Easy@Home EE-5201W User manual

WARM MIST HUMIDIFIER
HUMIDIFICADOR DE VAPOR
CALIENTE
English……Page 3
Español…..Página 15
User Manual
Manual
del usuario

Contents
Parts list.....................................................................3
Contents ...............................................................3
General information..................................................4
Safety instructions ................................................5
User instructions .......................................................7
Troubleshooting..................................................10
Cleaning and maintenance......................................11
Other useful information ........................................13
Technical specifications ......................................13
Storing ................................................................13

Parts list
3
Main parts
1. Mist chamber
2. Humidifier base
3. Water level sensor
4. Tip over switch (bottom)
5. Heating element
6. Control knob
7. Indicator light
8. Reset button (bottom)
9. Medicine cup
10. Water tank
11. Water tank cap
Contents of packaging
(Note: Humidifier is pre-assembled and ready to use)
Humidifier base
Water tank
Mist chamber
Medicine cup
Instruction manual
1
2
4
5
9
1
0
8
7
6
11
3

General information
4
General information
When using an electrical appliance, basic safety precautions should also be observed,
including the following. PLEASE READ AND SAVE ALL INSTRUCTIONS BEFORE USING
THE WARM MIST HUMIDIFIER.
DO NOT carry water tank by handle when it is filled with water. It is advisable to
carry filled water tank with two hands.
DO NOT operate outdoors. This humidifier is intended for indoor use only.
DO NOT TOUCH THE STEAM VAPOR. Steam can cause burns.
DO NOT remove the water tank during operation or within 15 minutes after the
humidifier is turned off and unplugged. Serious injury may result.
DO NOT operate without water. Always have water in the water tank when
operating the humidifier.
Use only clean, cool tap water to fill the tank. DO NOT use hot water.
DO NOT pour water in any openings other than the water tank.
Be sure that the water tank cap is firmly tightened. DO NOT aim mist directly at
children, walls, furniture, or electrical appliances.
Use only a 110-120VAC outlet. ALWAYS plug and unplug humidifier with dry
hands.
Never operate the humidifier with a damaged power supply cord or plug.
Always place the humidifier on a smooth, flat, lint free, non-metallic, waterproof,
level surface, and away from direct sunlight. Keep the power supply cord away
from heated surfaces and areas where it could be walked on or tripped over.
Unplug the humidifier when not in use and whenever you clean or move the
humidifier.
DO NOT add medication of any type into the mist channel, base or water tank. Do
not cover any openings on the humidifier or insert objects into any openings.
ONLY add liquid vapor medicine to the medicine cup included with the humidifier.
The humidifier should not be left unattended in a closed room as the air could
become saturated and leave condensation on walls or furniture. Leave room
door partly open.
The humidifier requires daily and weekly cleaning to operate appropriately. Refer
to cleaning instructions.
NEVER use detergents, gasoline, glass cleaner, furniture polish, paint thinner or
other household solvents to clean any part of the humidifier.
Do not tilt or tip the unit or attempt to empty or fill it while it is in operation.
SAVE ALL INSTRUCTIONS

Safety instructions
5
Safety instructions
WARNING: Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire or serious personal injury. The
warnings, cautions, and instruction discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood
by the operator that common sense and caution are a factor which cannot be
built into this product, but must be supplied by the operator.
CAUTION: A short power supply cord is provided to reduce the risk of personal
injury resulting from becoming entangled in or tripping over a longer cord.
To avoid a circuit overload when using this humidifier, do not operate another
high-wattage product on the same electrical circuit.
Avoid the use of an extension cord because the extension cord may overheat
and cause a risk of fire. However if you have to use an extension cord, the
extension cord should be rated for 13 amps, 125V, 1625 watts.
The power supply cord must be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or tripped over
accidentally.
Electric power
If the electric circuit is overloaded with other appliances, your humidifier may not
operate properly. The humidifier should be operated on a separate electrical
circuit from other operating appliances.
Polarized plug
This humidifier has a polarized plug (one blade is wider than the other). As a safety
feature to reduce the risk of electrical shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified electrician. Do not attempt to
defeat this safety feature.
Safety warning
Although your Warm Mist Humidifier is easy to operate, for your safety, the
warnings below must be followed:
1. Do not place the Warm Mist Humidifier near a heat source.
2. Never leave the Warm Mist Humidifier unattended while connected to the
electrical outlet.

Safety instructions
6
3. To avoid any accidental burns, never put a hand over front net guard or cover
when the Warm Mist Humidifier is in operation.
4. Use the Warm Mist Humidifier on a stable surface away from water.
5. Do not unplug the Warm Mist Humidifier by pulling on the power supply cord.
6. The Warm Mist Humidifier must be unplugged:
A. Before any cleaning or maintenance.
B. After use.
C. If it appears to be faulty.
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.
SAVE THESE INSTRUCTIONS

User instructions
7
Fig. 2
Fig. 1
User instructions
Before First Use
CHECK HUMIDIFIER PLACEMENT - Place the Humidifier on a non-metallic, lint free,
waterproof, level surface for best performance. This is to help disperse the mist
in the air and prevent it from being knocked or tipped over.
CAUTION:
DO NOT operate the humidifier without water in the water tank.
DO NOT plug in the power supply cord with wet hands; electric shock could
happen.
Be sure the humidifier is switched to OFF (O) and the humidifier is unplugged
from the electrical outlet.
Select a location for your humidifier on a flat surface approximately 4 inches
away from a wall.
DO NOT place the humidifier on a finished floor or near furniture which can be
damaged by moisture or water. Place on a water resistant surface.
DO NOT place Humidifier on top of a towel, or a carpeted surface. The air vent
on the bottom may become blocked, and overheat the humidifier.
How to operate
CAUTION: ALWAYS USE CAUTION WHEN
HANDLING WARM MIST HUMIDIFIER. DO NOT
DROP THE WARM MIST HUMIDIFER.
Lift the water tank off the humidifier base.
Turn over the water tank and unscrew the
water tank cap at the bottom of the tank by
turning it counterclockwise. (See Fig. 1)
Fill water tank with cold water; do not fill all
the way to the rim. (See Fig. 2) DO NOT CARRY
FULL WATER TANK BY HANDLE. ALWAYS HOLD
FULL WATER TANK WITH TWO HANDS ON
EITHER SIDE OF THE WATER TANK.
DO NOT use hot water. Use cool tap water.
DO NOT add any medication to the water.
DO NOT pour water into Mist Channel.

User instructions
8
Fig. 3
Replace the water tank cap, aligning the
threads on the tank with the threads on the
cap, and turn it clockwise. (See Fig. 3)
Turn the tank over, holding one hand by the
top handle and another hand under the
water tank. Place the full water tank on the
base, making sure it fits securely. Place the
medicine cup on top of the mist channel.
Plug the power supply cord into a wall socket
and turn on the unit. The On/Off dial is located on the base.
The power light will turn blue.
Use the On/Off dial to adjust the intensity of the mist output by selecting
either (1) for lower mist output or (2) for higher mist output.
When the humidifier runs out of water the blue power light will turn off and
the mist output will stop. This safety feature sues a water level sensor to turn
off the heating element once the water level sinks below the required level in
the water basin. A small orange light will appear to indicate that the
humidifier has automatically turned off. Turn the humidifier off and unplug
before removing and refilling the water tank.
IMPORTANT: Overheat red light
When the humidifier runs out of water, the BLUE light will turn off and mist will
stop. If the unit has overheated, a small RED light will turn on (light will appear
near the “2” on Control Knob). The RED light indicates that the unit has
overheated. Turn the humidifier off, unplug the unit, allow the basin and water to
cool, then empty water in basin. Turn the humidifier basin over and press the
Reset Button, with a pen or pencil tip, on the bottom of the Water Basin. This will
reset the humidifier.
How to use the medicine cup
The medicine cup allows the addition of
medications recommended for use with warm
mist humidifiers only.
Remove the medicine cup from the top of the
mist chamber for easier filling.
BE CAREFUL not to overfill the medicine cup.
Overfilling may cause medicine to spill into mist

User instructions
9
chamber. Medicine in the mist chamber may affect the operation of the
humidifier.
Place medicine cup on the top of the mist chamber.
DO NOT add any medication or other additives such as essential oils directly
to the water.
A note about humidity
It is best to keep the humidity level at about 30-50 percent of relative
humidity.
The comfort level of humidity will vary from room to room and with changing
weather conditions.
In cold weather, windows and even some walls may fog or develop frost from
excessive indoor humidity. If this occurs, reduce the mist intensity setting to
avoid damage from condensed water dripping on windowsills.
Too much humidity in the room may allow moisture to accumulate on
surfaces where bacteria and fungi can grow. Moisture that gathers may also
damage furniture and walls, especially wallpaper.
To eliminate excessive humidity, especially in small rooms, leave the room
door open and adjust the mist intensity control setting.
NOTE: Light Indicator
Blue Light –unit is running properly
Orange Light –unit is out of water
Red Light –unit is overheating

Troubleshooting
10
Troubleshooting
CAUTION: DO NOT attempt to repair the motor or nebulizer yourself. If the
humidifier continues to not operate please call our service center.
Problem
Solution
If humidifier
does not have
any power:
Ensure unit is properly plugged into a power outlet.
Check that the Control Knob is turned to the ON
position.
If Power On indicator light does not come on, contact
[email protected]e.
Condensation
forms around
humidifier and
windows:
Adjust Control Knob to decrease mist output to low.
Leave room door cracked open during humidifier
operation.
If humidifier has
stopped, BLUE
light is off and
small RED light is
on:
Adjust Control Knob to turn humidifier off and unplug.
Empty water basin, turn over and using a tiny object,
press the center of the Red Reset Button on bottom of
humidifier.
If there is a
strange odor:
Clean the Water Tank with the water and vinegar
solution and rinse with clean water.
Leave the empty Water Tank open for some time
(without the Water Tank Cap attached) in a cool place.
The power
indicator light is
blue, but there is
no mist being
emitted:
Check that there is water in the Water Tank.
Make sure that nothing is blocking the mist output.
Check that the Fan Vent on the bottom of the
humidifier is not blocked.
Empty and rinse the Water Basin with cool tap water.
Check for possible mineral deposits on the Water Level
Sensor and Heating Element.

Cleaning and maintenance
11
Cleaning and maintenance
Care and cleaning
Portable humidifiers require regular cleaning in order to reduce the risk of bacterial
growth, and to remove any scale residue to maintain good operational performance.
Follow the procedures below for healthy maintenance of your Warm Mist Humidifier.
How to clean the water tank
1. Turn switch to off (O) and unplug from the wall outlet.
2. Be sure the unit has cooled for at least 15 minutes. Lift the water tank from base
and place in sink or tub.
3. Fill water tank with ½ cup water and 1 tablespoon of vinegar.
4. Let stand twenty minutes, shaking vigorously with two hands every few minutes.
5. Carefully empty the tank after 20 minutes, and rinse with warm water until you
can no longer detect a vinegar smell.
How to clean the heating element in the base
1. To remove the mist chamber, slide the mist chamber latch to the left and
carefully lift the mist chamber off the water basin.
2. Fill the heating element with undiluted white vinegar.
3. Let stand for 20 minutes. Dampen soft, clean cloth or sponge with undiluted
white vinegar and wipe out heating element to remove scale. DO NOT use soap,
detergents or abrasive cleaners.
4. Rinse heating element using clean warm water, being careful not to submerge the
base in the water. Dry thoroughly. DO NOT IMMERSE WATER BASIN IN WATER.
5. Soak the removable mist chamber in a solution of equal parts white vinegar and
water for 20 minutes. Rinse thoroughly and then wipe dry with a soft clean cloth.
6. To attach the mist chamber, slide the mist chamber latch to the left and place the
mist chamber onto the water basin. Release the latch to secure the mist chamber
to the water basin.
How to clean humidifier exteriors
1. DO NOT IMMERSE THE BASE IN WATER OR ANY OTHER LIQUID. An electric shock
may result or the humidifier may be damaged.
2. Wipe all exterior surfaces of the base with a soft, dry cloth.

Cleaning and maintenance
12
Daily maintenance
1. Turn switch to off (O) and unplug from the wall outlet.
2. Be sure the unit has cooled for at least 15 minutes. Lift the water tank from base
and place in sink or tub.
3. Carry the humidifier base to the sink and drain any remaining water. Wipe clean
and dry with a clean cloth.
4. Drain water from the water tank. Wipe clean, and dry with a clean cloth. Let the
water tank air dry when not in use.
Weekly maintenance (Removing scale)
NOTE: We recommend cleaning the humidifier WEEKLY or more often if you have
hard water or notice a build-up of impurities or detect unpleasant odors.
Repeat steps 1-4 above.
End of season maintenance and storing
1. Follow above weekly cleaning procedure at the end of the humidification season,
or when the humidifier will not be used for several days, being sure to dry all
parts. Allow the water tank to thoroughly air dry before storage. DO NOT store
with water inside any part of the humidifier.
2. Leave tank cap partially loosened during storage to prevent tank cap and gasket
from sticking together. This will prolong the life of the gasket.
3. Save original box for easy storage. Store humidifier in a cool dry location. Do not
place any heavy items on top of humidifier during storage as this may result in
possible damage of humidifier.
IMPORTANT: Failure to keep this humidifier clean from mineral deposits normally
contained in any water supply will affect the efficiency of the operation. Customer
failure to follow these instructions may void the warranty.
CAUTION:
Always be sure that the humidifier is unplugged and switched OFF before cleaning or
attempting to store the humidifier. NEVER PLUG OR UNPLUG HUMIDIFIER WITH WET
HANDS.
DO NOT leave water in the water tank or water basin when the humidifier is not in
use. If water remains in the water tank for more than a day or two, bacterial growth is
possible.

Other useful information
13
Other useful information
Technical specifications
Model Number EE-5201W
Rating Voltage 120V –60Hz
Rated Wattage 280W
Storing
Store the Warm Mist Humidifier in a dry location.
Do not place any heavy items on top of item during storage as this may result
in possible damage.
Service center
If you have any questions in regards to the operation of this appliance please
contact our service center at:
Tel: [phone]
Business Hours: Mon-Fri 10:00am –5:00pm EST
Email: [e-mail]
Environmental protection
If the appliance should no longer work at all, please make sure that it is disposed
of in an environmentally friendly way.

Other useful information
14
Contenido
Lista de componentes .............................................15
Contenido ...........................................................15
Información general..................................................4
Instrucciones de seguridad .................................18
Modo de empleo.....................................................20
Identificación y solución de problemas...............23
Limpieza y mantenimiento......................................24
Información adicional de utilidad ...........................27
Especificaciones técnicas ....................................27
Almacenamiento.................................................27

Lista de componentes
15
Componentes principales
1. Cámara de vapor
2. Base del humidificador
3. Sensor del nivel de agua
4. Interruptor de seguridad
contra caídas (parte
inferior)
5. Elemento de
calentamiento
6. Perilla de control
7. Luz indicadora
8. Botón de reinicio (parte
inferior)
9. Taza para medicamentos
10. Tanque de agua
11. Tapa del tanque de agua
Contenido del empaque
(Nota: El humidificador ha sido previamente ensamblado y está listo para usarse)
Base del humidificador
Tanque de agua
Cámara de vapor
Taza para medicamentos
Manual de instrucciones
1
2
4
5
9
1
0
8
7
6
11
3

Información general
16
Información general
Al usar un aparato eléctrico, también se deben tomar precauciones básicas de
seguridad, incluyendo las siguientes. POR FAVOR LEA Y CONSERVE TODAS LAS
INSTRUCCIONES ANTES DE USAR EL HUMIDIFICADOR DE VAPOR CALIENTE.
NO transporte el tanque de agua por la agarradera cuando esté lleno de agua.
Se recomienda transportar el tanque lleno de agua con las dos manos.
NO lo ponga en funcionamiento en el exterior. Este humidificador está
diseñado únicamente para su uso en interiores.
NO TOQUE EL VAPOR QUE SE EMITE. El vapor puede causar quemaduras.
NO quite el tanque de agua mientras esté en uso ni dentro de los 15 minutos
después de haber apagado y desconectado el humidificador. Podrían ocurrir
lesiones graves.
NO lo utilice sin agua. Siempre coloque agua en el tanque de agua durante el
uso del humidificador.
Use solo agua de la llave, limpia y fría para llenar el tanque. NO utilice agua
caliente.
NO vierta agua en ninguna abertura que no sea el tanque de agua.
Asegúrese de que la tapa del tanque esté bien ajustada. NO permita que el
vapor apunte directamente a niños, paredes, muebles o aparatos eléctricos.
Utilice únicamente una toma de corriente eléctrica de 110 a 120 VCA.
SIEMPRE enchufe y desenchufe el humidificador con las manos secas.
Nunca utilice el humidificador con un cable de alimentación o enchufe
dañados.
Siempre coloque el humidificador sobre una superficie lisa, plana, sin pelusas,
impermeable, no metálica, nivelada y que se encuentre alejada de la luz
directa de sol. Mantenga el cable de alimentación alejado de superficies
calientes y de áreas donde pudiera ser pisado o provocar tropiezos.
Desconecte el humidificador cuando no esté en uso y siempre que necesite
limpiarlo o moverlo.
NO agregue medicamentos de ningún tipo dentro del canal de vapor, la base o
el tanque de agua. No cubra ninguna abertura del humidificador ni introduzca
objetos por ninguno de sus orificios. SOLO agregue medicamentos líquidos
que puedan evaporarse en la taza para medicamentos incluida en el
humidificador.

Información general
17
No debe dejar sin atención al humidificador en una habitación cerrada, ya que
el aire podría saturarse y dejar condensación en paredes y muebles. Deje la
puerta de la habitación parcialmente abierta.
El humidificador requiere limpieza diaria y semanal para que funcione
correctamente. Consulte las instrucciones de limpieza.
NUNCA utilice detergentes, gasolina, limpiadores de vidrios, lustradores de
muebles, diluyente de pintura ni otros solventes domésticos para limpiar
cualquier parte del humidificador.
No incline ni voltee la unidad, ni intente vaciarla o llenarla mientras esté en
funcionamiento.
CONSERVE TODAS LAS INSTRUCCIONES

Instrucciones de seguridad
18
Instrucciones de seguridad
ADVERTENCIA: Lea y entienda todas las instrucciones. No seguir todas las
instrucciones indicadas a continuación podría ocasionar descargas eléctricas,
incendios o lesiones personales de gravedad. Las advertencias, avisos de
precaución e indicaciones que se mencionan en este manual de usuario, no
pueden abarcar todas las posibles condiciones y situaciones que podrían ocurrir. El
usuario debe comprender que el sentido común y la cautela son elementos que no
se pueden fabricar como parte de este producto, sino que deben ser
proporcionados por el mismo usuario.
PRECAUCIÓN:se incluye un cable de alimentación eléctrica corto para reducir el
riesgo de sufrir lesiones personales que pudieran resultar por haberse enredado o
tropezado con un cable más largo.
Para evitar una sobrecarga de los circuitos eléctricos cuando use este
humidificador, no opere ningún otro aparato con alta potencia en watts, en el
mismo circuito eléctrico.
Evite el uso de un cable de extensión ya que el cable de extensión podría
sobrecalentarse y provocar un riesgo de incendio. Sin embargo, si usted
requiere el uso de un cable de extensión, dicha extensión deberá tener una
clasificación de 13 amperes, 125 V, 1625 watts.
El cable de alimentación eléctrica se debe acomodar de tal forma que no
cuelgue sobre el borde de un mostrador o de una mesa en donde los niños
pudieran jalarlo o tropezarse accidentalmente.
Energía eléctrica
Si el circuito eléctrico se sobrecarga con otros aparatos electrodomésticos, es
posible que su humidificador no funcione adecuadamente. El humidificador se
deberá operar en un circuito eléctrico distinto al de otros aparatos
electrodomésticos en funcionamiento.
Enchufe polarizado
Este humidificador cuenta con un enchufe polarizado (una clavija es más ancha
que la otra). Como una característica de seguridad para reducir el riesgo de sufrir
una descarga eléctrica, este enchufe está diseñado para encajar en un
tomacorriente polarizado en una sola posición. Si el enchufe no encaja
completamente en el tomacorriente, invierta la posición del enchufe. Si aún así no

Instrucciones de seguridad
19
encaja, comuníquese con un electricista calificado. No intente deshacer esta
característica de seguridad.
Advertencia de seguridad
Aunque su humidificador de vapor caliente es fácil de utilizar, por su seguridad,
deben seguirse las siguientes advertencias:
1. No coloque el humidificador de vapor caliente cerca de una fuente de calor.
2. Nunca desatienda el humidificador de vapor caliente mientras esté conectado
a una toma de corriente eléctrica.
3. Para evitar cualquier quemadura accidental, nunca coloque su mano sobre la
malla o cubierta de protección delantera cuando el humidificador de vapor
caliente esté en funcionamiento.
4. Utilice el humidificador de vapor caliente sobre una superficie estable y
alejada del agua.
5. No desconecte el humidificador de vapor caliente jalando del cable de
alimentación eléctrica.
6. El humidificador de vapor caliente debe desconectarse:
A. Antes de limpiarlo o darle mantenimiento
B. Después de haberlo usado.
C. Si parece estar defectuoso.
ESTE PRODUCTO ESTÁ DISEÑADO ÚNICAMENTE PARA USO DOMÉSTICO.
CONSERVE ESTAS INSTRUCCIONES

Modo de empleo
20
Fig. 1
Fig. 2
Modo de empleo
Antes del primer uso
VERIFIQUE LA UBICACIÓN DEL HUMIDIFICADOR: Coloque el humidificador sobre
una superficie nivelada, no metálica, sin pelusas e impermeable para obtener un
mejor rendimiento. Esto ayudará a dispersar el vapor en el aire y a prevenir que se
caiga o vuelque.
PRECAUCIÓN:
NO haga funcionar el humidificador si el tanque de agua está vacío.
NO conecte el cable de alimentación eléctrica con las manos mojadas; podría
ocurrir una descarga eléctrica.
Compruebe que el humidificador esté apagado, en “OFF” (O) y desconectado
de la toma de corriente eléctrica.
Elija un lugar para el humidificador sobre una superficie plana a unas 4
pulgadas de distancia de la pared.
NO coloque el humidificador sobre un piso con acabado, ni cerca de muebles
que puedan dañarse por acción de la humedad o del agua. Coloque el aparato
sobre una superficie resistente al agua.
NO coloque el humidificador sobre una toalla ni sobre una superficie
alfombrada. Esto podría bloquear el orificio de ventilación de aire inferior y en
consecuencia, sobrecalentar el humidificador.
Cómo utilizarlo
PRECAUCIÓN: SEA SIEMPRE CUIDADOSO AL
MANIPULAR EL HUMIDIFICADOR DE VAPOR
CALIENTE. NO DEJE CAER EL HUMIDIFICADOR
DE VAPOR CALIENTE.
Levante el tanque de agua y retírelo de la
base del humidificador.
Voltee el tanque de agua y desenrosque la
tapa del tanque de agua ubicada en la parte
inferior girándola en sentido contrario a las
manecillas del reloj. (Consulte la Fig. 1)
Llene el tanque de agua con agua fría; no lo
llene hasta el borde (Consulte la Fig. 2). NO
TRANSPORTE EL TANQUE LLENO DE AGUA
USANDO LA AGARRADERA. SIEMPRE
SOSTENGA EL TANQUE LLENO DE AGUA CON
