EKOM DK50-3X4VR/M User manual

User manual
EN
DK50-3X4VR/M

October 2018
Z_2195/2018
Chap. 2 – pgs.5

COMPRESSOR
DK503x4VRM_ED
EKOM spol. s r. o.
Priemyselná 5031/18
SK-921 01 Piešťany
Slovak Republic
tel.: [phone]
fax: [phone]
www.ekom.sk
email: [email protected]
DATE OF LAST REVISION
10/2018
NP-DK50-3x4VRM_ED-EN-
2_10-2018
112000284-0001

DK50 3x4VR/M
NP-DK50-3x4VRM_ED-EN-2_10-2018 - 4 - 10/2018
CONTENTS
IMPORTANT INFORMATION ........................................................................................................... 5
1.CE MARKING ........................................................................................................................... 5
2.CONTRAINDICATIONS AND SIDE-EFFECTS ........................................................................ 5
3.NOTICE .................................................................................................................................... 5
4.WARNINGS AND SYMBOLS ................................................................................................... 7
5.STORAGE AND TRANSPORT ................................................................................................ 7
6.TECHNICAL DATA .................................................................................................................. 8
7.PRODUCT DESCRIPTION .................................................................................................... 10
8.PRODUCT FUNCTIONALITY ................................................................................................ 11
9.PNEUMATIC SCHEMATIC .................................................................................................... 13
OPERATION ................................................................................................................................... 14
10.TURNING THE COMPRESSOR ON ...................................................................................... 14
INSTALLATION .............................................................................................................................. 18
11.CONDITIONS FOR USE ........................................................................................................ 18
12.PLACEMENT OF THE COMPRESSOR ................................................................................ 19
13.COMPRESSED AIR CONNECTIONS ................................................................................... 20
14.ELECTRICAL CONNECTIONS .............................................................................................. 21
15.COMMISSIONING ................................................................................................................. 22
16.SWITCHING THE COMPRESSOR ON ................................................................................. 22
17.SWITCHING OFF AND SHUTTING DOWN THE COMPRESSOR ....................................... 23
MAINTENANCE .............................................................................................................................. 23
18.PRODUCT MAINTENANCE ................................................................................................... 23
TROUBLESHOOTING AND REMEDYING PROBLEMS ............................................................... 28
19.SOLVING COMMON PROBLEMS ......................................................................................... 28
20.REPAIR SERVICE ................................................................................................................. 30
ANNEXES ....................................................................................................................................... 31
21.INSTALLATION RECORD ..................................................................................................... 31

DK50 3x4VR/M
10/2018 NP-DK50-3x4VRM_ED-EN-2_10-2018
- 5-
IMPORTANT INFORMATION
1. CE MARKING
Products labelled with the CE marking meet
the requirements of the European Union
Medical Device Directive (93/42/EEC).
2. CONTRAINDICATIONS AND SIDE-EFFECTS
There are no contraindications or side-effects known.
3. NOTICE
The product is designed and manufactured to
be safe for the user and its surrounding
environment when used in the defined
manner. Keep the following warnings in mind.
This keeps risks to a minimum.
3.1. General warnings
 The user manual aids in correct installation,
operation and maintenance of the product.
It is included with the product and must be
kept close to it at all times. Careful review
of this manual will provide the information
necessary for the proper operation of the
product as intended.
 The product contains a condensing-type of
dryer, which has a separate user manual.
 Only the original packaging ensures
protection of the equipment during
transport. Save this packaging should you
ever have to return the equipment. The
manufacturer is not liable for damages
caused by faulty packaging when returning
a product for transport during the warranty
period.
 Use a fork lift truck or similar hoisting
equipment for any movement or handling of
the product.
 The manufacturer only guarantees the
safety, reliability and function of the
equipment if:
- installation, new settings, changes,
modifications and repairs are performed by
the manufacturer or its representative, or a
service provider authorized by the
manufacturer.
- the product is used pursuant to the user
manual.
3.2. General safetywarnings
 Use and operation of the product must
comply with all local codes and regulations.
The operator and user are responsible for
following all appropriate regulations in the
interests of performing work safely.
 Only the use of original parts guarantees
the safety of operating personnel and
reliable operation of the product itself. Only
use accessories and parts mentioned in the
technical documentation or expressly
approved by the manufacturer.
 The manufacturer assumes no liability for
any damages or other risks if any
accessories or parts other than mentioned
in the technical documentation or expressly
approved by the manufacturer are used.
This warranty does not cover damages
originating from the use of accessories or
consumables other than those specified or
suggested by the manufacturer.
 The user must make sure that the
equipment is functioning correctly and
safely every time it is used.
 The user / operator must be capable of
safely using and properly operating the
product. The user must be trained to
operate the product and must be
experienced.
 Create operating regulations for the person
operating the product.
