
3 If your new Dyson vacuum cleaner is a replacement or
additional to another cleaner, what type of cleaner is that?
Upright – bagless Upright – bag
Barrel – bagless Barrel – bag
4 Why did you choose to buy a Dyson vacuum cleaner?
(please choose up to 5 options)
Dyson reputation
Good for pet hair pick-up
Performs consistently well
No loss of suction
Previous experience of Dyson
Good for people suffering from asthma and allergies
Features
HEPA filter
Hygienic and germ free cleaning
Price/special offer
Wanted a bagless cleaner
Compact and easy to store
Store staff recommendation
Picks up more dust than others
Latest model/technology
Reliability/quality
Friend/family recommendation
Other
5 Where did you first hear about the Dyson model you bought?
From friends and family
Saw it on the internet
From TV/a magazine advert
Saw it in a store catalogue
Saw it in a store
Recommended by salesperson
6 Do you other Dyson products?
Handheld Fan
No
7 What is your average household income?
Less than $45,000
Between $45,000 – $74,999
Between $75,000 – $100,000
Over $100,000
8 Do you have any household pets?
Dog Cat
None
9 Does anyone in your household suffer from any of the following?
Asthma Allergies
No
10 To which age group do you belong?
16 – 24 25 – 34
35 – 44 45 – 54
55 – 64 65+
11 Would you recommend a Dyson vacuum cleaner to your family and
friends?
Yes No
12 Do you have children?
Pre-school Aged 5-17 years
Aged +17 years Children no longer at home
Pregnant No children
QUESTIONNAIRE
Please take a few moments to answer our questions.
They will help us develop new products for the future.
THANK YOU FOR YOUR TIME

Cheque/money order made payable to: Dyson Appliances.
Credit card Mastercard Visa
Card Number
Increase your cover to 5 years when you purchase an extended guarantee from Dyson (Australia only). This option is just AU$79.00. Dyson is committed
to providing the best Aftersales Service, which is why we offer the option to extend your 2 year guarantee to 5 years. The Dyson extended guarantee
is underwritten by Dyson Appliances (Aust) Pty Ltd. To purchase, just complete the fields below. Send both sections to us, together with your cheque/money
order or credit card details, within 2 years of your vacuum cleaner purchase. Offer to purchase the extended guarantee is only available within 2 years of
customers purchasing their vacuum cleaner. Offer not available to customers who have purchased an extended warranty from a retailer.
2 year guarantee – plus option to extend to 5 years.
Declaration
I hereby apply for the Dyson vacuum cleaner extended guarantee in accordance with the terms and conditions of your plan. I confirm the vacuum
cleaner is in good working order and used for domestic puposes only and declare that the details on this proposal are true and complete to the best of
my knowledge and belief.
Signature Date WARNING Any false statement may
render this plan invalid
GUARANTEE FORM
Section 2: Dyson 2+3 year guarantee
REGISTER BY PHONE
Call our dedicated Helpline
AU 1800 239 766 NZ 0800 397 667
SG 7000 435 7546 ID 021 707 39766
REGISTER BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER ONLINE
Visit our website to register
your full parts and labour
2 year guarantee.
www.dyson.com.au/register
Serial number
Please complete Section 1 to register as a Dyson machine owner, and return it in the envelope provided. Alternatively, register online (Australia only).
Section 1: Dyson 2 year guarantee
Date of purchase / / Country of purchase AU NZ SG ID
Store of purchase
Yes No
1 year 2 years 3 years
Did you purchase an extended warranty from the retailer?
If yes, for what additional period?
Title First name Surname
email Contact number
Address
Privacy Act
Dyson may use this information for future marketing and research purposes (including sending commercial electronic messages) and may disclose
it to third parties for the purposes of providing the services you have requested or to our business partners or professional advisers. If you wish to
access your personal information or see our full privacy policy, please contact us at [e-mail]
If you do not wish to receive marketing information by these methods from Dyson please tick this box.
Postcode
Expiry Date M/M Y/Y
/ /
