Eickemeyer HIRAY 5 User manual

USER MANUAL
Item no. 701105
TELEPHONE [phone]
www.eickemeyer.com
HIRAY 5
X-RAY MACHINE

2
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com

3
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
CONTENT
1. Introduction .............................................................................................................................. 4
2. Description................................................................................................................................ 4
3. The APR Technique .................................................................................................................. 8
How to use of APR Function...............................................................................................................8
Storing new APR Data in Memory (Initialization or Renewal)................................................8
4. Operation .................................................................................................................................. 9
Assembly....................................................................................................................................................9
Preparation before making the Exposure......................................................................................9
How to Operate.......................................................................................................................................9
5. Specifi cations..........................................................................................................................11
System Confi guration......................................................................................................................... 11
Performance Specifi cations.............................................................................................................. 11
Input Specifi cations............................................................................................................................ 11
X-Ray Tube ............................................................................................................................................. 12
Collimator............................................................................................................................................... 12
Protection Type for Electrical Shock............................................................................................. 12
Protection for Electrical Shock ....................................................................................................... 12
X-Ray Leakage....................................................................................................................................... 12
Optimum Ambient Conditions ....................................................................................................... 12
Dimensions (in cm) ............................................................................................................................. 12
Net Weight ............................................................................................................................................. 12
Included Accessory.............................................................................................................................. 12
6. Power Source for HiRay 5......................................................................................................13

4
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
1. INTRODUCTION
HiRay 5 is the most advanced portable and high-power X-Ray unit available both for the fi eld and clinic application, which is
120 kV in tube voltage, and 5 kW in maximum output power. The built-in collimator with 2 crossing lines and 2 laser pointers
confi rm an easy and quick acquirement of each radiographic position, limiting the need for remarks. By means of the automatic
mAs control technique, the real kV selected on the panel is always maintained even at the place where the line voltage is
dropped by high impedance in order to obtain the expected fi rm result.
HiRay 5 is the mono block type, including:
• Generator (includes X-Ray tube in the H.T. Transformer with 5-kW inverter)
• Built-in collimator and 2 laser pointers
• Line cable
• Hand switch with curled cable
2. DESCRIPTION
Names and Operations Fig. 1–4
Number Name Description
1 Control panel
It sets up radiographic conditions
2 Spirit level It is used for testing whether the device is level
3 Horizontal direction collimator knob It adjusts the size of irradiation fi eld in a horizontal
direction
4 Vertical direction collimator knob It adjusts the size of irradiation fi eld in a vertical direction
5 Tape measure It is used for measuring the position of a cassette
6 Hand switch connector It connects a hand switch cable
7DR I / F connector Interface connector for DR system
8 Power switch If I is pushed, the power is ON
If 0 is pushed, the power is OFF
9 Power connector It connects a power cable
10 Handle It supports a main body at the time of radiography
11 Plastic plate with cross line The cross position is a target point
12 Laser pointer Quick SID confi rmation
13 Rubber feet Rubber feet

5
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
331 mm
Fig. 1
12 1211
203 mm
260 mm
1
4
416 mm
FFA
75
1
3
1
8
2
4
3
0
3
5
4
0
Fig. 2
2
8
9
76
Fig. 4Fig. 3
350 mm
160 mm
15 mm
22.5 mm
5
1313
310

6
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
The Name and the Function of each Switch and Display of Fig. 5
Nummer Name Beschreibung
14 Reset switch A push resets fl ickering of wait lamp when the exposure is
interrupted
15 APR switch A push turns the APR function on. When the APR function
is on, the APR lamp lights, and a push stores a new setting
in APR memory
16 Body direction switches For selecting body direction
17 Body size switches For selecting body size
18 Body position switches For selecting body position
19 kV decrement switch For selecting and setting kV
20 kV increment switch For selecting and setting kV
21 mAs decrement switch For selecting and setting mAs
22 mAs increment switch For selecting and setting mAs
23 Field lamp switch Field lamp lights for 30 seconds
24
Indicator lamps
LINE (Green) This lamp lights when the power is on
WAIT (Red) This lamp lights for waiting or error
READY (Green) This lamp lights when ready for exposure
X-RAY (Yellow) This lamp lights during exposure
25 kV display
26 mAs display

7
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
Fig. 5
HIRAY 5
kV
APR
BABY XS SM
LX
L
LINE WAIT READY X-RAY
NASAL SKULL C-SPINE T-SPINE L-SPINE
VD/DVLATERAL
PELVIS/
HIP JOINT
SCALPULA LUNG ABDOMEN
HUMERUS CARPUS FEMUR
PHALANX TARSUS
LAMP
Reset
mAs
14 24
26
17
18
16
2220 21
19
23
25
15

8
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
3. THE APR TECHNIQUE
How to use of APR Function
1. Selecting APR mode. (APR on).
Push APR switch (No. 15 of Fig. 5). Then, the APR lamp lights and the APR function is activated.
2. Selecting APR techniques:
• Set body direction by selecting VD/DV or LATERAL switch (No. 16 of Fig. 5).
• Set body size by selecting body size switches (No. 17 of Fig. 5).
• Set body position by selecting body position switches (No. 18 of Fig. 5).
• After all settings are fi nished, selected radiation techniques will be displayed on kV and mAs indicators (No. 25 and 26
of Fig. 5). Then, the preparation of exposure is completed.
Storing new APR Data in Memory (Initialization or Renewal)
1. If the APR function is off, press the APR switch (No. 15 of Fig. 5).
2. Select a body direction, using the body direction switches (No. 16 of Fig. 5).
3. Select a body size, using the body size switches (No. 17 of Fig. 5).
4. Select an APR position to which new data are stored, using the position switches (No. 18 of Fig. 5).
5. Set new kV and mAs data by using the kV and mAs switches (No. 19, 20, 21, and 22 of Fig. 5).
6. Keep pushing the APR switch (No. 15 of Fig. 5) for approximately 2 seconds until the buzzer sounds. Then, new APR data
are stored in the memory.
Note!
There are no factory settings in the APR memory. Please register a set of APR data for your application before you
use the unit fi rst time.

9
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
4. OPERATION
Assembly
Unpack the unit and inspect it for possible damage. Extend the cable out to their fullest length. Pay careful attention to the
cables and inspect them for worn or broken insulation. If they show signs of undue wear, do not plug the unit in or attempt
to use it. Connect a plug of the hand switch cable to the socket (No. 6 of Fig. 4) for a plug of the hand switch cable.
Then connect a plug of the line cable to the socket (No. 9 of Fig. 4) for a plug of the line cable and the other plug to the power
source, confi rming the power switch (No. 8 of Fig. 4) is at “OFF” position.
Preparation before making the Exposure
At the fi rst installation or if the unit has not been used for more than 2 weeks, a warming up procedure of the X-Ray tube is
necessary to ensure the longevity of the X-Ray tube (tube aging).
A recommended warming up procedure is as below:
1. Suffi cient radiation protection should be taken.
2. Make the following exposures at 15 seconds intervals:
– 5 exposures at 60 kV/ 5.0 mAs
– 5 exposures at 80 kV/ 5.0 mAs
– 5 exposures at 120 kV/ 5.0 mAs
Once this aging procedure is performed, it is not required for next time. So the unit is ready for immediate exposure unless
has been not in use for more than 2 weeks.
How to Operate
1. Turn the power switch (No. 8 of Fig. 4) to “ON” position and make sure the kV and mAs displays (No. 25 and 26 of Fig. 5) are
lighted.
2. Select proper technique for the exposure, using the kV selector and mAs selector (No. 19, 20, 21 and 22 of Fig. 5).
3. In case the APR technique is to use please see pages 10 and 11 (The APR technique).
4. By pressing the collimator lamp switch (No. 23 of Fig. 5), the halogen lamp is lighted. Illuminated area is adjusted by
turning two X-Ray fi eld adjustment knobs (No. 3 of Fig. 3 and No. 4 of Fig. 2).
The center of the X-Ray fi eld is obtained by two crossing lines. Two laser pointers (No. 12 of Fig. 1) are also lighted.
Thus the crossing point (the distance between two beams at the crossing point is within 5 mm) of these laser beam makes
it possible to obtain quick and easy confi rmation of 75 ± 2 cm of SID and almost the center of a radiographic fi eld (which is
considered to be within the range of 1.5 cm from center of the crossing point of the collimator) at 75 cm of SID even under
the sunlight. Those lights are extinguished automatically after 30 seconds in order to save the life of bulbs and prevent from
overheating.
5. To make an exposure, press the hand switch half way down. After about 2 seconds after this fi rst push, the fi lament of the
tube is heated. The ready lamp lights after the heating of fi lament.
Then depress the hand switch fully down for X-Ray exposure. The X-Ray lamp lights during the exposure, which informs
you about the exposure. Audible buzzer sounds at the end of the exposure
6. After the exposure, the wait lamp lights and next exposure is ready when this lamp is extinguished. This wait lamp also
works as the alarm lamp and the lamp is fl ickering continuously in case any issue occurs in the circuit.

10
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
Notes!
• The exposure should be created by two step depression as stated above. However, full depression at one time
is also possible. In this case, the exposure is obtained after approx. 2 seconds after the full depression.
• The exposure button of the hand switch should be depressed until the exposure is fully completed.
• The exposure can be terminated at any time by releasing the exposure button. The wait lamp is fl ickering after
this interruption. Press reset button to return the unit to normal operation.
• The unit needs to have a waiting period of 10 seconds until next exposure in order to protect the system from
damage by overheating that would be caused by continuous exposures. The waiting time is fi xed at 10 seconds.
No exposures can be taken during this period.
• DThe device is only to be operated with the included original cable (Fig. 6).
• The device is explicitly to be used with the help of a stand (Fig. 7).
Caution!
Do not place the laser pointer for direct eye exposure since the laser beam is dangerous to the eyes.
Fig. 7Fig. 6

11
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
5. SPECIFICATIONS
System Confi guration
• Main unit includes:
– X-Ray monoblock (Tube & H.T. Transformer)
– Digital controller
– Built-in collimator
• Power cable (6 meter long)
• Hand switch with curled cable (2.5 meter long at full extension)
Performance Specifi cations
• Controller: High-frequency inverter type
• Rating
– Tube voltage: 40 – 120 kV (in 1 kV steps)
– mAs setting: 0,3 – 100 mAs (in 26 kV steps)
0.3 0.4 0.5 0.6 0.8 1.0 1.3 1.6 2.0 2.5 3.2 4.0 5.0 6.3 8.0 10 13 16 20 25 32 40 50 63 80 100
• mA setting: 30 – 100 mA (automatic)
40–50 kV
0.3–16 mAs / 100 mA
20–100 mAs / 80 mA
83–90 kV
0.3–25 mAs / 50 mA
32–100 mAs / 40 mA
51–62 kV
0.3–20 mAs / 80 mA
25–50 mAs / 70 mA
63–100 mAs / 60 mA
91–100 kV
0.3–10 mAs / 50 mA
13–50 mAs / 40 mA
63–100 mAs / 30 mA
63–72 kV
0.3–16 mAs / 70 mA
20–40 mAs / 60 mA
50–100 mAs / 50 mA
101–110 kV
0.3–20 mAs / 40 mA
25–100 mAs / 30 mA
73–82 kV
0.3–16 mAs / 60 mA
20–63 mAs / 50 mA
80–100 mAs / 40 mA
111–120 kV
0.3–10 mAs / 40 mA
13–100 mAs / 30 mA
• Output power: Max. 5.04 kW (at 72 kV / 70 mA, 16 mAs)
• Max. deviation:
kV: ± 3 %
mA: ± 5 %
mAs: ± 10 %
Input Specifi cations
• Power requirement: AC 200 – 240 V ± 10 % (50 / 60 Hz)
• Input current: Max. 40 A (short-time rating)

12
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
X-Ray Tube
• Type: OX / 110-15 (CEI)
• Focal spot: 1,8 mm (large)
• Target angle: 15 degrees
• Anode heat storage capacity: 30 kJ (42 kHU)
• Inherent fi ltration: higher than 0.5 mm Al eq.
• Total fi ltration: higher than 2.5 mm Al eq.
Collimator
Irradiation fi eld light projection type
Protection Type for Electrical Shock
Class I
Protection for Electrical Shock
B-type device
X-Ray Leakage
Within 1 mGy/h at 1 m from focal spot
Optimum Ambient Conditions
Temperature: 20 ± 15 °C
Humidity: 69 ± 20 % rF
Dimensions (in cm)
L 35 x W 20.3 x H 16
Net Weight
14 kg (only main unit)
Included Accessory
• Aluminium case
• User Manual
• Test data sheet
• Hand switch
• Power cord with fi lter

13
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
6. POWER SOURCE FOR HIRAY 5
The recommended input conditions of the HiRay 5 are as follows:
1. Input voltage: AC 200 – 240 V
2. Input current: 30 A (input current depends on the exposure conditions and the input voltage)
Please take the following precautions during installation:
Case A:
To attain maximum performance, connect the HiRay 5 to a 30 A or higher power source, setting the circuit breaker at
30 A.
Wire size of the power cord: AWG12
Length of the cord: 6 m or less
Connect the power cord directly to the breaker on the
electrical circuit
HiRay 5
Circuit breaker
30 A
Case B:
If using the HiRay 5 with a receptacle, do not connect other devices to the same circuit.
Circuit breaker
15–20 A
Not connected
Not connected Not connected
HiRay 5
Case C:
Operation of the HiRay 5 is not advised if other devices share the same circuit. Adequate power cannot be supplied
to the HiRay 5 and can overload the circuit tripping breaker resulting in a decline in output power of the X-Ray and
potential damage to the HiRay 5 and the other devices on the circuit.
Circuit breaker
15–20 A
Other device
Other device Other device
HiRay 5

14
USER MANUAL HIRAY 5 X-RAY MACHINE
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com
Other Precautions
• The permissible range of the input voltage is ± 10 % of the rated value (180 V – 264 V AC). If exceeding the range, use a
transformer to step down the voltage to the appropriate value.
• Make sure to ground the HiRay 5 to avoid electrical shock.
• Pay attention to the change of the input voltage during exposure, if it drops under 180 V due to a drop in voltage, the HiRay
5 might malfunction even though it was installed correctly as in either Case A or Case B above.
• When using wired connection as noted in Case B, after unplugging the HiRay 5 do not touch its electrode directly after
unplugging it as there is a danger of electric shock. Wait for at least 10 seconds for the unit to discharge.
• To avoid dropping the input voltage, do not use an extension cord.

15
USER MANUAL HIRAY 5 X-RAY MACHINE
NOTES
T [phone] | F [phone] | [e-mail] | www.eickemeyer.com

GERMANY
EICKEMEYER KG
Eltastraße 8
78532 Tuttlingen
T [phone]
F [phone]
[e-mail]
www.eickemeyer.de
SWITZERLAND
EICKEMEYER AG
Sandgrube 29
9050 Appenzell
T [phone]
F [phone]
[e-mail]
www.eickemeyer.ch
UNITED KINGDOM
EICKEMEYER Ltd.
3 Windmill Business Village
Brooklands Close
Sunbury-on- Thames
Surrey, TW16 7DY
T [phone]
F [phone]
[e-mail]
www.eickemeyer.co.uk
POLAND
EICKEMEYER Sp. z o.o.
Al. Jana Pawła II 27
00-867 Warszawa
T [phone]
F [phone]
[e-mail]
www.eickemeyer.pl
DENMARK
EICKEMEYER ApS
Lysbjergvej 6, Hammelev
6500 Vojens
T [phone]
[e-mail]
www.eickemeyer.dk
NETHERLANDS
EICKEMEYER B.V.
Bedrijventerrein Pavijen-West
Bellweg 44
4104 BJ Culemborg
T [phone]
[e-mail]
www.eickemeyer.nl
ITALY
EICKEMEYER S.R.L.
Via G. Verdi 8
65015 Montesilvano (PE)
T [phone]
F [phone]
[e-mail]
www.eickemeyer.it
CANADA
EICKEMEYER Inc.
617 Douro Street, Suite #205
Stratford, Ont. Canada
N5A 0B5
T [phone]
F [phone]
[e-mail]
www.eickemeyervet.ca
