ekwb EK-Quantum Volume FLT Series User manual

INSTALLATION MANUAL
EKQuantum
Volume / Kinetic FLT

- 2 -
There are many ways to install your EK-Quantum Volume/Kinetic FLT as
it utilizes a standard fan mounting hole pattern with 15mm spacing, the
same as all EK radiators. The mounting holes have standard M4 threads
with maximum engagement of 10mm. Use of longer screws or screws
with incorrect threads such as those intended for fans or radiators may
damage your product!
Before you start using this product please follow these basic
guidelines:
Please carefully read the manual before beginning with the
installation process!
The EK fittings require only a small amount of force to screw
them firmly in place since the liquid seal is ensured by the
rubber o-ring gaskets.
The use of corrosion inhibiting coolants is always recommended
for any liquid cooling system. EKWB recommends any of the
EK-Cryofuel for worry-free usage.

- 3 -
TABLE OF CONTENT
INSTALLING EK-QUANTUM VOLUME / KINETIC FLT DIRECTLY 5
INSTALLING EK-QUANTUM VOLUME / KINETIC FLT WITH SUPPLIED MOUNTS 6
INSTALLING EK-QUANTUM VOLUME / KINETICFLT RESERVOIR IN TO THE CASE 7
ATTACHING THE FITTINGS 9
CONNECTING THE D-RGB LED STRIP 10
TESTING THE LOOP 10
SUPPORT AND SERVICE 11
SOCIAL MEDIA 11

- 4 -
FLT Reservoir can be mount in multiple directions.
Vertically and horizontally position is optional.
Do not mount FLT Reservoir when the pump is in dead position.

- 5 -
Using the included M4 screws you can mount the reservoir directly
to your chassis or any other standard fan mounting location.
INSTALLING EK-QUANTUM VOLUME / KINETIC FLT DIRECTLY
M4 x 10 DIN
7984 Screw
M4 x 10 DIN
7984 Screw

- 6 -
STEP 1
INSTALLING EK-QUANTUM VOLUME / KINETIC FLT WITH SUPPLIED MOUNTS
To enable installation of the reservoir onto fans, radiators or where
clearance for the pump is required EK supplies a pair of FLT mounts
along with M4 nuts, washers and additional screws. They can be
positioned across any pair of mounting holes in several orientations.
STEP 1
Position the mounts as desired on the reverse side of the reservoir.
STEP 2
Screw the mounts in place using supplied M4x8 screws and 2.5mm
allen key.
STEP 2
M4 x 8 DIN 7984 Screw

- 7 -
3a.
Included M4 nuts, washers and M4x10 screws can be used to mount
the flat reservoir to a fan.
INSTALLING EK-QUANTUM VOLUME / KINETICFLT RESERVOIR IN TO THE CASE
120 mm Fan
UNC 6-32 x 30
ISO 7380 Screw
3b.
Using 30mm long screws supplied with your radiator the reservoir
can be mounted onto the radiator and 25mm thick fans together.
M4 x 10 DIN
7984 Screw
M4 Nut
M4 metal Washer

- 8 -
3c.
Alternatively the shorter 5mm long screws from the radiator may be
used to mount only the reservoir.
M4 x 10 DIN
7984 Screw
M4 Nut
3d.
Lastly the supplied M4 nuts, washers and M4x10 screws may be
used to secure the reservoir to a case with the mounts. This is useful
when there is no clearance behind for the pump or to prevent all
airflow being blocked
UNC 6-32 x 5
ISO 7380 Screw
Radiator
FLT Mount
M4 metal Washer

- 9 -
EK-Quantum Kinetic FLT has two inlet and two outlet ports, one of each
must be used! All 4 unused ports should be blocked using G1/4 plugs.
ATTACHING THE FITTINGS
EK-Quantum Volume FLT has two ports which can be used as inlet or
outlet, the chosen outlet should connect directly to your pump! The
reservoir should be positioned above the pump to ensure it does not
run without coolant. Both unused ports should be blocked using
G1/4 plugs.
FILL
DRAIN
OUTLET
INTLET
OUTLET
FILL
DRAIN
INTLET / OUTLET

- 10 -
CONNECTING THE D-RGB LED STRIP
Plug the 3-pin connector from Water block’s D-RGB LED light to the
DRGB HEADER on the motherboard. The LED will work if the pin
layout on the header is as follows: +5V, Digital, empty, Ground.
Please ensure that the arrow indicated on the connector is
plugged into the +5V line as indicated on your motherboard.
Failure to do so will damage your motherboard or LED strip.
D-RGB Header
RGB Header
TESTING THE LOOP
To make sure the installation of EK components was successful, we
recommend you perform a leak test for 24 hours.
When your loop is complete and filled with coolant, connect the
pump to a PSU outside of your system. Do not connect power to
any of the other components. Turn on the PSU and let the pump
run continuously. It is normal for the coolant level to drop during this
process as air collects in the reservoir.
Inspect all parts of the loop, and in the eventuality that coolant leaks,
fix the issue and repeat the testing process. Ensure that all hardware is
dry before the system is powered on in order to prevent any damage.
