Electro-Voice REV User manual

Key Features
•950 Possible frequencies in 24MHz
operating band
• Optimized audio path to provide true wired
microphone sound
• Rugged machined aluminum handheld
transmitter with interchangeable
microphone elements
• Cast magnesium bodypack transmitter is
extremely light and durable.
• 5mW or 50mW transmit power on every
transmitter
•REV-Link PC software monitoring and
control of the receivers
•Advanced ClearScan™ scans for the
clearest channel and group of channels
General Description
The RE-V Wireless Microphone system combines frequency agility and
ease of use like no other. The RE-V transmitters and receivers operate over
a 24 MHz bandwidth in the UHF portion of the spectrum. The high quality
audio circuitry and advanced Radio Frequency (RF) signal processing offer
broadcast quality signal-to-noise and audio clarity.
By combining four different frequency bands up to 44 simultaneous
systems can work together on one stage. Advanced Clearscan™ scans all
available channels and displays a sorted list of the best coordinated groups
of channels. The scanning continues and sorts for the clearest channels in
the coordinated group giving the user the best possible channel for their
location.
The entire audio path has been optimized to provide the truest
representation of a wired microphone sound possible in a wireless system.
The Electro-Voice exclusive guitar audio optimization in the bodypack
transmitter and the receiver combine to give that “wired” sound back to the
bassist and guitarist. The guitar setting lowers the low end response down
to 30Hz, pads the input, and changes the audio for the best response
possible from a wireless.
The all new REV-H concert handheld transmitter is about the size and
shape of a wired microphone to encourage proper microphone technique
and uninhibited performances. An alternative REV-PH presentation
handheld includes a user accessible on/off/mute switch and another
lightweight, small handheld.
The Single and Dual receivers are full 19” rack mount units with integrated
mounting hardware and IEC universal power supplies. The REV-D
features antenna pass through that allows 6 channels of receive to be
connected to two antennas with just the cables that come with the units.
Both units have parallel RJ45 jacks that allow the connection of CAN bus
monitoring and control with a PC through the UCC-1 USB to CAN
converter.
REV
UHF Wireless
Microphone System
R

REV-Dual and REV-Single Receiver Specifications
Controls
Front Panel ...........................................On/Off, Menu, Set, Up, Down Buttons
1/4 in. Headset Jack with Selector and Volume
Indicators: LCD Backlit Display ........Group, Channel, Diversity, Label, Set-up Transmitter Battery
Level, Audio Signal Amplitude and RF Signal Strength, Squelch,
Audio output levels, and instrument mode
Connectors
Back Panel: .....................................1/4in. unbalanced adjustable line level output
XLR balanced adjustable line level output
CAN Bus in and out port
Antennas: ......................................................TNC Detachable 1/2 wave
RF Specifications
Frequency Range: ................................C1 Band 614-638 MHz (TV Channels 37-41)
C2 Band 650-674 MHz (TV Channels 44-47)
C3 Band 674-698 MHz (TC Channels 48-51)
C5 Band 722-746 MHz (TV Channels 56-59)
Number of Channels: ..............................950 possible (programmable in 25 kHz steps)
Diversity: .................................................DSP PosiPhaseäTrue Diversity
Squelch:..............................................Tone Code plus Adjustable Amplitude
RF Sensitivity: ..................................................<0.8mV for 12 dB SINAD
FCC Type Acceptance ..............................................Approved under Part 15
Audio Specifications
Frequency Response: ........................................100-15 kHz +/-2 dB Microphone
30-15 kHz +/-2 dB Instrument
Audio Output Level:
Balanced Output Adjustable ....................................10mV-1V RMS Adjustable
Unbalanced Output Adjustable .........................8 mV to 0.755V RMS (100k ohm load)
Distortion: .......................................Less than 0.5% (@ 1kHz, 40 kHz deviation)
Signal-to-noise Ratio:........................................................>110 dB (A)
Dynamic Range: ...............................................................>100 dB
Other
REV-D Antenna Output:............................................................TNC
Powered Antenna Inputs: ...............................................TNC 12Vdc, 15mA
Internal Switching Power Supply: ........................Universal Cord, 90-240 VAC, 50-60 Hz
CAN Bus Monitoring & Control:...............................RJ45 Jacks, REV-Link Software
Size: ....................1.72 in. H x 16 in. W x 12 in. D (43.7mm H x 406.4mm W x 304.8mm D)
dual receiver
POWER
I/O
R
set
menu
select
channel
12
channel 1
monitor
set
menu
channel 2
Single receiver
POWER
I/O
R
monitor
set
menu
channel
DUAL RECEIVER
AUDIO 2
MADE IN U.S.A.
OUT IN
ANTENNA
AUDIO 1 POWER
90-260 VAC 50-60 Hz
12 Vdc
150 mA
Out
PATENT NO. 6,256,484
HIGH
Z
HIGH
Z
OUT IN
ANTENNA
12 Vdc
150 mA
Out
BALANCED BALANCED
REV-D
REMOTE
CAN
BUS
SERIAL NO.
RECEIVER
AUDIO
MADE IN U.S.A.
ANTENNA
POWER
90-260 VAC 50-60 Hz
PATENT NO. 6,256,484
HIGH
Z
BALANCED
REV-S
ANTENNA
SERIAL NO.
REMOTE
CAN
BUS

REV-BP Transmitter
REV-H Handheld Transmitter
REV-PH Presentation Handheld Transmitter
755050755050
GPGP CHCH
REV-BPREV-BP
RR
SetSet
POWERPOWER
OFFOFF - ON- ON LOWLOW
BATTERYBATTERY
Controls: Power On/Off, Set, Up, Down
Indicators: Red LED Low Battery Indicator, Back
lit LCD display showing: Battery Level,
Channel/Group, or Frequency
Battery Life: 8 hours with 9V alkaline typical
Antenna: External 1/4 wave detachable
Connector: TA4F input for microphone, Pin 1 -
ground, Pin 2 - Mic input, Pin 3 - +5
Bias, Pin 4 - +5V through 3k ohm
RF Output Selectable: 5 mW or 50 mW typical
Case Material: Cast Magnesium
Size: 3.75 in. H x 2.6 in. W x 0.9 in D
94 mm H x 66 mm W x 23 mm D
755050
RR
SET
Controls: Power On/Off, Set, Up, Down
Displays: LCD display showing: Battery
Level, Channel/Group or
Frequency
Battery Life: 8 hours with 9V alkaline typical
Antenna: Internal 1/2 wave
Microphone Elements: EV N/D 767a or N/D 967
Dynamic EV RE510 or RE410
Condenser
RF Output Selectable: 5 mW or 50 mW typical
Case Material: High Impact ABS
Size (Length x max diameter): 24.8 cm (9.75 in.) x 52 mm (2.04
in.)
755050
RR
SET
MENU
755050
R
R
A
A
T
E
S
MENU
Controls: Power On/Off, Set, Up, Down
Displays: Backlit LCD display showing: Battery
Level, Channel/Group or Frequency
Battery Life: 10 hours with two AA alkaline typical
Antenna: Internal Proprietary
Microphone Elements: EV N/D 767a or N/D 967 Dynamic
EV RE510 or RE410 Condenser
RF Output Selectable: 5 mW or 50 mW typical
Case Material: Machined Aluminum
Size (Length x max diameter): 24.8 cm (9.75 in.) x 52 mm (2.04 in.)

REV ACCESSORIES AND SPARE PARTS
Description Model Number Order Number
Omnidirectional MicroMiniäLapel Mic: RE90TX 71753318
Unidirectional MicroMiniäLapel Mic: RE92TX 301456000
Unidirectional Horn Mic with Shcok Mount RE920TX 301815000
Lightweight omni headworn Mic: RE97TX 301XXX000
Headworn Cardioid Condenser Mic: HM7 HM7
Guitar Cord: MAC-G2 879526
1/2 Wave RX Antenna (C3 and C5 Bands): FA-1 860031
1/2 Wave RX Antenna (C1 and C2 Bands): CLA-3 870658-3
1/2 Wave Antenna Bracket: AB-2 71138000
UHF Antenna Amplifier (520-806 MHz): UAA-500 7186400
Antenna/Pwr Distribution (600-780 MHz): APD4+ 301614000
Termination Plug for APD4+: TP-2 650095
Directional Rx Antenna (450-900 MHz): LPA-500 LPA-500
Low Loss Coaxial Antenna Cable: CXU-25 ft
CXU-50 ft
CXU-75 ft
CXU-100 ft
71151025
71151050
71151075
71151100
Bodypack Pouch: WP-1000 879553
Cell Phone Style Belt Clip BC-1000 879518
Flat Metal Belt Clip BC-REV-Metal ASY000068000
767a Dynamic Head: RC2-767 ACC000008D7
967 Dynamic Head: RC2-967 ACC000008D9
RE410 Condenser Head: RC2-410 ACC000008C4
RE510 Condenser Head: RC2-510 ACC000008C5
Microphone Stand Adapter: MSA-REV 880308
12000 Portland Avenue South, Burnsville, MN 55337
Phone: [phone], Fax: [phone]
www.electrovoice.com
ãTelex Communications, Inc. 03/2007
Part Number
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact customer Service at:
[phone] Fax: [phone]
Other International locations. For customer orders, contact Customer Service
[phone] Fax: + 1 952 736-4212
For Warranty repair or service information, contact the Service Repair department at:
800/553-5992 or 402/467-5321
For technical assistance, contact Technical Support at: 800/392-3497 or 952/736-4656
Specifications subject to change without notice.
