Common sense features, uncommon quality
Widescreen LCD Monitors

The FlexScan S series are energy-saving and ergonomic monitors in 24.1" and
22" sizes with VA and TN panel technology.
Designed for business use, they are also ideal
for CAD and amateur digital photography.
Optimized Brightness with Auto EcoView
A sensor on the front bezel measures ambient light
and optimizes the screen’s brightness, ensuring that
these monitors are never too bright or too dark. This
results in improved ergonomics and reduced eye strain,
while cutting power consumption by up to 51%.
Confirm Power Savings with EcoView Index
A user-activated on-screen index shows the level
of power savings in correlation with the monitors’
brightness to encourage environmental consciousness.
EyeCare Mode
The FlexScan S2433W, S2243W, and S2233W incorpo-
rate EyeCare mode which helps to mitigate eye fatigue
when working in very dim ambient light. With just a
touch of a button, you can reduce screen brightness to
a minimum of 4 cd/m2. EyeCare mode also works with
the Auto EcoView function by automatically increasing
or decreasing luminance to user-defined preset levels,
thereby more accurately achieving ideal screen bright-
ness in very dimly lit rooms.
EyeCare Manager
EIZO’s EyeCare Manager prompts workers to take
scheduled breaks to avoid eye fatigue caused by pro-
longed monitor use. EyeCare also totals and displays
on-screen the monitors’ usage hours for each day and
month to promote improved work habits.
Improved Efficiency, Reduced Visual Fatigue
EIZO conducted a survey in 2008 to establish the rela-
tionship between eye fatigue and monitor use. Results
showed that features like Auto EcoView, ergonomic
stands, and the EyeCare Manager helped reduce eye
fatigue and improved work efficiency by 12.5%.
For a white paper regarding this study please visit
www.eizo.com/global/support/wp/pdf/wp_08-001.pdf
Zero Watts When Turned Off
The power save mode and off timer on these moni-
tors reduces their energy consumption to less than
1.5 watts. When turned off via the main power
switch, they consume no electricity at all.
Preset Modes for Optimum Viewing
EIZO’s Fine Contrast function has six preset modes:
Text mode for office applications, Movie mode for
video, Picture mode for graphics, sRGB mode for web
browsing, EyeCare mode for use in very dimly-lit envi-
ronments, and Custom mode for user-defined settings.
Model Auto EcoView
OFF*
Auto EcoView
ON
Power Reduction
FlexScan S2202W 38 W 23 W 39%
FlexScan S2233W 66 W 32 W 51%
FlexScan S2243W 69 W 36 W 47%
FlexScan S2402W 43 W 27 W 38%
FlexScan S2433W 71 W 40 W 43%
* Figures assume monitors are set to the default factory brightness of 100%.
Increases in Quantity of Monitor Work
Quantity of Work
Measurement Condition
Standard
(maximum brightness)
Appropriate
brightness
Appropriate brightness
+ correct working posture,
regular breaks
[%]115
110
105
100
0
4.6%
increase
7. 9%
increase
100%
104.6%
112.5%
EyeCare reminds
workers to take
regular breaks
to prevent eye
fatigue.
When EcoView
Index is fully
illuminated, the
monitor is operat-
ing at optimum
energy efficiency.
Auto EcoView opti-
mizes the screen’s
brightness to levels
akin to viewing
a sheet of paper
under ambient light
conditions.
Auto EcoView Sensor
Compact,
High Resolution Screen
The FlexScan S2243W features a 16:10 aspect ratio
with a 1920 × 1200 native resolution. Thanks to its
0.247 mm pixel pitch and display of 103 pixels per
inch, it shows 30% more information than a typi-
cal 22" monitor with a 1680 × 1050 resolution. The
FlexScan S2243W displays the same amount of infor-
mation as a typical 24.1" monitor, but occupies 10%
less desk space. This is ideal for offices or trading
floors where a 24.1" monitor is desired, but cannot be
installed due to space constraints.
511 mm566 mm
24.1" 22"
Typical 24.1" monitor FlexScan S2243W
The FlexScan S2243W occupies 10% less desk space than
a typical 24.1" monitor, but displays the same amount of
information.

Next Generation Connectivity
The FlexScan S2402W and S2202W come with
DVI-D (digital) and D-Sub (analog) inputs while the
other three models also include a DisplayPort (digi-
tal) input. With DisplayPort, audio and video signals
are transmitted via a single, high-bandwidth cable
at distances up to 15 meters without any signal
degradation.
DVI Input Level Adjustment
Compensates for degradation of image quality that
may occur when connecting a monitor with a signal
switch box or via a long cable.
Individual Adjustment of Gamma
To provide better image consistency in multi-monitor
environments, EIZO performs advanced gamma
adjustment at the factory, which minimizes discrep-
ancies among monitor gamma characteristics.
Placement Flexibility
All models except the FlexScan S2202W come with
the highly versatile FlexStand (shown below) which
offers title, swivel, portrait rotation, and up to 174
mm of height adjustment. The FlexStand S2202W
comes with a stand that features 100 mm of height
adjustment, tilt, swivel, and portrait mode.
Power Management Software
EIZO EcoView NET software allows your organiza-
tion to reduce its electric bills while minimizing its
burden on the environment by centralizing control
over the power settings of monitors on a network.
For FlexScan S series and other EIZO monitors
that support DDC/CI, you can adjust the brightness,
turn the Auto EcoView function on and off,
and lock the control buttons to prevent tampering
with screen settings. You can also switch a PC’s
primary power and a monitor’s secondary power on
and off regardless of the manufacturer.
For details see www.eizo.com/global/products/
accessories/flexscan/ecoview_net/index.html
Organize Applications with EIZO ScreenSlicer
This bundled
software utility
lets you more
effectively use
your screen
through partition-
ing. Simply drop
your windows
into configurable
partitioned areas and they will be aligned instantly
(Windows 7, Vista, and XP compatible).
ScreenManager Pro for LCD and ScreenTuner
Developed for Windows and Mac OSes respectively
and available from www.eizo.com, these two free
applications let you adjust your monitor’s color with
your mouse rather than the OSD menu buttons. With
ScreenManager Pro for LCD you can also assign a
preset mode to a specific application so that mode
becomes active whenever the application is in use.
Commitment to Quality
While outsourcing
production is now
common practice in
the monitor industry,
EIZO continues to
manufacture its prod-
ucts the same way it
has throughout its 40
year history — with its own staff at its own factories.
This allows EIZO to keep close control over pro-
duction quality and offer the industry’s only 5-year
manufacturer’s limited warranty.
Customer Assurance
EIZO strives to create a better work environment by
complying with strict environmental performance
requirements for low energy consumption, product
and package recyclability, and manufacturing pro-
cesses, as well as specific ergonomic and functional
conditions. This has earned all monitors in this bro-
chure the TCO Displays 5.0 certification.
S2433W
S2243W
S2233W
S2433W
S2243W
S2233W
DisplayPort
Connector
DisplayPort DVI-D D-Sub
Software windows aligned in parti-
tioned areas.
,THPS
>VYK7YVJLZZVY
)YV^ZLY
30°
Tilt
Height
Adjustment Portrait Swivel
Right
90°
344°
174
mm
Wide Color Gamut /
EasyPIX Compatibility
The wide color gamut of the FlexScan S2243W and
S2233W reproduces 95% of Adobe RGB, while
that of the S2433W reproduces 96%
of Adobe RGB. Compat-
ibility with the optional EIZO
EasyPIX accessory allows for
simple color match-
ing between monitor
and photo prints.

153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan
Phone [phone] Fax: [phone]
www.eizo.com
© 2010 Eizo Nanao Corporation
All product names are trademarks or registered trademarks of their respective companies.
EIZO EcoView NET, EIZO ScreenSlicer, and EIZO EasyPIX are tradmarks, and ScreenMan-
ager, FlexScan, and EIZO are registered trademarks of Eizo Nanao Corporation.
Specifications are subject to change without notice.
Panel Size 24.1" / 61 cm (611 mm diagonal) 24.1" / 61 cm (611 mm diagonal) 22" / 56 cm (558 mm diagonal) 22" / 56 cm (558 mm diagonal) 22" / 56 cm (558 mm diagonal)
Display Size (H × V) 518.4 × 324 mm 518.4 × 324 mm 473.8 × 296.1 mm 473.8 × 296.1 mm 473.8 × 296.1 mm
Type VA (with overdrive circuit) TN VA (with overdrive circuit) VA (with overdrive circuit) TN
Viewing Angles (H, V) 178°, 178° (at contrast ratio of 10:1) 170°, 160° (at contrast ratio of 10:1) 178°, 178° (at contrast ratio of 10:1) 178°, 178° (at contrast ratio of 10:1) 170°, 160° (at contrast ratio of 10:1)
178°, 178° (at contrast ratio of 5:1)
Brightness 360 cd/m2300 cd/m2350 cd/m2350 cd/m2300 cd/m2
Contrast Ratio 1000:1 1000:1 1200:1 1200:1 1000:1
Response Time (Typical) Gray-to-gray: 6 ms, black-white-
black: 16 ms Gray-to-gray: – , black-white-black: 5 ms Gray-to-gray: 6 ms, black-white- black: 12 ms Gray-to-gray: 6 ms, black-white- black: 12 ms Gray-to-gray: – , black-white-black: 5 ms
Native Resolution 1920 × 1200 (16:10 aspect ratio) 1920 × 1200 (16:10 aspect ratio) 1920 × 1200 (16:10 aspect ratio) 1680 × 1050 (16:10 aspect ratio) 1680 × 1050 (16:10 aspect ratio)
Pixel Pitch 0.270 × 0.270 mm 0.270 × 0.270 mm 0.247 × 0.247 mm 0.282 × 0.282 mm 0.282 × 0.282 mm
Display Colors 16.77 million from a palette of 1.06
billion 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion
Wide Gamut Coverage Adobe RGB: 96%, 92% vs. NTSC – Adobe RGB: 95%, 92% vs. NTSC Adobe RGB: 95%, 92% vs. NTSC –
Look-Up Table 10 bits per color 10 bits per color 10 bits per color 10 bits per color 10 bits per color
Video
and USB
D-Sub mini 15 pin •••••
DVI-D 24 pin • (with HDCP support) • (with HDCP support) • (with HDCP support) • (with HDCP support) • (with HDCP support)
DVI-I 29 pin –––––
DisplayPort • (with HDCP support) –• (with HDCP support) • (with HDCP support) –
Analog Scan. Freq. (H, V) 31 – 94 kHz, 55 – 76 Hz 31 – 94 kHz, 55 – 76 Hz 31 – 94 kHz, 55 – 76 Hz 31 – 82 kHz, 55 – 76 Hz 31 – 82 kHz, 55 – 76 Hz
Digital Scan. Freq. (H, V) 31 – 76 kHz, 59 – 61 Hz (VGA Text:
69 – 71 Hz)
31 – 76 kHz, 59 – 61 Hz (VGA Text:
69 – 71 Hz)
31 – 76 kHz, 59 – 61 Hz (VGA Text:
69 – 71 Hz)
31 – 65 kHz, 59 – 61 Hz (VGA Text:
69 – 71 Hz)
31 – 65 kHz, 59 – 61 Hz (VGA Text:
69 – 71 Hz)
USB Ports / Standard 1 upstream, 2 downstream / USB 2.0 – 1 upstream, 2 downstream / USB 2.0 1 upstream, 2 downstream / USB 2.0 –
Audio Speakers 0.5 W + 0.5 W speakers 0.5 W + 0.5 W speakers 0.5 W + 0.5 W speakers 0.5 W + 0.5 W speakers 0.5 W + 0.5 W speakers
Input / Output Terminals 3.5 mm stereo jack / 3.5 mm head-
phone jack 3.5 mm stereo jack / 3.5 mm head- phone jack 3.5 mm stereo jack / 3.5 mm head- phone jack 3.5 mm stereo jack / 3.5 mm head- phone jack 3.5 mm stereo jack / 3.5 mm head- phone jack
Power Power Requirements AC 100 – 120 V / 200 – 240 V, 50
/ 60 Hz
AC 100 – 120 V / 200 – 240 V, 50
/ 60 Hz
AC 100 – 120 V / 200 – 240 V, 50
/ 60 Hz
AC 100 – 120 V / 200 – 240 V, 50
/ 60 Hz
AC 100 – 120 V / 200 – 240 V, 50
/ 60 Hz
Power Consumption 40 W (typical), 95 W (maximum) 27 W (typical), 58 W (maximum) 36 W (typical), 90 W (maximum) 32 W (typical), 90 W (maximum) 23 W (typical), 51 W (maximum)
Power Save Mode Less than 1.5 W Less than 0.7 W Less than 1.5 W Less than 1.5 W Less than 0.7 W
Physical
Specifi-
cations
Height Adj. Range 157 mm 157 mm 174 mm 174 mm 100 mm
Tilt / Swivel / Pivot 30° Up, 0° Down / 172° Right, 172°
Left / 90° 30° Up, 0° Down / 172° Right, 172° Left / 90° 30° Up, 0° Down / 172° Right, 172° Left / 90° 30° Up, 0° Down / 172° Right, 172° Left / 90° 30° Up, 0° Down / 35° Right, 35° Left / 90°
Dimensions With Stand: 566 × 381.5 – 538.5 ×
242 – 256 mm; Without Stand: 566×
367 × 85 mm
With Stand: 566 × 381.5 – 538.5 ×
242 – 256 mm; Without Stand: 566×
367× 85 mm
With Stand: 511 × 347.5 – 521.5 ×
240.5 – 256 mm; Without Stand:
511 × 333 × 85 mm
With Stand: 511 × 347.5 – 521.5 ×
240.5 – 256 mm; Without Stand:
511 × 333 × 85 mm
With Stand: 507 × 439 – 521 ×
208.5 mm; Without Stand: 507 ×
333 × 74 mm
Net Weight With Stand: 10.2 kg; Without Stand:
7.2 kg With Stand: 10.2 kg; Without Stand: 7.2 kg With Stand: 9.6 kg, Without Stand: 6.6kg With Stand: 9.6 kg; Without Stand: 6.6kg With Stand: 8.8 kg; Without Stand: 5.8 kg
EcoView
Features
Auto EcoView •••••
EcoView Index •••••
OSD
Adjust-
ment
Func-
tions
Screen Adjustment Clock, Phase, Position, Range (Auto),
Signal Filter, Screen Size (full screen,
enlarge, normal), Smoothing (5
stages), Border Intensity
Clock, Phase, Position, Range (Auto),
Signal Filter, Screen Size (full screen,
enlarge, normal), Smoothing (5
stages), Border Intensity
Clock, Phase, Position, Range (Auto),
Signal Filter, Screen Size (full screen,
enlarge, normal), Smoothing (5
stages), Border Intensity
Clock, Phase, Position, Range (Auto),
Signal Filter, Screen Size (full screen,
enlarge, normal), Smoothing (5
stages), Border Intensity
Clock, Phase, Position, Range (Auto),
Signal Filter, Smoothing (5 stages)
Color Adjustment Brightness, Contrast, Gamma, Tem-
perature, Saturation, Hue, Gain, Reset
Brightness, Contrast, Gamma, Tem-
perature, Saturation, Hue, Gain, Reset
Brightness, Contrast, Gamma, Tem-
perature, Saturation, Hue, Gain, Reset
Brightness, Contrast, Gamma, Tem-
perature, Saturation, Hue, Gain, Reset
Brightness, Contrast, Gamma, Tem-
perature, Saturation, Hue, Gain, Reset
Power Management Power Save (VESA DPM, DisplayPort
Rev. 1.1a, and DVI DMPM), Off Timer
Power Save (VESA DPM and DVI
DMPM), Off Timer
Power Save (VESA DPM, DisplayPort
Rev. 1.1a, and DVI DMPM), Off Timer
Power Save (VESA DPM, DisplayPort
Rev. 1.1a, and DVI DMPM), Off Timer
Power Save (VESA DPM and DVI
DMPM), Off Timer
Sound Volume, Power Save, Source
(DisplayPort)
Volume Volume, Power Save, Source
(DisplayPort)
Volume, Power Save, Source
(DisplayPort)
Volume
Other Settings Signal Switching, Product Information
(name, serial number, resolution, operat-
ing time, etc.), OSD Menu Settings,
Adjustment Lock, DDC/CI Lock, DVI
Input Level, Languages (English, French,
German, Italian, Japanese, Simplified
and Traditional Chinese, Spanish, Swed-
ish), Power Indicator, Reset
Signal Switching, Product Information
(name, serial number, resolution, operat-
ing time, etc.), OSD Menu Settings,
Adjustment Lock, DDC/CI Lock, DVI
Input Level, Languages (English, French,
German, Italian, Japanese, Simplified
and Traditional Chinese, Spanish, Swed-
ish), Power Indicator, Reset
Signal Switching, Product Information
(name, serial number, resolution, operat-
ing time, etc.), OSD Menu Settings,
Adjustment Lock, DDC/CI Lock, DVI
Input Level, Languages (English, French,
German, Italian, Japanese, Simplified
and Traditional Chinese, Spanish, Swed-
ish), Power Indicator, Reset
Signal Switching, Product Information
(name, serial number, resolution, operat-
ing time, etc.), OSD Menu Settings,
Adjustment Lock, DDC/CI Lock, DVI
Input Level, Languages (English, French,
German, Italian, Japanese, Simplified
and Traditional Chinese, Spanish, Swed-
ish), Power Indicator, Reset
Signal Switching, Product Information
(name, serial number, resolution, operat-
ing time, etc.), OSD Menu Settings,
Adjustment Lock, DDC/CI Lock, DVI
Input Level, Languages (English, French,
German, Italian, Japanese, Simplified
and Traditional Chinese, Spanish, Swed-
ish), Power Indicator, Reset
Other
Features
Preset Modes Fine Contrast (EyeCare, Text, Picture,
Movie, sRGB, Custom), Auto Fine
Contrast1
Fine Contrast (Text, Picture, Movie,
sRGB, Custom), Auto Fine Contrast1Fine Contrast (EyeCare, Text, Picture, Movie, sRGB, Custom), Auto Fine
Contrast1
Fine Contrast (EyeCare, Text, Picture,
Movie, sRGB, Custom), Auto Fine
Contrast1
Fine Contrast (Text, Picture, Movie,
sRGB, Custom), Auto Fine Contrast2
ScreenManager Pro
for LCD
•••••
ScreenTuner •–••–
General Available Cabinet Colors Gray, Black Gray, Black Gray, Black Gray, Black Gray, Black
Certifications and
Standards
TCO Displays 5.0, EPEAT Gold (US),
TÜV/Ergonomics (including ISO
13406-2), TÜV/GS, c-Tick, CE, CB,
cTÜVus, FCC-B, Canadian ICES-
003-B, TÜV/S, VCCI-B, EPA Energy
Star, RoHS, WEEE, CCC, GOST-R
TCO Displays 5.0, EPEAT Silver
(US), TÜV/Ergonomics (including
ISO 13406-2), TÜV/GS, c-Tick, CE,
CB, cTÜVus, FCC-B, Canadian ICES-
003-B, TÜV/S, VCCI-B, EPA Energy
Star, RoHS, WEEE, CCC, GOST-R
TCO Displays 5.0, EPEAT Gold (US),
TÜV/Ergonomics (including ISO
13406-2), TÜV/GS, c-Tick, CE, CB,
cTÜVus, FCC-B, Canadian ICES-
003-B, TÜV/S, VCCI-B, EPA Energy
Star, RoHS, WEEE, CCC, GOST-R
TCO Displays 5.0, EPEAT Gold (US),
TÜV/Ergonomics (including ISO
13406-2), TÜV/GS, c-Tick, CE, CB,
cTÜVus, FCC-B, Canadian ICES-
003-B, TÜV/S, VCCI-B, EPA Energy
Star, RoHS, WEEE, CCC, GOST-R
TCO Displays 5.0, EPEAT Silver
(US), TÜV/Ergonomics (including
ISO 13406-2), TÜV/GS, c-Tick, CE,
CB, cTÜVus, FCC-B, Canadian ICES-
003-B, TÜV/S, VCCI-B, EPA Energy
Star, RoHS, WEEE, CCC, GOST-R
Supplied Accessories AC power cord, signal cables (DVI-D –
DVI-D, D-Sub – D-Sub), USB cable,
audio cable, EIZO LCD Utility Disk (PDF
user’s manual, ScreenManager Pro for
LCD [USB], ScreenSlicer software),
setup guide, warranty card
AC power cord, signal cables (DVI-D –
DVI-D, D-Sub – D-Sub), audio cable,
EIZO LCD Utility Disk (PDF user’s
manual, ScreenManager Pro for LCD
[DDC/CI], ICC Prole, ScreenSlicer
software), setup guide, warranty card
AC power cord, signal cables (DVI-D –
DVI-D, D-Sub – D-Sub), USB cable,
audio cable, EIZO LCD Utility Disk (PDF
user’s manual, ScreenManager Pro for
LCD [USB], ScreenSlicer software),
setup guide, warranty card
AC power cord, signal cables (DVI-D –
DVI-D, D-Sub – D-Sub), USB cable,
audio cable, EIZO LCD Utility Disk (PDF
user’s manual, ScreenManager Pro for
LCD [USB], ScreenSlicer software),
setup guide, warranty card
AC power cord, signal cables (DVI-D –
DVI-D, D-Sub – D-Sub), audio cable,
EIZO LCD Utility Disk (PDF user’s
manual, ScreenManager Pro for LCD
[DDC/CI], ICC Prole, ScreenSlicer
software), setup guide, warranty card
Warranty Five Years2Five Years2Five Years2Five Years2Five Years3
1The bundled ScreenManager Pro for LCD is needed to activate Auto Fine Contrast. The USB version is compatible with Microsoft Windows 7/Vista/XP/2000. The DDC/Ci version is compatible with 7/Vista. 2The usage time is limited to 30,000
hours or less, and the warranty period of the LCD panel is limited to three years from the date of purchase.
SPECIFICATIONS
