Easy@Home EE-5201W User manual

WARM MIST HUMIDIFIER
HUMIDIFICADOR DE VAPOR CALIENTE
English……3
Español…16
User Manual
Manual
del usuario

Table of contents
2
Table of contents
Parts list ......................................................................................4
Contents................................................................................ 4
Important safety instructions .................................................... 5
User instructions ........................................................................ 9
Troubleshooting..................................................................12
Cleaning and maintenance ...................................................... 13
Other useful information ......................................................... 14
Technical specifications ......................................................14
Storing.................................................................................14

Parts list
3
Main parts
1. Mist chamber
2. Humidifier base
3. Water level sensor
4. Tip over switch (bottom)
5. Heating element
6. Control knob
7. Indicator light
8. Medicine cup
9. Water tank
10. Water tank cap
11. Mist channel
Contents of packaging
(Note: Humidifier is pre-assembled and ready to use)
•Humidifier base
•Water tank
•Mist chamber
•Medicine cup
•Instruction manual
1
2
4
5
8
9
7
6
10
3
11

Important safety instructions
4
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should always be followed.
PLEASE READ AND SAVE ALL
INSTRUCTIONS BEFORE USING THE
WARM MIST HUMIDIFIER.
KEEP AWAY FROM WATER!
1. Read all instructions.
2. Close supervision is necessary when any appliance is used by or near children.
3. DO NOT carry water tank by handle when it is filled with water. It is advisable
to carry filled water tank with two hands.
4. DO NOT operate outdoors. This humidifier is intended for indoor use only.
5. DO NOT TOUCH THE STEAM VAPOR. Steam can cause burns.
6. Do not touch hot surfaces.
7. DO NOT remove the water tank during operation or within 15 minutes after
the humidifier is turned off and unplugged. Serious injury may result.
8. To protect against electric shock, do not immerse cord, plug, or base in water
or any other liquid.
9. DO NOT operate without water. Always have water in the water tank when
operating the humidifier.
10. Use only clean, cool tap water to fill the tank. DO NOT use hot water.
11. DO NOT pour water in any openings other than the water tank.
12. Be sure that the water tank cap is firmly tightened. DO NOT aim mist directly
at children, walls, furniture, or electrical appliances.
13. Use only a 110-120VAC outlet. ALWAYS plug and unplug humidifier with dry
hands.
14. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning.
15. Never operate the humidifier with a damaged power supply cord or plug, or
after the appliance malfunctions, or has been damaged in any manner. Please
call customer service for replacement or refund.
16. Do not let the cord hang over the edge of a table or counter or touch hot
surfaces. Do not place near a hot gas or electric burner.

Important safety instructions
5
17. Extreme caution must be used when moving an appliance containing hot
liquids.
18. Do not use the humidifier for other than intended use.
19. The use of accessory attachments not recommended by the manufacturer
may cause injuries.
20. Always place the humidifier on a smooth, flat, lint free, non-metallic,
waterproof, level surface, and away from direct sunlight. Keep the power
supply cord away from heated surfaces and areas where it could be walked on
or tripped over.
21. DO NOT add medication of any type into the mist channel, base or water tank.
Do not cover any openings on the humidifier or insert objects into any
openings. ONLY add liquid vapor medicine to the medicine cup included with
the humidifier.
22. The humidifier should not be left unattended in a closed room as the air could
become saturated and leave condensation on walls or furniture. Leave room
door partly open.
23. The humidifier requires daily and weekly cleaning to operate appropriately.
Refer to cleaning instructions.
24. NEVER use detergents, gasoline, glass cleaner, furniture polish, paint thinner
or other household solvents to clean any part of the humidifier.
25. Do not tilt or tip the unit or attempt to empty or fill it while it is in operation.
SAVE ALL INSTRUCTIONS!

Safety instructions
6
Safety instructions
WARNING: Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire or serious personal injury. The
warnings, cautions, and instruction discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood
by the operator that common sense and caution are a factor which cannot be
built into this product but must be supplied by the operator.
CAUTION: A short power supply cord is provided to reduce the risk of personal
injury resulting from becoming entangled in or tripping over a longer cord.
•To avoid a circuit overload when using this humidifier, do not operate another
high-wattage product on the same electrical circuit.
•Avoid the use of an extension cord because the extension cord may overheat
and cause a risk of fire. However, if you have to use an extension cord, the
extension cord should be rated for 13 amps, 125V, 1625 watts.
•The power supply cord must be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or tripped over
accidentally.
Electric power
If the electric circuit is overloaded with other appliances, your humidifier may not
operate properly. The humidifier should be operated on a separate electrical
circuit from other operating appliances.
Polarized plug
This humidifier has a polarized plug (one blade is wider than the other). As a safety
feature to reduce the risk of electrical shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified electrician. Do not attempt to
defeat this safety feature.
Safety warning
Although your Warm Mist Humidifier is easy to operate, for your safety, the
warnings below must be followed:
1. Do not place the Warm Mist Humidifier near a heat source.
2. Never leave the Warm Mist Humidifier unattended while connected to the
electrical outlet.

Safety instructions
7
3. To avoid any accidental burns, never put a hand over the front net guard or
cover when the Warm Mist Humidifier is in operation.
4. Use the Warm Mist Humidifier on a stable surface away from water.
5. Do not unplug the Warm Mist Humidifier by pulling on the power supply cord.
6. The Warm Mist Humidifier must be unplugged:
A. Before any cleaning or maintenance.
B. After use.
C. If it appears to be faulty.
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.
SAVE THESE INSTRUCTIONS

User instructions
8
Fig. 2
Fig. 1
User instructions
Before First Use
CHECK HUMIDIFIER PLACEMENT - Place the Humidifier on a non-metallic, lint free,
waterproof, level surface for best performance. This is to help disperse the mist in
the air and prevent it from being knocked or tipped over.
CAUTION:
DO NOT operate the humidifier without water in the water tank.
DO NOT plug in the power supply cord with wet hands; electric shock could
happen.
•Be sure the humidifier is switched to OFF (O) and the humidifier is unplugged
from the electrical outlet.
•Select a location for your humidifier on a flat surface approximately 4 inches
away from a wall.
•DO NOT place the humidifier on a finished floor or near furniture which can be
damaged by moisture or water. Place on a water-resistant surface.
•DO NOT place Humidifier on top of a towel, or a carpeted surface. The air vent
on the bottom may become blocked and overheat the humidifier.
How to operate
CAUTION: ALWAYS USE CAUTION WHEN
HANDLING WARM MIST HUMIDIFIER. DO NOT
DROP THE WARM MIST HUMIDIFER.
•Lift the water tank off the humidifier base.
•Turn over the water tank and unscrew the
water tank cap at the bottom of the tank by
turning it counterclockwise. (See Fig. 1)
•Fill water tank with cold water; do not fill all
the way to the rim. (See Fig. 2) DO NOT CARRY
FULL WATER TANK BY HANDLE. ALWAYS HOLD
FULL WATER TANK WITH TWO HANDS ON
EITHER SIDE OF THE WATER TANK.
•DO NOT use hot water. Use cool, tap water.
•NEVER add medication, essential oils or
additives directly to the water.
•DO NOT pour water into Mist Channel.

User instructions
9
Fig. 3
•Replace the water tank cap, aligning the
threads on the tank with the threads on the
cap, and turn it clockwise. (See Fig. 3)
•Turn the tank over, holding one hand by the
top handle and another hand under the
water tank. Place the full water tank on the
base, making sure it fits securely. Place the
medicine cup on top of the mist channel.
•Plug the power supply cord into a wall outlet
and turn on the unit. The On/Off dial is located on the base.
•The power light will turn blue.
•Use the On/Off dial to adjust the intensity of the mist output by selecting
either (LO) for lower mist output or (HI) for higher mist output.
•When the humidifier runs out of water, the blue power light will turn off and
the mist output will stop. This safety feature cues a water level sensor to turn
off the heating element once the water level sinks below the required level in
the water basin. A small orange light will appear to indicate that the
humidifier has automatically turned off. Turn the humidifier off and unplug
before removing and refilling the water tank.
IMPORTANT:
As a safety feature, when the humidifier runs out of water, the power indicator
light will turn off, an ORANGE light will appear near (HI) on the control knob and
the mist output will stop. Turn the humidifier off and unplug the unit before
removing and refilling the water tank.
Note: If the unit has overheated, a small RED light will appear near (HI) on the
control knob. Turn off the unit, unplug and allow to cool completely for 15 minutes
to reset the humidifier.
How to use the medicine cup
•The medicine cup allows the addition of
medications and essential oils recommended for
use with warm mist humidifiers only.
•Remove the medicine cup from the top of the
mist chamber for easier filling.
•BE CAREFUL not to overfill the medicine cup.
Overfilling may cause medicine to spill into mist

User instructions
10
chamber. Medicine in the mist chamber may affect the operation of the
humidifier.
•Place medicine cup on the top of the mist chamber.
•NEVER add any medication, essential oils or other additives directly to the
water.
A note about humidity
•It is best to keep the humidity level at about 30-50 percent of relative
humidity.
•The comfort level of humidity will vary from room to room and with changing
weather conditions.
•In cold weather, windows and even some walls may fog or develop frost from
excessive indoor humidity. If this occurs, reduce the mist intensity setting to
avoid damage from condensed water dripping on windowsills.
•Too much humidity in the room may allow moisture to accumulate on
surfaces where bacteria and fungi can grow. Moisture that gathers may also
damage furniture and walls, especially wallpaper.
•To eliminate excessive humidity, especially in small rooms, leave the room
door open and adjust the mist intensity control setting.
NOTE: Light Indicator
Blue Light –unit is running properly
Orange Light –unit is out of water
Red Light –unit is overheating

Troubleshooting
11
Troubleshooting
CAUTION: DO NOT attempt to repair the motor or nebulizer yourself. If the
humidifier continues to not operate, please call our service center.
Problem
Solution
If humidifier
does not have
any power:
•Ensure unit is properly plugged into a power outlet.
•Check that the Control Knob is turned to the ON
position.
•If Power On indicator light does not come on, contact
[email protected]e
Condensation
forms around
humidifier and
windows:
•Adjust Control Knob to decrease mist output to low.
•Leave room door cracked open during humidifier
operation.
If humidifier has
stopped, BLUE
light is off and
small RED light is
on:
•Adjust Control Knob to turn humidifier off and unplug.
•After 5 minutes, plug in humidifier and turn knob to
desired mist level.
If there is a
strange odor:
•Clean the Water Tank with a water and vinegar
solution and rinse with clean water.
•Leave the empty Water Tank open for some time
(without the Water Tank Cap attached) in a cool place.
The power
indicator light is
blue, but there is
no mist being
emitted:
•Check that there is water in the Water Tank.
•Make sure that nothing is blocking the mist output.
•Check that the Fan Vent on the bottom of the
humidifier is not blocked.
•Empty and rinse the Water Basin with cool tap water.
•Check for possible mineral deposits on the Water Level
Sensor and Heating Element.

Cleaning and maintenance
12
Cleaning and maintenance
Care and cleaning
Portable humidifiers require regular cleaning in order to reduce the risk of bacterial
growth, and to remove any scale residue to maintain good operational performance.
Follow the procedures below for healthy maintenance of your Warm Mist Humidifier.
How to clean the water tank
1. Turn switch to off (O) and unplug from the wall outlet.
2. Be sure the unit has cooled for at least 15 minutes. Lift the water tank from the
base and place in a sink or tub.
3. Fill water tank with ½ cup water and 1 tablespoon of vinegar.
4. Let it stand twenty minutes, shaking vigorously with two hands every few
minutes.
5. Carefully empty the tank after 20 minutes, and rinse with warm water until you
can no longer detect a vinegar smell.
How to clean the heating element in the base
1. To remove the mist chamber, slide the mist chamber latch to the left and
carefully lift the mist chamber off the water basin.
2. Fill the heating element with undiluted white vinegar.
3. Let it stand for 20 minutes. Dampen soft, clean cloth or sponge with undiluted
white vinegar and wipe out heating element to remove scale. DO NOT use soap,
detergents or abrasive cleaners.
4. Rinse heating element using clean, warm water, being careful not to submerge
the base in the water. Dry thoroughly. DO NOT IMMERSE WATER BASIN IN
WATER.
5. Soak the removable mist chamber in a solution of equal parts white vinegar and
water for 20 minutes. Rinse thoroughly and then wipe dry with a soft, clean cloth.
6. To attach the mist chamber, slide the mist chamber latch to the left and place the
mist chamber onto the water basin. Release the latch to secure the mist chamber
to the water basin.
How to clean humidifier exteriors
1. DO NOT IMMERSE THE BASE IN WATER OR ANY OTHER LIQUID. An electric shock
may result, or the humidifier may be damaged.
2. Wipe all exterior surfaces of the base with a soft, dry cloth.

Cleaning and maintenance
13
Daily maintenance
1. Turn switch to off (O) and unplug from the wall outlet.
2. Be sure the unit has cooled for at least 15 minutes. Lift the water tank from base
and place in sink or tub.
3. Carry the humidifier base to the sink and drain any remaining water. Wipe clean
and dry with a clean cloth.
4. Drain water from the water tank. Wipe clean, and dry with a clean cloth. Let the
water tank air dry when not in use.
Weekly maintenance (Removing scale)
NOTE: We recommend cleaning the humidifier WEEKLY or more often if you have
hard water or notice a build-up of impurities or detect unpleasant odors.
Repeat steps 1-4 above.
End of season maintenance and storing
1. Follow above weekly cleaning procedure at the end of the humidification season,
or when the humidifier will not be used for several days, being sure to dry all
parts. Allow the water tank to thoroughly air dry before storage. DO NOT store
with water inside any part of the humidifier.
2. Leave tank cap partially loosened during storage to prevent tank cap and gasket
from sticking together. This will prolong the life of the gasket.
3. Save original box for easy storage. Store humidifier in a cool, dry location. Do not
place any heavy items on top of humidifier during storage as this may result in
possible damage of humidifier.
IMPORTANT: Failure to keep this humidifier clean from mineral deposits normally
contained in any water supply will affect the efficiency of the operation. Customer
failure to follow these instructions may void the warranty.
CAUTION:
Always be sure that the humidifier is unplugged and switched OFF before cleaning or
attempting to store the humidifier. NEVER PLUG OR UNPLUG HUMIDIFIER WITH WET
HANDS.
DO NOT leave water in the water tank or water basin when the humidifier is not in
use. If water remains in the water tank for more than a day or two, bacterial growth is
possible.

Other useful information
14
Other useful information
Technical specifications
Model Number EE-5201W
Rating Voltage 120V –60Hz
Rated Wattage 280W
Storing
•Store the Warm Mist Humidifier in a dry location.
•Do not place any heavy items on top of item during storage as this may result
in possible damage.
Service center
If you have any questions in regards to the operation of this appliance, please
contact our service center at:
Tel: [phone]
Business Hours: Mon-Fri 10:00am –5:00pm EST
Email: [e-mail]
Environmental protection
If the appliance should no longer work at all, please make sure that it is disposed
of in an environmentally friendly way.

Índice
15
Índice
Lista de piezas............................................................................... 16
Contenido................................................................................ 16
Instrucciones importantes de seguridad..................................... 17
Instrucciones para el usuario....................................................... 21
Solución de problemas............................................................ 24
Limpieza y mantenimiento .......................................................... 25
Otra información útil................................................................... 28
Especificaciones técnicas ........................................................ 28
Almacenamiento..................................................................... 28

Lista de piezas
16
Piezas principales
1. Cámara de vapor
2. Base del humidificador
3. Sensor del nivel de agua
4. Interruptor de seguridad
contra caídas (parte
inferior)
5. Resistencia de
calentamiento
6. Perilla de control
7. Luz indicadora
8. Taza para medicamentos
9. Depósito de agua
10. Tapón del depósito de agua
11. Canal de vapor
Contenido del empaque
(Nota: El humidificador ha sido previamente ensamblado y está listo para usarse)
•Base del humidificador
•Tanque de agua
•Cámara de vapor
•Taza para medicamentos
•Manual de instrucciones
1
2
4
5
8
9
7
6
10
3
11

Instrucciones importantes de seguridad
17
INSTRUCCIONES IMPORTANTES DE
SEGURIDAD
Al usar aparatos eléctricos, siempre se deben seguir precauciones básicas de seguridad.
LEA Y GUARDE TODAS LAS
INSTRUCCIONES ANTES DE USAR EL
HUMIDIFICADOR DE VAPOR
CALIENTE.
¡MANTENER ALEJADO DEL AGUA!
1. Lea todas las instrucciones.
2. Es necesaria una atenta supervisión cuando el aparato es usado por niños o
cerca de estos.
3. NO transporte el tanque lleno de agua usando la agarradera. Se recomienda
tomar el tanque lleno de agua con las dos manos.
4. NO utilice este aparato al aire libre. El humidificador está diseñado solo para
uso en interiores.
5. NO TOQUE EL VAPOR. El vapor puede causar quemaduras.
6. No toque las superficies calientes.
7. NO quite el tanque de agua durante el funcionamiento o hasta 15 minutos
después de apagar y desenchufar el humidificador. Podría causar lesiones
graves.
8. Para protegerse contra descargas eléctricas, no sumerja el cable, enchufe o la
base en agua o ningún otro líquido.
9. NO utilizar sin agua. Siempre debe haber agua en el tanque cuando utilice el
humidificador.
10. Use solo agua limpia y fría para llenar el depósito. NO use agua caliente.
11. NO vierta agua por ninguna apertura excepto la del depósito de agua.
12. Asegúrese de que la tapa del tanque de agua esté bien cerrada. NO apunte el
vapor hacia niños, paredes, muebles o electrodomésticos.
13. Use solo un tomacorriente de 110-120 V CA. SIEMPRE enchufe y desenchufe
el humidificador con las manos secas.

Instrucciones importantes de seguridad
18
14. Desconectar del tomacorriente cuando no está en uso y antes de la limpieza.
Deje que se enfríe antes de poner o quitar piezas y antes de limpiarla.
15. Nunca opere el humidificador con un cable de alimentación o enchufe
dañado, después de una avería o si se ha dañado de cualquier manera. Llame
al servicio de atención al cliente para obtener un repuesto o reembolso.
16. No deje que el cable cuelgue sobre el borde de una mesa o mostrador, ni que
toque las superficies calientes. No colocar cerca de quemadores de gas o
eléctricos.
17. Debe tener mucho cuidado al mover cualquier electrodoméstico que
contenga líquidos calientes.
18. No utilice el humidificador para un uso que no sea el previsto.
19. El uso de accesorios o aditamentos no recomendados por el fabricante puede
causar lesiones.
20. Siempre coloque el humidificador sobre una superficie suave, plana, limpia,
no metálica, impermeable y nivelada lejos de la luz del sol. Mantenga el cable
de alimentación alejado de las superficies calientes y donde pueda pisarse o
causar tropezones.
21. NO agregue ningún tipo de medicamento al canal de vapor, la base o el
tanque de agua. No cubra las aberturas del humidificador ni inserte objetos en
ellas. SOLO agregue medicina líquida al depósito de medicina incluido con el
humidificador.
22. No debe dejar el humidificador sin supervisión en una habitación cerrada ya
que el aire podría saturarse y dejar condensación en las paredes y los
muebles. Deje la puerta parcialmente abierta.
23. El humidificador requiere de limpieza diaria y semanal para que funcione
correctamente. Consulte las instrucciones de limpieza.
24. NUNCA use detergentes, gasolina, limpiavidrios, pulidor de muebles, solvente
para pinturas u otros solventes domésticos para limpiar ninguna pieza del
humidificador.
25. No incline la unidad ni intente vaciarla o llenarla cuando esté funcionando.
¡GUARDE TODAS LAS INSTRUCCIONES!

Instrucciones de seguridad
19
Instrucciones de seguridad
ADVERTENCIA: Lea y entienda todas las instrucciones. Si no se cumplen todas las
instrucciones indicadas a continuación se pueden producir descargas eléctricas,
incendios o lesiones graves. Las advertencias, precauciones e instrucciones que se
detallan en este manual de instrucciones no cubren todas las condiciones y
situaciones posibles que podrían suceder. El operador debe entender que el
sentido común y la precaución son factores que no se pueden incluir en el
producto, sino que los debe aportar el operador mismo.
PRECAUCIÓN:Se incluye un cable de alimentación eléctrica corto para reducir el
riesgo de sufrir lesiones personales que pudieran resultar por haberse enredado o
tropezado con un cable más largo.
•Para evitar una sobrecarga en el circuito cuando use este humidificador,
no utilice otros productos de alto vataje en el mismo circuito eléctrico.
•Evite el uso de un cable de extensión ya que este podría sobrecalentarse y
provocar un incendio. Sin embargo, si necesita usar un cable de
extensión, este debe tener una calificación de 13 A, 125 V, 1625 W.
•El cable de alimentación se debe acomodar de tal forma que no cuelgue
sobre el borde de un mostrador o de una mesa en donde los niños
pudieran jalarlo o tropezarse accidentalmente.
Energía eléctrica
Si el circuito eléctrico se sobrecarga con otros electrodomésticos, es posible que
su humidificador no funcione adecuadamente. El humidificador se debe usar en
un circuito eléctrico distinto al de otros electrodomésticos en funcionamiento.
Enchufe polarizado
Este humidificador cuenta con un enchufe polarizado (una clavija es más ancha
que la otra). Como medida de seguridad para reducir el riesgo de descarga
eléctrica, este enchufe está diseñado para entrar en un tomacorriente polarizado
en un solo sentido. Si el enchufe no entra completamente en el tomacorriente,
gire el enchufe. Si aun así no encaja, contacte a un técnico electricista calificado.
No intente eliminar esta característica de seguridad.

Instrucciones de seguridad
20
Advertencia de seguridad
Aunque su humidificador es fácil de utilizar, por su seguridad, deben seguirse las
siguientes advertencias:
1. No coloque el humidificador de vapor caliente cerca de una fuente de calor.
2. Nunca desatienda el humidificador de vapor caliente mientras esté conectado
a un tomacorriente.
3. Para evitar cualquier quemadura accidental, nunca coloque su mano sobre la
malla o cubierta de protección delantera cuando el humidificador de vapor
caliente esté en funcionamiento.
4. Utilice el humidificador de vapor caliente sobre una superficie estable y
alejada del agua.
5. No desconecte el humidificador de vapor caliente jalando del cable de
alimentación eléctrica.
6. El humidificador de vapor caliente debe desconectarse:
A. Antes de cualquier operación de limpieza o mantenimiento.
B. Después de su uso.
C. Si parece estar defectuoso.
ESTE PRODUCTO ESTÁ DESTINADO EXCLUSIVAMENTE PARA
USO DOMÉSTICO.
GUARDE ESTAS INSTRUCCIONES
