Edge-Core AS5915-18X User manual

– 1 –
Quick Start Guide
Attach the Brackets
1. Attach each of the brackets to the device with four of the
included bracket screws.
Mount the Device in an EIA-310 Rack
1. Use the screws and cage/clip nuts supplied with the rack to
secure the device in the rack.
Ground the Device
1. Ensure the rack is properly grounded and in compliance with
international and local standards. Verify that there is a good
electrical connection to the grounding point on the rack (no
paint or isolating surface treatment).
2. Attach a grounding wire (#6 AWG/16 mm2) to the grounding
point on the device’s rear panel or side panel. Then connect the
other end of the wire to rack ground.
Connect Power
a. AC Power
1. Connect an AC power source to both AC power sockets.
Caution:
The device must be installed in a restricted-
access location.
Attention:
L’appareil doit être installé dans un
emplacement à accès restreint.
Note:
The device has the Open Network Install
Environment (ONIE) software installer pre-loaded on it, but
no software image. Information about compatible software
can be found at www.edge-core.com.
Note:
The drawings in this document are for illustration
only and may not match your particular model.
1
1
2
1
Caution:
The earth connection must not be removed unless
all supply connections have been disconnected.
Attention:
Le raccordement à la terre ne doit pas être retiré
sauf si toutes les connexions d’alimentation ont été
débranchées.
3
2
1
2
Rear Panel Side Panel
4
1
E032022-CS-R01
150200002482A
Cell Site Gateway
AS5915-18X | AS5915-18X AC
1.
AS5915-18X or AS5915-18X AC
2. Rack Mounting Kit—2 brackets and 8 screws
3. 2 AC power cords (AS5915-18X AC only)
4. Grounding kit—grounding lug, 2 screws, and 2 washers
5. Ring lugs (x4)
6. Documentation—Quick Start Guide (this document) and
Safety and Regulatory Information
1
Package Contents
2456
www.edge-core.com
*150200002482A_R01*
3

Quick Start Guide
– 2 –
b. DC Power
1. Connect an external DC power source to the PSUs. Or, connect
to a no-tolerance DC mains supply with a UL/CSA-approved
circuit breaker rated at 16 A.
1. Connect the ground wire / earth.
2. Connect the 36 – 72 VDC wire.
3. Connect the DC return wire.
Verify Power Status
1. Verify the device is receiving power by checking the system LEDs.
After power on, the PSU1/PSU2 LEDs should be on green.
Connect Network Cables
1. For the RJ-45 Management port, connect 100-ohm Category 5,
5e or better twisted-pair cable.
2. Connect DAC cables to the SFP/SFP+ slots. Or first install SFP/
SFP+ transceivers in the slots and then connect fiber optic
cabling to the transceiver ports.
3. As connections are made, check the port status LEDs to be sure
the links are valid.
Connect Timing Ports
1. Use a shielded cable to connect the Building-Integrated Timing
Supply (BITS) port to other devices that use BITS synchronization
signals.
2. Use a shielded cable to connect the Pulse-Per-Second (PPS) /
Time-of-Day (ToD) port to other devices that use these
synchronization signals.
3. Use coax cables to connect the 1-pulse-per-second (1PPS) in/
out SMB ports to other synchronized devices.
4. Use coax cables to connect the 10 MHz in/out SMB ports to
other synchronized devices.
Perform Initial System Boot
1. If the network operating system (NOS) installer is located on a
network server, first connect the RJ-45 Management (Mgmt) port
to the network using 100-ohm Category 5, 5e or better twisted-
pair cable. (Not required if the NOS installer is located on
attached storage.)
2. Boot the device. Wait for the ONIE software to locate and
execute the NOS installer, and then wait for the installer to load
the NOS software image.
Subsequent device boots will bypass ONIE and directly run the
NOS software.
Caution:
Before connecting power supply cables to the
device, ensure that power to the feed lines is turned off at the
supply circuit breaker or disconnected from the power bus.
Attention:
Avant de connecter les câbles d’alimentation à
l’appareil, assurez-vous que l’alimentation des lignes
d’alimentation est coupée au niveau du disjoncteur
d’alimentation ou déconnectée du bus d’alimentation.
Caution:
Use a UL/IEC/EN 60950-1 and/or 62368-1
certified power supply to connect to a DC converter, and a
#14 AWG/1.5 mm2(for 36 VDC to 72 VDC PSU) copper
wire to connect to a DC PSU.
Attention:
Utilisez une alimentation certifiée UL/IEC/EN
60950-1 et/ou 62368-1 pour vous connecter à un
convertisseur CC, et un fil de cuivre # 14 AWG / 1,5 mm2
(pour alimentation 36 V CC à 72 V CC) pour se connecter
à une alimentation CC.
1
3
21
5
1
6
2
3
1
7
2
1
3 4
8

Quick Start Guide
– 3 –
(Optional) Install the Air Filter
1. Unscrew and remove the air filter slot cover.
2. Slide the air filter assembly (ordered separately) into the slot and
secure it with its two captured screws.
Hardware Specifications
Note:
Refer to the network operating system (NOS) installer
and NOS documentation for details on software options
and set up for ONIE.
9
2
1
Size (WxDxH) 440 x 240 x 43.7 mm (17.32 x 9.45 x 1.72 in.)
Weight 3.8 kg (8.38 lb), with two installed PSUs
Temperature Operating: -40° C to 70° C (-40° F to 158° F)
Storage: -40° C to 85° C (-40° F to 185° F)
Humidity Operating: 5% to 95% (non-condensing)
Power
Consumption
119 Watts maximum @ 25° C
48 VDC PSU
Power Rating 48 VDC, 180 Watts
DC Input 36 V – 72 V, 6 A
AC PSU
AC Input 100–240 VAC, 50/60 Hz, 2.5 A maximum
Regulatory Compliances
Emissions EN 55032:2015+AC:2016, Class B
BS EN 55032:2015+A1:2020
EN 300 386 V2.1.1
FCC Title 47, Part 15, Subpart B, Class B
VCCI CISPR 32:2016, Class B
BSMI Class B, CNS 13438
Immunity EN 55035:2017/A11:2020
EN 55024:2010+A1:2015
BS EN 55035:2017+A11:2020
BS EN 55024:2010+A1:2015
IEC 61000-4-2/3/4/5/6/8/11
Environmental Storage:
◆ETSI EN 300 019-1-1 Class 1.1
◆Temperature: -5°C to +45°C (+23°F to +113°C)
Transportation:
◆ETSI EN 300 019-1-2 Class 2.3
◆Temperature: -40°C to +70°C (-40°F to +158°C)
Operating Conditions:
◆ETSI EN 300 019-1-3 Class 3.2
◆Temperature: -40°C to +65°C (-40°F to +149°C)
◆Relative Humidity: 5% to 95%
Safety CB IEC/EN60950-1 & IEC/EN62368-1
UL/CSA No 62368-1
BSMI CNS14336-1

– 4 –
快速入門指南
安裝托架
1.
用四顆隨附的托架螺絲將每個托架裝到本裝置上。
將本裝置裝到 EIA-310 機櫃上
1.
使用機櫃隨附提供的螺絲與支架
/
彈簧夾螺帽將本裝置固定於
機櫃上。
將本裝置接地
1.
請確保機櫃正確接地,並符合國際與當地標準。確認與機櫃接
地點間有良好的電氣連接性 (無油漆或絕緣表面處理)。
2. 將接地線 (#6 AWG/16 mm2) 安裝在本裝置後面板或側面板
接地點上。接下來,將接地線另一端連接至機櫃接地。
連接電源
a. 交流電源
1. 將交流電源連接至交流電源插座。
注意:
裝置必須安裝在限制進入地點。
說明:
本裝置預先安裝了 「開放網路安裝環境 (Open
Network Install Environment,ONIE)」軟體安裝程式,
但沒有軟體圖示。關於相容軟體的資訊可參閱:
www.edge-core.com。
說明:
本文件中的示意圖僅供參考,可能與特定型號有
所差異。
1
1
2
1
注意:
在切斷所有電源接線前,不得移除接地連接。
3
2
2
1
後面板 側面板
4
1
1.
AS5915-18X
或
AS5915-18X AC
2. 機櫃安裝套件 —2 個托架和 8 個螺絲
3. 2 x 交流電源線 ( 僅AS5915-18X AC)
4. 接地單元 —接地壓耳、2 顆螺絲和 2 個墊圈
5. 環形壓耳 (x4)
6. 文件-
快速入門指南
(本文件)及 《
安全法規資訊》
包裝內容物
行動通信基地台閘道
AS5915-18X | AS5915-18X AC
1
www.edge-core.com
2456
3

快速入門指南
– 5 –
b. 直流電源
1.
將外部直流電源連接至
PSU
。或將無容差直流主電源連接具備
UL/CSA
標準認證的
16A
斷路器。
1.
連接接地線
/
接地端。
2. 連接 36 – 72 VDC 線。
3. 連接直流回流線。
確認電源狀態
1.
檢查系統
LED
,確認本裝置是否接通電源。
開啟電源後,PSU1 /PSU2 LED 應亮綠燈。
連接網路線
1.
使用
100-ohm
第
5
類、
5e
類或更優之雙絞線電纜,連接至
RJ-45
管理埠。
2. 連接 DAC 電纜至 SFP/SFP+ 插槽。或先將 SFP/SFP+ 收發器
裝到插槽中,然後連接光纖電纜至收發器埠。
3. 連接完成後,請檢查連接埠狀態 LED,確保連結有效。
連接時序連接埠
1.
用包覆纜線將大樓綜合時脈供應裝置
(BITS)
連接埠連接有使用
BITS
同步訊號的其他裝置。
2. 用包覆纜線將每秒脈波數 (PPS) /日時間 (ToD) 連接埠連接有
使用同步訊號的其他裝置。
3. 使用同軸纜線連接 1 每秒脈衝 (1PPS) 輸入 /輸出 SMB 連接埠
至其他同步化裝置。
4. 使用同軸纜線連接 10 MHz 輸入 /輸出 SMB 連接埠至其他同
步化裝置。
執行初次系統啟動
1.
若網路作業系統 (
NOS
)安裝程式位於網路伺服器,先使用
100-ohm
第
5
類、
5e
類或更優之雙絞線電纜,連接
RJ-45
管
理(
Mgmt
)埠至網路。(若
NOS
安裝程式位於所附儲存設備
中,則不需要。)
2. 啟動本裝置。等待 ONIE 軟體找尋並執行 NOS 安裝程式,並
等待安裝程式載入 NOS 軟體映像檔。
之後本裝置啟動時,會跳過 ONIE,直接運行 NOS 軟體。
注意:
將電源供應器纜線連接到本裝置前,請務必在電
源斷路器關閉接到饋線的電源,或從電源匯流排切斷電
源。
注意:
使用符合 UL/IEC/EN 60950-1 及/或62368-1 標
準的電源供應器連接直流轉換器和 #14 AWG 銅線 /1.5
mm2(適用於 36 VDC 至72 VDC PSU)連 接 至 DC PSU。
1
3
21
5
1
備註:
有關 ONIE 軟體選項和設置的詳細資訊,請參閱
網路作業系統 (NOS)安裝程式和 NOS 文件。
6
1
2
3
7
1
34
2
8

快速入門指南
– 6 –
(選用 ) 安裝空氣濾網
1.
卸下螺絲並取下空氣濾網插槽蓋。
2. 將空氣濾網總成 ( 另外訂購 ) 滑入插槽並用兩支固定螺絲緊
固。
硬體規格
9
1
2
尺寸(寬 x 深x
高)
440 x 240 x 43.7 mm (17.32 x 9.45 x 1.72 in.)
重量 3.8 kg (8.38 lb),包含兩個安裝電源供應器
溫度 操作:-40° C 至70° C (-40° F 至158° F)
儲存:-40° C 至85° C (-40° F 至185° F)
濕度 操作:5% 至95% ( 無冷凝 )
最大功耗 最大 119 瓦@ 25° C
48 VDC 電源供應器
額定功率 48 VDC, 180 瓦
DC 輸入 36 V – 72 V, 6 A
交流電源供應器
交流輸入 100–240 VAC, 50/60 Hz, 2.5 A 最大
符合法規
排放 EN 55032:2015+AC:2016, Class B
BS EN 55032:2015+A1:2020
EN 300 386 V2.1.1
FCC Title 47, Part 15, Subpart B, Class B
VCCI CISPR 32:2016, Class B
BSMI Class B, CNS 13438
電磁耐受性 EN 55035:2017/A11:2020
EN 55024:2010+A1:2015
BS EN 55035:2017+A11:2020
BS EN 55024:2010+A1:2015
IEC 61000-4-2/3/4/5/6/8/11
環境 儲存環境 :
◆ETSI EN 300 019-1-1 Class 1.1
◆溫度範圍 : -5°C to +45°C (+23°F to +113°C)
運輸環境 :
◆ETSI EN 300 019-1-2 Class 2.3
◆溫度範圍 : -40°C to +70°C (-40°F to +158°C)
操作環境 :
◆ETSI EN 300 019-1-3 Class 3.2
◆溫度範圍 : -40°C to +65°C (-40°F to +149°C)
◆相對溼度 : 5% to 95%
安全性 CB IEC/EN60950-1 & IEC/EN62368-1
UL/CSA No 62368-1
BSMI CNS14336-1
