Eden 94124-EDAMZ Manual

Simply attach the gear driver to the top of the base and
connect to your hose
Method A
Connect the adaptor to
the base, attach the hose
with the quick lockable
connector, then simply
snap on the water hose
to begin using.
LOCK
WATER
+
94124-EDAMZ
5 spray patterns -
Flat, Fan, large, multi and Mist!
Adjustable diameter tabs
prevent water waste
Filter prevents
sediments and dirt from
getting into sprinkler
Flow through design allows
for additional units to be
connected in series
Wide H shape
platform design for
added stability
For setup, you can choose Method A or B
Quick Connect Adapter ts
most brands of garden hoses
To extend, simply remove the end-cap and attach
another hose and connect another sprinkler.
MULTI-PATTERN SPRINKLER
PLUS MISTING SYSTEM
Method B

Higher level will create a higher arc resulting
in greater water coverage.
Lower levels will reduce coverage.
Convenient indicators are included to
help setup when you need to water again.
Level Adjustment Indicator
HIGHER LEVEL (+) 0 ~ 3 :
The appearance of gradual
reduction in water while
providing a more dispersed
pattern and further distance.
LEVEL WATER:
The ow is depend on water
source.
It’s the middle point between
dispersed and concentrated
patterns.
40 PSI Large Multi Flat Fan
Radius of Spray 39 ft (12 m ) 37 ft (11.5 m) 29 ft (9 m) 27 ft (8.5 m)
Coverage Area
up to
4860 sq ft
(452 m²)
4470 sq ft
(415 m²)
2730 sq ft
(250 m²)
2440 sq ft
(226 m²)
LOWER LEVEL (-) 0 ~ 3 :
Increase water ow while
providing a more
concentrated direct ow of
water.
The Quick Connect Adapter (2 pcs) and Hose Connector
with Water Stop (1 pc) simplify your watering experience.
Simply attach the connector at the end of your hose.
Then, connect the adapters to your watering tools.
Interchange various tools in a snap without turning o the
water as the adapter will stop the water ow. No more
kinking or hose twisting as the adapter allows the hose to
swivel 360 degrees.
A
C
A B C D
B
D
Quick and easy connections to 5/8-inch and
1/2-inch garden hoses, sprinklers, nozzles, and or
any other garden watering tools
-For outdoor use with cold water only
-Do not spray near electrical connections
-When not in use, rinse the tool with water
to remove most of the dirt, dry your tool,
and store indoors
This product can expose you to chemicals
including styrene, which is known to the
State of California to cause cancer.
For more information go to
www.P65Warnings.ca.gov
UNLOCK
LOCK
UNLOCK LOCK
Secure twist-and-lock
mechanism prevents
accidental disconnection
Adjust the range tabs and angle cap to change the spray
coverage (from 5°up to 360°) and spraying angle to water
just where you need without wasting water.
Spray Coverage and Distance Adjustment
Depending on your watering needs, you can manually select from the various pattern settings :
FLAT - The at pattern will provide a at wave of water.
FAN - The fan pattern disperses water in a wide fan shape.
MIST - This pattern is useful to cool down a small area.
LARGE - This pattern covers the maximum area.
MULTI - This is a combination of the Flat, Fan and Large patterns.
Spray Pattern Adjustments
FLAT FAN MIST LARGE MULTI
 CAUTION 
