Edge-Core RG230 User manual

Powered by Accton
www.edge-core.com
User Guide
RG230
Indoor WiMAX
Residential Gateway

User Guide
RG230
Indoor IEEE 802.16e-2005 Mobile WiMAX Gateway,
with 2.3/2.5/3.5 GHz Frequency Band Support,
Four LAN (RJ-45) Ports,
Two VoIP (RJ-11) Ports,
and Optional 802.11g Wi-Fi

RG230
E032008-CS-R01
1*************

i
Compliances
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
• Consult the dealer or an experienced radio/TV technician for help
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
IMPORTANT NOTE: FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF
exposure compliance. To maintain compliance with FCC RF exposure compliance
requirements, please follow operation instruction as documented in this manual.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
The availability of some specific channels and/or operational frequency bands are country
dependent and are firmware programmed at the factory to match the intended
destination. The firmware setting is not accessible by the end user.
Japan VCCI Class B

ii
EC Conformance Declaration
Marking by the above symbol indicates compliance with the Essential Requirements of
the R&TTE Directive of the European Union (1999/5/EC). This equipment meets the
following conformance standards:
• EN 60950-1 (IEC 60950-1) - Product Safety
• EN 301 489-1, EN 301 489-4 - EMC requirements for radio equipment
• EN 50385 - Country specific SAR requirements
This device is intended for use in all European Community countries:

iii
About This Guide
Purpose
This guide details the hardware features of the WiMAX Residential Gateway including its
physical and performance-related characteristics, and how to install the device and use its
configuration software.
Audience
This guide is for PC users with a working knowledge of computers. You should be familiar
with basic networking concepts.
Conventions
The following conventions are used throughout this guide to show information:
Note: Emphasizes important information or calls your attention to related features or
instructions.
Caution: Alerts you to a potential hazard that could cause loss of data, or damage the
system or equipment.
Warning: Alerts you to a potential hazard that could cause personal injury.
Related Publications
The following publication gives basic information on how to install and use the WiMAX
Residential Gateway.
Quick Installation Guide
As part of the WiMAX Residential Gateway’s software, there is online help that describes
all configuration related features.
Revision History
This section summarizes the changes in each revision of this guide.
March 2008 Revision
This is the first revision of this guide. This guide is valid for software release v0.1.0.6.

iv

v
Table of Contents
Chapter 1: Introduction 1-1
RG230 Hardware Description 1-2
Scan Button 1-3
Reset Button 1-3
WiMAX Antennas 1-3
WiMAX External Antenna Connectors 1-3
Power Status Indicator LED 1-4
Wi-Fi Status Indicator LED 1-5
WiMAX Signal Indicator LEDs 1-5
10BASE-T/100BASE-TX LAN Ports 1-5
VoIP Phone Ports 1-6
Power Adapter Socket 1-6
Backup Battery Charger (Optional) 1-6
SIM Card Slot 1-7
RG230 Wi-Fi Option 1-8
Chapter 2: Installing the RG230 2-1
Package Checklist 2-1
Installation Overview 2-1
Select a Location 2-1
Cable Connections 2-2
Chapter 3: Initial Configuration 3-1
Accessing the Web Management Interface 3-1
Using the Setup Wizard 3-3
The Advanced Setup Menu 3-12
Chapter 4: System Settings 4-1
Host Name 4-1
System Time 4-2
Administrator Settings 4-3
Firmware Update 4-3
Configuration Tools 4-4
System Status 4-6
System Log 4-8
Reset 4-9

vi
Table of Contents
Chapter 5: Gateway Configuration 5-1
WAN Settings 5-2
Dynamic IP Address 5-3
Static IP Settings 5-3
L2TP Settings 5-4
PPPoE Settings 5-5
DNS 5-6
LAN 5-7
LAN Settings 5-7
DHCP Client List 5-8
NAT 5-8
Virtual Server 5-8
Port Mapping 5-10
DMZ 5-11
Firewall 5-11
Firewall Options 5-12
Client Filtering 5-13
MAC Control 5-14
Route 5-15
UPnP 5-16
Chapter 6: WiMAX Settings 6-1
Profile Configuration 6-1
Authentication 6-2
Subscriber Station Information 6-3
Antenna Setting 6-4
Chapter 7: VoIP Settings 7-1
SIP Account 7-2
SIP Setting 7-3
Dial Plan 7-4
Call Feature 7-6
Codecs 7-8
Call Block Setting 7-9
Phone Setting 7-10
Chapter 8: Wi-Fi Settings 8-1
Wireless Settings 8-1
Wireless Security 8-5
WEP Shared Key Security 8-6
WPA/WPA2 Security 8-7

vii
Table of Contents
WPA/WPA2 PSK Security 8-8
MAC Authentication 8-9
Appendix A: Troubleshooting A-1
Diagnosing LED Indicators A-1
Cannot Connect to the Internet A-1
Cannot Access Web Management A-2
Forgot or Lost the Password A-2
Resetting the Unit A-2
Appendix B: Specifications B-1
Physical Specifications B-1
WiMAX Specifications B-2
VoIP Specifications B-2
Wi-Fi Specifications B-3
Compliances B-4
Appendix C: Cables and Pinouts C-1
Twisted-Pair Cable Assignments C-1
10/100BASE-TX Pin Assignments C-1
Straight-Through Wiring C-2
Crossover Wiring C-2
RJ-11 Ports C-3
Appendix D: License Information D-1
The GNU General Public License D-1
Glossary
Index

viii
Table of Contents

ix
Tables
Table 1-1 RG230 Models 1-1
Table 1-2 Power Status LED 1-4
Table 1-3 Wi-Fi Status LED 1-5
Table 1-4 WiMAX Signal Status LEDs 1-5
Table 1-5 LAN Port Status LEDs 1-6
Table 4-1 System Settings 4-1
Table 5-1 Gateway Configuration 5-1
Table 6-1 WiMAX Settings 6-1
Table 8-1 Wi-Fi Settings 8-1
Table A-1 Troubleshooting Chart A-1
Table C-1. 10/100BASE-TX MDI and MDI-X Port Pinouts C-2
Table C-2. RJ-11 Port Pinout C-3

x
Figures
Figure 1-1 Front of the RG230 1-2
Figure 1-2 Base of the RG230 1-2
Figure 1-3 Back of the RG230 1-3
Figure 1-4 RG230 LED Indicators 1-4
Figure 1-5 Front of the RG230 1-7
Figure 1-6 3.5 GHz RG230 with Wi-Fi 1-8
Figure 2-1 CPE Connections 2-2
Figure 3-1 Login Page 3-1
Figure 3-2 Home Page 3-2
Figure 3-3 Host Settings 3-3
Figure 3-4 Time Zone 3-4
Figure 3-5 WAN Type 3-5
Figure 3-6 WAN Type - Static IP Address 3-6
Figure 3-7 WAN Type - L2TP 3-7
Figure 3-8 WAN Type - PPPoE 3-8
Figure 3-9 Profile Configuration 3-9
Figure 3-10 DNS Configuration 3-10
Figure 3-11 Wizard Setup Finished 3-11
Figure 3-12 Advanced Setup 3-12
Figure 4-1 System Host Name 4-1
Figure 4-2 System Time 4-2
Figure 4-3 Setting a Password 4-3
Figure 4-4 Firmware Update 4-3
Figure 4-5 Configuration Tools 4-4
Figure 4-6 Restore Factory Default Configuration 4-4
Figure 4-7 Backup/Restore Settings 4-5
Figure 4-8 System Status – Internet 4-6
Figure 4-9 System Status – Gateway 4-6
Figure 4-10 System Status – Information 4-7
Figure 4-11 System Log 4-8
Figure 4-12 Reset Unit 4-9
Figure 5-1 WAN Settings 5-2
Figure 5-2 Dynamic IP Address 5-3
Figure 5-3 Static IP Settings 5-3
Figure 5-4 L2TP Settings 5-4
Figure 5-5 PPPoE Settings 5-5
Figure 5-6 DNS Settings 5-6
Figure 5-7 LAN Settings 5-7
Figure 5-8 DHCP Client List 5-8
Figure 5-9 Virtual Server 5-9
Figure 5-10 Port Mapping 5-10
Figure 5-11 DMZ Settings 5-11

Figures
xi
Figure 5-12 Firewall Setting 5-11
Figure 5-13 Firewall Options 5-12
Figure 5-14 Client Filtering Settings 5-13
Figure 5-15 MAC Control 5-14
Figure 5-16 Routing Table 5-15
Figure 5-17 UPnP Setting 5-16
Figure 6-1 WiMAX Profile Configuration 6-1
Figure 6-2 WiMAX Profile Authentication - EAP-TTLS 6-2
Figure 6-3 WiMAX Profile Authentication - EAP-TLS 6-2
Figure 6-4 Subscriber Station Information 6-3
Figure 6-5 WiMAX Antenna Setting 6-4
Figure 7-1 SIP Account Settings 7-2
Figure 7-2 SIP Setting 7-3
Figure 7-3 Dial Plan Settings 7-5
Figure 7-4 Call Features 7-7
Figure 7-5 Codecs 7-8
Figure 7-6 Call Block Setting 7-9
Figure 7-7 Phone Setting 7-10
Figure 8-1. Wireless Settings 8-2
Figure 8-2. Wireless Security 8-5
Figure 8-3. WEP Shared Key Security 8-6
Figure 8-4. WPA/WPA2 Security 8-7
Figure 8-5. WPA/WPA2 PSK Security 8-8
Figure 8-6. MAC Authentication 8-9
Figure C-1 RJ-45 Connector C-1
Figure C-2 Straight-Through Wiring C-2
Figure C-3 Crossover Wiring C-2
Figure C-4 RJ-11 Port Pinout C-3

Figures
xii

1-1
Chapter 1: Introduction
The RG230 WiMAX Residential Gateway is a WiMAX subscriber station designed to
provide Internet access for a home or small office. The unit provides a gateway
function between a WiMAX service provider and a local Ethernet LAN. The device
enables a service provider to deliver last mile broadband wireless access as an
alternative to wired DSL or cable modems.
The RG230 is a plug-and-play indoor unit (IDU). There are two available models for
each of the 2.3, 2.5, and 3.5 GHz WiMAX frequency bands. Which model you use
will depend on the frequency band of your service provider’s WiMAX service. The
RG230 models also include built-in WiMAX antennas, either standard
“omnidirectional” type or high-performance “switched-beam” type.
The RG230 includes four RJ-45 Ethernet switch ports for LAN connections and two
RJ-11 Voice over IP (VoIP) phone ports. An 802.11b/g Wi-Fi module is available for
the 3.5 GHz models that provides a local Wi-Fi access point service.
The following table lists the available RG230 models.
The RG230 offers a user-friendly web-based management interface for the
configuration of all the unit’s features. Any PC directly attached to the unit can
access the management interface using a web browser, such as Internet Explorer
(version 6.0 or above) or Firefox (version 1.5 or above).
The initial configuration steps can be made through the web browser interface using
the Setup Wizard. It is recommended to make the initial changes by connecting a
PC directly to one of the RG230’s LAN ports.
Table 1-1 RG230 Models
Frequency Band Model Number Description
2.3 GHz RG230-2.3-4D2V-Omni Including omnidirectional antennas.
RG230-2.3-4D2V-Switch Including switched-beam antennas.
2.5 GHz RG230-2.5-4D2V-Omni Including omnidirectional antennas.
RG230-2.5-4D2V-Switch Including switched-beam antennas.
3.5 GHz RG230-3.5-4D2V1W-Omni Including omnidirectional antennas and Wi-Fi.
RG230-3.5-4D2V1W-Switch Including switched-beam antennas and Wi-Fi.

Introduction
1-2
1
RG230 Hardware Description
The front of the RG230 provides an array of system status indicators. The back
includes four LAN ports for 10/100 Mbps Ethernet connections, two RJ-11 Voice
over IP (VoIP) phone ports, and a DC power jack.
The following figures show the external components of the RG230:
Figure 1-1 Front of the RG230
Figure 1-2 Base of the RG230
Power Status Indicator
Wi-Fi Indicator
WiMAX Signal Indicators
(7 LEDs)
Scan Button
WiMAX External Antenna
Connectors
Reset Button

RG230 Hardware Description
1-3
1
Figure 1-3 Back of the RG230
Scan Button
Press the button for less than 3 seconds to start a partial scan to find the best of
known frequency channels. Press and hold down the button for longer than
3 seconds to perform a full frequency scan of all channels.
Reset Button
This button is used to reset the RG230 or restore the factory default configuration. If
you press the button for less than 1 second, the unit will perform a hardware reset. If
you press and hold down the button for 5 seconds or more, any configuration
changes you may have made are removed, and the factory default configuration is
restored to the unit.
WiMAX Antennas
Two internal antennas are built into the RG230 for WiMAX communications. Either
“omnidirectional” or “switched-beam” antennas, depending on the model. The
omnidirectional antennas transmit and receive signals in all directions equally. The
switched-beam antennas detect the direction of the service provider’s base station
and only transmit and receive signals in that direction. Models with the built-in
switched-beam antennas provide better WiMAX performance than those with the
omnidirectional antennas.
WiMAX External Antenna Connectors
Two connectors are available on the top of the unit for attaching optional external
antennas. Depending on a user’s location, the use of an external antenna may
provide a better connection to a WiMAX base station. External antennas also offer
various possible mounting locations.
PHONE 1 PHONE 2LAN 1 LAN 2 LAN 3 LAN 4
DC IN
2A
10-19V
RJ-45 LAN Ports
(include Link/Activity LEDs)
VoIP Phone Ports Power Socket

Introduction
1-4
1
Power Status Indicator LED
The RG230 includes a Power LED indicator that simplifies installation and WiMAX
network troubleshooting. The LED, which is located on the front panel, is described
in the following table.
Figure 1-4 RG230 LED Indicators
Table 1-2 Power Status LED
Status Description
On Green The unit has a network association with a WiMAX base station.
Flashing Green Indicates one of the following conditions:
• When flashing with three of the WiMAX signal LEDs turned on,
indicates authentication has failed.
• When flashing with one of the WiMAX signal LEDs turned on, indicates
authentication has timed out.
On Orange Indicates one of the following conditions:
• After power on, indicates the unit is running its self test.
• The unit is in scan mode or selecting the base station with the
strongest signal.
• Indicates the network entry process has restarted.
Flashing Orange The unit is being reset to factory defaults.
On Red A system failure has occured.
Off No power is being supplied to the unit.
Power
WiFi
Power Status LED
Wi-Fi Status LED
WiMAX Signal LEDs
