EFFILUX EFFI-FLEX-LG User manual
USER MANUAL
www.elux.com1/6USER MANUAL EN EFFI-FLEX-LG-CGX V1.0.2022
GENERAL PRODUCT INFORMATION
Une version française de cette notice est disponible sur la page produit correspondante de notre site web.
User manual
www.elux.com
GENERAL WARNINGS AND PRECAUTIONS OF USE
Operating environment Temperature: 0 to 40°C - Humidity: 20 to 85RH% (without condensation) - Altitude: Up to 2000m
Storage environment Temperature: -20 to 60°C - Humidity: 20 to 85RH% (without condensation)
Informations Overvoltage category I - Protective class III - Pollution degree 3
Well-ventilated places with minimal dust. Places free from any liquid, chemical product or steam.
Places free from corrosive or combustible gas. Places that are not subject to sudden temperature changes.
Places away from water taps, boilers, humidiers, air conditioners, heaters or stoves.
Do not disassemble or modify the product. Do not look directly at the LED light without protection.
Do not try to x any damages on the product by yourself. Make sure special protective glasses are used with UV products (<420nm).
Do not touch the product with wet hands. Do not use homemade cables.
Wire and keep the ying leads cables in a dry area (regardless of the product’s
degree of protection).
Make sure the product does not show any moisture or liquid inside before
switching it ON.
Make sure the power supply and the cable/connector are adapted to the
product specications.
The device must be powered by a 24V safety power supply in accordance to
local Electrical Safety rules
Do not inverse electrical polarity - check your connections and the conventions. The product packaging must be removed before use.
The cTÜVus certication is only applicable for the white (000) and red (625) devices, with a power consumption under 150W and, powered with a power supply
that fullls SELV and Limited Energy according IEC 61010-1 9.4) With a power consumption under 150W (depending on the size and the software version) and,
powered with a power supply that fullls SELV and Limited Energy according IEC 61010-1 9.4
www.elux.com2/6USER MANUAL EN EFFI-FLEX-LG-CGX V1.0.2022
PART NUMBER KEY
EFFI-FLEX-LG -XXXX -ZZZ -WW -PP
Optical Length (mm) Wavelength Window Lens position
200 465 (Blue) LD (Lightly-diuse) P0 (90°)
400 525 (Green) SD (Semi-diuse) P1 (45°)
600 625 (Red) OP (Opaline) P2 (25°)
... All 200mm 850 (Infrared) P3 (10°)
1400 000 (White)
OPTICS
Kit with all diusers EFFI-FLEX-LG-XXXX-ZZZ-KIT
Polarizer accessory EFFI-FLEX-LG-XXXX-ZZZ-WW-PP-POL
Custom wavelength EFFI-FLEX-LG-XXXX-ZZZ-WW-PP
Other wavelengths upon request.
ELECTRONICS
Customized software
(Strobe length & frequency modication)
EFFI-FLEX-LG-XXXX-ZZZ-WW-PP-SWxxxxxx
Specic for each customized software. If the device consumption exceed 150W, regulations’ compliancy may be
impacted, please contact Elux.
External power supply Version EFFI-FLEX-LG-XXXX-ZZZ-WW-PP-CPW
Customized software mandatory. Specic user manual.
Daisy Chain Version EFFI-FLEX-LG-XXXX-ZZZ-WW-PP-CHS
Number of chainable bars: see page 3
Daisy Chain Version with output female
connector on the opposite cap
EFFI-FLEX-LG-XXXX-ZZZ-WW-PP-CHO
Number of chainable bars: see page 3
NPN trigger Version EFFI-FLEX-LG-XXXX-ZZZ-WW-PP-NPN
NPN trigger on pin 2 instead of PNP trigger on pin 4
MECHANIC
Longer length (Up to 2800mm) EFFI-FLEX-LG-XXXX-ZZZ-WW-PP
If the device consumption exceeds 150W, regulations’ compliancy may be impacted, please contact Elux.
AVAILABLE ACCESSORIES
DIFFUSERS
Lightly-diuse: EFFO-FLEX2-LD-XXXX
Semi-diuse: EFFO-FLEX2-SD-XXXX
Opaline: EFFO-FLEX2-OP-XXXX
POLARIZER EFFO-FLEX2-POL-XXXX
POWER SUPPLIES Power supply: EFFI-PWR-WWW-24V-102-YY*
Compact power supply: EFFI-SPWR-090W-24V-102-YY**
EXTENSION CABLES
2 meters: EFFC-CAB-M12-FM-5-DD-L2
5 meters: EFFC-CAB-M12-FM-5-DD-L5
10 meters: EFFC-CAB-M12-FM-5-DD-L10
FASTENERS T-Nut Kit: EFFV-BOLT-0011
Pivot joint Kit: EFFM-1-0002
CAMERA FILTERS EFFO-FLR-...
*YY = Type of outlet UK, CH, EU, US, ...
www.elux.com3/6USER MANUAL EN EFFI-FLEX-LG-CGX V1.0.2022
Power supply / Electrical Input 24V DC +/-10%
Connector
(depending on the power consumption)
1x M12 - 5 pins or 1x M12 Power (T-coded) - 4 pins
If M12 Power - indicated in the product reference EFFI-FLEX-LG-XXXX-ZZZ-WW-PP-1M12P
Power consumption
Average Approx. 20W for each 200mm.
Peak (Max) 6A max for XXXX<1000mm - 12A max for XXXX≥1000mm
Inrush 6A max - 50ms max for XXXX<1000mm - 12A - 50ms max for XXXX≥1000mm
Max consumption strobe signal (PNP) 2mA
M12 - 5 pins
male connector 1 +24 V
Brown cable
PNP TRIGGER 4
(Light ON if VPNP> 4VDC)
Black cable
GND 3
Blue cable
M12 Power (T-coded) - 4 pins
male connector 1 +24 V
Brown cable
PNP TRIGGER 4
(Light ON if VPNP> 4VDC)
Black cable
GND 3
Blue cable
MegaStrobe
Strobing time (internal protection) 400µs max
Frequency (internal protection) 150Hz max
Rising time <1µs
Falling time <2µs
CHS/CHO CONFIGURATIONS (DAISY-CHAIN OPTIONS)
ELECTRICAL INSTALLATION -STD CONNECTOR CONFIGURATION
www.elux.com4/6USER MANUAL EN EFFI-FLEX-LG-CGX V1.0.2022
OPTICAL FLEXIBILITY
EFFO-FLEX-POL
Important note
LD
window
Unscrew the M4 screws and
remove the cap
Slide out the window and all lenses Place the lenses & window in
desired conguration
Open the EFFI-Flex-LG and insert
the LD window
Insert the polarizer under the LD
window
Close the product
MECHANICAL CONSIDERATION
IP rating IP5X
Dimensions 60mm x 47mm x Length = Optical length + 35mm
Fixing One T-slot on the back for M6 T-nuts 8mm slot (2x M6 T-nuts included)
(OUTPUT connector with the same pinout specication than INPUT connector) Optical length of the product
INPUT Connector OUTPUT Connector 200mm 400mm 600mm 800mm 1000mm 1200mm 1400mm
1x M12 - 5 pins male 1x M12 - 5 pins female 42XXXXX
1x M12P - 4 pins male 1x M12P - 4 pins female female 14 7 43222
www.elux.com5/6USER MANUAL EN EFFI-FLEX-LG-CGX V1.0.2022
REGULATIONS COMPLIANCY
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003du Canada.
Regulations & Marking CE (Safety standard: IEC 62471) - UKCA - FCC - ICES-3/NMB-3 - TÜV (The supply of the device has to fulll SELV and
Limited Energy according IEC 61010-1 9.4)
Environmental Standards RoHS Directives (2011/65/EU, 2015/863/EU and China RoHS) - REACH Regulation - WEEE Regulation
Country of Origin France - Manufactured by Elux
Model number FLG001 & FLG002
www.elux.com6/6USER MANUAL EN EFFI-FLEX-LG-CGX V1.0.2022
CONTACT INFORMATION
ENVIRONMENTAL REGULATIONS
WARRANTY
For more information, please refer to the warranty information available on Elux’s website.
