Electrolux EAT1AX User manual

EAT1AX
EN Blast chiller Operating instructions 2
IT Abbattitore di temperatura Istruzioni per l’uso 16
DE Kühlzelle Bedienungsanleitungen 30
FR Cellule de refroidissement Mode d’emploi 44

2www.electrolux.com
CONTENTS
DESIGNED FOR YOU
Thank you for purchasing an Electrolux appliance. You have chosen a product based
on decades of professional experience and innovation. Ingenious and stylish, it was
designed with you in mind. Optimal performance is guaranteed whenever you wish to
use it. Welcome to Electrolux.
Visit our website to:
For advice, to download our brochures, resolve any fault or obtain information
on support: www.electrolux.com
Register your product for even better service:
www.electrolux.com/productregistration
Buy accessories, consumables and genuine spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER SERVICE AND MAINTENANCE
We always recommend the use of original spare parts.
When contacting the Service Centre, make sure you have the following details at
hand. The information can be found on the data plate: Model, appliance number
(PNC) and serial number.
Caution/Warning - Important Safety information.
General information and tips.
Environmental considerations.
Subject to change.
1. SAFETY INFORMATION ...........................................................................................3
2. SAFETY INSTRUCTIONS .........................................................................................4
3. DESCRIPTION OF THE PRODUCT .........................................................................6
4. CONTROL PANEL .....................................................................................................7
5. PREPARATION FOR INITIAL USE ...........................................................................9
6. DAILY USE ................................................................................................................9
7. TIPS AND RECOMMENDATIONS ..........................................................................13
8. CLEANING AND CARE ...........................................................................................14
9. TROUBLESHOOTING .............................................................................................14
10. ENVIRONMENTAL CONSIDERATIONS ...............................................................15

3ENGLISH
1. SAFETY INFORMATION
Read the instructions with care before installing and
operating the appliance. The manufacturer is not
responsible for injuries and damage caused by improper
installation and use of the appliance. Always keep the
instructions at hand for future reference.
1.1 Safety of children and vulnerable people
• This appliance can be used by children aged 8 years
and older and adults with limited physical, sensory or
mental abilities or lack of experience or knowledge
concerning use of the equipment, only if supervised or
instructed on the use of the appliance and only if they
understand the risks involved.
• Do not allow children to play with the appliance.
• Keep packaging materials out of the reach of children.
• Cleaning and maintenance operations should not be
performed by unsupervised children.
1.2 General safety warnings
• The appliance is designed for domestic use and similar
purposes, for example:
- in country houses, shop kitchens, o󰘲ces and other
work environments;
- by guests at hotels, motels, bed and breakfasts and
in other residential environments.
• Use the appliance only to preserve foods.
• Check that the ventilation openings of the appliance
and in the recessed structure are not obstructed.
• Do not use mechanical devices or other arti󰘰cial
means not recommended by the manufacturer for the
de-icing.
• Do not damage the refrigeration circuit.
• Do not use electrical appliances inside the food
storage components.

4www.electrolux.com
• Do not use water or steam spray to clean the
appliance.
• Clean the appliance with a soft damp cloth. Only use
neutral detergents. Do not use abrasive cleaners,
scouring pads, solvents or metal objects.
• Do not use this appliance to store explosive
substances such as aerosol cans containing a
󰘱ammable propellant.
• If the power cord is damaged, it must be replaced
by the manufacturer, an authorised technician or a
quali󰘰ed person in order to avoid dangerous situations.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
The appliance must be installed
by quali󰘰ed personnel.
• Remove all packaging materials.
• Do not install or use the appliance if it
is damaged.
• Follow the instructions provided with
the appliance.
• Always handle the appliance with
care as it is very heavy. Always wear
safety gloves.
• Make sure that air can circulate freely
around the appliance.
• Wait at least 4 hours before
connecting the appliance to the
mains. This allows the oil to 󰘱ow back
into the compressor.
• Do not install the appliance near
heaters, stoves, ovens and hobs.
The back of the appliance must rest
against the wall with duct.
• Do not install the appliance in an area
exposed to direct sunlight.
• Do not install this appliance in places
that are too damp or cold, for example
in structural additions, garages or
cellars.
• To move the appliance, lift it up from
its front edge so as not to scratch the
󰘱oor.
2.2 Electrical connection
WARNING!
Risk of 󰘰re and electrical shock.
• All electrical connections must be
made by a quali󰘰ed electrician.
• The appliance must be earthed.
• Make sure that the electrical data on
the rating plate corresponds with the
values of the power supply system. If
not, contact an electrician.
• Always use an electrical outlet with
an adequately installed protective
contact.
• Do not use power strips and extension
cords.

5ENGLISH
• Make sure not to damage the
electrical components (e.g. the power
plug, power cord or compressor).
Contact the Service Centre or an
electrician to replace the electrical
components.
• The power cord must remain below
the level of the power plug.
• Insert the power plug in the socket
only after installation. Make sure that
the power plug can still be accessed
after installation.
• Do not pull the power cord to
disconnect the appliance. Always hold
the plug when pulling it out.
2.3 Use
WARNING!
Risk of 󰘰re and electrical shock.
• Do not change the speci󰘰cations of
this appliance.
• Do not place electrical devices (e.g.
ice cream makers) in the appliance
unless speci󰘰cally allowed by the
manufacturer.
• Make sure not to damage the
refrigeration circuit. It contains an
R404 mixture, a non-󰘱ammable gas at
atmospheric pressure.
• In the case of damage to the
refrigeration circuit, make sure that no
󰘱ames or sparks can develop in the
room. Ventilate the room well.
• Do not place hot objects on the plastic
parts of the appliance.
• Do not store 󰘱ammable liquids and
gas in the appliance.
• Do not put or keep liquids or
󰘱ammable materials, or highly
󰘱ammable objects on, inside or near
the appliance.
• Do not touch the compressor or
condenser. These are hot.
2.4 Maintenance and
cleaning
WARNING!
Risk of injury or damage to the
appliance.
• Before performing maintenance,
always switch o󰘯 and unplug the
appliance.
• The cooling unit of the appliance
contains hydrocarbons. The unit must
be re󰘰lled and inspected only by
quali󰘰ed personnel.
• Regularly check the drain of the
appliance and clean it if necessary.
Obstruction of the drain can cause the
pooling of water.
2.5 Disposal
WARNING!
Risk of injury or su󰘯ocation.
• Unplug the appliance.
• Cut o󰘯 the power cord and dispose
of it.
• Remove the door catch to prevent
children and pets from being trapped
in the appliance.
• The refrigeration circuit and the
insulation materials are ozone-
friendly.
• The insulating foam contains
󰘱ammable gases.
• Contact the local authorities for
information on how to properly
dispose of the appliance.
• Do not damage the components of the
refrigeration unit that are close to the
heat exchanger.

6www.electrolux.com
3. DESCRIPTION OF THE PRODUCT
1Control panel
2Rack holder
3Food sensor
4Gasket
5Wire shelf
6Handle for installation
The blast chiller is designed for the
professional sector and is intended to
be used to chill (+3°C) and blast freeze
(-18°C) food.
Raw and cooked foods preserved in this
way maintain their organoleptic qualities
in the interest of 󰘱avour and freshness.
At the end of each selected cycle, the
appliance automatically switches to the
holding phase, keeping the product at the
preset temperature for a maximum of 24
hours.
1 2 3 4 5 6
3.1 Accessories
Wire shelf x 2 Sponge
Food sensor

7ENGLISH
4. CONTROL PANEL
1ON/OFF key
2Display lock (3 s)
3TEMPERATURE key
4UP key
5TIMER/ALARM
6CONFIRM key
7DOWN key
8DE-ICE
9BACK key
1 2 3 4 5
6789
4.1 Control panel
Sensor
key
Function Comment
1ON/OFF To turn the blast chiller on/o󰘯.
2LOCK Display lock. Press this for 3 seconds to activate or
deactivate it when a program is in progress.
3Temperature Used to test the cell temperature for the current
program.
4Up key To go up a vertical list or scroll left/right.
5Minute
minder
The user can set a timer/alarm.
6OK Con󰘰rms an action.
7Down key To go down a vertical list or scroll left/right.
8De-ice Function for removing ice in the cell.
9Back key Used during the selection of programs to return to
the previously selected level or program.

8www.electrolux.com
4.2 Display
A. Cooling function
B. Time
C. Cooling indicator
D. Temperature
E. Duration of cycle/residual time
Symbol Function
Minute minder The function is active.
Time indication The current time appears.
Temperature The temperature appears on the display.
Set temperature The set temperature value appears on the
display.
Food sensor Use of the food sensor appears on the display.
Duration The required duration of the cycle appears on
the display.
End of cycle The residual time appears on the display.
Timer The time elapsed since the start of the cycle
appears on the display.
A B C
E D
Other indicators on the display.

9ENGLISH
5. PREPARATION FOR INITIAL USE
WARNING!
Refer to the chapters on safety.
5.1 Initial cleaning
Remove the accessories and removable
shelf supports from the appliance.
Refer to the chapter "Cleaning
and Care".
5.2 Initial connection
After connecting the appliance to the
mains, set the language and time.
1. Press and to set the value.
2. Press to con󰘰rm.
6. DAILY USE
WARNING!
It is advisable to use the food
sensor to optimise the operating
times and consumption of the
blast chiller.
Make sure to insert the food sensor in the
middle of the food (see 󰘰gure).
6.1 Browsing the menus
1. Switch on the appliance.
2. Press and to set the option in the
menu.
3. Press to go to the sub-menu or
accept the setting.
Press at any time to return to
the main menu.

10 www.electrolux.com
Procedure for blast chilling or freezing with food sensor
1. Press the ON/OFF key.
2. Select the required program and
press OK to con󰘰rm.
3. Select “Food sensor”, insert this in the
food and press OK to con󰘰rm.
5. The appliance runs the blast chilling
cycle until the set temperature is
reached.
At the end of the cycle, the appliance
will switch to holding mode.
Procedure for blast chilling or freezing with weight
Gentle
Chilling +5°
Blast
Chilling +3°
Blast
Freezing -18°
1.5 Kg
0.5 Kg
1.0 Kg
4. Select the quantity and press OK to
con󰘰rm.
4. Modify the temperature as required
and press OK to con󰘰rm.
1. Press the ON/OFF key.
2. Select the required program and
press OK to con󰘰rm.
3. Select “Weight” and press OK to
con󰘰rm.
5. The appliance starts the blast
chilling cycle. The total time and
progressive time of the cycle
appear on the display.
At the end of the cycle, the appliance
will switch to holding mode.
Food sensor
Weight
Gentle
Chilling +5°
Blast
Chilling +3°
Blast
Freezing -18°
Food Sensor
Weight

11
ENGLISH
6.2 Blast chiller functions
Symbol Function Application Temperature/
weight
range
Size
Gentle chillingFood sensor +5 / +10°C Whole
Weight 1-2-3 Kg Slices/Soup/
Sauces
Blast chilling Food sensor 0 / +10°C Whole
Weight 0.5-3 Kg Slices/Soup/
Sauces
Blast freezing Food sensor -5 / -20°C Whole
Weight 0.5-3 Kg Slices/Soup/
Sauces
Assisted cooling Wine Red 16°C /
White 10°C /
Sparkling 5°C
2-4-6
Cans 4-8-12
1.5 L plastic bottle 2-4-6
Assisted
freezing
Fruit & vegetables
-18°C
0.5-3 Kg
Sashimi /
Raw 󰘰sh -20°C
3 Kg
Ice cream /
Desserts
Blast freezing of
ice cream -20°C
Ice cream ready
to serve -14°C
Ice
cubes
0.5-3 Kg
WARNING!
Keep the door closed during
every blast chilling or freezing
program.
If the door is not closed, the
program does not start and a
message appears on the screen
prompting you to close it. If the
door is opened during the
blast chilling or freezing cycle,
the fan stops and then so does
the compressor (after about 1
minute).
If the door remains open for more
than two minutes the program is
terminated.

12 www.electrolux.com
6.3 Guidelines for the functions
Symbol Function Use
Gentle chilling Load less than 0.5kg, single portion
all vegetables (even if above 0.5kg)
desserts, liquid foods and sauces
vacuum cooking, mixtures
Blast chilling Load more than 0.5kg, single portion
meat, 󰘰rst courses au gratin
puddings, whole 󰘰sh
Blast freezing Any food
semi-frozen desserts

13ENGLISH
7. TIPS AND RECOMMENDATIONS
7.1 Pre-cooling
Selecting the chilling cycles +5, +3, -18
automatically activates pre-cooling and
“Pre-cooling done, please insert food
now” appears on the appliance.
The assisted cooling and freezing cycles
do not involve pre-cooling.
7.2 Loading the machine
To ensure good performance of the
machine and prevent alteration of the
food:
• arrange the products in such a way
as to favour the circulation of cold air
throughout the cell;
• avoid prolonged and frequent opening
of the doors.
WARNING!
Make sure that the food items to
be blast chilled and/or frozen do
not overlap and are no greater
than 65 mm in thickness. Do not
exceed the load recommended by
the manufacturer (3 kg).

14 www.electrolux.com
8. CLEANING AND CARE
8.1 Routine cleaning
The appliance must be cleaned on a
regular basis.
Avoid pulling, moving or damaging pipes
and/or cables in the appliance. When
cleaning the internal parts, do not use
detergents, scouring powders, strongly
scented products or wax polishes as they
may damage the surface and leave a
strong odour.
• Wash the inside surfaces with a
solution of warm water and baking
soda. Use 2 tablespoons of baking
soda per litre of water.
• Wash the shelves with a mild
detergent.
• Wring the excess water from the
sponge or cloth before cleaning
near the controls or any electrical
components.
• Wash the inside and accessories with
warm water and mild soap.
• Regularly inspect the door seals and
use a damp cloth to remove dirt and
residues.
• Rinse and dry thoroughly.
Make sure not to damage the
refrigeration system.
After cleaning, plug the appliance back
into the mains.
8.2 Periods of inactivity
If the appliance is not to be used for
a long period, adopt the following
precautions:
• unplug the appliance;
• remove all the accessories;
• clean the appliance and all the
accessories;
• leave the door open to prevent the
formation of unpleasant odours.
9. TROUBLESHOOTING
WARNING!
Refer to the chapters on safety.
9.1 What to do when...
Problem Possible cause Solution
The appliance does
not start up.
No power Check the electrical
connection.
Ice in the cavity. Excessive use of the
appliance.
De-ice the appliance leaving
the door open.
Switch o󰘯 the machine at the
end of the cycle.
Excessive
formation of water
at the base of the
cavity.
Intensive use of the appliance
and subsequent de-icing.
Use the sponge provided to
dry the cavity.
The message
“Please close
door to continue
program” appears
on the display.
The door is not closed
properly.
Check that the supporting
surface of the gasket is clean.
Remove any ice on the frame
of the door/gasket.

15ENGLISH
The touch screen
does not respond
to the commands.
The display is dirty. Clean the display and switch
the machine o󰘯 and on again.
The food does not
reach the required
temperature
Incorrect setting of the chilling
cycle.
Check the program and the
distribution of food in the
cavity.
Food is not arranged properly
on the trays.
Check for any obstruction in
the distribution of air.
Food is excessively thick. Reduce the thickness of the
food.
There is a cover or lid. Remove the cover or lid.
The temperature
indicated by the
food sensor is
incorrect.
Incorrect insertion of the food
sensor.
Check the position of the food
sensor in the product.
The food sensor is damaged. Use only timed or assisted
programs and contact the
Service Centre to request a
replacement.
The appliance
prompts the user
to insert the food
sensor when it
is in fact already
inserted.
Broken food sensor. Contact the technical Service
Centre.
10. ENVIRONMENTAL CONSIDERATIONS
Recycle materials bearing the symbol .
Put the packaging in special containers
for recycling. Help protect the
environment and human health by
recycling waste electrical and electronic
equipment.
Do not dispose of appliances marked with
the symbol with normal household
waste.
Take the product to your local recycling
facility or contact your municipal o󰘲ce.

16 www.electrolux.com
INDICE
PENSATI PER VOI
Grazie per aver acquistato un’apparecchiatura Electrolux. Avete scelto un prodotto
che ha alle spalle decenni di esperienza professionale e innovazione. Ingegnoso ed
elegante, è stato progettato pensando a voi. Quindi, in qualsiasi momento desiderate
utilizzarlo, potete esser certi di ottenere sempre i migliori risultati. Benvenuti in
Electrolux.
Visitate il nostro sito web per:
Ricevere consigli, scaricare i nostri opuscoli, eliminare eventuali anomalie,
ottenere informazioni sull’assistenza: www.electrolux.com
Registrare il vostro prodotto e ricevere un servizio migliore:
www.electrolux.com/productregistration
Acquistare accessori, materiali di consumo e ricambi originali per la vostra
apparecchiatura: www.electrolux.com/shop
SERVIZIO CLIENTI E MANUTENZIONE
Consigliamo sempre l’impiego di ricambi originali.
Quando si contatta l’Assistenza, accertarsi di disporre dei seguenti dati. Le
informazioni si trovano sulla targhetta di identi󰘰cazione: Modello, numero
dell’apparecchio (PNC), numero di serie.
Avvertenza/Attenzione - Importanti Informazioni di sicurezza.
Informazioni e suggerimenti generali.
Informazioni sull’ambiente.
Con riserva di modi󰘰che.
1. INFORMAZIONI PER LA SICUREZZA .....................................................................17
2. ISTRUZIONI PER LA SICUREZZA ...........................................................................18
3. DESCRIZIONE DEL PRODOTTO.............................................................................20
4. PANNELLO COMANDI..............................................................................................21
5. PREPARAZIONE AL PRIMO UTILIZZO ...................................................................23
6. UTILIZZO QUOTIDIANO...........................................................................................23
7. CONSIGLI E SUGGERIMENTI UTILI........................................................................27
8. PULIZIA E CURA.......................................................................................................28
9. RISOLUZIONE DEI PROBLEMI................................................................................28
10. CONSIDERAZIONI SULL’AMBIENTE.....................................................................29

17ITALIANO
1. INFORMAZIONI PER LA SICUREZZA
Leggere attentamente le istruzioni fornite prima di
installare e utilizzare l’apparecchiatura. Il produttore
non è responsabile se un’installazione ed un uso non
corretto dell’apparecchiatura provocano lesioni e danni.
Tenere sempre le istruzioni a portata di mano come
riferimento futuro.
1.1 Sicurezza dei bambini e delle persone vulnerabili
• Questa apparecchiatura può essere usata da bambini
a partire dagli 8 anni e da adulti con limitate capacità
󰘰siche, sensoriali o mentali o con scarsa esperienza o
conoscenza sull’uso dell’apparecchiatura, solamente
se sorvegliati o se istruiti relativamente all’uso
dell’apparecchiatura e se hanno compreso i rischi
coinvolti.
• Non consentire ai bambini di giocare con
l’apparecchiatura.
• Tenere i materiali di imballaggio al di fuori della portata
dei bambini.
• La pulizia e gli interventi di manutenzione non devono
essere eseguiti dai bambini senza supervisione.
1.2 Avvertenze di sicurezza generali
• L’apparecchiatura è destinata all’uso domestico ed usi
simili, ad esempio:
- in case di campagna, cucine di negozi, u󰘲ci ed altri
ambienti di lavoro;
- da clienti di hotel, motel, bed and breakfast e altri
ambienti residenziali.
• Utilizzare l’apparecchiatura esclusivamente per
conservare alimenti.
• Veri󰘰care che le aperture di ventilazione, sia
sull’apparecchiatura che nella struttura ad incasso, non
siano ostruite.
• Non usare dispositivi meccanici o altri mezzi arti󰘰ciali
non raccomandati dal produttore allo scopo di

18 www.electrolux.com
accelerare il processo di sbrinamento.
• Non danneggiare il circuito refrigerante.
• Non utilizzare apparecchiature elettriche all’interno dei
componenti di conservazione degli alimenti.
• Non nebulizzare acqua ne utilizzare vapore per pulire
l’apparecchiatura.
• Pulire l’apparecchiatura con un panno inumidito e
morbido. Utilizzare solo detergenti neutri. Non usare
prodotti abrasivi, spugnette abrasive, solventi od
oggetti metallici.
• Non conservare in questa apparecchiatura sostanze
esplosive come bombolette spray contenenti un
propellente in󰘰ammabile.
• Se il cavo di alimentazione è danneggiato, deve essere
sostituito dal produttore, da un tecnico autorizzato o
da una persona quali󰘰cata per evitare situazioni di
pericolo.
2. ISTRUZIONI PER LA SICUREZZA
2.1 Installazione
ATTENZIONE!
L’installazione
dell’apparecchiatura deve essere
eseguita da personale quali󰘰cato.
• Rimuovere tutti i materiali di
imballaggio.
• Non installare o utilizzare
l’apparecchiatura se è danneggiata.
• Attenersi alle istruzioni fornite insieme
all’apparecchiatura.
• Prestare sempre attenzione in fase
di spostamento dell’apparecchiatura
dato che è molto pesante. Indossare
sempre guanti di sicurezza.
• Assicurarsi che l’aria possa
circolare liberamente attorno
all’apparecchiatura.
• Attendere almeno 4 ore prima
di collegare l’apparecchiatura
all’alimentazione. Questo serve a
consentire all’olio di 󰘱uire nuovamente
nel compressore.
• Non installare l’apparecchiatura in
prossimità di radiatori, fornelli, forni o
piani cottura. La super󰘰cie posteriore
dell’apparecchiatura deve essere
appoggiata alla parete con canale.
• Non installare l’apparecchiatura dove
sia esposta alla luce solare diretta.
• Non installare questa apparecchiatura
in luoghi troppo umidi o freddi, come
aggiunte strutturali, garage o cantine.
• Per spostare l’apparecchiatura,
sollevarla per il bordo anteriore, così
da non gra󰘲are il pavimento.
2.2 Collegamento elettrico
ATTENZIONE!
Rischio di incendio e scossa
elettrica.
• Tutti i collegamenti elettrici devono
essere realizzati da un elettricista
quali󰘰cato.
• L’apparecchiatura deve disporre di
una messa a terra.
• Veri󰘰care che i dati elettrici riportati
sulla targhetta dei dati corrispondano
a quelli dell’impianto. In caso
contrario, contattare un elettricista.
• Utilizzare sempre una presa
elettrica con contatto di protezione
correttamente installata.
• Non utilizzare prese multiple e
prolunghe.

19ITALIANO
• Accertarsi di non danneggiare
i componenti elettrici (ad es. la
spina di alimentazione, il cavo di
alimentazione, il compressore).
Contattare il Centro di assistenza o un
elettricista per sostituire i componenti
elettrici.
• Il cavo di alimentazione deve
rimanere sotto il livello della spina di
alimentazione.
• Inserire la spina di alimentazione
nella presa solo al termine
dell’installazione. Veri󰘰care che
la spina di alimentazione rimanga
accessibile dopo l’installazione.
• Non tirare il cavo di alimentazione per
scollegare l’apparecchiatura. Tirare
sempre dalla spina.
2.3 Utilizzo
ATTENZIONE!
Rischio di incendio e scossa
elettrica.
• Non apportare modi󰘰che alle
speci󰘰che di questa apparecchiatura.
• Non introdurre apparecchiature
elettriche (ad es. gelatiere)
nell’apparecchiatura se non
speci󰘰catamente consentito dal
produttore.
• Fare attenzione a non danneggiare
il circuito refrigerante. Esso
contiene miscela R404, un gas non
in󰘰ammabile a pressione di una
atmosfera.
• Nel caso di danno al circuito
refrigerante, assicurarsi che non
sviluppino 󰘰amme libere e scintille nel
locale. Aerare bene l’ambiente.
• Non appoggiare oggetti
incandescenti sulle parti in plastica
dell’apparecchiatura.
• Non conservare gas e liquidi
in󰘰ammabili nell’apparecchiatura.
• Non appoggiare o tenere liquidi
o materiali in󰘰ammabili, né
oggetti facilmente incendiabili
sull’apparecchiatura, al suo interno o
nelle immediate vicinanze.
• Non toccare il compressore o il
condensatore. Sono incandescenti.
2.4 Manutenzione e pulizia
ATTENZIONE!
Rischio di lesioni o danni
all’apparecchiatura.
• Prima di eseguire qualunque
intervento di manutenzione, spegnere
l’apparecchiatura ed estrarre la spina
dalla presa.
• L’unità refrigerante
dell’apparecchiatura contiene
idrocarburi. L’unità deve essere
ricaricata ed ispezionata
esclusivamente dal personale
quali󰘰cato.
• Controllare regolarmente lo scarico
dell’apparecchiatura e se necessario
pulirlo. L’ostruzione dello scarico può
causare un deposito di acqua.
2.5 Smaltimento
ATTENZIONE!
Rischio di lesioni o so󰘯ocamento.
• Staccare la spina dall’alimentazione
elettrica.
• Tagliare il cavo di rete e smaltirlo.
• Rimuovere il blocco porta per evitare
che bambini e animali domestici
rimangano chiusi all’interno
dell’apparecchiatura.
• Il circuito refrigerante e i materiali di
isolamento rispettano l’ozono.
• La schiuma isolante contiene gas
in󰘰ammabili.
• Contattare le autorità locali per
ricevere informazioni su come smaltire
correttamente l’apparecchiatura.
• Non danneggiare i componenti
dell’unità refrigerante che si trovano
vicino allo scambiatore di calore.

20 www.electrolux.com
3. DESCRIZIONE DEL PRODOTTO
1Pannello comandi
2Porta griglie
3Termosonda
4Guarnizione
5Ripiano a 󰘰lo
6Maniglia per installazione
L’abbattitore di temperatura deriva dal
settore professionale ed è destinato
all’abbattimento della temperatura (+3°C)
e alla surgelazione (–18°C) degli alimenti.
Gli alimenti crudi e cotti, trattati in questo
modo, conservano inalterate le loro
qualità organolettiche preservandone il
gusto e la freschezza.
Alla 󰘰ne di ogni ciclo selezionato
l’apparecchiatura passa automaticamente
alla fase di mantenimento, mantenendo
il prodotto alla temperatura preimpostata
per un massimo di 24 ore.
1 2 3 4 5 6
3.1 Accessori
Ripiano a 󰄈lo x2 Spugna
Termosonda
