ELEKTROBOCK BPT322 GST User manual

1
WIRELESS ROOM THERMOSTAT
WITH GSM MODULE
BPT322 GST
BPT322 GST
A sophisticated wireless thermostat which can be remotely controlled by means of SMS messages from your mobile phone. Wireless version
enables easy and quick installation. It is not necessary to install labour-consuming lines between the thermostat and boiler that must come
through floors. The transmitter includes two devices, temperature controller and GSM module, which cooperate, thus increasing the comfort
of the heating system control. Simple control elements are used for setting; intuitive navigation in the selected language (CZ/PL/EN/DE/
RU/SVK). Remote control is executed by means of brief SMSs which enable you, for example, to change the required temperature or turn
off the system. The receiver is equipped with a code self-learning system and the E-EPROM memory which saves the code stored even in
the event of voltage failure. BPT322 GST works with two-way communication at the frequency of 433.92 MHz. The assembly may reach
the range of up to 35 m (in built-up area). This unique wireless thermostat with a big backlit display and intelligent PID-control offers a wide
variety of usage in residential houses, offices as well as recreation areas.
receiver - wall mounted
TWO-WAY COMMUNICATION
- guarantees reliability of signal transmission and enables
acquiring of return information
MADE IN CZECH REPUBLIC
transmitter
• Enable to change the required temperature or change the mode by
means from mobile phone
• Big, well-arranged and backlit display
• Intuitive navigation in the selected language (CZ/PL/EN/DE/RU/
SVK)
• 9 weekly programs
• 6 temperature changes per every day
• Programming by 10 minutes and 0.5 °C
• Programming by days or Mon-Fri, Sat-Sun and Mon-Sun
• Possibility of setting HYSTERESIS, PI regulation or PID regulation
• Possibility of connectin an external temp. sensor
• Preliminary heating start function
• Possibility of short-term temperature change
• Even-odd week selection
• Current temperature correction
• Key lock
• Boiler operating hours total
• Manual mode (MANU)
• Permanent shutdown (OFF)
• Holiday mode
• Summer mode
• Anti-freeze temperature (3°C)
• TEST function
• Automatic SUMMER/WINTER time change
• Clock backup in case of power failure, approx. 7 days if
rechargeable batteries are used (not included in the packing)
- GSM module integrated
- modern design
- stand for stable setting at the optimum
location
• Receiver mains supply of 230 V/ 50 Hz
• Receiver with the CODE SELF-LEARNING system and
E-EPROM memory (saving the code even at voltage
failure)
• Two-wire connection to the boiler (potential-free
contact
• Indicator LED signalling the states
- mains supply indication
- transmission/ reception of signals
- failure state
- relay switched

2
RECEIVER CONTROL ELEMENTS
RECEIVER INSTALLATION
- lift off the front cover, see Figs 1,2
- attach the receiver to the wall (or to an installation box)
- turn off main switch
- connect the receiver acc. to the diagram (use terminals for room thermostat - 2 wires)
- connect the receiver to the 230 V/50 Hz power supply
- switch on the power. The green LED will light up and the receiver is ready for activation
Install the receiver (in internal rooms) as far from big metal objects as possible (at least 0.5 m) and far from
power lines owing to interference of the signal received!
It is recommended that the device is installed by a person with adequate qualification in electrical engineering!
The BPT322 GST assembly is configured and ready to use – to put the receiver and transmitter in operation, just
use the TEST function (see page 5)!
If the receiver memory has, however, been cleared – the red diode is flashing – proceed as follows:
1) Press the receiver’s “FUNCTION BUTTON” for about 1.5 sec; the blue and red LEDs start flashing alternately; and the
receiver is awaiting the code (“learning mode“).
2) Press twice the “ MENU “ button on the receiver (after connecting the power supply and activating, see page 3), choose
the TEST mode by turning the“ “ button, and confirm it by pressing “ “button. The TEST RFM message is displayed,
by turning “ “ button start the test.
The sign for wireless transmitting “ “ appears shortly on the transmitter and once communication is established the RFM
sing will lit permanently.
3) The code receipt in the receiver is indicated by simultaneous flashing of the blue and red LEDs; thus the code has been
learnt. After the code receipt, the output relay is switched several times to verify correct function of BPT322 GST.
CODE LEARNING
Wiring diagram:
Front cover lift of:
Fig.1 Fig.2
Indicating LEDs:
GREEN LIT UP - electrical power connection on
BLUE SHORT BLINKING - sending or receiving a signal
RED BLINKING - empty E-EPROM memory
RED LIT UP - FAILURE Error mode (if no signal is received from the transmitter in
6 hours, will switch to a2 min. ON and 8 min. OFF sequence)
BLUE+RED BLINKING ALTERNATELY - code learning mode
BLUE+RED BLINKING CONCURRENTLY - code accepted
BLUE+RED LIT TOGETHER - memory erase mode
ORANGE LIT UP - relay is switched on
Holes for installation on KU/KP68
FUNCTION BUTTON
- SHORT PRESS (for approx. 1 s)
CODE LEARNING mode
- LONG PRESS (for apprrox. 3s)
RESET (memory clearing)
output terminals
for boiler
(potential-free
switching
contact)
power supply
terminals
230 V/50Hz
NL
BOILER

Backlit display
After you press any button,
the display is backlit automatically
for at least 5 s.
Controls
turning = change of temperature setting
short press = selection (entry) confirmation
= quick change of required temperature or
program (see page 10);
viewing other information (see page 10)
long press = step back (only in the CONST mode,
see page 7)
press = opening the main menu or returning
a step back
The GSM aerial is included in the
packing (can be replaced by
an external one
with higher sensitivity).
1
2
3
4
5
67 981011
15
17
18
19
20
12 13
16
14
Connector for external sensor
can be used with sensors CT04-10k
(order No. 0012), CT01-10k (order No.
0015) or CT02-10k (order No. 0013)
Connector for power supply No. 1
for the AD05-jack power supply
(included in the packing)
Connector for power supply No. 2
for power source installed in a wiring
box (not included in the packing)
SIM card holder
space for inserting the SIM card
(the SIM card is not included in the
packing)
Backup batteries room
to backup the time running, always use
rechargeable batteries of the AA/R6
type (not included in the packing)
RESET
press this button with MENU butto
for restoring to default settings
(see page 8)
3
TRANSMITTER DESCRIPTION
LCD DESCRIPTION
1, Current day (in the Prog mode,
selection of days to be programmed
2, Heating on indication
3, Current room temperature
4, Clock setting mode
5, Modes for setting programs (PROG)
and constants (CONST) (page 5)
6, Automatic mode (page 5)
7, Manual mode (page 5)
8, Holiday mode (page 5)
9, Permanent shut-off (page 5)
10, Summer mode (page 8)
11, Boiler inspection indication (page 10)
12, Signal transmission indication
13, Signal transmission ERROR
14, External sensor connection indication
(see page 9)
15, Wireless mode indication
16, Key lock indication (page 10)
17, Current time
18, Current date/ required temperature
19, Status line, dynamically changing
according to the process running
20,Low battery indication
Type AD05-jack
5V/ DC, 2.5 A
Open the SIM card
holder and insert the
SIM card in the direction
indicated; then close the
holder again.
Type CT04-10k
silicone conductor, leng-
th 3 m for measurements
up to 99 °C, including
connector
GST type – external
9 dBm, SMA connector
(not included in the
packing); can be
purchased separately,
order No. 1330,
on www.elbock.cz.
Use the type:
5V / DC, 2,5 A
(SELV)
MIND THE
POLARITY!!
0 V+5 V

4
TRANSMITTER INSTALLATION
The transmitter must be installed as far from interference sources (TV, PC, etc.) as possible; it must not be placed on a metal base. Pay
attention to the thermal characteristics of the given place at installation.
1) Remove the control part from the bottom cover of the device (Fig. 1).
2) Insert the activated SIM card into the SIM card holder at the back of the control part (see page 3).
3) If you want to back up the time, install the fully charged rechargeable batteries (see Fig. 2).
4) Mount the control part onto the bottom cover.
5) Connect the power supply to the connector No. 1 or No. 2 (see page 3). ATTENTION BPT322 GST MUST BE POWERED FROM
ONE SOURCE!!
6) The transmitter is freely portable and can be located, for instance, on the table. We recommend you to use the delivered table stand
(installation acc. to Fig. 3)
7) If installed on the wall, no power lines must run around the thermostat!
8) Test the wireless communication between the transmitter and the receiver – page 5 (TEST).
9) Upon the first start (or reset), the thermostat shows the “SET CLOCK”, “ENTER PIN” messages; set the current time and date acc.
to the instructions on page 5, enter the PIN acc. to page 9 and select language acc. page 7.
Fig.1
Fig.3
Fig.2
AA recharge-
able battery
AA recharge-
able battery
The thermostat enables backup of time in case of power
failure. You must use rechargeable batteries 2x1.2 V,
type AA/R6. After power failure, the time remains cur-
rent (approximate service life: 2 years, according to the
type of batteries used).The advantage is recharging of
the batteries after the power supply is restored.
CAUTION: THE BATTERIES ARE NOT USED FOR
SUPPLYING THE THERMOSTAT, FOR WHICH
THE AD05-jack POWER SOURCE MUST BE USED
(see page 3).
TEST GSM SET TIME
ENTER PIN
SET TIME
CONSTANTS 13 ENTER PIN
SET HOUR
FIRST SWITCH-ON
GSM module is being
checked.
Press the “ MENU “, button twice;
choose the CLOCK mode by
turning the “ „ button and make
the settings acc. to page 5.
Press the “ MENU “, button twice;
choose the CONST mode by
turning the “ „ button; move on
to set CONST13 acc. to page 9.
After you switch on BPT322 GST first, the following message appears on the LCD; follow the instructions to make the corresponding
settings (INSERT SIM CARD BEFORE POWER CONNECTION):

5
OPERATING MODES AND TRANSMITTER SETTING
AUTO MOdE
MANU MOdE
OFF MOdE
HOLIdAY
SET TEMP
SET TIME
SET HOUR
PROGRAMMING
CONSTANTS
TEST MOdE
ON OFF
Pressing any button first, you activate the display backlit. By another short press of the “ MENU “ button, you open the main menu in which
you can choose operating modes.
AUTO
The thermostat works according to the weekly program settings (this program can be changed; for detailed
description, see PROG, page 6).
MANU (default temperature setting of 21°C)
The thermostat works according to the temperature setting until the next manual change.
OFF
The thermostat is permanently switched off until the next manual change of the mode.
HOLIDAY
The thermostat maintains the preset temperature until the preset date and selected time. After expiry of the
preset period, it automatically returns to the AUTO/ MANU mode last selected before the holiday.
Press twice the “ MENU “, choose the AUTO mode by turning the “ “ and press the “ “ button to confirm.
(the Pr3 weekly program set by default, see page 6)
Press twice the “ MENU “, choose the MANU mode by turning the “ “ and press the “ “ button to confirm.
“.
(the anti-freeze temperature of 3 °C is kept – cannot be changed)
Press twice the “ MENU “, choose the OFF mode by turning the “ “ and press the “ “ button to confirm.
Press twice the “ MENU “ button, choose the mode by turning the “ “ and press the “ “ button to
confirm.
Step by step, set the temperature which the thermostat should keep during the holiday, date and time of your
return from the holiday. Change the values by turning the “ “ button and confirm each change by pressing
the “ “ button.
After making the settings, press the“ “ button to return to the basic screen.
Note: The holiday mode can be cancelled any time by selecting another AUTO or MANU mode.
CLOCK SETTING
Setting the current time and date.
Press twice the “ MENU “ button, choose the CLOCK mode by turning the “ “ button, and press the
“ “ button to confirm.
Change the values by turning the “ “ button and confirm each change by pressing the “ “ button (the
parameter modified is always flashing); pressing the “ “ button, you return to the menu).
PROG
You can set 9 weekly programs with 6 temperature changes per day. The Pr1 and Pr2 programs are empty;
Pr3 to Pr7 programs are set by default. The PrU and PrL are also set by default, intended for the EVEN/ODD
week option (for details, see pages 6 and 8).
(PROGRAMMING)
CONST
Setting the control parameters. For a detailed description, see page 7.
Press twice the “ MENU “ button, choose the CONST mode by turning the “ “ button, and press the
“ “ button to confirm.
(CONSTANTS)
TEST
Testing the correct connection to boiler.
Press twice the “ MENU “, choose the TEST mode by turning the “ “ button, and press the “ “ button
to confirm (RELAY TEST is showed on LCD). Turn the “ “ button to start testing. The output relay will be
switched on/off several times (the ON/OFF messages appear on the LCD).
SMS form: Auto
Change of the mode to AUTO. Thermostat will be work acc. last setting weekly program.
SMS form: Manu
Change of the mode to MANU. Thermostat will be keep last setting temperature.
SMS form: Off
Change of the mode to OFF. You can cancel the mode by the SMS: Temp xx or Auto or Manu

6
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.3
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.4
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.5
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.6
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.7
U
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
L
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.1 program No.2
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Tables of temperature programs:
Note:
5/21 means
that the required
temperature at 5
o’clock is 21 °C
All the
indicated
programs
can be
changed!
PROGRAMMING
SELECT dAY
TIME CHANGES
SELECT PROGRAM
Odd-EVEN MOdE
Even or odd week selection:
PROG
You can set 9 weekly programs with 6 temperature changes per day. The Pr1 and Pr2 programs are empty;
Pr3 to Pr7 programs are set by default. The PrU and PrL are also set by default, intended for the EVEN/ODD
week option (for details, see page 6).
Press twice the “ MENU “ button, choose the PROG mode by turning the “ “ button, and press the “ “
button to confirm.
The selected program number is flashing on the display. Turning the “ “ button, choose the program which
you want to change and press the “ “ button to confirm. Turning the “ “ button, choose the number of
days to be programmed (you can program day-by-day or 1-5 = Mon-Fri, 6-7 = Sat-Sun, or 1-7 = Mon-Sun)
and press the “ “ button to confirm.
The 1st change time starts flashing; set the time by turning the “ “ button and press the “ “ button to
confirm. Set the temperature for this time by turning the “ “ button and press again the “ “button to con-
firm. The 2nd change time appears on the display. Proceed in the same way as with the first change setting.
In this way, you can set up to 6 temperature changes per day. To return one step back, shortly press the
“ “ button; to return to the main menu, press the “ “ button long.
After changing the preset program, check whether all the changes made conform to your requirements!
It is not necessary to apply all six changes to one day!
(PROGRAMMING)
Change in the program settings:
This setting is suitable, for example, for shift operation (the requirements on thermal comfort in the object
change every week). The PrU and PrL programs will alternate automatically. The programs can also be modi-
fied according to your requirements.
Press twice the “ MENU “ button, choose the CONST mode by turning the “ “ button, and press the “ “
button to confirm. Repeat pressing the“ “ button until the constant No. 9 appears on the LCD. Set YES by
turning the “ “ button, and press the “ “ button to confirm.

7
CONSTANTS
TEMP.
TEMP.
TYPE OF REGUL.
t
t
T
Heating
ON
desired
temp.
t
t
T
Heating
ON
desired
temp. proportional
band
t
t
T
Heating
ON
desired
temp.. hysteresis
TYPE OF REGUL.
CONST
Setting the control parameters.
1
2
3
ENGLISH
Setting the limit of the minimum temperature which can be set. If using the GSM module, you will be
informed by an SMS that the room temperature has dropped below this value. Choose within the range
from 3 °C to 10 °C (by 0.5 °C).
4CONTROL TYPE
Press twice the “ MENU “ button, choose the CONST mode by turning the“ “ button, and press the “ “
button to confirm.
Language selection (CZ/PL/EN/DE/RU/SVK).
Choose the language by turning the “ “ button and press the “ “ button to confirm.
MINIMUM CONTROL TEMPERATURE
Set the value by turning the “ “ button and press the “ “ button to confirm.
MAXIMUM CONTROL TEMPERATURE
PI = proportional-integral control
The PI-control principle consists in comparison of the current room temperature with the desired temperature.
The PI-control aims at achieving and maintaining the desired temperature without overshooting (see the graph). For correct function of the
PI-control, set the control parameters according to the type of the heating system with respect to the room thermal inertia;
see CONST 6.
Note: If the PI-control is selected, CONST 5 is skipped automatically.
(CONSTANTS)
(English language set by default)
(5 °C set by default)
(39 °C set by default)
Setting the limit of the maximum temperature which can be set. If using the GSM module, you will be
informed by an SMS that the room temperature has risen above this value. Choose within the range from
15 °C to 39 °C (by 0.5 °C).
Set the value by turning the “ “ button and press the “ “ button to confirm.
(PID control set by default)
Choose the type of control by turning the “ “ button and press the “ “ button to confirm.
HS = Hysteresis
Difference between the desired and current temperature.
If the hysteresis is 1 °C and the desired temperature is 20 °C, the thermostat switches off at 20 °C, and on at 19 °C (see the graph).
For correct hysteresis function, set the parameters according to the heating system type; see CONST 5.
Note: If hysteresis is selected, CONST 6 is skipped automatically.
Selection of the control type:
PID = proportional-integral-derivative control
The PID-control principle consists in continuous comparison of the current room temperature with the desired temperature,
and automatic adaptation of the controller to the given conditions.
This is the most perfect continuous control; you can achieve not only short control time, but also high accuracy without permanent con-
trol deviation. The minimum switch-on time is internally set to 2 minutes, the proportional band is 2 °C, the time interval is automatically
recalculated according to current temperature conditions.
Note: If the PID-control is selected, CONST 5 and CONST 6 are skipped automatically.
PID-CONTROL
PI-CONTROLHYSTERESIS
CAUTION! ONLY IN CASE OF LOCKING BY PASSWORD (see CONST19)
If the “ “ key symbol appears on the LCD, the constant selected cannot be modified and you must know the
PASSWORD (see CONST 19, page 8). You can change the constant after entering the password. After you exit the
CONST mode, the security lock of the constants related to the control will be activated automatically.
Note: The graphs are just tentative; the real control course differs according to current conditions in the measured object!

8
HYSTERESIS
MIN TIME ON
MIN TIME ON
PI ZONE
PRE SWITCH MOdE
SUMMER MOdE
Odd-EVEN MOdE
HEATING
TEMP CORRECT
(factory setting of 2 min.)
MINIMUM SWITCH-ON TIME
(factory setting of 2 °C)
PI-CONTROL BAND
Set the interval by turning the “ “ button, and confirm with the “ “ button.
Select within the range of 1 to 5 minutes. The setting is given by the
heating system type, and depends on the PI-control time period selection.
Setting according to the table is recommended.
Set the value by turning the “ “ button, and confirm with the “ “ button.
TThis value determines the temperature at which the PI-control starts functioning. For example, the
desired temperature is 22 °C, the proportional band is 1.5 °C. Up to 20.5 °C, the source heats fully.
When this value is reached, the PI-control starts. The PROPORTIONAL band can be set within the
range of 0.5 to 3.0 °C (by 0.1 °C).
Set the PI band by turning the “ “ button, and confirm with the “ “ button.
5SETTING HYSTERESIS PARAMETERS
(factory setting of 0.5 °C)
(factory setting of 2 min)
HYSTERESIS
MINIMUM SWITCH-ON TIME
6SETTING PI-CONTROL PARAMETERS
(factory setting of 10 min.)
PI-CONTROL INTERVAL
Select according to the object’s thermal inertia. The optimum setting usually falls within the range of
10 to 15 min. The adjustable range is 5 min to 20 min (by 1 min).
Here you can set the minimum switch-on time of the boiler in minutes at hysteresis. Select within the
range from 1 to 5 minutes according to the type of the heating system used (see the table).
Set from 0.1 to 6 °C. According to the value preset, the thermostat switches on at the temperature:
T switching = T required - HYSTERESIS
Set the hysteresis by turning the “ “ button, and confirm with the “ “ button.
Set the value by turning the “ “ button, and confirm with the “ “ button.
Heating type Minimum source
switch-on time
Electric heating 1
Plate radiators 2 (3)
Cast iron radiators 4
Floor heating 5
7
This function guarantees you the required temperature at the required time. You need not consider when
to switch the heating on in order to be warm when getting up in the morning without heating unnecessarily
long in advance. You just program the time at which you want the desired temperature. Within two opera-
ting days, the program ascertains the thermal constants of the room and then it switches the heating on
in advance sufficiently. The preliminary switch-on time is limited to 2 hours.
PRELIMINARY SWITCH-ON OF HEATING
Set YES/NO by turning the “ “ button and press the “ “ button to confirm.
(NO set by default)
8
In this mode, you are not allowed to switch the heating on. It can particularly be used in the summer
period, when you need not heat. After you enable this mode, the “ “ symbol appears on the display.
Note: The anti-freeze protection (3 °C) is still enabled. In this mode, you cannot change the temperature
or set the holiday mode!
SUMMER MODE
Set YES/NO by turning the “ “ button and press the “ “ button to confirm.
(NO set by default)
9
If you choose “YES”, the PrU and PrL programs will alternate automatically according to the current week
(even/odd). This setting is suitable, for example, for shift operation (the requirements on thermal comfort
in the object change every week).
EVEN-ODD WEEK SELECTION (NO set by default)
Set YES/NO by turning the “ “ button and press the “ “ button to confirm.
10
Setting the thermostat function.
HEATING = the output relay (for heating systems) switches if the current temperature drops below the desired value
COOLING = the output relay (for cooling systems) switches if the current temperature rises above the desired value
HEATING / COOLING SELECTION (HEAT set by default)
Set HEAT/COOL by turning the “ “ button and press the “ “ button to confirm.
11
This is used for correcting the temperature measured by the thermostat. The setting can only be done
after 12 hours of operation, when the internal sensor temperature has settled. Measure the room
temperature with a thermometer; if it is different from the temperature on the thermostat,
set the correction within the range of -5 °C do +5 °C.
TEMPERATURE CORRECTION
Set the correction by turning the “ “ button and press the “ “ button to confirm.
(0 °C set by default)

9
ERROR PIN
Checking the
GSM module.
PIN entered
correctly.
Wrong PIN.
Reset BPT322 GST
and enter PIN again.
13 ENTER PIN
14 GSM TEST
EXT SENSOR12
12 EXT SENSOR
EXT SENS STOP
INSERT SIM
SIM card not inser-
ted. Insert the SIM
card, disconnect
power to the 5 s,
make adjustment
and repeat test.
TO SENdER
TO ANOTHER NR
420000000000---
tEL nO
When choosing 2) and 3) option we enter a phone number n the international format (420123456789),
to which return SMS messages on the thermostat condition should be sent. Is possible to enter a phone
number min. 10-digit to 15-digit.
PHONE NUMBER SETTING
Turning the “ “ button, enter the phone number stepwise; confirm each setting with the “ “ button.
Allows the following options:
1) TO SENdER = SMS will be sent back to the telephone number from which the message was sent.
2) TO ANOTHER NR = SMS will be sent back to the telephone number entered in the thermostat.
3) bOTH NUMbERS = SMS will be sent back to both telephone numbers (combination options 1 and 2).
15 RELAY TEST
RELAY TEST
Testing the correct connection the thermostat to boiler (this function is identical with the TEST mode
in the main menu).
Start the test by turning the “ “ button. The output relay is switched on/off several times (the ON/OFF
messages appear on the LCD). The “ “ button displays the next constant; pushing “ “ you return to
the main menu.
15
ON OFF
13
Enter the PIN code of the SIM card inserted in the thermostat.
PIN CODE SETTING
Turning the “ “ button, enter 4 digits stepwise; confirm each setting with the “ “ button.
GSM TEST
14
12
The external sensor can be used for:
1, control according to the room temperature - the sensor is located in the room ( - - - option)
2, control according to the floor temperature - the sensor is located in the floor (- - - option)
EXTERNAL SENSOR SELECTION
Set the external sensor option by turning the “ “ button and press the “ “ button to confirm.
( - - - set by default)
- - - If connected, the external sensor measures the temperature at the place of its installation
(suitable, for example, for places at which the thermostat cannot be located, yet you want to
control according to this room);
15…99,5°C If connected, the external sensor monitors the floor temperature; the maximum
temperature allowed for floor heating must be set (control according to the room
temperature, with simultaneous floor temperature monitoring).
If the preset limit temperature is exceeded, the thermostat is switched off irrespective of the room
temperature, and the “EXT SENS STOP” message appears on the LCD. The heating device is switched
on again if the external sensor temperature drops by 0.5 °C.
If the external sensor is unconnected or faulty, the “EXT SENS ERROR” message appears on the LCD.
If an external sensor is connected, the symbol appears on the LCD (to approx. 2 minutes).
3, maximum floor temperature monitoring - the sensor is located in the floor (selection of 15 to 99.5°C)
After setting the PIN code of the SIM card inserted in the thermostat is performed to test the GSM
module and PIN validation.
Turning the “ “ button to start test of GSM module and checking of PIN code.
The“ “ button displays the next constant,; pushing “ “ you return to the main menu.

10
16 LOCK
17 KEYCOdE
18 SERVICE dAY
19 PASSWORd
YOUR CODE
20 VERSION
TEMP. IN AUTO
TEMP IN MANU
OPER HOURS H.C.
TEMP 2Nd SENS
20 VERSION (restoring the default settings)
Firmware version, informative parameter only.
If you press the “ “ button long (for about 3 s), the RESET message appears shortly on the LCD and
the thermostat returns to the default settings!
KEY LOCK
This is used for locking the controls as a protection against undesirable interference of a foreign person.
16
KEY CODE
This constant can be set if CONST 16 = YES. It is used for setting the code by which you will be able to
activate the controls. Set a four-digit combination (range from 0 to 9).
The keys will be locked within 1 minute (after opening the basic display). The “ ” symbol appears on
the LCD. If you press the “ “ or “ “ button, the LCD asks you to enter the key code; after entering
the correct code, you are able to make any changes (the controls are functional again). The controls will
automatically be locked again after you finish the setting (within approx. 1 min).
17
BOILER INSPECTION REMINDER
Set the date on which you want to be informed about the necessity of the prescribed boiler service. At the
required time, the “MAINTENANCE NECESSARY” message and the “ ” symbol will appear on the bot-
tom line of the LCD (you can cancel the message by setting a new date for the next boiler maintenance!).
18
Set YES/NO by turning the “ “ button and press the “ “ button to confirm.
Gradually set 4 digits by turning the “ “ button; confirm each setting with the “ “ button.
RECOMMENDATION: - Record the key code in the table
- You can cancel the code by setting CONST 16 to NO, or by restoring the
default settings of the thermostat (see CONST 20).
- in case of loss of the code, it is necessary to bring the thermostat to factory settings using pressing
buttons RESET (see page 1) and MENU (will erase all settings changes).
Gradually set the day, month and year by turning the“ “ button, confirm each setting with the “ “.
(NO set by default)
(1.1.2032 set by default)
19 PASSWORD (not set by default)
It is used for locking the constants related to the given control settings. Suitable for service technicians.
After a numerical code has been entered, the user cannot change constants No. 4, 5, 6 and 10.
If you open the CONST mode and browse the constants, the “ ” symbol appears next to the constants
locked; if you turn the “ “ button, the password is required! Unless you enter the password, the con-
stants remain locked. To try to unlock them again, you must exit the CONST mode and browse up the
constant locked again.
Turning the “ “ button, gradually enter four digits and confirm each setting with the “ “.
USER TIPS
QUICK CHANGE OF REQUIRED TEMPERATURE / PROGRAM IN THE AUTO MODE
Press twice the ““ ; the required temperature starts flashing on the display. Change the required tempera-
ture by turning the “ “ button and press the “ “. The change will last until the next program change.
Press twice the ““; the required temperature starts flashing on the display. Change the required tempe-
rature by turning the “ “ button and press the “ “. The change will last until the next manual temperature
change.
Press thrice“ “, the setting programm starts flashing on the display. Change it by turning “ “
button and press the “ “.
SMS form: Temp xx (where xx are only integers within the range of CONST2 and CONST3)
Change of the desired temperature; the change will last until the next temperature change given
by the program.
QUICK CHANGE OF REQUIRED TEMPERATURE IN THE MANU MODE
SMS form: Temp xx (where xx are only integers within the range of CONST2 and CONST3)
Change of the desired temperature; the change will be permanent.
OPERATIONAL HOURS
Push the “ “ button four times. The boiler operating hours appear on the LCD. The figure on the picture
means 906 hours 43 minutes.
Resetting the counter:
When operational hours are displayed, turn the “ “ button anti-clockwise.
EXTERNAL SENSOR TEMPERATURE
Push the “ “ button five times. The current temperature of the external sensor appears on the LCD; the
value is only informative, and appears only if the external sensor is monitoring the maximum floor temperature
(see CONST 12, page 9).

11
Info Information on the heating system status
Auto Setting AUTO mode, thermostat will be work acc. last setting weekly program
Manu Setting MANU mode, thermostat will be keep last setting temperature
Off Heating system switched off permanently. ; to cancel the function, use the
Temp xx message, thermostat will automatically enter into the MANU mode with the
given temperature or SMS message Auto (for AUTO mode) or Manu (for MANU)
Temp xx Required temperature change (only integer numbers can be entered, they must fall
within the permitted range of maximum and minimum temperatures –CONST2 and
CONST3).
Call Back call
xx = temperature value in °C (always a two-digit number, e.g. 05)
!
Requir: xx.x Temperature required (user set)
Act: xx.x Current room temperature
Set on
Set off
Heating system On
Heating system Off
AUTO
MANU
OFF
Thermostat in automatic AUTO mode
Thermostat in manual MANU mode
Thermostat in the OFF mode (permanently off)
Sig: x Signal strength at the place where the module is located; where x is the
value within the range of 0 to 5:
0..undeterminable or no signal detected
1..the worst strength
5..the best signal strength
Sens 2: xx.x Current temperature of the external sensor
Battery! Low batteries in the thermostat
Noakcept! Error indicated (wrong SMS format, etc.)
xx.x = temperature value in °C
SIGNAL GSM x Determines the signal strength at the place where the thermostat is located;
where x is a value within the range from 0 to 5:
0..undeterminable or no signal detected
1..worst level
5..best level of signal
REQUIR TEMP Information on the desired temperature preset
PROGR 3 PERIOd 2 Information on the program preset (e.g., 3) and the time interval running
(interval 2)
SMS RECEIVEd Information the thermostat received new SMS
HOLIdAY IN 22.7 Only displayed in the holiday mode; informs on the end of holiday when the
thermostat restores the last selected AUTO/MANU mode.
T EXT SENS 25.0 Current temperature of the external sensor, displayed only if the sensor is
connected
EXT SENS STOP If the preset limit temperature of the external sensor in the maximum floor
temperature monitoring function is exceeded (see page 7), the thermostat is
switched off
Info: If using a credit card, you must make a paid call once in 3 months. This call is executed automatically (in 80 days, between 4 and 9
PM) to the phone number entered in the thermostat (CONST tEL nO); after 20 s, the call is terminated automatically. You can execute this
function earlier by means of the “Call” SMS message.
Note: If the minimum / maximum room temperature (preset CONST 2 and 3) is exceeded, the “WARNING” SMS is
automatically sent in a form similar to that in the „Info“ form.
BACK MESSAGES ARE SENT WITHIN 3 MINUTES!
FORMS OF BACK MESSAGES FROM THE THERMOSTAT
Any type of mobile phone can be used for sending and receiving back messages!
If you can set the font size (format) in your phone, always use the MEDIUM size when writing messages
(if there are three options), or the BIG size (if there are two options).
FORMS OF MESSAGES SENT
INFORMATION IN THE LCD DYNAMIC LINE

12
MADE IN CZECH REPUBLIC
ELEKTROBOCK CZ s.r.o.
Blanenská 1763
Kuřim 664 34
Tel.: [phone]
www.elbock.cz
not included in the
packing, type CT04-10k,
CYXY 2 x 0.5 mm,
10 kΩ, lenght 3 m,
plastic case PVC
(CT01-10k and
CT02-10k sensors can
also be used)
External sensor:
included in the
packing
type AD05-Jack,
5V/ DC, 2.5 A
Power source:
Dimensions - receiver:
Dimensions - transmitter:
136.5 28.5
83
TECHNICAL PARAMETERS
VOLTAGE FAILURE:
By short voltage failure on receiver comes to connection establishment with transmitter within one hour. It is necessary to set only time (all other settings
remain saved in memory), if there are not rechargeable batteries in the transmitter.
RED LED LIT ON RECEIVER (FAILURE):
The thermostat is in failure mode (2 minutes ON and 8 minutes OFF).
1) Check the transmitter (power supply control).
2) Test the thermostat for correct connection by using TEST mode see page 5.
If the connection between transmitter and receiver is not established, please contact the service department under www.elbock.cz.
PRACTICAL EXAMPLES OF USING
THE THERMOSTAT DOES NOT RESPOND TO SMS COMMANDS:
1) Check the transmitter (power supply control).
2) Check if the SIM card is activated.
If the connection between transmitter and receiver is not established, please contact the service department under www.elbock.cz
USING AND SETTING OF BPT322 GST:
The thermostat is located in a room where anti-freeze temperature must be maintained (e.g. 7°C).
1. Connect the BPT322 GST strictly according to the instructions.
2. Choose the MANU mode.
3. Press the “ “ button and set the temperature of 7 °C by turning the “ “ button.
4. Before arriving at the object, write an SMS in your mobile with the wording: Temp 23; then send the SMS to the number of the SIM card inserted in your
thermostat. After receiving the message, the thermostat automatically switches on the heating system until the desired temperature is reached.
Then BPT322 GST automatically sends the “BACK SMS message” informing you about the temperature change made. After arriving at the object, you can
change the temperature according to your needs on the thermostat directly.
CERTIFICATE OF GUARANTEE
(guarantee period for the product amounts to 2 years)
product No.: date of sale:
stamp of shop:
examined by:
Pb
LEAD FREE
in compliance with RoHS
In case of guarantee or post-guarantee service, send the
thermostat including proof of purchase to the manufacturer’s
address. The guarantee does not cover faults resulting from
incompetent installation or interference in the device design.
DECLARATION OF CONFORMITY
We, ELEKTROBOCK CZ s.r.o., herewith declare that the product
BPT322 GST conforms to the basic requirements and other
corresponding provisions of the Directive 1999/5/EC.
Issued: 01.04.2012 on www.elbock.cz
Receiver
Power supply 230 V/ 50 Hz
Communication
type two-way
Frequency 433.92 MHz
Range 300 m (free area)
35 m (built-up area)
Sensitivity < -102 dBm
Output relay, max. 8 A
Protection IP20
Working temp. 0°C TO +40°C
Transmitter
Power supply 5 V/ DC, 2.5 A,
typ AD05 - Jack
GSM module SIM 900
Aerial direct 1dB
HF power < 10 mW
Frequency 433.92 MHz
Hysteresis 0.1 to 6°C
Adjustable temp. range +5°C to 39°C
Temperature setting po 0.5°C
Measurement accuracy ± 0,5°C
Protection IP20
Working temperature 0°C to +40°C
