Edwards T-Station 75 User manual

D395-93-880
Issue A Original
Instruction Manual
T-Station 75
Description Item
Number Description Item Number
T-Station 75W NW40 200-230 V 50/60 Hz TS75W1001 T-Station 75D NW40 200-230 V 50/60 Hz TS75D1001
T-Station 75W NW40 100-120 V 50/60 Hz TS75W1002 T-Station 75D NW40 100-120 V 50/60 Hz TS75D1002
T-Station 75W ISO63 200-230 V 50/60 Hz TS75W2001 T-Station 75D ISO63 200-230 V 50/60 Hz TS75D2001
T-Station 75W ISO63 100-120 V 50/60 Hz TS75W2002 T-Station 75D ISO63 100-120 V 50/60 Hz TS75D2002
T-Station 75W CF63 200-230 V 50/60 Hz TS75W3001 T-Station 75D CF63 200-230 V 50/60 Hz TS75D3001
T-Station 75W CF63 100-120 V 50/60 Hz TS75W3002 T-Station 75D CF63 100-120 V 50/60 Hz TS75D3002

This product has been manufactured under a quality system registered to ISO9001
Declaration of Conformity
We, Edwards,
Crawley Business Quarter,
Manor Royal,
Crawley,
West Sussex, RH10 9LW, UK
declare under our sole responsibility, as manufacturer and person within the EU authorised to assemble
the technical file, that the product(s)
T-Station 75
T S 7 5 - X X – 0 0 X
The material numbers cover a family of products where the
following features may vary:- turbomolecular pump inlet flanges,
electrical supply and backing pumps.
Backingpumps:
E2M1.5
XDD1
to which this declaration relates is in conformity with the following standard(s) or other normative
document(s)
EN ISO 12100-2: 2003 Safety of Machinery. Basic Concepts, General Principles for
+ A1: 2009 Design. Technical Principals.
EN1012-2:1996, A1: 2009 Compressors and Vacuum Pumps. Safety Requirements,
VacuumPumps.
EN61010-1: 2001 Safety Requirements for Electrical Equipment for Measurement,
Control and Laboratory Use. General Requirements.
EN 61326-1: 2006 Electrical Equipment for Measurement, Control and Laboratory
Use. EMC requirements. General Requirements.
Industrial location, Class B Emissions.
EN50581:2012 Technical Documentation for the Assessment of Electrical and Electronic
Products with respect to the Restriction of Hazardous Substances
and fulfils all the relevant provisions of
2006/42/EC Machinery Directive
2006/95/EC Low Voltage Directive
2004/108/EC Electromagnetic Compatibility (EMC) Directive
2011/65/EU* Restriction of Certain Hazardous Substances (RoHS) Directive
* i.e. The product(s) contain less than - 0.1wt% for hexavalent chromium, lead, mercury, PBB and PBDE; 0.01wt% for
cadmium - in homogeneous materials (subject to the exemptions allowed by the Directive). The RoHS Directive does
not legally apply to industrial vacuum equipment until July 2019 (July 2017 for instruments).
Note: This declaration covers all product serial numbers from the date this Declaration was signed
onwards.
14.03.2013, Eastbourne
Peter Meares, GV Technical
Support Manage
r
Date and Place
P200-05-980 Issue B

© Edwards Limited 2011. All rights reserved. Page i
Edwards and the Edwards logo are trademarks of Edwards Limited.
Contents
D395-93-880 Issue A
Contents
Section Page
1 Introduction .......................................................................................1
1.1 Scope and definitions ................................................................................................... 1
1.2 Description ................................................................................................................ 2
1.2.1 Overview ..................................................................................................................2
1.2.2 General description of the T-Station major components .......................................................... 2
2 Technical data ....................................................................................4
2.1 General .................................................................................................................... 4
2.2 Operating and storage data ............................................................................................ 4
2.3 Electrical connections ................................................................................................... 4
2.4 Electrical data ............................................................................................................ 7
2.5 Pumping media ........................................................................................................... 8
2.6 Materials exposed to gases pumped .................................................................................. 9
2.7 Vent gas specification and vent control data ....................................................................... 9
3 Installation ....................................................................................... 11
3.1 Safety .....................................................................................................................11
3.2 Unpack and inspect .....................................................................................................11
3.3 Locate the T-Station ...................................................................................................12
3.4 Bench-top fixing ........................................................................................................12
3.5 Fill the rotary pump with oil ..........................................................................................12
3.6 Connect the T-Station to your vacuum system .....................................................................13
3.7 Connect to your exhaust extraction system ........................................................................13
3.8 Connect the electrical supply .........................................................................................14
3.9 Configure the T-Station ................................................................................................14
3.9.1 Turbo pump delay ......................................................................................................14
3.9.2 Connecting a vacuum gauge ..........................................................................................15
3.10 Commissioning the installation .......................................................................................16
4 Operation ........................................................................................ 17
4.1 Control panel description .............................................................................................17
4.2 Start up ...................................................................................................................17
4.3 Menu structure ..........................................................................................................18
4.3.1 Turbo screen .............................................................................................................19
4.3.2 Gauge screen ............................................................................................................20
4.3.3 Vent valve screen .......................................................................................................21
4.3.4 Turbo set-point screen .................................................................................................21
4.3.5 Calibrate gauge screen ................................................................................................23
4.3.6 Units screen .............................................................................................................24
4.4 Gas-ballast control (E2M1.5) ..........................................................................................25
4.5 Electrical supply failure ...............................................................................................25
5 Maintenance ..................................................................................... 26
5.1 Safety ....................................................................................................................26
5.2 Maintenance plan ......................................................................................................26
5.3 Inspect the hoses, pipelines and connections ......................................................................27
5.4 Fault-finding .............................................................................................................27
5.5 Error numbers ...........................................................................................................28
5.6 Factory default settings ...............................................................................................29
gea/0147/03/11

D395-93-880 Issue A
Page ii © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Contents
6 Storage and disposal ........................................................................... 30
6.1 Storage ...................................................................................................................30
6.2 Disposal ...................................................................................................................30
7 Spares and accessories ......................................................................... 31
7.1 Introduction .............................................................................................................31
7.2 Spares .....................................................................................................................31
7.3 Accessories ...............................................................................................................31
7.3.1 TAV vent-valve and vent-port adaptor (for DX turbo pump) .....................................................31
7.3.2 Outlet mist filter (for E2M1.5 rotary vacuum pump) ..............................................................31
Index .............................................................................................. 33
For return of equipment, complete the HS Forms at the end of this manual.
Illustrations
Figure Page
1 Components of the T-Station .......................................................................................... 3
2 Equipment dimensions (mm) ........................................................................................... 5
3 Pin connections for a 15-way sub-miniature ‘D’ type socket ..................................................... 6
4 Pin connections for an 8-way RJ45 .................................................................................... 6
5 Maximum allowed rate of pressure rise during venting: pressure against time (with pump initially at full
rotational speed) 10
6 Turbomolecular pump start delay with XDD1 diaphragm pump .................................................15
7 Front panel display .....................................................................................................17
8 Menu Structure ..........................................................................................................18
Tables
Table Page
1 Turbo pump connector pin-out ........................................................................................ 6
2 Active gauge connector pin-out ....................................................................................... 7
3 Electrical data ............................................................................................................ 7
4 T-Station technical data ................................................................................................ 9
5 Vent gas specification and vent control .............................................................................. 9
6 Checklist of components ...............................................................................................11
7 Front panel symbols and their functions ............................................................................17
8 Menu items ...............................................................................................................17
9 Fault finding .............................................................................................................27
Associated publications
Publication title Publication number
Diaphragm Pump - XDD1 A746-02-885
Rotary Vane Pump - E2M0.7 / E2M1.5 A371-32-880
Turbomolecular Pumps - EXT75DX / EXT255DX B722-40-880

© Edwards Limited 2011. All rights reserved. Page 1
Edwards and the Edwards logo are trademarks of Edwards Limited.
Introduction
D395-93-880 Issue A
1Introduction
1.1 Scope and definitions
This manual provides installation, operation and maintenance instructions for the Edwards T-Station. You must use
the T-Station as specified in this manual.
Read this manual before you install and operate the T-Station. Important safety information is highlighted as
WARNING and CAUTION instructions; you must obey these instructions. The use of WARNINGS and CAUTIONS is defined
below.
CAUTION
Cautions are given where failure to observe the instruction could result in damage to the equipment, associated
equipment and process.
Details of the Supplementary Publications is provided at the end of the Contents list of this manual. These
Supplementary Publications can be accessed from the CD manual which is supplied with your T-Station.
The Supplementary Publications you receive also contain WARNING and CAUTION instructions. When you install and
operate the T-Station, you must refer to these Supplementary Publications and obey all of the WARNING and CAUTION
instructions which they contain.
The following IEC warning labels appear on the product and in the manual:
The units used throughout this manual conform to the SI international system of units of measurement.
WARNING
Warnings are given where failure to observe the instruction could result in injury or death to
people.
Warning - refer to accompanying documentation.
Warning - risk of electric shock.
Warning - hot surfaces.

D395-93-880 Issue A
Page 2 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Introduction
1.2 Description
1.2.1 Overview
The T-Station is a small compact fully automatic pumping system which is suitable for a wide range of vacuum
applications. The T-Station can be supplied with either an XDD1 oil free diaphragm pump or an E2M1.5 rotary vane
pump, both system variants use an EXT75DX turbomolecular pump.
The T-Station is controlled by an easy to use touch pad control module. A single gauge input included can be
connected to a range of Edwards active gauges allowing for pressure measurement and or control management of
the turbomolecular pump.
The compact size of the T-Station is ideal for use on bench-tops or suitable mobile platforms. The open system
configuration allows easy maintenance of the main pump components.
1.2.2 General description of the T-Station major components
For the general description of the major components used on the T-Station, click on (CD) the appropriate instruction
manual reference against each product type.
Diaphragm pump XDD1 A746-02-885
Rotary vane pumps E2M0.7 / E2M1.5 A371-32-880
Turbomolecular pumps EXT75DX / EXT255DX B722-40-880

© Edwards Limited 2011. All rights reserved. Page 3
Edwards and the Edwards logo are trademarks of Edwards Limited.
Introduction
D395-93-880 Issue A
Figure 1 - Components of the T-Station
1. E2M1.5 gas-ballast control
2. Backing pump oil mist filter (optional
accessory not supplied)
3. Turbomolecular pump inlet
4. Backing pump
5. TAV vent valve (optional accessory not
supplied)
6. Turbomolecular pump connector
7. Vacuum gauge input
8. T-Station control unit
9. Mains input (fused refer to Section 2.3)
10.Backing pump mains connector
11.T-Station lifting handles
12.T-Station fixing points for bench top
mounting (refer to Section 3.4)

D395-93-880 Issue A
Page 4 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2Technicaldata
Note: The operating, storage conditions and performance of the T-Station may depends on the type of backing
pump fitted to the T-Station; refer to the technical data in the appropriate supplementary publications.
2.1 General
2.2 Operating and storage data
2.3 Electrical connections
Dimensions Refer to Figure 2
Electrical data Refer to Table 3 - Electrical data
Degree of protection (to IEC34-5: 1981) IP20
Mass
XDD1 combination
E2M1.5 combination 17 kg max 21 kg max
Ambient operating temperature range 12 °C to 40 °C
Ambient storage temperature range -30 °C to 70 °C
Maximum operating altitude 2000 m max
Equipment type Indoor use only
Pollution degree 2
Maximum ambient operating humidity Max 90% RH non cond at 40 °C
Sound level 56 dB(A)
Maximum outlet pressure
XDD1 pump
E2M1.5 pump 1.1 bar absolute (1.1 x 105Pa)
1.5 bar absolute (1.5 x 105Pa)
Maximum permitted external magnetic field 5 mT (DX turbo)
Electrical supply (refer to Figure 1 item 9)
Inlet plug type
Integral fuse rating IEC60320 10 A Type T, 20 mm
Backing pump (refer to Figure 1 item 10)
Outlet socket type IEC60320
Turbomolecular pump (refer to Figure 1 item 6)
Connector type
Power supply
Maximum output power
15-way sub-miniature ‘D’ type socket
24 V d.c. nominal
80 W
Active gauge (refer to Figure 1 item 7)
Connector type
Power supply
Maximum power rating
RJ45 8-way
24 V d.c. nominal
4 W

© Edwards Limited 2011. All rights reserved. Page 5
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
D395-93-880 Issue A
Figure 2 - Equipment dimensions (mm)

D395-93-880 Issue A
Page 6 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
Figure 3 - Pin connections for a 15-way sub-miniature ‘D’ type socket
Figure 4 - Pin connections for an 8-way RJ45
Table 1 - Turbo pump connector pin-out
Pin Function
1 Power supply positive
2Signalcommon
3 Start signal output
4RS232Tx
5 Serial enable output
6 Power supply positive
7RS232Rx
8 Power supply common
9 Speed signal input
10 Screen
11 Power supply positive
12 Screen
13 Power supply common
14 Power supply common
15 Normal signal input

© Edwards Limited 2011. All rights reserved. Page 7
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
D395-93-880 Issue A
2.4 Electrical data
If your T-Station uses an E2M1.5, the motor start-up current is drawn for less than one second, so you must use slow-
blow fuses to prevent unnecessary fuse failure when the pump starts. If you use the pump at temperatures lower
than 12 °C (53.6 °F), the start-up current will be drawn for longer; this may cause the motor thermal overload device
to open.
Table 2 - Active gauge connector pin-out
Pin Function
1 Power supply positive
2 Power supply common
3Signalinput
4 Identification
5Signalcommon
6 Control line 1
7 Control line 2
8N/C
Table 3 - Electrical data
Pump combination Supply Voltage
50/60 Hz Current (A) Power (W)
Full load Start
XDD1 / EXT75DX
100 3.1 -
310
120 2.6 -
200 1.6 -
230 1.35 -
E2M1.5 / EXT75DX
100 4.7 13.6 470
120 3.92 12.0
200 2.2 6.4 430
230 1.9 5.7

D395-93-880 Issue A
Page 8 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.5 Pumping media
CAUTION
Do not use the turbo pump to pump gases containing more than 20% oxygen unless the pump is gas purged. If
you do, the lubricant will polymerise and the pump may fail prematurely.
CAUTION
Do not use a turbo pump to pump mercury vapour and do not allow mercury (for example, from a McLeod gauge)
to come into contact with the pump. If you do, the pump rotor may corrode and fail.
Note: Concentrations of gases may be modified by the compression of the pump.
The turbo turbo pump is designed to pump the following residual gases normally used in high-vacuum systems:
You can use the pump to pump oxygen and water vapour, subject to the following conditions:
Oxygen - when the pump is purged by an inert gas, oxygen can be pumped at concentrations above 20% by
volume. Refer to the EXT75DX instruction manual (B722-40-880) for Purge gas specification. However, if the
pump is not purged, the oxygen concentration must be less than 20% by volume.
Water vapour - you must ensure that vapour does not condense inside the pump.
WARNING
Vent dangerous gases and gas mixtures safely, do not expose people to these gases. If pumping
hazardous gases or vapours, observe the safety recommendations of the supplier of the gas/
vapour.
WARNING
Do not use the turbo pump to pump pyrophoric or explosive gas mixtures, as it is not suitable for
this purpose. The pump and its connections are not designed to contain an explosion.
WARNING
Do not expose any part of the human body to vacuum.
Air Carbon dioxide
Methane Neon
Propane Krypton
Butane Helium
Carbon monoxide Ethane
Nitrogen Argon
Hydrogen

© Edwards Limited 2011. All rights reserved. Page 9
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
D395-93-880 Issue A
If you wish to pump a gas not in the list above, contact your supplier for advice. If you do not contact your supplier,
you may invalidate the warranty on the pump. The pump is not suitable for pumping aggressive or corrosive gases.
2.6 Materials exposed to gases pumped
The following materials and component types are exposed to the gases pumped:
Aluminium alloys, stainless steels, fluoroelastomer and nitrile O-rings, hydrocarbon lubricant, felt, rare earth
magnets, silicon nitride, phenolic resin, carbon-fibre reinforced epoxy resin, fire retardant polypropylene,
polyamide and PVC.
2.7 Vent gas specification and vent control data
Although the pump may be vented to atmosphere, high relative humidity of the air may greatly increase the
subsequent pump-down time. To reduce pump-down times you should vent with dry, clean gases. Refer to the DX
turbo pump manual (B722-40-880) for the vent valve connection and refer to Section 4.3.3 of this manual for a
description of the vent options available on the T-Station and how to configure them.
Table 4 - T-Station technical data
Parameter EXT75DX
ISO63 EXT75DX 63CF EXT75DX NW40
Inlet pumping speed:
N2 61 l s-1 61 l s-1 42 l s-1
He 57 l s-1 57 l s-1 49 l s-1
H2 53 l s-1 53 l s-1 48 l s-1
Inlet compression ratio:
N2 > 1 x 1011 > 1 x 1011 > 1 x 1011
He 1 x 1061 x 1061 x 106
H2 5 x 1045 x 1045 x 104
Ultimate pressure:
with rotary vane backing pump *
*Ultimate pressure 48 hours after bakeout with 2-stage rotary vane backing-pump.
< 5 x 10-9 mbar < 5 x 10-10 mbar < 5 x 10-9 mbar
with diaphragm backing pump †
†Ultimate pressure 48 hours after bakeout with backing pressure < 5 mbar (500 Pa).
< 5 x 10-8 mbar < 5 x 10-9 mbar < 5 x 10-8 mbar
Table 5 - Vent gas specification and vent control
Vent gas specification and control Reference data
Vent gas Dry air, nitrogen, argon and other inert gases
Maximum dew point at atmospheric pressure -22 °C
Maximum size of particulates 1 μm
Maximum concentration of oil 0.1 parts per million
Recommended time for rotational speed to reach 50% > 15 seconds
Maximum allowed rate of pressure rise Refer to Figure 5

D395-93-880 Issue A
Page 10 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
Figure 5 - Maximum allowed rate of pressure rise during venting: pressure against time (with pump initially at
full rotational speed)

© Edwards Limited 2011. All rights reserved. Page 11
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
D395-93-880 Issue A
3 Installation
3.1 Safety
When you refer to a manual supplied as a Supplementary Publication, you must obey all of the WARNING and
CAUTION instructions in the manual.
A suitably trained and supervised technician must install the T-Station.
Check that all the required parts are available and of the correct type before you start work.
Ensure that the installation technician is familiar with the safety procedures which relate to the products
pumped. Wear the appropriate safety-clothing when you come into contact with contaminated components.
Isolate the other components in your system from the electrical supply so that they cannot be operated
accidentally.
Do not reuse O-rings and Co-Seals if they are damaged.
Dispose of components, grease and oil safely (refer to Section 6).
Take care to protect sealing-faces from damage.
We recommend you leak-test the system after installation is complete.
3.2 Unpack and inspect
Remove the outer cover and all packing materials, remove the protective covers from the inlet and outlet ports,
inspect the system for any damage. If the T-Station is damaged, notify your supplier and the carrier in writing within
three days; state your order number and invoice number. Retain all packing materials for inspection. Do not use the
T-Station if it is damaged. Check that your package contains the items listed in Table 6. If any item is missing, notify
your supplier within three days.
If the T-Station is not to be used immediately, replace the protective covers. Store the T-Station in suitable
conditions as described in Section 6.1.
WARNING
Obey the safety instructions given below and take note of appropriate precautions. If you do not,
you can cause injury to people and damage to equipment.
Table 6 - Checklist of components
Qty Description Check ()
1 T-Station 
1 T-Station CD instruction manual P450-00-000 
1 Ultragrade 15 oil 1 ltr (supplied only with E2M1.5) 
1 Inlet seal (either trapped O-ring, Co-seal or copper compression gasket suitable for
the inlet-flange type) 
1 Connector (24 V) - for driving accessories from Podule socket 
1 Inlet-strainer 

D395-93-880 Issue A
Page 12 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
3.3 Locate the T-Station
CAUTION
When locating the T-Station, care should be taken not to restrict the ventilation grid located under the base of
the T-Station. Failing to observe this may result in over heating of the turbomolecular pump.
3.4 Bench-top fixing
There are two M8 fixing points located at the rear of the T-Station base (refer to Figure 1, item 12). Using suitable
brackets or straps (not supplied), we recommend that you should secure the T-Station to your bench-top to prevent
excessive movement in the unlikely event of a pump failure. Please note, we cannot provide straps or brackets as
we unable to determine the best type fixing for your bench-top location. We recommend you should source or
fabricate these fixings locally.
3.5 Fill the rotary pump with oil
If the T-Station uses an E2M1.5 rotary vane pump, you must fill it with the correct quantity of oil (supplied with the
equipment) before you operate the equipment. For further information refer to the EM Rotary Vane Pump manual
A371-32-880.
Fill the pump with oil as described below.
1. Remove the oil filler-plug.
2. Pour oil into the pump until the oil-level just reaches the MAX mark on the bezel at the top of the sight-glass. If
the oil-level goes above the MAX mark, remove the drain-plug and drain the excess oil from the pump.
3. After a few minutes, recheck the oil-level. If the oil-level is now below the MAX mark, pour more oil into the
pump.
4. Refit the oil filler-plug. Tighten the plug firmly by hand. Do not over tighten.
WARNING
Heavy objects can cause muscle strain or back injury. The mass of the T-Station will differ
depending on the model supplied, refer to Section 2.1 for the equipment mass.
WARNING
Important: The turbo pump used on the T-Station stores a large amount of kinetic energy when it
is running at full speed. In the unlikely event of a malfunction (rotor seizure), the stored energy
could cause a slight movement of the T-Station platform. If the T-Station is operating on a bench-
top, we advise that the following steps should be taken:
Position the T-Station at least 10-15 cm away from the edge of the bench-top and adjacent
devices.
and or,
Tether or fix the T-Station to your bench-top, see Section 3.4.

© Edwards Limited 2011. All rights reserved. Page 13
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
D395-93-880 Issue A
3.6 Connect the T-Station to your vacuum system
The turbo pump can be securely fixed to the vacuum system via the inlet-flange. Make sure that the pump-inlet and
all components fitted to the pump-inlet are clean and dust-free. If the pump-inlet is not kept clean, the pump-down
time may be increased.
If the pump has a CF flange, use the copper compression gasket supplied with the pump and use a full
complement of bolts to connect the inlet-flange of the pump to the vacuum system.
If the pump has an ISO flange, use a minimum of four claw clamps (each torque to 10 Nm) to connect the
inlet-flange of the pump to the vacuum system. Alternatively, use a rotatable collar and the combined inlet
screen and trapped O-ring supplied with the pump to connect the inlet-flange of the pump to the vacuum
system; use a full complement of bolts with the rotatable collar.
If the pump has an NW flange, use the centring ring supplied with the pump and a metal NW clamp to
connect the inlet-flange of the pump to the vacuum system.
All inlet flange bolts must be re-tightened once the system is under vacuum. Ensure that no torques or other forces
are transmitted to the pump from the vacuum system or the associated pipelines.
3.7 Connect to your exhaust extraction system
Note: This section applies to E2M1.5 versions only.
The exhaust system must be configured so that the maximum pressure at the pump outlet does not exceed 0.5 bar
gauge (1.5 bar absolute, 1.5 x 105Pa) at full pump throughput. Make sure that the exhaust pipeline cannot become
blocked. If you have an exhaust- isolation valve, make sure that you cannot operate the pump with the valve closed.
WARNING
Connect the turbo pump inlet to your vacuum system before applying power to the T-Station. This
will ensure that the pump cannot operate accidentally causing injury.
WARNING
If you install your vacuum system directly onto the T-Station, the weight of the system must be no
more than 10 kg and the centre of gravity must be positioned laterally within the bounds of the
base plate. If this is not the case, the vacuum system must be supported to ensure that the
T-Station does not topple.
WARNING
Vent dangerous gases and gas mixtures safely, do not expose people to these gases. If pumping
hazardous gases or vapours, observe the safety recommendations of the supplier of the gas/
vapour.

D395-93-880 Issue A
Page 14 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
3.8 Connect the electrical supply
CAUTION
Always make the electrical connections to the T-Station after the equipment has been installed on your vacuum
system. Always disconnect the electrical supply from the T-Station before removing the equipment from the
vacuum system.
Check that your electrical supply is suitable for this equipment. Refer to Table 3 for the electrical requirements for
this equipment. Make the electrical connection to the T-Station using a cable fitted with an IEC60320 connector. A
range of suitable cables is available from your supplier.
3.9 Configure the T-Station
As supplied from the factory, the T-Station will control the system as follows:
System start is selected:
The TAV vent valve will close*.
The backing pump will turn on.
The turbomolecular pump will start accelerating up to full rotational speed.
System off is selected:
The backing pump will turn off.
The turbomolecular pump drive will turn off and the pump will start to decelerate.
The TAV vent valve will open fully from 50% of full rotational speed*.
* This operation refers to systems which have been fitted with an Edwards TAV vent valve (optional accessory). For
more vent options refer to Section 4.3.3.
3.9.1 Turbo pump delay
The T-Station can be configured to delay the turbo pump after the backing pump has started (refer to Section 4.3.4),
this is helpful to prevent the turbomolecular pump from accelerating under high pressure for a prolonged period if
the volume being pumped is greater than 2 litres. This option is especially useful if your T-Station uses an XDD1
diaphragm pump. Below the chart shows the recommended delay period for a turbo / XDD1 pump combination.
WARNING
Ensure that the electrical installation of the T-Station conforms with your local and national safety
requirements. It must be connected to a suitably fused and protected electrical supply and a
suitable earth point.

© Edwards Limited 2011. All rights reserved. Page 15
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
D395-93-880 Issue A
Figure 6 - Turbomolecular pump start delay with XDD1 diaphragm pump
3.9.2 Connecting a vacuum gauge
CAUTION
Do not connect Barocel capacitance manometers to the T-Station gauge connector. Doing so will result in
damage to the gauge and will invalidate the warranty.
A single compatible active gauge can be fitted to the T-Station. Fit the gauge using an Edwards active gauge cable
into the gauge connector located on the side of the controller housing (refer to Figure 1). For active gauge control
and set-up refer to Section 4.3.2.
The following Edwards active gauges are suitable for use with the T-Station:
APG100 Active Pirani vacuum gauge
APGX-H Active Linear Convection gauge
AIM-X Active Inverted Magnetron gauge
WRG-S Active Wide Range gauge
ASG Active Strain gauge

D395-93-880 Issue A
Page 16 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
3.10 Commissioning the installation
After you have installed the T-Station, use the following procedure to test the system.
1. Make sure that all the electrical connections are secure.
2. Switch on the electrical supply and your exhaust-extraction system (if available).
3. To operate the system press the START/STOP key. Check that the equipment operates as described in
Section 3.9.
4. Check that the turbo pump reaches normal speed. If the pump inlet is valved or capped off, it should take
approximately 100 - 150 seconds for the turbo to reach normal speed. If you have attached a vacuum chamber to
the pump inlet, this time may take longer.
5. To turn OFF the system, press the START/STOP key followed by the ENTER key to confirm. Check that the
equipment closes down as described in Section 3.9.
For full operational details and how to navigate using the front panel control key pad refer to Section 4.3.
