Electrolux EHD90LLUM User manual

Electrolux Home Products Australia
telephone: [phone]
fax: [phone]
email: [e-mail]
web: www.electrolux.com.au
Electrolux Home Products New Zealand
phone: [phone]
fax: [phone]
email: [e-mail]
web: www.electrolux.co.nz
The Thoughtful Design Innovator.
Do you remember the last time you opened a gift that made you say
“Oh! How did you know? That’s exactly what I wanted!” That’s the kind of
feeling that the designers at Electrolux seek to evoke in everyone who
chooses or uses one of our products. We devote time, knowledge, and a
great deal of thought to anticipating and creating the kind of appliances that
our customers really need and want.
This kind of thoughtful care means innovating with insight. Not design for
design’s sake, but design for the user’s sake. For us, thoughtful design means
making appliances easier to use and tasks more enjoyable to perform, freeing
our customers to experience that ultimate 21st century luxury, ease of mind.
Our aim is to make this ease of mind more available to more people in more
parts of their everyday lives, all over the world. So when we say we’re thinking
of you, you know we mean just that.
Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com.au or www.electrolux.co.nz
Thank you for choosing the new
Electrolux induction cooktop – the most
beautiful cooktop in the world.
This product combines beauty and style
with induction technology to deliver you a
truly modern cooking solution. To ensure
that you get the most enjoyment out of
your Electrolux induction cooktop please
take a few moments to review this manual.
Enjoy!
• Important safety instructions 1
• Displays 3
• Operating the appliance 4
• Locking/unlocking the control panel 5
• Using the child safety device 6
• Switching the power boost function
on and off 7
• Using the timer 8
• Automatic switch off 11
• Tips on cooking and frying 12
• Examples of cooking applications 14
• Cleaning and care 15
• Troubleshooting 17
• Disposal 19
• Installation instructions 20
• Assembly 22
• Information label 23
• Warranty 24
• Service 25
Contents
The symbols you will see in this booklet
have these meanings:
This symbol indicates information
concerning your personal safety
This symbol indicates information on
how to avoid damaging the cooktop
This symbol indicates tips and
information about use of the cooktop
This symbol indicates tips and
information about economical and
ecological use of the cooktop
dangerous voltage
This symbol indicates risk of injury
from electrical current
electrolux induction cooktop contents i
user manual
induction cooktop
EHD90LLUM
P/No. 867 200 534-A-190407-01
© Copyright 2007 Electrolux Home Products Pty Ltd
ABN 51 004 762 341
Print code: EAURORAUM_Dec 07
Congratulations

Electrolux Home Products Australia
telephone: [phone]
fax: [phone]
email: [e-mail]
web: www.electrolux.com.au
Electrolux Home Products New Zealand
phone: [phone]
fax: [phone]
email: [e-mail]
web: www.electrolux.co.nz
The Thoughtful Design Innovator.
Do you remember the last time you opened a gift that made you say
“Oh! How did you know? That’s exactly what I wanted!” That’s the kind of
feeling that the designers at Electrolux seek to evoke in everyone who
chooses or uses one of our products. We devote time, knowledge, and a
great deal of thought to anticipating and creating the kind of appliances that
our customers really need and want.
This kind of thoughtful care means innovating with insight. Not design for
design’s sake, but design for the user’s sake. For us, thoughtful design means
making appliances easier to use and tasks more enjoyable to perform, freeing
our customers to experience that ultimate 21st century luxury, ease of mind.
Our aim is to make this ease of mind more available to more people in more
parts of their everyday lives, all over the world. So when we say we’re thinking
of you, you know we mean just that.
Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com.au or www.electrolux.co.nz
Thank you for choosing the new
Electrolux induction cooktop – the most
beautiful cooktop in the world.
This product combines beauty and style
with induction technology to deliver you a
truly modern cooking solution. To ensure
that you get the most enjoyment out of
your Electrolux induction cooktop please
take a few moments to review this manual.
Enjoy!
• Important safety instructions 1
• Displays 3
• Operating the appliance 4
• Locking/unlocking the control panel 5
• Using the child safety device 6
• Switching the power boost function
on and off 7
• Using the timer 8
• Automatic switch off 11
• Tips on cooking and frying 12
• Examples of cooking applications 14
• Cleaning and care 15
• Troubleshooting 17
• Disposal 19
• Installation instructions 20
• Assembly 22
• Information label 23
• Warranty 24
• Service 25
Contents
The symbols you will see in this booklet
have these meanings:
This symbol indicates information
concerning your personal safety
This symbol indicates information on
how to avoid damaging the cooktop
This symbol indicates tips and
information about use of the cooktop
This symbol indicates tips and
information about economical and
ecological use of the cooktop
dangerous voltage
This symbol indicates risk of injury
from electrical current
electrolux induction cooktop contents i
user manual
induction cooktop
EHD90LLUM
P/No. 867 200 534-A-190407-01
© Copyright 2007 Electrolux Home Products Pty Ltd
ABN 51 004 762 341
Print code: EAURORAUM_Dec 07
Congratulations

Cooking surface layout Control panel layout
Cooking zone indicators
Timer function Timer display
Timer
Display
Power boost function
Heat setting selector
On/Off
with power indicator
Lock
Touch control sensor fields
The appliance is operated using Touch Control sensor fields. Functions are controlled
by touching sensor fields and confirmed by displays and acoustic signals.
Touch the sensor fields from above, without covering other sensor fields.
Sensor Fields Function
On / Off To switch the appliance on and off
Increase settings Increasing heat setting/time
Decrease settings Decreasing heat setting/time
Timer Timer selection
Lock Locking/unlocking the control panel
Power boost Switching the power boost function on and off
ii product description electrolux induction cooktop electrolux induction cooktop control panel layout iii
Important Notice
Before calling a Service Technician please check carefully the operating instructions,
service booklet and the warranty terms and conditions.
FOR SERVICE
or to find the address of your nearest
state service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
ELECTROLUX HOME PRODUCTS
www.electrolux.com.au
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
FREE CALL 0800 10 66 10
(New Zealand only)
SERVICE NEW ZEALAND
ELECTROLUX HOME PRODUCTS
www.electrolux.co.nz
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in New Zealand
FREE CALL 0800 10 66 20
(New Zealand only)
electrolux induction cooktop service 25
904mm
556mm
46mm
Dimensions
Cut-out dimensions
704mm
444mm
radius
55mm
Induction cooking zone 1400W
with power boost function 2500W
Induction cooking zone 1800W
with power boost function 2800W
Control panel Control panel
Induction cooking zone 2200W
with power boost function 3100W
Induction cooking zone 1800W
with power boost function 2800W
Corian®frame
Decorative
lighting strip
145mm
180mm
210mm
180mm
Corian® is a registered trademark of E. I. du Pont de Nemours and Company.
Chux® and Magic Eraser® are registered trademarks of the Clorox Australia Pty Limited
If you were not able to remedy the problem
yourself, please contact the Customer Care
Department or one of our service partners.
In order to be able to assist you quickly, we require
the following information:
– Model description
– Product number (PNC)
– Serial number (S No.)
(for numbers see rating plate)
– Type of fault
– Any error messages displayed by
the appliance
So that you have the necessary reference numbers
from your appliance at hand, we recommend that
you write them in here. They are locataed either n
the carton or base of product.
Serial number: ....................................................................
Location of product
information label
Information label
Assembled in China from German designed and made induction hob technology.

Cooking surface layout Control panel layout
Cooking zone indicators
Timer function Timer display
Timer
Display
Power boost function
Heat setting selector
On/Off
with power indicator
Lock
Touch control sensor fields
The appliance is operated using Touch Control sensor fields. Functions are controlled
by touching sensor fields and confirmed by displays and acoustic signals.
Touch the sensor fields from above, without covering other sensor fields.
Sensor Fields Function
On / Off To switch the appliance on and off
Increase settings Increasing heat setting/time
Decrease settings Decreasing heat setting/time
Timer Timer selection
Lock Locking/unlocking the control panel
Power boost Switching the power boost function on and off
ii product description electrolux induction cooktop electrolux induction cooktop control panel layout iii
Important Notice
Before calling a Service Technician please check carefully the operating instructions,
service booklet and the warranty terms and conditions.
FOR SERVICE
or to find the address of your nearest
state service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
ELECTROLUX HOME PRODUCTS
www.electrolux.com.au
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
FREE CALL 0800 10 66 10
(New Zealand only)
SERVICE NEW ZEALAND
ELECTROLUX HOME PRODUCTS
www.electrolux.co.nz
FOR SPARE PARTS
or to find the address of your nearest
state spare parts centre in New Zealand
FREE CALL 0800 10 66 20
(New Zealand only)
electrolux induction cooktop service 25
904mm
556mm
46mm
Dimensions
Cut-out dimensions
704mm
444mm
radius
55mm
Induction cooking zone 1400W
with power boost function 2500W
Induction cooking zone 1800W
with power boost function 2800W
Control panel Control panel
Induction cooking zone 2200W
with power boost function 3100W
Induction cooking zone 1800W
with power boost function 2800W
Corian®frame
Decorative
lighting strip
145mm
180mm
210mm
180mm
Corian® is a registered trademark of E. I. du Pont de Nemours and Company.
Chux® and Magic Eraser® are registered trademarks of the Clorox Australia Pty Limited
If you were not able to remedy the problem
yourself, please contact the Customer Care
Department or one of our service partners.
In order to be able to assist you quickly, we require
the following information:
– Model description
– Product number (PNC)
– Serial number (S No.)
(for numbers see rating plate)
– Type of fault
– Any error messages displayed by
the appliance
So that you have the necessary reference numbers
from your appliance at hand, we recommend that
you write them in here. They are locataed either n
the carton or base of product.
Serial number: ....................................................................
Location of product
information label
Information label
Assembled in China from German designed and made induction hob technology.

Please comply with these instructions.
If you do not, any damage resulting is
not covered by the warranty.
This appliance conforms with the
following EU Directives:
– 2006 / 95 / EEC dated 12.12.2006 Low
Voltage Directive
– 200 / 108 / EEC dated 31.12.200 EMC
Directive
– 93 / 68 / EEC dated 22.07.1993 CE
Marking Directive
Correct use
• Thisapplianceisnotintendedforuse
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Donotleavetheapplianceunattended
during operation.
• Thisapplianceshouldbeusedonlyfor
normal domestic cooking and frying of
food.
• Theappliancemustnotbeusedasa
work surface or as a storage surface.
• Additionsormodicationstothe
appliance are not permitted.
• Donotplaceorstoreammable
liquids,highlyinammablematerialsor
fusibleobjects(e.g.plasticlm,plastic,
aluminium) on or near the appliance.
Children’s safety
• Childrenshouldbesupervisedtoensure
they do not play with the appliance.
• Toavoidsmallchildrenandpets
unintentionally switching the appliance
on, we recommend activation of the
child safety device.
• Thecookingzoneswillbecomehot
during use, young children should be
kept away to avoid burns.
General safety
• Theappliancemayonlybeinstalledand
connected by trained, registered service
engineers.
• Built-inappliancesmayonlybeused
after they have been built in to suitable
built-inunitsandworksurfacesthat
meet standards.
• Intheeventoffaultswiththeappliance
or damage to the glass ceramic
(cracks or splits), the appliance must
be switched off and disconnected from
the electrical supply, to prevent the
possibility of an electric shock.
• Repairstotheappliancemustonlybe
carried out by trained service engineers.
Important safety instructions
electrolux induction cooktop important safety instructions 1

Safety during use
• Removestickersandlmfromtheglass
ceramic.
• Thereistheriskofburnsfromthe
appliance if used carelessly.
• Cablesfromelectricalappliances
must not touch the hot surface of the
appliance or hot cookware.
• Overheatedfatsandoilscanignitevery
quickly.Warning!Firehazard!
• Switchthecookingzonesoffatcontrols
after each use, do not rely on the pan
detectors.
• Userswithimplantedpacemakers
should keep their upper body at least
30cmfrominductioncookingzones
that are switched on.
• Riskofburns!Donotplaceobjects
made of metal, such as knives, forks,
spoons and saucepan lids on the
cooking surface, as they can get hot.
Safety when cleaning
• Forcleaning,theappliancemustbe
switched off and cooled down.
• Forsafetyreasons,thecleaningof
theappliancewithsteamjetorhigh-
pressure cleaning equipment is not
permitted.
How to avoid damage to the appliance
• Theglassceramicandsurrounding
Corian®frame can be damaged by
objects falling onto them.
• Theedgeoftheglassceramicand
surrounding Corian®frame can also
be damaged by being knocked by the
cookware.
• Cookwaremadeofcastiron,cast
aluminium or with damaged bottoms
can scratch the glass ceramic and
surrounding Corian®frame if pushed
across the surface.
• Beforespillagecanbecomeburntonto
the cooking surface, remove it with a
damp cloth.
• Donotusethecookingzoneswith
empty cookware or without cookware.
• Toavoiddamagingcookwareandglass
ceramics, do not allow saucepans or
frying pans to boil dry.
• Theventilationgapof5mmbetween
the worktop and front of the unit
underneath it must not be covered.
2 important safety instructions electrolux induction cooktop

Display Description
Cookingzoneisswitchedoff
Heat settings Heat setting is set
Fault Malfunction has occurred
Pan detection Cookware is unsuitable or too small or
no cookware has been placed on the
cookingzone
Residualheat Cookingzoneisstillhot
Child safety device Lock/child safety device is engaged
Power boost Power boost function is switched on
Automaticswitchoff Switchoffisactive
electrolux induction cooktop displays 3
Displays
Residual heat indicator
Warning! Risk of burns from residual
heat. After being switched off, the
cooking zones need some time to
cool down. Look at the residual heat
indicator .
Residual heat can be used for melting
and keeping food warm.
Theinductioncookingzonescreatethe
heat required for cooking directly in the
baseofthecookware.Theglassceramic
is merely heated by the residual heat of the
cookware.
Thecooling fan switches itself on and off
depending upon the temperature of the
electronics.

4 operating the appliance electrolux induction cooktop
Use the induction cooking zones with
suitable cookware.
Switchingtheapplianceon
and off
Control panel Display Pilot light Perimeter
lighting strip
Switchon Touch for 2 seconds /lights up lights up
Switchoff Touch for 1 second /none goes out goes out
After switching on, within approx.
10 seconds a heat setting or a function
must be set, otherwise the appliance
automatically switches itself off.
Settingtheheatsetting
Control panel Display
Increase Touch to /
Decrease Touch to
Switchoff Touch and at the same time
Operatingtheappliance

Thecontrolpanel,withtheexceptionof
the“On/Off”sensoreld,canbelockedat
any time in order to prevent the settings
being changed e.g. by wiping over the
panel with a cloth.
Control panel Display
Switchon Touch (for 5 seconds)
Switchoff Touch previously set heat setting
When you switch the appliance off,
the locking function is automatically
switched off.
electrolux induction cooktop locking/unlocking the control panel 5
Locking/unlocking the control panel

Thechildsafetydeviceprevents
unintentional use of the appliance.
Setting the child safety device
Step Control panel Display/Signal
1. Switchontheappliance
(Do not set the heat setting)
2. Touch until the signal sounds Acousticsignal
3. Touch
Applianceswitchesoff.Thechildsafetydeviceisengaged.
Overriding the child safety device
Thechildsafetydevicecanbereleased
in this way for a single cooking session; it
remains activated afterwards.
Step Control panel Display/Signal
1. Switchontheappliance
2. Touch and at the same time / acoustic signal
Untiltheapplianceisnextswitchedoff,itcanbeusedasnormal.
Releasing the child safety device
Step Control panel Display/Signal
1. Switchontheappliance
2. Touch until the signal sounds Acousticsignal
3. Touch
Applianceswitchesoff.Thechildsafetydeviceisreleased.
6 using the child safety device electrolux induction cooktop
Usingthechildsafetydevice
