EdilKamin Iris Plus User manual
Iris Plus & Little Models
EdilKamin Pellet Fire Installation & Operation Manual
Important information .................................... 2
Operation and fuel ......................................... 3
Technical specifications ................................. 4
Assembly & installation .................................. 5
Pellet fire vent systems .................................. 6
Dimensions ................................................... 8
Installation clearances.................................... 9
Control panels & weekly timer................. 10-13
Troubleshooting......................................14-15
Cleaning and maintenance .......................... 15
FEBRUARY 2011
page 2
• THEAPPLIANCEANDFLUE-SYSTEMSHALLBE
INSTALLEDINACCORDANCEWITHAS/NZS2918
ANDTHEAPPROPRIATEREQUIREMENTSOFTHE
RELEVANTBUILDINGCODEORCODES.
• THEPELLETFIREMUSTNOTBELOCATED
IMMEDIATELYBELOWANELECTRICALSOCKET-
OUTLET.
• CAUTION:THEPELLETFIREHASMOVINGPARTS.
DISCONNECTPOWERBEFORESERVICING.
WARNING!Important Information
The pellet fire is designed to heat the room it is installed in by
radiation and by air movement from the front grilles. The heat is
generated by automatic pellet combustion in the firebox.
The only risks which may derive from use of the pellet fire are
linked with non-compliance with the installation instructions,
direct contact with live electrical parts (inside) or with the fire or
hot parts (glass, pipes and hot air outlet), and the introduction
of foreign substances. Only use wood pellets as fuel.
If components fail, the pellet fire is fitted with safety devices
which turn it off. This must be allowed to happen without
interference.
For correct operation, the pellet fire must be installed in
compliance with the instructions on pages 5 & 6 and the door
must not be opened while running: combustion is managed
automatically so no manual operations are needed.
Please take particular note of the following:
using a vacuum cleaner.
cleaner and cloth. Do not clean door glass when hot.
temperatures. Install a child guard if children present.
in the immediate vicinity of the pellet fire.
embers.
pellet fire is installed or air inlets in the pellet fire itself.
near electrical parts.
regards fire safety, and provided with all the facilities
operation.
device from the mains power supply.
Safety Information
Iris Plus Little
Please record and retain the following information for future reference
...............................................................................................................................................................................
Installation address ...........................................................................................................................................................................
Phone Hm............................................... Mobile ......................................... Work ........................................................................
Model .................................................................................................... ..........................................................
Retailer purchased from ...................................................................................................................................................................
Retailer Address ............................................................................................. Date Purchased .......................................................
Comments ......................................................................................................................................................................................
......................................................................................................................................................................................
Purchase Information
page 3
The Iris Plus and Little are pellet burning fires which manage
pellet combustion electronically.
The fuel (pellets) is taken from the storage hopper (A) and
by a gearmotor (C).
The pellets are ignited by hot air produced by a heating
element (E) which is drawn into the combustion chamber by a
centrifugal fan (M).
The combustion smoke produced is drawn out of the firebox
by the same centrifugal fan (M), and expelled from the outlet
(F) at the bottom rear of the pellet fire.
Air is blown into the hollow space at the back of the firebox by
a fan (G), where it is heated before coming out into the room
from the front grille (I).
The amount of fuel and the smoke extraction/combustion air
to achieve highly efficient fuel consumption.
All operating stages are managed and displayed using the
display-control panel (L) and two knobs on the front panel
under the door (Little Model only) which allow all operating
stages to be managed and displayed.
The same functions may also be managed by remote control
(optional).
The pellet hopper is at the top of the pellet fire. The hopper
is filled through a lid found at the back of the top The internal
structure of the pellet fire is completely made of cast iron.
The external covering of the Iris Plus is ceramic, and the
external covering of the Little is metal.
Operation of your pellet fire (Iris Plus & Little models)
The Iris Plus and Little pellet fires are designed and
programmed to burn wood pellets.
Pellets are small cylinders about 6mm in diameter made from
sawdust or shredded waste wood, pressed at high pressure
without the addition of adhesives or other foreign material.
To prevent damage to the pellet fires, do not burn any other
substances. The use of other materials (including wood),
which can be detected by laboratory analysis, invalidates the
guarantee.
EdilKamin has designed, tested and programmed its
pellet fires to perform best with pellets with the following
characteristics:
The use of unsuitable pellets can lead to decreased
performance, operating anomalies, stoppages due to
clogging, dirty glass, unburnt fuel, etc.
The pellets can be easily analysed by visual examination.
Good quality: smooth, even short lengths, not very dusty.
Poor quality: with horizontal and vertical splits, very dusty,
variable lengths and mixed with foreign matter.
The Fuel
Iris Plus Little
L
a
I
e
D
F
N
M
g
C
CDe
F
N
M
g
I
L
a
page 4
2A FUSE
AUX
2A FUSE
RS232
RS485
P/TEMP
FLOW
ROOM
SCREW
FEEDER MOTOR
THERMOCOUPLE
SMOKE
MOTOR
SMOKE SPEED
SAFETY
THERMOSTAT
Technical Specifications (Iris Plus & Little models)
IRISPLUS&LITTLEMODELS(SAFETYDEVICES)
Thermocouple: Placed at the smoke outlet to detect the temperature,
turns the pellet fire on and off and controls its operation based on
defined parameters.
Air flow sensor: Installed at the intake duct, it trips when the
smoke circuit.
Safety thermostat: Trips when the temperature inside the pellet fire is
too high. It stops pellet loading, causing the pellet fire to shut down.
IRISPLUS&LITTLEMODELS(ELECTRICALSPECIFICATIONS)
Power supply
0/1 switch yes
Average power consumption 150 W
Power consumption during ignition 400 W
infrared
Electronic circuit board protection 5 x 20 2 A 250 VAC fuse
IRISPLUS(TECHNICAL&HEATINGSPECIFICATIONS)
Hopper capacity 15kg
Efficiency
Heat Output 3.4/8kW
Fuel consumption 0.9/2.0 kg/h
Heatable room dimensions 150m2
Weight 140kg
Smoke duct diameter (male) 80mm
Air intake duct diameter (male) 40mm
LITTLE(TECHNICAL&HEATINGSPECIFICATIONS)
Hopper capacity 15kg
Efficiency
Heat Output 3.4/5kW
10/30 hours
Fuel consumption 0.5/1.45 kg/h
Heatable room dimensions (min/max) 120m2
Weight 136kg
Smoke duct diameter (male) 80mm
Air intake duct diameter (male) 40mm
The heatable room dimensions are calculated on the basis
important to consider the location of the pellet fire in the room
heated.
Please note: External electrical devices may cause interference. Work
related to live parts/components, servicing and/or inspections must be
carried out by qualified staff.
Optional extras
Remote Control (cod. N. 254160)
It is possible to buy a remote control to turn the pellet fire
page 5
Positioning the pellet fire
1 If possible position the fire in a room that is centrally
located in the home and direct the fire so that it blows hot
air into the living area first then forces the air out into the
rest of the house.
Avoid positioning the fire close to your TV or sitting area
so as not to be distracted by any fan noise. Unlike a
conventional wood fire you do not need to be close to
a pellet fire; they act more like central heating systems
pushing warm air throughout the house.
2 Check clearances to combustible materials, refer to chart
and drawings on page 9.
3 Ensure a power outlet is within 1.5 metres.
4 Check the vent pipe will clear structural beams, trusses or
studs.
5 Check that curtains cannot come in contact with the pellet
fire.
combustibles.
If the vent pipe is to be installed through the ceiling, use
the Metro Ceiling Vent Kit. Insert the condensation tee into
the 80mm outlet at the rear of the pellet fire. Assemble
and fit the vent system to the pellet fire as per instructions
supplied with the vent kit.
If the vent is to exit through the rear wall use the Metro
Through Wall Vent Kit, the condensation tee is located
outside.
panels (Iris Plus only) position the pellet fire in the desired
9 Once you are satisfied you have the pellet fire in its final
8mm holes provided at the centre of the pellet fire base.
Then proceed as follows in the order shown (Iris Plus only):
the 2 rear panel screws;
enough to insert the two side tiles (11) into the aluminium
bars (12-13); Take care not to damage the data cable on
the rear display;
tiles (11) into the aluminium bars (10-13);
previously removed screws;
If combustion air is drawn from outside the home, ensure that
a suitable grill and wind protector is fitted as wind gusts will
upset the combustion sensors, the Metro Direct Vent Kits are
suitable for this.
Check for compatibility with other devices
extractor fans or any other devices that could reduce the
pressure in the room.
Assembly and Installation of your Pellet Fire (Iris Plus & Little models)
• ALLVENTPIPEJOINTSMUSTBERIVETEDAND
SEALEDWITHHIGHTEMPERATURESILICONE.
DONOTUSEFIRECEMENT!
WARNING!Important Information
• MIXINGOFAPPLIANCEORFLUESYSTEM
COMPONENTSFROMDIFFERENTSOURCES
ORMODIFYINGTHEDIMENSIONAL
SPECIFICATIONOFCOMPONENTSMAY
RESULTINHAZARDOUSCONDITIONS.
WHERESUCHACTIONISCONSIDERED,THE
MANUFACTURERSHOULDBECONSULTEDIN
THEFIRSTINSTANCE.
CAUTION!Important Information
page 6
Pellet Fire Vent System (Iris Plus & Little models)
Fire Safety Distances and Location
The Pellet Fire must be level for it to work correctly. Check the
in compliance with the following safety conditions:
- minimum distance from combustible materials around the
sides and back of the Pellet Fire (see specifications and
clearances chart (page 9)
from the front of the Pellet Fire
heat-insulating material must be placed between the two,
extending out by at least 100mm at the sides and 200mm
at the front.
If the vent pipe is to exit through a wall made of wood or
a double lined through wall vent system, such as the Metro
through wall vent kit.
Air Intake
The room where the Pellet Fire is installed must have an air
intake of at least 80 cm² to ensure a supply of fresh air to
replace the air consumed by combustion.
Alternatively, the Pellet Fire can be supplied with air drawn
directly from the outside through a pipe extension, we use
100mm, which must have a free section of at least 12 cm²,
must be protected by a mesh. The pipe must not exceed 1
metre in length and should not have any sharp bends.
It must be fitted with a wind guard, as wind gusts will upset
Assembly and Installation of your Pellet Fire (Iris Plus & Little models)
Venting System
Your pellet fire works under negative pressure (vacuum).
The exhaust fan of your pellet fire pulls air from the air intake,
through the pellet fire and pushes it out the venting. Air
passing through the burn pot is used to burn the pellets.
Proper vent pipe sizing is very important to ensure the pellet
fire operates properly. A proper size approved vent should
be used to provide the least resistance for movement of the
combustion air.
Your pellet fire is certified for 100mm exhaust venting. The
vent pipes on the exhaust side of the exhaust fan are under
completely sealed to prevent any leakage of exhaust fumes
and smoke into the house. If you smell smoke, the venting
has not been properly sealed. Use only high temperature
RTV silicone for sealing. Aluminum tape is not considered an
The venting of this pellet fire is not allowed to pass unshielded
spaces. If the venting must go through a wall or combustible
partition, the installation must conform to the Installation Code
2918:2001. For more detailed venting information, please refer
Exhaust Vent Termination Requirements
The exhaust vent must terminate into an open space. Under
no circumstances is the vent allowed to terminate into closed
or semi-closed spaces. Venting into a garage, under a sun
deck, porch or any other space where the concentration of
fumes may occur is prohibited.
• DONOTUSEMAKESHIFTMATERIALSORMAKECOMPROMISESINTHEINSTALLATION.ITISAFIREHAZARD.
• DONOTINSTALLAFLUEDAMPERINTHEEXHAUSTVENTINGSYSTEMOFTHISPELLETFIRE.
• DONOTCONNECTTHISPELLETFIRETOACHIMNEYFLUESERVINGANOTHERAPPLIANCE.
WARNING!Important Information
page 7
A: Stainless steel vent
B: Air intake (minimum internal section 50mm diameter)
Although EdilKamin pellet fires have been tested and
approved for 100mm side wall and 200mm rear wall
clearance. We recommend sufficient space be provided
(minimum 200mm) on each side of the pellet fire to service the
unit. If this is not possible, provision must be made available to
remove the unit for servicing.
Pellet Fire Vent System (Iris Plus & Little models)
IRIS PLUS - FIGURE 2
LITTLE - FIGURE 2
IRIS PLUS - FIGURE 1
LITTLE - FIGURE 1
600mm
minimum
a
B
a
a
B
a
600mm
minimum
600mm
minimum
600mm
minimum
PAGE8
Pellet Fire Dimensions (Iris Plus & Little models)
LITTLE (SIDE PROFILE)
LITTLEIRIS PLUS
LITTLE (REAR PROFILE)
IRIS PLUS (SIDE PROFILE) IRIS PLUS (REAR PROFILE)
600mm 480mm
600mm
950mm
320mm
500mm
530mm
215mm106mm
480mm
315mm
160mm
134mm 106
940mm
490mm
3
2
7
6
23
7
6
PAGE9
EdilKamin Installation Clearances & Specifications
Installation Clearances
Minimum clearances shown are in mm, and all figures for
clearances are to combustible materials. All EdilKamin pellet
Rear Clearance Options
The 100mm rear clearance measurement “4” is based on the
EdilKamin pellet fire having the vent system penetrating the
rear wall behind the pellet fire and is the minimum clearances
surface of the vent system to a combustible wall. A 250mm rear clearance
is therefore recommended. Also consider the thickness of the scotia as this
will determine how close the vent can be to the wall.
Optional Direct Vent Combustion Air Supply
The EdilKamin pellet fires have a direct vent option which
when installed draws the combustion air from outside the
home, further improving the efficiency of the pellet fire. This is
recommended as the Iris Plus and Little pellet fires can use up
to 24 cubic metres of room air every hour.
There are three methods of supplying the pellet fire with
combustion air. They are as follows;
cavity
If using a thru wall exhaust vent in combination with a DV
air intake kit, be sure to offset the DV air hole approximately
depending on type of kit used.
Warranty
Your EdilKamin Pellet fire is covered by a full 12 month
warranty, and a three year firebox warranty.
This warranty is
in the operation manual.
100/250mm*
200mm
200mm
530mm
1
200mm
200mm
490mm
1
5 5
800mm 8
44
200mm
5
9
9
160mm
EdilKamin Iris Plus 600 950 530 140kg 8kW Yes 0.61
EdilKamin Little 480 940 136kg 5kW Yes 0.38
Model Clearances 1 2 3 4 5 6 7 8 9
EdilKamin Iris Plus 200 106 100/250* 200 320 800 160
EdilKamin Little 200 106 100/250* 200 315 680 160
830/980mm
100/250mm*
680mm 8
IRIS PLUS (REAR PROFILE)
600mm
320mm
215mm
106mm
3
76
LITTLE (REAR PROFILE)
480mm
315mm
160mm134mm 106
3 2
76
IRIS PLUS LITTLE IRIS PLUS/LITTLE
950mm
2
PAGE10
The Iris Plus Control Panel
Right adjuster wheel
panel. The display shows the power or temperature set.
Left adjuster wheel
lower than the minimum necessary to ensure cooling of the
internal pellet fire parts.
Panel 0/1 button
Panel MENU key
For switching the fire from manual to automatic operation and
vice versa, and entering time programming mode (prog).
“+” and “-” panel keys
For moving around in time programming mode (prog).
Display unit messages
operating stage
commands.
When the pellet fire is on standby, this flashes to show
the mode it will restart in and when
Operation - Before ignition
The first few times the pellet fire is ignited there may be a slight
smell of paint, which disappears rapidly.
Auger loading
If the pellet hopper empties completely, press and release the
+ and - keys together to fill the auger. IR will be displayed.
Press O/I to end.
This must be done before igniting the pellet fire again if it has
shut down due to running out of pellets.
It is normal for a few pellets to be left in the hopper, which the
auger is not able to pick up.
Ignition
Automatic ignition
Hold the 0/1 key down for two seconds with the pellet fire on
standby to start the ignition procedure. Ac appears on the
display for a few minutes (the ignition procedure does not
actually take a preset time: it is automatically shortened if the
appears after about five minutes. It is normal for a little smoke
Manual ignition
At temperatures of less than 3°C (too low for the heating element
to glow) or if the heating element is temporarily out of order, a
firelighter may be used for ignition.
Operating modes
between modes)
right wheel) and the ventilation (with the left wheel).
Automatic: set the temperature which the room is to reach;
it (P3) or maintain it (P1).
If you set a lower temperature than current room temperature,
the pellet fire operates at P1 and consumes the corresponding
depend on the type of pellet used, the normal variability associated with solid
fuels and the periodic automatic combustion chamber cleaning (which does
Switching off
Hold the 0/1 key down for two seconds while the pellet fire is
operating. The shutdown procedure starts and the word “Off”
appears on the display (for a total of 10 minutes).
During shutdown:
• DONOTUSEFLAMMABLELIQUIDSOR
AEROSOLSTOSTARTORREKINDLETHEFIRE
• DONOTUSEFLAMMABLELIQUIDSOR
AEROSOLSINTHEVICINITYOFTHIS
APPLIANCEWHENITISOPERATING
• AVOIDCONTACTWITHHOTVENTPIPE
WARNING!Important Information
PAGE11
Weekly Timer Program built into the Iris Plus Control Panel
Weekly time programmer built into panel
Using the weekly time programmer built into the central panel
it is possible to set 3 ignition programmes:
It is possible to enable one or more of the three settings on
When on standby, the display alternates between showing the
ignition mode (P1, P2, P3 or a temperature) and the clock.
Refer to page 10 for each of the buttons to press.
Setting the clock
appears then release, tS appears.
3. Press the “-” key until SEt appears.
changed with the “-” key, which decreases the time by
one minute each time it is pressed, and with the “+” key,
which increases it by 15 minutes each time it is pressed.
with the “-” and “+” keys.
Enabling programmes
appears then release, tS appears.
3. Press the “+” key until ProF appears.
If so you can exit thie section by pressing O/1 and proceed to setting
program section.
5. Press the “+ “ or “–” key until PrOn appears.
8. The pellet fire is now in PrOn mode and will accept timed
on and off commands.
Setting a program (e.g. Pr01)
appears then release, tS appears.
3. Press the “+” key twice until Pr 1 appears.
“on time”. It may be changed with the “+” and “–” keys in
ten-minute intervals.
with the off time. This may be changed with the “+” and
“-” keys in ten-minute intervals.
program 1 is not enabled on day 1, Monday). This may be
changed into Ond1 (which means program 1 is enabled
on day 1, Monday) using the “+” and “-” keys.
the desired day or days are selected then toggle on or off
fire to turn on at 4pm and off at 6pm Monday to Friday
with Program 1 then turning on at 8am and off at 10am
Saturday and Sunday with program 2.
On and off times may be set for Pr 2 and Pr 3 in a similar way,
and it can be decided which days they are enabled on.
speed up for 10 seconds to blow excess ash from the burn pot.
PAGE12
On/Off Key on panel
To switch the fire on and off, and to exit from the setting menu.
“Menu” Key on the panel
(use +/- to vary the selected mode).
Messages displayed on the screen
operating stage
wait 20-30 seconds before entering
other commands.
When the pellet fire is on standby, it displays the mode
of operation with which it will restart and the time
(flashing).
Operation –
Before ignition
The first few times the pellet fire is ignited there may be a slight
smell of paint, which disappears rapidly.
temperature).
Auger loading
Any time the pellet hopper is fully empty, press the + key
followed by the Menu key for a few seconds to fill the auger.
IR will be displayed.
This operation must be carried out before ignition if the pellet
fire ceased operating because it had run out of pellets.
It is normal for a few pellets, which the auger is not able to pick
up, to remain in the hopper.
The auger filling phase will deactivate automatically after
approximately 4 seconds, when the pellets begin to fall in
the burn pot. The refilling phase can be stopped manually by
y.
Ignition
Automatic ignition
/OFF key down for two seconds with the pellet
fire on standby to start the ignition procedure. Ac will appear
on the display for a few minutes. The ignition procedure does
not have a set duration: it is automatically shortened if the
electronics detect that certain tests have been passed. The
Manual ignition
At temperatures below 3°C (too low for the heating element
to glow) or if the heating element is temporarily out of order, a
firelighter may be used for ignition.
current time and either the current POWER setting or the
current preset room temperature.
“Power” [The heat output P1 P2 P3]
“Air” [The speed of the room circulation fan 1 - 9]
“Temp” [The temperature the inbuilt thermometer is set to in
degrees C 10 - 30]
desired setting is displayed.
on the type of pellet used, the normal variability associated with solid fuels
replace the essential cold vacuum cleaning by the user before ignition).
Switching off
shutdown procedure; the message “of” is then displayed (for a
total of 10 minutes).
During shutdown:
The Little Control Panel
• DONOTUSEFLAMMABLELIQUIDSOR
AEROSOLSTOSTARTORREKINDLETHEFIRE
• DONOTUSEFLAMMABLELIQUIDSOR
AEROSOLSINTHEVICINITYOFTHIS
APPLIANCEWHENITISOPERATING
WARNING!Important Information
PAGE13
Weekly Timer Program built into the Little Control Panel
Weekly time programmer built into panel
Using the weekly time programmer built into the central panel
it is possible to set 3 ignition programmes:
One or more of the three programs can be enabled for
When on standby the display alternates between displaying
the ignition mode (P1, P2 or P3 or a temperature) and the
current time.
Refer to page 12 for each of the buttons to be pressed.
Setting the clock
appears then release, tS appears.
2. Press (-) and “Prog” will appear.
3. Press “Menu” and “ProF” will appear. Press the (-) key
and “SEt” will be displayed.
4. Confirm with the “Menu” key, which will display
and (+) keys.
5. Once the hour has been set, confirm with “Menu” and the
keys.
6. Confirm with “Menu” and “Prog” will appear.
Enabling programmes
appears then release, tS appears.
2. Press (-) and “Prog” will appear.
3. Press “Menu” and “ProF” will appear.
If so you can exit thie section by pressing O/1 and proceed to setting
program section.
4. Confirm by pressing the “Menu” key, pass now to “on”
with the (-) or (+) keys.
5. Confirm with the “Menu” key and “Prog” will appear.
6. The pellet fire is now in “PrOn” mode and will accept
timed on and off commands.
Setting a program (e.g. Pr01)
appears then release, tS appears.
2. Press (-) and “Prog” will appear.
3. Press “Menu” and “ProF” or “PrOn” will appear. Press (+)
until “Pr 1” appears (after PrOn has been set previously).
4. Confirm with the “Menu” key and OnP1 will appear and
then the desired set hour for programme 1 ignition.
5. The time can be changed using the On/off (-) or (+) keys.
for day1, continue to go through the days, disabling/
8. Press (+) to enable it, after which Ond1 appears,
indicating that program 1 is enabled for Monday.
10. Press the “On/off” to exit.
11. Pr02 and Pr03 on and off times and the days on which
they are enabled can be set in a similar way.
12. A small green bar will light-up in the bottom right corner of
the control panel when a program is enabled for that day.
speed up for 10 seconds to blow excess ash from the burn pot.
PAGE14
If the pellet fire shuts down, the reason is shown on the
display.
H1 no depression: problem connected with air circulation;
H2 smoke expulsion motor failure;
SF
AF (H4) ignition failed;
H5 power failure stoppage;
H6 thermocouple failure or disconnection;
H7 excessive smoke temperature.
(Iris Plus) key on the panel is pressed. Do not restart the pellet
fire until the problem has been looked into and the cause
removed.
To start the pellet fire up again after a shutdown, let the
shutdown procedure end (10 minutes marked by a beep) then
problems. Advice for each of the cases mentioned above is
shown on the next page.
(H1) No vacuum
not close tightly (e.g. bad seal), there is an air intake or smoke
extraction problem or the combustion chamber is clogged up.
Check:
- door is closed
- combustion air extraction duct (clean it, taking care not to
clean a PC keyboard)
- pellet fire position: must not be against the wall-
connected with the type of pellets used)
- smoke duct (clean)- installation (if it does not comply with
regulations and has more than 2-3 bends then the smoke
outlet is not acceptable)
Cold test the sensor if malfunction is suspected. If the value
displayed does not vary when the conditions are changed, for
example the door is opened, then the sensor is faulty.
The low pressure alarm may also occur during ignition as the
cycle starts.
(H2) No expulsion
(trips if the smoke extraction revolution sensor detects a fault)
- Check that the smoke extractor is working properly.
- Check revolution sensor connection.
- Check that the smoke duct is clean.
Troubleshooting (Iris Plus & Little models)
Display-control panel off no mains voltage
Remote control (optional)
not working
excessive distance from pellet fire
Outlet air not hot too much soot in heat exchanger
No flame appears (remember
that it only appears 5 minutes
after pressing the 0/1 key)
the auger has not been filled
Ignition failure build up of unburnt material in
combustion chamber
The ignition/off does not
start at the time required
incorrect setting:
page 10 (Iris Plus) and page 12 (Little)
Possible Causes of Shutdown (Iris Plus & Little models)
•
THECHIMNEYANDSMOKEDUCTSCONNECTED
TOTHEPELLETFIREMUSTBESWEPTATLEAST
ONCEAYEAR.
• LACKOFREGULARCONTROLSANDCLEANING
INCREASESTHERISKOFFIREINTHECHIMNEY,
SHOULDAFIREOCCURPROCEEDASFOLLOWS:
• YOUMUSTISOLATETHEPOWERSUPPLYBEFORE
EXTINGUISHINGTHECHIMNEYFIRE.
• EMPTYTHEPELLETHOPPER.
• CONSULTSPECIALISEDPERSONNELBEFORE
RESTARTINGTHEMACHINEAFTERTHEINCIDENT.
WARNING!Important Information
PAGE15
SF (H3) No fire
(Trips when the thermocouple detects that the smoke temperature is
- a lack of pellets
- the maximum temperature thermostat has tripped
(this is unusual as it would indicate an excessive smoke temperature)
AF (H4) No start
maximum of 15 minutes).
Distinguish between the following two cases:
No flame has appeared
Check:
- position and cleaning of the combustion chamber
- that the combustion chamber receives combustion air
- that the heating element is working- room temperature
Try lighting with firelighter
A flame has appeared but AR is displayed after AF
Check:
- that the thermocouple is working correctly
- that the start temperature is set within the parameters
(H5) Power Failure stoppage
H5 error power restored after power failure, both fans will run
is fully cooled, the fans will stop after approx 15 minutes.
Press O/l twice to restart. Check electrical connection and
voltage drops.
(H6) Thermocouple Fault
(Trips if the thermocouple is faulty or disconnected)
Check connection between the thermocouple and the circuit
board. Check operation during cold testing.
(H7) Over temp
(Shut down due to excessive smoke temperature)
Excessive smoke temperature may be caused by: type
of pellets, smoke extraction fault, blocked duct, incorrect
installation or gearmotor “drift”.
Troubleshooting (Iris Plus & Little models)
After each bag of fuel
Clean with a vacuum cleaner when the pellet fire is cold. To
protect your vacuum cleaner, we recommend always using
a vacuum pot connected to your vacuum cleaner, which are
available from your Metro Dealer. The whole process takes
only a few minutes a day.
- Vacuum-clean the door, vacuum-clean the hearth and
vacuum-clean the space around the combustion chamber
where the ash falls (there is no extractable ash pan).
- Remove the combustion chamber or clean it with a
scraper, and unblock any blocked holes on all sides.
- Vacuum-clean the combustion chamber compartment,
clean touching edges and replace the combustion
chamber.
- If necessary clean the glass with glass cleaner (when cold).
After a few months use dry air (PC keyboard type) to clean the
Every season (by a qualified technician)
-
General internal and external cleaning.
- Carefully clean the heat exchange pipes.
- Carefully clean and de-scale combustion chamber and
corresponding compartment.
- Clean fan and mechanically inspect play and fastenings.
- Clean the vent system.
and check thermocouple.
- Clean, inspect and de-scale ignition heating element
compartment and change the heating element itself if
necessary.
- Clean/check display-control panel.
- Visually inspect electric cables, connections and power cord.
- Clean pellet hopper and check auger-gearmotor assembly
play.
- Test auger loading, ignition, operation for ten
minutes and
shutdown.
• NEVERLOOSENTHEALLENSCREWSINSIDETHE
FIREBOX:THELOADERWILLFALL.
• NEVERVACUUM-CLEANHOTASH,SINCEITMAY
DAMAGETHEVACUUMCLEANER.
• ONLYEMPTYTHEHOPPERANDVACUUM-CLEAN
THEBOTTOMIFTHEPELLETFIREISNOTINUSE,
ANDINANYCASEEVERY15DAYS.
• REGULARMAINTENANCEISESSENTIALFOR
GOODPELLETFIREOPERATION.
• BEFORECARRYINGOUTANYMAINTENANCE,
DISCONNECTTHEDEVICEFROMTHEMAINS
POWERSUPPLY.
• FAILURETOCARRYOUTMAINTENANCELEADS
TOFORFEITUREOFTHEGUARANTEE.
CAUTION!Important Information
Cleaning and Maintenance of your pellet fire (Iris Plus & Little models)
page 16
Warranty for your pellet fire (Iris Plus & Little models)
Warranty
Your EdilKamin Pellet fire is covered by a full twelve month
warranty, and a three year firebox warranty.
Standard EdilKamin Warranty
(NZ Consumer laws apply to this warranty)
Pioneer Manufacturing Limited warrants the cast iron firebox
against defective materials and workmanship which would
render it unfit for normal domestic use within a period of three
years after date of original purchase.
All other parts including electrical components, door, door seal
and glass, are warranted for a period of one year from date of
original purchase for domestic use against defective materials
and workmanship.
Warranty Conditions:
• The heater must be installed, operated and maintained
strictly in accordance with the building code and the
manufacturer’s installation and operation manuals.
• This warranty covers replacement or repair at the
manufacturer’s discretion but excludes freight, travel and/
or any other associated costs.
• Operation of this appliance in violation of the warnings
in the operation and installation manual will void this
warranty.
• Failure to do the necessary inspection & maintenance
of this appliance in accordance to the instructions in the
operation manual will void this warranty. It is critical that
the fire not be operated with faulty or missing door seals,
cracked or broken door glass. These require regular
inspection/maintenance and if not maintained will void the
firebox warranty
• The manufacturer or their agents are not liable for any loss
or expense direct or indirect arising from the failure of any
part or operation of the appliance.
• A claim under this warranty should be directed to the
retailer who supplied the EdilKamin Pellet fire, or if this is
not possible write direct to the manufacturer stating details
of fault, serial number of your EdilKamin Pellet fire, proof of
purchase and name of retailer.
Warranty Exclusions:
This Manufacturers Warranty DOES NOT cover:
• Service calls which are not related to any defect in the
Product (I.e operational, installation or fuel issues). The
cost of a service call will be charged if the problem is not
found to be a product fault.
• Defects caused by factors other than normal domestic use
or use in accordance with the product’s operation manual.
• Defects to the Product caused by accident, neglect,
misuse or act of God. [eg: broken ceramics, power surges
etc]
• The cost of repairs carried out by non-authorised repairers
or the cost of correcting such unauthorised repairs.
• Normal recommended maintenance as set out in the
Product’s Owners Operation Manual.
Service under this manufacturer’s warranty must be provided
by a repairer authorised by Pioneer Manufacturing Limited.
Such service shall be provided during normal business hours.
Pioneer Manufacturing Limited reserves the right change
details without notice
Standards and Compliance Declaration:
The Iris Plus and Little Pellet Fires have been tested and
comply with: AS/NZS 2918:2001, AS/NZS 4886:2007, AS/
NZS 5078:2007, EN60355-1:2002 and EMC EN55014-1:2000
The Iris Plus and Little Pellet Fires have been manufactured by
EdilKamin, a UNI EN ISO 9001 certied company.
GADGET6872 02/11
Mamaku Street, Inglewood 4330, New Zealand
PO Box 11, Inglewood 4347, New Zealand
Ph (06) 756 6520 • Fax (06) 756 6540
info@metrores.co.nz • www.metrores.co.nz
Other manuals for Iris Plus
1
This manual suits for next models
1
Table of contents
Other EdilKamin Stove manuals
EdilKamin
EdilKamin IDROFLEXA Quick start guide
EdilKamin
EdilKamin BLADE2 H 18 UP Quick start guide
EdilKamin
EdilKamin CHARME-KARMA-FEELING Quick start guide
EdilKamin
EdilKamin KIRA H 18 Quick start guide
EdilKamin
EdilKamin NANCY Quick start guide
EdilKamin
EdilKamin ITALIANA CAMINI CLASSICA Quick start guide
EdilKamin
EdilKamin FANTASY Quick start guide
EdilKamin
EdilKamin DEMY Quick start guide
EdilKamin
EdilKamin Blade2 12 Up Quick start guide
EdilKamin
EdilKamin Melody MIMI Quick start guide
EdilKamin
EdilKamin IDROSALLY Quick start guide
EdilKamin
EdilKamin DAISY Quick start guide
EdilKamin
EdilKamin LILLE 5 Quick start guide
EdilKamin
EdilKamin MYA Quick start guide
EdilKamin
EdilKamin Vyda2 Air Tight Installation and operating instructions
EdilKamin
EdilKamin FANTASY Quick start guide
EdilKamin
EdilKamin ITALIANA CAMINI NELLY Quick start guide
EdilKamin
EdilKamin SALLY Quick start guide
EdilKamin
EdilKamin ARIS PLUS Quick start guide
EdilKamin
EdilKamin CELIA Air Tight Quick start guide
Popular Stove manuals by other brands
Plamen International
Plamen International SP 850 N Technical instructions
KAL-FIRE
KAL-FIRE Heat Pure 45 quick start guide
Austro Flamm
Austro Flamm Scotty Duo operating manual
Haas+Sohn
Haas+Sohn HSP 7 DIANA GRANDE RLU 451.08 Equipment sheet
Comfort Bilt
Comfort Bilt HP22 Operator's manual
New World
New World NW50HLG User & installation instructions
Valor
Valor Hamlet Operating & installation manual
MHSC
MHSC Stratford SS38 Installation & operating instructions
Heartland Appliances
Heartland Appliances Oval 1902 Installation requirements
Hunter Stoves
Hunter Stoves DI Lusso Eco R6 Cube Instructions for Installation/Operating/Maintenance/Servicing
Stanley
Stanley K100 Installation and operating instructions
Morso UK
Morso UK 1410 Installation & operating instructions
