ekwb EK-Quantum Reflection PC-O11D D5 PWM D-RGB User manual

USER GUIDE
DISTRIBUTION PLATE
EKQuantum
Reflection PC-O11D D5 PWM D-RGB

Before you start using this product please follow these basic guidelines:
Please carefully read the manual before beginning with the
installation process!
The EK Fittings require only a small amount of force to screw
them firmly in place since the liquid seal is ensured by the
rubber O-ring gaskets.
The use of corrosion inhibiting coolants is always recommended
for any liquid cooling system. EKWB recommends any of the
EKCryofuel for worry-free usage.

- 3 -
TABLE OF CONTENT
BOX CONTENTS 4
PREPARING THE 011D CHASSIS 5
INSTALLING THE DISTRIBUTION PLATE IN THE 011D 6
RECOMMENDED DISTRIBUTION PLATE CONFIGURATIONS 7
CONNECTING THE D-RGB LED STRIP 9
CONNECTING THE PUMP 9
TESTING THE LOOP 10
SUPPORT AND SERVICE 11
SOCIAL MEDIA 11

- 4 -
BOX CONTENTS
EK-Quantum Reflection PC-O11D
D5 PWM D-RGB
M3 x 11 7991DIN (2 pcs) M4 x 14 7991DIN (3 pcs)
Allen Key 2.5 mm (1 pc)
EK-Loop Multi Allen Key
Allen Key 2 mm (1 pc)

- 5 -
PREPARING THE 011D CHASSIS
Before installing the distribution plate, carefully read
the PC case manual.
STEP 1
Unscrew the factory provided screws and remove the top panel
from the case.
STEP 2
STEP 2
Remove side and the front panel from the case.
STEP 1
Factory provided Screws

- 6 -
INSTALLING THE DISTRIBUTION PLATE IN THE 011D
STEP 1
Carefully place the EK-Quantum Reflection PC-O11D D5 PWM D-RGB
distribution plate into the PC case and align the mounting holes.
STEP 1
STEP 2
Secure the distribution plate to the chassis with three (3) M4 x
14 DIN7991 and two (2) M3 x 11 DIN7991 screws (as shown in
the diagram).
STEP 2
M3 x 11 DIN7991
M4 x 14 DIN7991

- 7 -
RECOMMENDED DISTRIBUTION PLATE CONFIGURATIONS
It is mandatory to use at least one of each type of port and all
remaining ports should be sealed using the supplied plugs. The
EK-Loop Multi Allen Key (6mm, 8mm, 9mm) may be used to install
all EK fittings, do not use excessive force.
If one of the prescribed components will not be installed (ie.
bottom radiator or GPU block) then one IN and one OUT port
must still be joined together in order for this distribution plate
to function!
TOP
RADIATOR
OUTLET
GPU INLET
GPU OUTLET
DRAIN
TOP
RADIATOR
INLET
CPU INLET
CPU OUTLET
BOTTOM
RADIATOR
OUTLET
BOTTOM
RADIATOR
INLET

- 8 -
FILL (exterior)
DRAIN (exterior)

- 9 -
CONNECTING THE D-RGB LED STRIP
Plug the 3-pin connector of the distribution plate D-RGB LED light
to the D-RGB HEADER on the motherboard. The LED will work if the
pin layout on the header is as follows: +5V, Digital, Empty, Ground.
D-RGB Header
RGB Header
CONNECTING THE PUMP
The EK-D5 PWM pump has two connectors.
1. 4-pin Molex: It must be connected directly to your PSU at all
times as it is used to power the pump.
2. 4-pin PWM fan: It can be connected to your motherboard’s
CPU_ Fan or designated water pump header. It can also be
connected to a controller. This cable is used to control and report
the rotational speed of the pump. If it’s not connected, the pump
will run at maximum speed (100% PWM).
4-pin molex
connector
4-pin PWM fan
connector

- 10 -
To make sure the installation of EK components was successful, we
recommend you perform a leak test for 24 hours.
When your loop is complete and filled with coolant, connect the
pump to a PSU outside of your system. Do not connect power to
any of the other components. Turn on the PSU and let the pump
run continuously. It is normal for the coolant level to drop during this
process as air collects in the distribution plate.
Inspect all parts of the loop, and in the eventuality that coolant leaks,
fix the issue and repeat the testing process. Ensure that all hardware is
dry before the system is powered on in order to prevent any damage.
TESTING THE LOOP

For assistance please contact:
http://support.ekwb.com/
