Instruction Leaflet K1121V10
Leat
December 2019
 Product luminaires comply with EN60598 and are suitable for use in normal interior conditions.
o o
 This luminaire has an ambient temperature range of -10 C to 25 C for the non-emergency version
o o
 For Emergency variants - This luminaire has an ambient temperature range of 5 C to 25 C, to ensure the batteries work correctly
1 Recessed - Bracket Installation
Fixing Centres (per fitting)
1.0m
1.5m
2.0m
700mm
2700mm + centre fixing
3.0m
1200mm
1700mm
IMPORTANT: Once brackets
are fully installed. Plaster surface
before installing the Leat.
a)
Cut aperture to required size.
Using the flat bracket (sold separately) as a drilling template, drill 4 x holes
5mm dia, through pilot holes. See ‘Bracket Orientation’.
Counter sink the drilled holes so c/sk screws (supplied) sit flush with
the plasterboard.
Dimn ‘a’
Drilling Direction
240mm MAX Plasterboard
160mm MIN
44x44mm
Wooden
Battens
Recommended Wooden Batten Spacing
For Plasterboard Support
Drilling Direction
b) Secure each slider to
plasterboard using M5
c/sk screws supplied
Dim ‘a’
Trimmed
Trimless
79.0mm
76.0mm
Bracket Orientation
When using the flat bracket for the drill hole locations make sure the metalwork is
in the correct orientation.
The image on the left shows the orientation for the trimless variant and the image on
the right shows the orientation for the trimmed version.
c) Fold flat bracket over and fix spring clip.
Fit main bracket into slider brackets. Ensure that
dimension ‘a’ from bottom of plasterboard to the inside
face of main face is adhered to. Tighten slider
bracket screws to hold main bracket in place.
Dim ‘a’
Aperture
Trim - 65.5mm wide
Trimless - 57.0mm wide
Fixing crs
Aperture
Trim - Run Length + 8.0mm
Trimless - Run Length + 10.5mm

Fixing Centres
Suspension Ceiling Fixing
Fix ceiling boss
mounting surface
using suitable
wood screw
Feed 1-5m long wire
into body as shown
- screw body into
ceiling boss
a) Follow procedures ‘a’ to ‘c’ as per ‘Surface
Bracket Installation’.
b) Fix suspension wire to surface (see ‘Suspension
Ceiling Fixing’).
c) locate the suspension wire thread through
the central surface bracket hole, and secure
with supplied M4 nut supplied. Offer the
Leat up to the surface brackets and fix
Suspension Wire Installation
3
c) Disconnect the connecting block
from the geartray to the housing.
Then fully remove the geartray.
a) Remove diffuser using the
suction cup (supplied) positioned
at the centre of the diffuser.
(Stand alone only)
b) Using a screwdriver, gently
disengage the geartray using
the slotted tabs
Fixing Centres
1.0m
1.5m
2.0m
700mm
2700mm + central fixing
3.0m
1200mm
1700mm
d) Once spring clips are secure, fix housing into the spring clips.
Ensure the spring clips are located above the 21mm diameter
holes in the back of the housing, for future removal.
(see table for hole locations).
e) Wire (as shown in section 4)
supply cable into luminaire,
re-connect the connecting
block and fix geartray and
diffuser back into place
2 Surface Bracket Installation
IMPORTANT DO NOT REMOVE ENDCAPS
December 2019
Leat
Instruction Manual - K1121V10

Continuous Installation
a) Follow procedures ‘a’ to ‘c’ as per
‘Surface Bracket Installation’.
b) Install desired fixing method
(recessed, surface or suspended)
and wire.
c) Fix both leat housings using the
Connector plates
d) Wire connecting block (see bottom right) from
the incoming Leat and connect to the Leat
previously installed.
e) Continuous runs over 3m - fit endplates with pre-fitted steel
clip from LEADEKS Kit (to be ordered seperately) one endplate per start and end of run.
Continuous runs up to 3m - Fit LEAEC - One endplate per start and end of run
f) Fix geartray clamp into the geartray at the start of the run and fix in place. Then fix the next geartray,
locating it in the clamp. Repeat the process for any additional Leats.
g) Once geartrays have been installed cut and fit diffusers as shown below
5
Wiring D1 D2
L3N L2
L1
LUMINAIRE MUST BE EARTHED
ISOLATE MAINS SUPPLY BEFORE WIRING
Trim Installation
6
RED - Dali (+/-)
WHITE - Dali (+/-)
Unused
BLACK - Live Unswitched
BROWN - Live Switched
GREEN/YELLOW - Earth
BLUE - Neutral
D1 -
D2 -
L3 -
L2 -
L1 -
-
N -
2
NOTE: Solid core only. Max 2.5mm
First slide the connecting plates into housing,
sitting the bottom of the plate in the small
channel. Fix plate in position with supplied
screw (Do not over tighten). Connect the next
housing onto the plate and secure.
Connector Plates
1
2
RED - Dali (+/-)
WHITE - Dali (+/-)
Unused
BLACK - Live Unswitched
BROWN - Live Switched
GREEN/YELLOW - Earth
BLUE - Neutral
N 1 23 + -
When installing gear
tray ensure pegs (1) on
endplate are engaged into slots (2)
in end of gear tray
Start End
2 - 3mm 2 - 3mm
Ensure there is
2 - 3mm diffuser
under endplate
Cut end of diffuser
to ensure that 2 - 3mm
can be fitted under
endplate.
Fit diffuser down
length of fitting
Continuous runs over 3m
h) Continuous runs up to 3m - Fit diffuser into housing. diffuser is pre-cut to
required length, the cut length allows for diffuser expansion.
Start of Run
Cable Entry
Geartray Clamp
Diffuser
4
a)
b)
Follow above instructions but
omitting ‘d)’
Fit end trim from LEADEKR
kit (kit ordered seperatley)
c) Push trim fully down, drill 2.2mm
dia hole into endplate, using trim
slot as guide. Secure trim to
endplate using screw supplied
with LEADEKR kit
Continuous runs over 3m
Side view
of the trim
fully installed
Housing
Trim
Grub Screw
b
e
c
d
Continuous runs up to 3m
c) Fit LEAREETK to
endplate by pushing
it into position. No grub
screw needed.
b) Offer trim up to
the edge of the
Leat housing.
Once located, tighten
grub screws with
a 2mm allen key.
a) Fit LEAEC one endplate
per start and end of run
d) Place steel insert on the
endplate
e) Fold over lazy bend tab
to fix the insert in position.
December 2019
Leat
Instruction Manual - K1121V10

K1121V10
Eaton
Wheatley Hall Road, Doncaster, South Yorkshire, DN2 4NB
Sales
T: [phone]
F: [phone]
E: [e-mail]
General
[phone]
[phone]
[e-mail]
International Sales
[phone]
[phone]
[e-mail]
Safe Operation
1. Check the rating label for voltage and frequency before connecting this
luminaire to the electrical supply.
2. Ensure that the mains supply is switched off when working on this
luminaire, whether installing or carrying out any other servicing.
3. Do not mount luminaire on or close to readily flammable materials.
4. To prevent damage to driver, do not mix with conventional magnetic
ballasts on the same electrical circuit.
5. Where use in more onerous situations is required, e.g. In part-
completed buildings before “drying-out” is completed, or areas where
ambient temperatures are outside the normal temperature range, then
consult our Sales Office.
6. The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualified person.
7. When used as intended this product complies with the EMC Directive
2014/30/EU and Low Voltage Directive 2014/35/EU.
Servicing and Disposal
1. At commissioning and handing over of installation ensure that a copy of
these instructions is presented to the authority responsible for the
operation and maintenance of the luminaries.
2. Servicing, e.g. cleaning, must only be carried out after the electricity
supply has been switched off. It must not be assumed that luminaries
with LEDs not lit are switched off, always check before servicing.
3. Cleaning should be carried out at regular intervals to ensure that dirt
does not accumulate to an extent that will impair the thermal safety or
optical performance of the luminaire. Regular cleaning will also ensure
that the optical performance of the luminaries is maintained.
4. Avoid touching the LED array surface. To clean - Blow surface with
either dry air or nitrogen gas.
5. At the end of life the luminaire is classed as WEEE under directive
2012/19/EU and should be disposed of in accordance with local
legislation.
Luminaire Service
Luminaire Cleaning
End of Life and Components Disposal
WEEE
December 2019
Leat
Leat
Connecting Plates
Leat Corner  Remove front cover from corner
 Offer up the Leat Corner up to
the continuous Leat with the
Connecting Plates in position
holding both parts together (See
‘Connector Plates’ in step 4).
 Screw the plates to both parts,
ensuring they are butted up
together.
 Connect the plug and socket from
both parts. Corner through wiring
can be swapped around to switch
corner direction.
 Fix front cover back on the Leat
Corner
Leat Corner (100mm) - Sold Seperatley
Leat Corner (500mm) - Sold Seperatley
A (External)
B
A = Overall Length (measured)
B = Diffuser Cut Length
(A - 0.286m) x 0.994 = B
e.g. 10.068m - 0.286m = 9.782m
9.782m x 0.994 = 9.723m
0.143m 0.143m
 Follow steps ‘a, b, c, d’ and ‘f’ under
‘Continuous Installation’ on page 3.
 After step ‘f’ cut the diffuser, using the
formula on the right to ascertain the
diffuser cut length
Instruction Manual - K1121V10
Suspension Wire
Location
Suspension Wire
Location
270mm
Fit both suspensions wires as
before, over the 21mm diameter
holes.
!! CRITICAL TO QUALITY !!
