ekwb EK-FC780 GTX Classy Rev.2.0 Backplate Guide

All disclosures, notices and warranty conditions are being written on the back of the box. Revision 1.0. Released on 8th of October, 2013.
Installation and mounting manual for EK-FC780 GTX Classy Rev.2.0
Backplate
This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability
whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at www.ekwb.com for updates. Before
installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box.
STEP 1: GENERAL INFORMATION. Sample picture of nVidia GeForce 780 GTX Classified graphics card.
STEP 2: PREPARING YOUR GRAPHICS CARD
EK-FC780 GTX Classy Backplate Rev.2.0 is very easy to install. First install EK-FC780 GTX Classy series water block according to its installation
manual. If you have it already installed, please check the picture below to see which mounting screws are to be left in their position and which are
to be removed. Please remove the four (4) M3x4 DIN7985 screws and their washers (marked with arrow).
STEP 3: APPLYING THE THERMAL PADS
EK-FC780 GTX Classy Backplate Rev.2.0 features passive cooling of the printed circuit board and it’s components therefore it is mandatory to install
the enclosed thermal pad. Please install enclosed 1mm thick thermal pad (Thermal Pad A –1mm (100x16)) as shown on the picture below. You may
need to trim the excess thermal pad.
Thermal PAD A 1mm
EK-FC780 GTX Classy Backplate Rev.2.0

All disclosures, notices and warranty conditions are being written on the back of the box. Revision 1.0. Released on 8th of October, 2013.
STEP 4: ATTACHING EK-FC780 GTX Classy BACKPLATE Rev.2.0 TO THE GRAPHICS CARD
Take enclosed mounting screws and install them as shown on picture below. EKWB recommends users to start with four (4) M3x8 DIN 7991 and
two (2) M3x4 DIN7985 (HINT: do not tighten screws until they are all positioned in their mounting holes) in the middle of the card and then
continue outwards. The backplate has milled in standoffs, so there is no fear of over tightening of the screws. Nevertheless do not exaggerate with
screwing force as there is no need for it.
(By all means users must also consider that this product is intended to be used only with EK-FC780 GTX Classy series water blocks. No other 3rd
party heat sinks or coolers are supported!)
IMPORTANT DISCLOSURES
VERY IMPORTANT NOTICE: Once the installation is completed, it is a recommended practice to test the cooling circuit for leaks prior to powering up the
computer. We recommend a 24 hour leak test prior to powering up the computer. Do not test the water block using city water pressure. This will rupture the top
of the housing and render the block unusable (and will void your warranty).While all efforts have been made to provide the most comprehensive tutorial possible,
EK Water Blocks assumes no liability expressed or implied for any consequential damage(s) occurring to your equipment as a result of using EK Water Blocks
cooling products, either due to errors or omissions on our part in the above instructions, or due to failure or defect in the EK Water Blocks cooling products.
WARRANTY:
Our products are warranted against defects in materials or workmanship for a period of 24 months beginning from the date of delivery to the final user. During
this period, products will be repaired or have parts replaced at our discretion provided that: (I) the product is returned to the agent from whom it was
purchased; (II) the product has been purchased by an end user and has not used for commercial purposes; (III) the product has not been misused, handled
carelessly, or used in a manner other than in accordance with the instructions provided describing its installation and proper use. This warranty does not confer
rights other than those expressly set out above and does not cover any claims for consequential loss or damage. This warranty is offered as an extra benefit and
does not affect your statutory rights as a consumer. This warranty is voided if the product comes in contact with aggressive UV additives or other improper
liquids.
EK blocks are sealed with warranty void circular label, which proves that the block has withstood a pressure leak test. Removing it will void leak-free guarantee
and not the guarantee on the product itself. Any other RMA issues can be reported to EK Support at http://www.ekwb.com/support for further analysis.
REQUIRED TOOLS AND MOUNTING SCREWS:
Philips head screwdriver scissors 2mm allen key
M3X8 DIN 7991 screw
M3x4 DIN 7985 screw
PVC WASHER
