Edwards E2M175S User manual

A366-99-840
Issue C Original
Instructions
E2M175S and E2M275S Rotary Pump Service Kits
Description Item Number
Clean and Overhaul Kit A366-01-131
Blade Kit for E2M175S A366-01-134
Blade Kit for E2M275S A367-01-134

Important safety Information
zVacuum pumps are potentially dangerous if incorrectly used, repaired or maintained, so please approach the
repair or maintenance with caution.
zAny incorrectly fitted spare parts could damage your pump and could be potentially dangerous.
zNever allow unqualified personnel to attempt to remove or replace any part of the pump.
zIf you have any doubts about the servicing procedures or the products capabilities please contact Edwards.
zBefore returning any equipment to Edwards for repair please follow the Edwards HS1 procedure and
complete an HS2 declaration form to warn of any substances used or produced in the equipment that can be
dangerous. The procedure and forms are included with the pump instruction manuals and can be down-
loaded together with Edwards local contact details from www.edwardsvacuum.com
zAlways conform to service schedules unless adverse conditions necessitate more frequent servicing.
zReport any defect before an accident or consequential damage can occur.
zObserve local and country specific regulations, norms and guidelines.
zNever allow anyone to remove large or heavy components without adequate lifting equipment.
zBefore maintenance work is begun, ensure the pump is switched off and isolated from the mains.
zThe pump may have been exposed to processes which use hazardous substances or produces by-products
which are dangerous to human health and safety, for example, chemically active, biologically active or
radioactive substances.
zBefore working on a pump, ensure that the correct personal protective equipment is available and being
used. Always wear safety goggles. Wear a breather mask with positive air pressure and take other
precautions if you believe the pump may be contaminated with hazardous substances and dusts.
zWhen applying sealants and lubricants, prevent contact with the skin by wearing suitable gloves.
zSeals may contain fluoroelastomer, which when properly handled is not dangerous but which may produce a
toxic and corrosive residue (hydrogen fluoride or hydrofluoric acid) in the event of excessive heat or fire
depending on the circumstances of degradation and other materials involved.
zOn completion of maintenance, check the pump functions correctly and that all guards and protection
devices are fitted and working correctly and that the pump is electrically safe.
zIf the pump is used for handling hazardous substances check the pump for leak-tightness before use.
zDispose of waste oil and any process by-products in accordance with local and national safety and
environmental requirements. It is usually illegal to dispose of waste oil into drains or water courses, or to
bury it.
Edwards Limited
Manor Royal
Crawley, West Sussex, UK
RH10 9LW
Tel: +(44) 1293 528844
Fax: +(44) 1293 533453
© Edwards Limited 2008.
Edwards and the Edwards
logo are trademarks of
Edwards Limited.

© Edwards Limited 2008. All rights reserved. Page i
Edwards and the Edwards logo are trademarks of Edwards Limited.
Contents
A366-99-840 Issue C
Contents
Section Page
1 Introduction .......................................................................................1
2 Kit Parts ............................................................................................2
2.1 Parts in the Clean and Overhaul Kit .................................................................................. 2
2.2 Parts in the Blade Kits .................................................................................................. 4
3 How to use the Kits ............................................................................. 12
Illustrations
Figure Page
1 Kit items for main oil box sub-assembly ............................................................................. 5
2 Kit items for inlet valve sub-assembly ................................................................................ 6
3 Kit items for oil box end-plate and oil filter sub-assembly ....................................................... 7
4 Kit items for gas ballast valve sub-assembly ........................................................................ 8
5 Kit items for oil distributor sub-assembly ............................................................................ 9
6 Kit items for HV stator sub-assembly ................................................................................10
7 Kit items for LV stator sub-assembly ................................................................................11
Tables
Table Page
1 Clean and Overhaul Kit items .......................................................................................... 2
2 E2M175S Blade Kit items ................................................................................................ 4
3 E2M275S Blade Kit items ................................................................................................ 4
Trademark credits
Viton™ is a trademark of DuPont Performance Elastomers L.L.C.
Ipsitech 9001(8)-2008

This page has been intentionally left blank.
A366-99-840 Issue C
Page ii © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.

© Edwards Limited 2008. All rights reserved. Page 1
Edwards and the Edwards logo are trademarks of Edwards Limited.
Introduction
A366-99-840 Issue C
1Introduction
These instructions apply to both the Clean and Overhaul Kit and the Blade Kits, which are supplied separately:
zWe recommend that you use all the items in the Clean and Overhaul Kit, particularly all rubber components,
when you service the pump. The items supplied in the kit are listed in Table 1. These items are shown in
Figures 1to 7. Instructions for the use of the kit are given in Section 3.
zUse a Blade Kit together with a Clean and Overhaul Kit when you replace the rotary pump blades. You must
replace all the blade assembly items with those supplied in the appropriate Blade Kit. The items supplied in
the Blade Kits are listed in Table 2 for the E2M175S and in Table 3 for the E2M275S. These items are shown in
Figures 6and 7. Instructions for the use of the Blade Kits are given in Section 3.

A366-99-840 Issue C
Page 2 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
2KitParts
2.1 Parts in the Clean and Overhaul Kit
Table 1 - Clean and Overhaul Kit items
Illustration
Item Description Quantity
supplied
Size (mm) and feature (if applicable)
Length x diameter (x width)
∅= inside diameter
(X) - number of coils in a spring
5 *Piston ring 1
13 *O-ring 1 0146-24 Viton ™
14 *O-ring 1 0171
15 *O-ring 1 0181
16 *O-ring 1 0331
17 *Split pin 1 1/16 inch diameter x 1 inch long
Stainless Steel
15 Valve pad 1
37 Piston face 1
47 Shaft seal sleeve 1
53 Felt ballast filter 2
58 Dowty seal 1 1/2inch BSP
65 Ballast valve 1
77 Distributor gasket 1
78 Diaphragm 1
79 LV exhaust valve rubber 1
80 Filter head gasket 1
81 Ballast gasket 1
82 Ballast gasket 1
83 Valve body gasket 1
84 Exhaust gasket 1
85 End plate gasket 1
87 Body gasket 1

© Edwards Limited 2008. All rights reserved. Page 3
Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
A366-99-840 Issue C
Illustration
Item Description Quantity
supplied
Size (mm) and feature (if applicable)
Length x diameter (x width)
∅= inside diameter
(X) - number of coils in a spring
109 Dowty seal 1 1/8inch BSP
110 Dowty seal 6 1/4inch BSP
111 Dowty seal 1 1 inch BSP
113 Oil seal 1 Viton ™
114 Oil seal 3 Viton ™
117 O-ring 1 111
118 O-ring 2 0210
119 O-ring 1 0213
120 O-ring 2 0216
121 O-ring 1 0239
122 O-ring 2 0335
123 O-ring 1 0340
124 O-ring 1 0448
125 O-ring 1 4A
126 O-ring 3 0056-24
180 Exhaust valve rubber 1 E2M175S only
180 Exhaust valve rubber 1 E2M275S only
181 Lid gasket 1 E2M175S only
181 Lid gasket 1 E2M275S only
182 Knitmesh gasket 1 E1M175S only
182 Knitmesh gasket 1 E2M275S only
207 Body nut 1
231 Exhaust warning label 1
*Inlet valve assembly item: see Figure 2.
Table 1 - Clean and Overhaul Kit items

A366-99-840 Issue C
Page 4 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
2.2 Parts in the Blade Kits
Table 2 - E2M175S Blade Kit items
Illustration
Item Description Quantity supplied
239 HV blade 2
237 LV blade 2
238 Oil pump blade 1
Table 3 - E2M275S Blade Kit items
Illustration
Item Description Quantity supplied
239 HV blade 2
237 LV blade 2
238 Oil pump blade 1

© Edwards Limited 2008. All rights reserved. Page 5
Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
A366-99-840 Issue C
Figure 1 - Kit items for main oil box sub-assembly

A366-99-840 Issue C Page 6 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
Figure 2 - Kit items for inlet valve sub-assembly

© Edwards Limited 2008. All rights reserved. Page 7 Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
A366-99-840 Issue C
Figure 3 - Kit items for oil box end-plate and oil filter sub-assembly

A366-99-840 Issue C Page 8 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
Figure 4 - Kit items for gas ballast valve sub-assembly

© Edwards Limited 2008. All rights reserved. Page 9
Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
A366-99-840 Issue C
Figure 5 - Kit items for oil distributor sub-assembly

A366-99-840 Issue C Page 10 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
Figure 6 - Kit items for HV stator sub-assembly
Supplied separately in the appropriate Blade Kit

© Edwards Limited 2008. All rights reserved. Page 11 Edwards and the Edwards logo are trademarks of Edwards Limited.
Kit Parts
A366-99-840 Issue C
Figure 7 - Kit items for LV stator sub-assembly
Supplied separately in the appropriate Blade Kit

A366-99-840 Issue C
Page 12 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
How to use the Kits
3 How to use the Kits
Where appropriate, refer to the pump instruction manual for information about routine maintenance of the pumps.
1. Disconnect the rotary pump from the electrical supply and allow it to cool.
2. Drain the oil from the rotary pump.
3. Dismantle the pump and, referring to Figures 1to 7as appropriate, replace the components with those in the
Clean and Overhaul Kit. Clean all exposed surfaces with a suitable cleaning fluid.
4. Inspect the rotary pump blade assembly for signs of wear. Ensure there is less than 0.15 mm clearance between
each blade and its rotor slot: if the clearance is greater than 0.15 mm, you must replace the blades if you wish
to obtain good vacuum performance. Seal the used blades in a plastic bag and dispose of the blades in
accordance with all local and national safety and environmental requirements.
5. Reassemble the pump using the appropriate new gaskets supplied.
6. Fill the rotary pump oil box with the correct quantity of new oil.
7. The Clean and Overhaul Kit contains an exhaust warning label (item 231). If such a label is not already fitted to
the pump:
zRemove the backing strip from the label.
zAttach the label to the top of the oil box lid, close to the exhaust outlet: see Figure 1.
8. Connect the electrical supply and switch on the rotary pump:
zCheck the direction of rotation of the pump.
zCheck that the oil level in the sight glass on the pump end-plate falls by 3 to 5 mm when you start the pump.
If this does not happen, refer to the pump instruction manual.
9. Open the gas ballast valve and operate the rotary pump for at least 1 hour.
