E2S D2xB1X05 Series User manual

European Safety Systems Ltd.
Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D211-00-201-IS Issue 1 20-08-22 Sheet 1 of 6
INSTRUCTION MANUAL
D2xB1X05 & D2xB1X10 Xenon Beacons
For use in Hazardous Locations
D2XB1X05
D2XB1X10
1) Product Table
2) Warnings
DO NOT OPEN WHEN AN EXPLOSIVE
ATMOSPHERE IS PRESENT
DO NOT OPEN WHEN ENERGISED
POTENTIAL ELECTROSTATIC CHARGING
HAZARD - CLEAN ONLY WITH A DAMP
CLOTH
HIGH VOLTAGE SHOCK HAZARD. WAIT 5
MINUTES AFTER REMOVING POWER
BEFORE OPENING THE ENCLOSURE
Avertissement:
NE PAS OUVRIR UN PRESENCE
D’ATMOSPHERE EXPLOSIVE
NE PAS OUVRIR ENERGIE
DANGER POTENTIEL CHARGE
ÉLECTROSTATIQUE - NETTOYER
UNIQUEMENT AVEC UN CHIFFON HUMIDE
HAUT TENSION, RISK DE CHOC.
ATTENDEZ 5 MINUTES APRES AVOIR
DEBRANCHE L’ALIMENTATION AVANT
D’OUVRIR LA BOITIER
3) Rating & Marking Information
All units have a rating label, which carries the following
important information:
• Unit Model.
• Voltage Range
• Nominal Voltage
See Table 1 for electrical ratings of each Unit Model.
3.1. Fire Alarm Ratings
The Following models are certified as visual alarm devices for
private mode visual alarm devices in accordance with
UL1638 Fifth Edition / CAN/ULC-S526 Fourth Edition when
used with clear or red lens covers:
D2XB1X05DC024 ; D2XB1X05DC048
D2XB1X10DC024 ; D2XB1X10DC048
See fire instruction manual D211-00-201-IS-SC-UL
Model Nom. Voltage Voltage Range Operating
rms Current
D2xB1X05DC024 24Vdc 20-28Vdc 296mA
D2xB1X05DC048 48Vdc 48Vdc 145mA
D2xB1X05AC115 115Vac 115-120Vac 50/60Hz 80mA
D2xB1X05AC230 230Vac 220-230Vac 50/60Hz 30mA
D2xB1X10DC024 24Vdc 20-28Vdc 609mA
D2xB1X10DC048 48Vdc 48Vdc 260mA
D2xB1X10AC115 115Vac 115-120Vac 50/60Hz 185mA
D2xB1X10AC230 230Vac 220-230Vac 50/60Hz 107mA
Table 1: Electrical Ratings.

European Safety Systems Ltd.
Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D211-00-201-IS Issue 1 20-08-22 Sheet 2 of 6
3.2. ATEX / IECEx / UKEx Ratings
Standards
EN IEC 60079-0:2018 / IEC60079-0:2017 (Ed 7):
Explosive Atmospheres - Equipment. General Requirements
EN IEC 60079-7:2015 +A1:2018 / IEC 60079-7:2018 (Ed. 5.1):
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
EN 60079-31:2014 / IEC 60079-31:2013 (Ed 2):
Explosive Atmospheres - Equipment Dust Ignition Protection by
E
nclosure "t"
Ratings
D2xB1:
X05DC024
Ex ec IIC T2 Gc Ta -40°C to +50°C
Ex tc IIIC T80°C Dc Ta -40°C to +50°C
D2xB1:
X05DC048
X05AC115
X05AC230
Ex ec IIC T3 Gc Ta -40°C to +50°C
Ex tc IIIC T95°C Dc Ta -40°C to +50°C
D2xB1:
X10DC024
Ex ec IIC T1 Gc Ta -40°C to +50°C
Ex tc IIIC T105°C Dc Ta -40°C to +50°C
D2xB1:
X10DC048
X10AC115
X10AC230
Ex ec IIC T2 Gc Ta -40°C to +50°C
Ex tc IIIC T95°C Dc Ta -40°C to +50°C
Certificate No. DEMKO 14 ATEX 4786493904X
IECEx ULD 14.0004X
UL21UKEX2131X
ATEX Mark, Equipment
Group and Category:
II 3G
II 3D
CE Marking
UKCA Marking
3.3. NEC & CEC Ratings
NEC & CEC Class / Division Ratings for US / Canada
Standards
UL 121201-2021 (Ed. 9)
CAN/CSA C22.2 No. 213-17 (Ed. 3)
Ratings
D2xB1:
X05DC024
Class I Div 2 ABCD T2D Ta -40°C to +50°C
Class I Div 2 ABCD T3 Ta -40°C to +45°C
Class II Div 2 FG T6 Ta -40°C to +50°C
Class III Div 1&2 Ta -40°C to +50°C
D2xB1:
X05DC048
X05AC115
X05AC230
Class I Div 2 ABCD T3 Ta -40°C to +50°C
Class II Div 2 FG T5 Ta -40°C to +50°C
Class II Div 2 FG T6 Ta -40°C to +40°C
Class III Div 1&2 Ta -40°C to +50°C
D2xB1:
X10DC024
Class I Div 2 ABCD T1 Ta -40°C to +50°C
Class I Div 2 ABCD T2 Ta -40°C to +45°C
Class II Div 2 FG T4A Ta -40°C to +50°C
Class II Div 2 FG T5 Ta -40°C to +45°C
Class III Div 1&2 Ta -40°C to +50°C
D2xB1:
X10DC048
X10AC115
X10AC230
Class I Div 2 ABCD T2B Ta -40°C to +50°C
Class II Div 2 FG T5 Ta -40°C to +50°C
Class II Div 2 FG T6 Ta -40°C to +40°C
Class III Div 1&2 Ta -40°C to +50°C
Installation must be carried out in compliance with the National
Electric Code / Canadian Electric Code
NEC Class / Zone ratings US
Standards
UL 60079-0 (Ed. 7):
Explosive Atmospheres - part 0: Equipment - General
Requirements
UL 60079-7 (Ed. 5):
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
UL 60079-31 (Ed. 2)
Explosive Atmospheres - Equipment Dust Ignition Protection by
E
nclosure "t"
Ratings
D2xB1:
X05DC024
Class I Zone 2 AEx ec IIC T2 Gc Ta -40°C to
+50°C
Zone 22 AEx tc IIIC T80°C Dc Ta -40°C to +50°C
D2xB1:
X05DC048
X05AC115
X05AC230
Class I Zone 2 AEx ec IIC T3 Gc Ta -40°C to
+50°C
Zone 22 AEx tc IIIC T95°C Dc Ta -40°C to +50°C
D2xB1:
X10DC024
Class I Zone 2 AEx ec IIC T1 Gc Ta -40°C to
+50°C
Zone 22 AEx tc IIIC T105°C Dc Ta -40°C to +50°C
D2xB1:
X10DC048
X10AC115
X10AC230
Class I Zone 2 AEx ec IIC T2 Gc Ta -40°C to
+50°C
Zone 22 AEx tc IIIC T95°C Dc Ta -40°C to +50°C
Installation must be carried out in compliance with the National
Electric Code.
CEC Class / Zone ratings Canada
Standards
CAN/CSA C22.2 No. 60079-0 (Ed. 4) 02/2019
Explosive Atmospheres - Part 0: Equipment - General
Requirements
CAN/CSA C22.2 No. 60079-7 (Ed. 2)
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
CAN/CSA C22.2 No. 60079-31 (Ed. 2)
Explosive Atmospheres - Equipment Dust Ignition Protection by
E
nclosure "t"
Rating
D2xB1:
X05DC024
Ex ec IIC T2 Gc X Ta -40°C to +50°C
Ex tc IIIC T80°C Dc Ta -40°C to +50°C
D2xB1:
X10DC024
Ex ec IIC T1 Gc X Ta -40°C to +50°C
Ex tc IIIC T105°C Dc Ta -40°C to +50°C
D2xB1:
X05DC048
X05AC115
X05AC230
Ex ec IIC T3 Gc X Ta -40°C to +50°C
Ex tc IIIC T95°C Dc X Ta -40°C to +50°C

European Safety Systems Ltd.
Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D211-00-201-IS Issue 1 20-08-22 Sheet 3 of 6
116,0mm [4,52in.]
116,0mm [4,52in.]
179,2mm [6,99in.]
130,1mm [5,07in.]
132,4mm [5,17in.]
Ø6,92mm [Ø0,270in.] 3/4" NPT
(For pole mount)
M4 X 12mm
Countersunk screw,
customer to fix
D2xB1:
X10DC048
X10AC115
X10AC230
Ex ec IIC T2 Gc X Ta -40°C to +50°C
Ex tc IIIC T95°C Dc Ta -40°C to +50°C
Installation must be carried out in compliance with the Canadian
Electric Code
4) Zones, Gas Group, Category and
Temperature Classification
When connected to an approved system the D2X beacon
may be installed in:
Area Classification
Zone 2
Explosive gas air mixture not likely to occur in
normal operation, and if it does, it will only exist
for a short time.
Zone 22
Explosive dust air mixture not likely to occur in
normal operation, and if it does, it will only exist
for a short time.
Gas Groupings
Group IIA Propane
Group IIB Ethylene
Group IIC
Hydrogen and Acetylene
Temperature Classification
for Gas Applications
T1
450
ºC
T2 300ºC (Excluding D2xB1X10DC024)
T3 200ºC
(D2xB1X05DC048 & D2xB1X05AC only)
Dust Groupings
(ATEX / IECEx
/ UKEX
only)
Group IIIA
Combustible Flyings
Group IIIB
Non
-
conductive Dust
Group IIIC
Conductive Dust
Maximum Surface Temperature for Dust Applications
(ATEX / IECEx
/ UKEX
only)
D2xB1:
X05DC024 80°C
All 48VDC,
115VAC &
230VAC units
95ºC
D2xB1:
X10DC024 105ºC
Equipment Category
3G / 3D
Equipment Level Protection
Gc, Dc
Ambient Temperature Range
-
4
0°C to
+70°C
IP Rating
IP6X to EN/IEC60079
-
0
IP66 to EN60529
To maintain the ingress protection rating, the two off cable entries
must be fitted with suitably rated, certified cable entry and/or
blanking devices during installation.
Type Rating
Per
UL50E /
NEMA250:
4 / 4X / 3R / 13
5) Special Conditions of Use
Special Condition for safe Use as stated on the Type
Examination Certificate DEMKO 14 ATEX 4786493904X /
CoC IECEx ULD 14.0004X / UL21UKEX2131X:
When used for a Group III application, the surface of the
enclosure may store electrostatic charge and become a
source of ignition in applications with a low relative humidity
<~30% relative humidity where the surface is relatively free of
surface contamination such as dirt, dust, or oil.
Guidance on protection against the risk of ignition due to
electrostatic discharge can be found in EN TR50404 and IEC
TR60079-32.
End user shall adhere to the manufacturer’s installation and
instruction when performing housekeeping to avoid the
potential for hazardous electrostatic charges during cleaning,
by using a damp cloth.
To maintain the ingress protection rating and mode of
protection, the cable entries must be fitted with suitably rated,
certified cable entry and/or blanking devices during
installation.
6) Product Mounting and Access
6.1. Location and Mounting
The location of the beacon should be made with due regard
to the area over which the warning signal must be visible. It
should only be fixed to services that can carry the weight of
the unit.
The D2x beacon should be secured to any flat surface using
the two 7mm fixing holes in the feet of the base. The 2-off
feet must first be fitted to the base using the 2-off M4 X
12mm countersunk screws provided. The unit can also be
pole mounted using the ¾” NPT Entry in the centre of the
base. See Fig. 1.
Fig. 1 Fixing Location for Beacon

European Safety Systems Ltd.
Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D211-00-201-IS Issue 1 20-08-22 Sheet 4 of 6
- +
LL NN
6.2. Access to the Enclosure
Warning – High voltage may be
present, risk of electric shock.
DO NOT open when energised,
disconnect power before opening.
Warning – Hot surfaces. External
surfaces and internal components
may be hot after operation, take
care when handling the equipment.
To access the enclosure, loosen the four M4 posi pan head
screws and withdraw the cover.
Fig. 2 Accessing the Enclosure.
To replace cover, check that the ‘O’ ring seal is in place.
Carefully push the cover in place. Insert M4 screws with fiber
washers and tighten to 3Nm torque.
7) Selection of Cable. Cable Glands, Blanking
Elements & Adapters
When selecting the cable size, consideration must be given
to the input current that each unit draws (see Table 1), the
number of sounders on the line and the length of the cable
runs. The cable size selected must have the necessary
capacity to provide the input current to all of the sounders
connected to the line.
The entries can be ordered with one of the following options:
2-off M20 x 1.5 thread, 2-off ½” NPT thread & 1-off ¾” NPT
thread
If a high IP (Ingress Protection) rating is required then a
suitable sealing washer must be fitted under the cable glands
or blanking plugs.
For use in explosive dust atmospheres, a minimum ingress
protection rating of IP6X must be maintained.
For use in explosive gas atmospheres, a minimum ingress
protection rating of IP54 must be maintained.
NPT plugs should be greased before insertion.
8) Cable Connections
Electrical connections are to be made into the terminal blocks
on the PCBA located in the enclosure. See section 6 of this
manual for access to the enclosure.
Wires having a cross sectional area between 0.5 mm² to
2.5mm² can be connected to each terminal way. If an input
and output wire is required the 2-off Live/Neutral or +/-
terminals can be used. If fitting 2-off wires to one terminal
way the sum of the 2-off wires must be a maximum cross
sectional area of 2.5mm². Strip wires to 8mm. Wires may also
be fitted using ferrules. Terminal screws need to be tightened
down with a tightening torque of 0.56 Nm / 5 Lb-in. When
connecting wires to the terminals great care should be taken
to dress the wires so that when the cover is inserted into the
chamber the wires do not exert excess pressure on the
terminal blocks. This is particularly important when using
cables with large cross sectional areas such as 2.5mm².
9) Wiring
For further wiring schematics refer to document D211-06-201
9.1. AC Wiring
3-off 2-way terminal blocks are provided on the AC beacon
for power. There are 2-off Live, 2-off Neutral and 2-off Earth
terminals in total.
Fig. 4 D2xB1X05/D2xB1X10 AC Terminals
9.2. DC Wiring
3-off 2-way terminal blocks are provided on the AC beacon
for power. There are 2-off +ve, 2-off -ve and 2-off Earth
terminals in total.
Fig. 6a D2xB1X05/D2xB1X10 48 VDC Terminals
(Appropriate cable
entry devices to be
customer supplied)
Cover
4-off
M4 Cover
Screws

European Safety Systems Ltd.
Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D211-00-201-IS Issue 1 20-08-22 Sheet 5 of 6
+
-
Fig. 6b D2xB1X05/D2xB1X10 24 VDC Terminals
10) Line Monitoring (DC Units only)
On D2xB1X05/D2xB1X10 DC units, DC reverse line
monitoring can be used if required. All DC beacons have a
blocking diode fitted in their supply input lines. An end of line
monitoring resistor can be connected across the +ve and –ve
terminals. If an end of line resistor is used it must have the
following values:
Min. Resistance Min. Power
24V DC 3.9KΩ 0.5W
1KΩ 2W
48V DC 15KΩ 0.5W
3.9KΩ 2W
The resistor must be connected directly across the +ve and
-ve terminals as shown in the following drawing. Form the
resistor legs as shown in Fig. 8a, remove the +ve and –ve
terminal plugs and fit the resistor across the two terminal
plugs before refitting them to the PCBA as shown in Fig. 8a
or 8b. A spacing of at least 1/16” (1.58mm) must be provided
through air and over surfaces between uninsulated live parts.
Fig. 7 End of Line Resistor Forming
Fig. 8a End of Line Resistor Placement
(D2xB1DC048)
Fig. 8b End of Line Resistor Placement
(D2xB1DC024)
11) Interchangeable & Spare Parts
The Beacon lens cover is interchangeable, contact E2S Ltd
for a replacement lens cover available in various colours.
To change the lens cover, unscrew the 4-off M5 posi pan
head screws, spring and flat washers using a screwdriver.
Remove the wire guard and replace the old lens cover with
the new lens cover.
Fig. 9 Replacement of beacon lens cover
Fit the wire guard back onto the housing, over the new lens
cover aligning the fixing holes of the guard, lens cover and
housing. Refit the fixings to hold into place, the fixings MUST
be fitted in the order shown above.
Warning – Hot surfaces. External surfaces
and internal components may be hot after
operation, take care when handling the
equipment.
End of Line
Resistor
M5 screw
M5 spring washer
M5 flat washer
-
+
End of Line Resistor
E
+
-

European Safety Systems Ltd.
Impress House, Mansell Road, Acton, London W3 7QH
www.e2s.com
Tel: +44 (0)208 743 8880
Document No. D211-00-201-IS Issue 1 20-08-22 Sheet 6 of 6
12) DIP Switch
Please note that the D2xB1X05DC024 & D2xB1X10DC024
beacon PCBAs have a DIP Switch that is NOT customer
configurable. This should only ever be set to ‘00’.
Fig. 7 DIP Switch setting ‘00’
13) Maintenance, Overhaul & Repair
Maintenance, repair and overhaul of the equipment should
only be carried out by suitably qualified personnel in
accordance with the current relevant standards:
EN60079-19
IEC60079-19
Explosive atmospheres - Equipment repair,
overhaul and reclamation
EN 60079-17
IEC60079-17
Explosive atmospheres - Electrical
installations inspection and maintenance
To avoid a possible ELECTROSTACTIC CHARGE the unit
must only be cleaned with a damp cloth.
Units must not be opened while an explosive atmosphere is
present.
If opening the unit during maintenance operations a clean
environment must be maintained and any dust layer removed
prior to opening the unit.

_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH www.e2s.com Tel: +44 (0)208 743 8880
Document No. D211-00-201-IS-SC-UL Issue A 26-07-22 Sheet 1 of 1
FIRE
INSTRUCTION MANUAL
D2xB1X05 & D2xB1X10 Xenon Beacons
For use in Hazardous Locations
1) Warnings
DO NOT PAINT
Avertissement:
NE PAS PEINTURER
2) Rating & Marking Information
2.1 Fire Alarm Ratings
The Following models are certified as visual alarm devices for private mode visual alarm devices in accordance with UL1638 Fifth
Edition / CAN/ULC-S526 Fourth Edition when used with clear or red lens covers:
D2xB1X05DC024 / D2xB1X05DC048
D2xB1X10DC024 / D2xB1X10DC048
On-axis light output per UL1638 at 1Hz:
Model
Lens cover colour
Light output in cd
D2xB1X05DC024 clear 17.4
red 5.4
D2xB1X05DC048 clear 30
red 12
D2xB1X10DC024 clear 53.4
red 17.4
D2xB1X10DC048 clear 82
red 26
2.2 surge current ratings for use in fire alarm systems
Model
Peak
Surge current
RMS surge current
D2xB1X05DC024 1.04A 437mA
D2xB1X05DC048 12.7A 1.45A
D2xB1X10DC024 0.99A 620mA
D2xB1X10DC048 14.5A 780mA

ALL DIMENSIONS IN MM
IF IN DOUBT, ASK -
DO NOT SCALE
2S
warning signals
NTS
D2xB1X05 & D2xB1X10
WIRING DIAGRAM
D211-06-201
11
OF
R.N.POTTS
R.S. RAIT
B. ISARD
27-06-2019
27-06-2019
27-06-2019
MOD No. REASON - INITIAL - DATEISSUE
1INTRODUCTION
RSR 02-01-2020
D2x
DC XENON D2XB1X05 / X10 UNITS
Line Monitoring
Power: +ve & -ve
AC D2XB1X05 / X10 UNITS
Power: Live & Neutral
2UPDATED FORMAT
DH 17-05-2022
R1
-
-
+
+
+ve IN
+ve OUT
-ve OUT
-ve IN
EARTH IN
EARTH OUT
E
E
L
L
N
N
NEUTRAL IN
NEUTRAL OUT
LIVE OUT
LIVE IN
EARTH IN
EARTH OUT
E
E

E2S Telephone: +44 (0)20 8743 8880 Fax: +44 (0)20 8740 4200 Email: [email protected] www.e2s.com DC-061_Issue_J (D2x).docx - Page 1 of 2 - QAF_252_Issue_5
EU Declaration of Conformity
Manufacturer: European Safety Systems Ltd.
Impress House, Mansell Road, Acton
London, W3 7QH
United Kingdom
Authorised Representative: E2S Warnsignaltechnik UG
Charlottenstrasse 45-51
72764 Reutlingen
Germany
Equipment Type: D2xS1, D2xC1X05, D2xC1X10
D2xB1X05, D2xB1X10, D2xB1LD2, D2xB1XH1, D2xB1XH2, D2xB1LD3
D2xC2X05, D2xC2X10, D2xC2LD2, D2xC2XH1, D2xC2XH2, D2xC2LD3
D2xJ1
Directive 2014/34/EU: Equipment and Protective Systems for use in Potentially Explosive Atmospheres (ATEX)
Notified Body for EU
type Examination
(Module B)
:
UL International Demko A/S
Notified Body No.: 0539
Borupvang 5A, 2750 Ballerup, Denmark
EU
-
type Examination Certificate
(Module B)
:
DEMKO 14 ATEX
4786493904X
Notified Body for Quality Assurance Notification
/ Conformity to EU
-
type
based on
quality assurance of the production process (Module D):
Sira Certification Service
Notified Body No.: 2813
CSA Group Netherlands B.V, Utrechtseweg 310, 6812 AR, Arnhem, Netherlands
Quality Assurance Notification
(Module D)
:
SIRA 05 ATEX M342
Provisions fulfilled by the equipment:
II 3G Ex
ec
IIC
T6/
T4
/T3
/T2/T1 Gc
II 3D Ex tc IIIC Ex tc IIIC T55/75/80/85/90/95/105/110°C Dc
IP66 Ingress / Dust Protection to EN60079-0 / EN60079-31
Standards applied:
EN IEC 60079
-
0:2018
EN IEC 60079-7:2015 +A1:2018
EN 60079-31:2014
Directive 2014/30/EU: Electromagnetic Compatibility Directive (EMC)
Standards applied:
EN 61000
-
6
-
1:2007
EN 61000-6-2:2005
EN 61000-6-3:2007 / A1:2011 / AC: 2012
EN 61000-6-4:2007 / A1: 2011
Directive 2011/65/EU: Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS)
The product and all the components contained within it are in accordance with the restriction of the use of hazardous substances in electrical and electronic
equipment, including amendment by Directive 2015/863/EU.
Regulation (EC) 1907/2006: Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH)
The product and all the components contained within it are free from substances of very high concern.
Other Standards and Regulations
EN 60529:1992+A2:2013 - Degrees of protection provided by enclosures (IP code) – enclosure rated IP66

E2S Telephone: +44 (0)20 8743 8880 Fax: +44 (0)20 8740 4200 Email: [email protected] www.e2s.com DC-061_Issue_J (D2x).docx - Page 2 of 2 - QAF_252_Issue_5
Martin Streetz Document No.: DC-061_Issue_J
Quality Assurance Manager Date and Place of Issue: London, 22/08/2022
EU Declaration of Conformity
On behalf of European Safety Systems Ltd., I declare that, on the date the equipment accompanied by this declaration is placed on the market, the equipment
conforms with all technical and regulatory requirements of the above listed directives, regulations and standards.
This Declaration is issued under the sole responsibility of the manufacturer.

E2S Telephone: +44 (0)20 8743 8880 Fax: +44 (0)20 8740 4200 Email: [email protected] www.e2s.com DC-102_Issue_A - Page 1 of 2 - QAF_252_Issue_5
UKCA Declaration of Conformity
Manufacturer: European Safety Systems Ltd.
Impress House, Mansell Road, Acton
London, W3 7QH
United Kingdom
Equipment Type: D2xS1, D2xC1X05, D2xC1X10
D2xB1X05, D2xB1X10, D2xB1LD2, D2xB1XH1, D2xB1XH2, D2xB1LD3
D2xC2X05, D2xC2X10, D2xC2LD2, D2xC2XH1, D2xC2XH2, D2xC2LD3
D2xJ1
Directive UKSI 2016:1107 (as amended by UKSI 2019:696) – Schedule 3A, Part 1 : Product or Protective System Intended for use in Potentially Explosive Atmospheres
(UKCA)
Notified Body for
UK
type Examination
(Module B)
:
UL International (UK) Ltd
Notified Body No.: 0843
Unit 1‐3 Horizon Kingsland Business Park, Wade Road,
Basingstoke, Hampshire RG24 8AH UK
UK
‐
type Examination Certificate
(Module B)
:
UL21UKEX2131X
Notified Body for Quality Assurance Notification
/ Conformity to EU
‐
type
based on
quality assurance of the production process (Module D):
Sira Certification Service
Notified Body No.: 0518
Rake Lane, Eccleston, Chester CH4 9JN, UK
Quality Assurance Notification
(Module D)
:
CSAE 22UKQAN0046
Provisions fulfilled by the equipment:
II 3G Ex
ec
IIC
T6/
T4
/T3
/T2/T1 Gc
II 3D Ex tc IIIC Ex tc IIIC T55/75/80/85/90/95/105/110°C Dc
IP66 Ingress / Dust Protection to EN60079‐0 / EN60079‐31
Standards applied:
EN IEC 60079
‐
0:2018
EN IEC 60079‐7:2015 +A1:2018
EN 60079‐31:2014
Directive 2014/30/EU: Electromagnetic Compatibility Directive (EMC)
Standards applied:
EN 61000
‐
6
‐
1:2007
EN 61000‐6‐2:2005
EN 61000‐6‐3:2007 / A1:2011 / AC: 2012
EN 61000‐6‐4:2007 / A1: 2011
Directive 2011/65/EU: Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS)
The product and all the components contained within it are in accordance with the restriction of the use of hazardous substances in electrical and electronic
equipment, including amendment by Directive 2015/863/EU.
Regulation (EC) 1907/2006: Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH)
The product and all the components contained within it are free from substances of very high concern.
Other Standards and Regulations
EN 60529:1992+A2:2013 ‐ Degrees of protection provided by enclosures (IP code) – enclosure rated IP66

E2S Telephone: +44 (0)20 8743 8880 Fax: +44 (0)20 8740 4200 Email: [email protected] www.e2s.com DC-102_Issue_A - Page 2 of 2 - QAF_252_Issue_5
Martin Streetz Document No.: DC‐102_Issue_A
Quality Assurance Manager Date and Place of Issue: London, 22/08/2022
UKCA Declaration of Conformity
On behalf of European Safety Systems Ltd., I declare that, on the date the equipment accompanied by this declaration is placed on the market, the equipment
conforms with all technical and regulatory requirements of the above listed directives, regulations and standards.
This Declaration is issued under the sole responsibility of the manufacturer.
Other manuals for D2xB1X05 Series
1
This manual suits for next models
9
Table of contents
Other E2S Lighting Equipment manuals

E2S
E2S MC1LD2FDC024 User manual

E2S
E2S BExBGL2D-P User manual

E2S
E2S BExBG21D User manual

E2S
E2S BExTBG05D-P User manual

E2S
E2S STExB2X05 User manual

E2S
E2S AlertAlight AL121H User manual

E2S
E2S D2xB1LD3 User manual

E2S
E2S E2xB05 User manual

E2S
E2S Spectra H100 TF User manual

E2S
E2S BExCBG05-05D-P User manual
