Elite Screens EB100HW2-E12 Quick reference guide

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 1
EVANESCE B SERIES
Section 1: Screen Design
1.1 What is it for?
The Evanesce B is a versatile in-ceiling projection screen that conveniently disappears from view when
not in use. It can be installed from within the above-ceiling airspace or from below thanks to its
removable base panels that were originally designed for the European market.
1.2 How does it work?
Its GREENGUARD certified MaxWhite® FG (fiberglass-backed) 1.1 gain matte white material provides
superb color temperature with wide diffusion uniformity. The screen is moved by a strong, fast-acting
tubular motor and comes with a full IR/RF wireless, 12-volt trigger and Ethernet control package.
Section 2: Product Features
2.1 Characteristics
Screen Material
•GreenGuard® Certified MaxWhite® Fiberglass (FG) front projection material with black backing
•1.1 Gain with a 180° wide-viewing angle for commercial and residential presentations
•Not compatible with Ultra/Short-throw Projectors
•Black masking borders enhance picture contrast
•4K Ultra HD, Active 3D, and HDR Ready
•Available in the following diagonal sizes:
•100" and 120" in 4:3 format
•92", 100", 110" and 120" in 16:9 format
Design and Installation
•Aluminum housing with white finish (RAL9003) is slim yet strong and moisture resistant
•Concealed in-ceiling recessed front projection screen for multi-use rooms
•Installation kit included for above or below ceiling
Control System
•Internal Radio Frequency/Infrared receivers with IR, RF remotes included
•Low voltage 3-way position wall switch
•Standard 5-12 volt trigger to synchronize screen operation with the projector's power cycle
•RJ45 port allows 3rd party control systems integration
•Optional in-wall up/down switch (part# ZIW-W) - sold separately
•Optional wireless 5-12v triggers - sold separately
Quality and Reliability
•Tubular motor allows swift operation with a superior weight tolerance and operational lifespan
•Flame Retardant: Complies with NFPA 701 Standards
•GREENGUARD® and GREENGUARD® Gold Certified
•2-year Parts & Labor manufacturer's warranty
•3-year warranty offered through ENR-G program (Education, Non-Profit, Religious and Government)

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 2
2.2 Certifications
2.3 Model Numbers
Model Number Diagonal
Size
Aspect
Ratio
View
Height
(in)
View
Width
(in)
Screen
Material Gain Case Color
Net
Weight
(lbs)
Gross
Weight
(lbs)
Packaging
Dimensions
(LxHxW)
EB92HW2-E12 92" 16:9 45.1 80.2 MaxWhite® FG 1.1 White 28.1 50.6 99.2"x8.3"x7.7"
EB100VW2-E12 100" 4:3 60.0 80.0 MaxWhite® FG 1.1 White 38.7 51.9 100.0"x8.3"x7.9"
EB120VW2-E8 120" 4:3 72.0 96.0 MaxWhite® FG 1.1 White 36.3 58.8 115.4"x8.3"x7.7"
EB100HW2-E12 100" 16:9 49.0 87.2 MaxWhite® FG 1.1 White 30.6 52.5 105.7"x7.9"x7.5"
EB110HW2-E12 110" 16:9 53.9 95.9 MaxWhite® FG 1.1 White 33.4 56.8 115.0"x8.3"x7.7"
EB120HW2-E8 120" 16:9 58.8 95.9 MaxWhite® FG 1.1 White 35.9 59.6 122.8"x7.5"x7.9"
EB100HW2-E8 100" 16:9 49.0 87.2 MaxWhite® FG 1.1 White 30.5 51.2 106.2"x8.1"x7.6"
Section 3: Screen Material Specifications
3.1 Characteristics
MaxWhite® Fiberglass (FG) is fiberglass backed for
added stiffness which provides the flattest possible
non-tensioned screen surface with universal
applications. This material provides wide viewing
uniform diffusion while giving precise definition,
color reproduction and black & white contrast. The
screen surface has a black-backing to eliminate light
penetration, is mildew resistant and washable with
mild soap and water.
* Manufacturer tip: This is an enhanced matte
white product for higher end DLP/LCD projectors suitable for commercial and residential
presentations.

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 3
Features & Benefits
•Multi-layer weave with textured surface
•Fiberglass backing with black backing
•Gain: 1.1
•View Angle: 180° (90° ± LR)
•Not compatible with Ultra/Short-throw Projectors
•Mildew Resistant
•Active 3D, 4K Ultra HD, and HDR ready
•Surface can be cleaned with mild soap and water
•Flame Retardant: Complies with NFPA 701 Standards
•GREENGUARD® and GREENGUARD® Gold Certified | UL 2818
Specifications
Thickness
0.36 mm (0.014”)
Weight
350 g/m2
Maximum Height
3.2 M (10 ft)
On-axis gain
1.0
Half-Gain Angle
Does not reach half gain
3.2 Gain and Viewing Angle Chart

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 4
Section 4: Execution
4.1 Important Safety & Warning Precautions
Caution: The screen’s Black Top Drop is already set to its maximum drop distance. There is NO extra Black Top
Drop in the roller. Please be aware of this as it will void your warranty with Elite Screens. Unapproved changes or
modifications (except for cutting the power cord for hardwire installations) to this unit are prohibited and will void
your warranty. For more information, please contact our Technical Support Department at [phone] Ext.
604.
•Please retain this user’s guide for future reference.
•To avoid damaging the unit, do not use with any unauthorized accessories not recommended by
the manufacturer.
•Handle the unit carefully during transportation to avoid any damages.
•To ensure safe and reliable operation, direct connection to a properly grounded power source is
advised.
•The power outlet supplying power to the unit should be close to the unit and easily accessible.
•Do not install the unit on uneven, inclined surfaces;
•Do not install in damp places to avoid an electric shock or short circuit.
•Do not place any heavy objects over the power cord.
•Position the power cord properly to avoid creating a trip obstacle.
•To avoid an electrical shock or fire, due to a loose contact or short circuit, do not overload the
power cord.
•The internal & external parts of this unit are not end user serviceable. Do not attempt to
disassemble this unit by yourself. No one except authorized technicians can open and make
repairs to this unit.
•Make sure the power source that this unit is connected to has a continuous power flow.
•If there is need to use an extension cord, make sure the cord has an equal rating as the appliance
to avoid over heat.
•Do not handle the power plug when your hands are wet or your feet are in contact with water.
•Properly dispose of this equipment according to the environmental regulations in your area when
product is no longer of service.
Do not use this unit under the following circumstances.
•Disconnect the power cord under the conditions of heavy rain, wind thunder or lightning.
•Avoid direct sun light, rain shower and moisture.
•Keep away from fire sources and high temperature to prevent this device from overheating.
•Cut off the power supply first before transportation or maintenance.
•To avoid possible injury and/or an electric shock, do not attempt to use this screen if there is
obvious damage or if there are any evident broken parts.

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 5
4.2 Installation Warning
The instructions provided in this user’s guide are for reference only. Please consult a professional
installation company for further installation and safety advice. The installer must insure that proper
mounting hardware is used to provide adequate strength suitable for the installation. Elite Screens is not
liable for any faulty installations. For limit adjustment instructions, please contact our Technical Support
Department at [phone] Ext. 604
The Screen’s Top Black Drop is already set to its maximum drop distance. There is NO extra top black drop in
the roller. Please be aware of this as it will void the limitation of your warranty.
Individual modifications to this product are prohibited and will void the warranty with the manufacturer. Please
contact Elite Screens Customer Service for any questions.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur on a particular installation. If this equipment
causes harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures.
Reorient or relocate the receiving antenna of the device which may be casing the interference.
Increase the separation between the screen and the device’s receiver.
Connect the equipment into a different power outlet other than the device.
4.3 Pre-Installation
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
3. In order to protect the screen from exposure to stains, keep the screen out of contact with foreign
particles such as dust, sawdust, and/or liquids.
NOTE:
Regardless of the mounting method, the screen should be securely supported so that the vibration or pulling on
the viewing surface will not cause the casing to become loose or fall. The installer must insure the fasteners that
are used are of adequate strength and suitable for the installation location.

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 6
4.4 Controls and Accessories
Evanesce B Series| Controls and Accessories
A. IR Remote
B. RF Remote
C. Wall switch control box
D. 5-12 volt trigger cable
E. IR extended “eye” receiver
F. Wireless 5-12v (3.5 mm)
mono trigger cable
G. AAA batteries
H. Bubble leveler
4.5 Screen Operation
Electric Current: Depending upon region, your Elite Screen will operate on 100v, 110v, or 220v voltage.
1. After ensuring the power outlet & screen are compatible (voltage), plug the power cord into the power outlet.
2. Once the screen has power, you’ll be able to control it using any of the 6 methods described below.
6 ways to control your Evanesce B
1. IR remote control (Item A, Fig 1): The Infrared functions by direct line of
sight contact with a beam range of 30 feet. Aim the IR remote at the “eye”
receiver once it has been connected to the control box’s RJ45 port.
2. IR “Eye” Receiver (Item E, Fig 2): The IR “Eye” Receiver plugs directly
into the control box’s RJ45 port to present a low profile line-of-sight control
option for your IR remote control even in a recessed ceiling installation.
3. RF Remote Control (Item B): The radio waves eliminate the need for a direct
line of sight with a range of 100 feet.
4. 3-Way Wall Switch (Item C, Fig 3): The 3-way wall switch is a wall mount
switch with an up/stop/down button and plugs directly into the control box’s
RJ45 port.
UP
STOP
DOWN
Fig.1
IR/RF remote

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 7
Fig.3
IR “eye” receiver
Fig.2
3 Way Wall Switch
(does not have IR sensor)
Control box
Control box
5. 5-12 volt trigger (Item D, Fig 4):The built-in 5-12V
trigger input allows your screen to synchronize its drop &
rise with the projector’s power cycle. The screen deploys
when the projector powers up and will retract when the
projector powers down. The 5-12 volt RJ45 cable connects
to your projector’s trigger output via a separate cable that
may or may not be provided by the manufacturer of the
projector. The trigger feature will not work without an
output cable from the projector, but it can be tested by
connecting the Red (+) and Green (-) cable to a 9-volt
battery.
DC 5-12V out
The back ofthe
projector
Wireless 5-12V trigger cable
UP
Stop
Down
Fig 5
5-12 volt trigger cable
Fig.4
RJ45 Input
6. Wireless 5-12 volt trigger (Item F, Fig 5): The RF
remote control serves as a dual purpose, independently as
a handheld remote control, or in conjunction with the
Wireless 5-12 volt trigger cable. The radio frequency
technology can be programmed to send a wireless signal to
synchronize its drop/rise with the projector’s power cycle.
Here’s how to set up your Wireless 5-12 volt trigger | Synchronization Instructions
Step1: Connect one end of the 3.5 mm wireless 5-12 volt trigger cable to the RF remote.
Step 2: Connect the other 3.5 mm end of the wireless 5-12 volt trigger cable to your projector
Step 3: Make sure to unplug your screen from the power outlet
Step 4: Hold the UP button on your RF remote
Step 5: While holding the UP button, plug the screen back to the power outlet
Step 6: Wait 5 seconds and then release the UP button
Step 7: Your 5-12V wireless trigger should now be activated with your screen and ready to be used and able to
control your screen with your projector’s power cycle
Repeat the steps again if not successful.
(Please be aware, the projector on/off cycle may take longer to fully activate. It usually takes around 20-
30seconds for full off and on cycle each time)

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 8
4.6 Hardware Parts List
Please make sure all parts listed below are included before proceeding with the installation.
Hardware Parts List for above ceiling installation
A. Suspension Bracket x 2
B. Suspension Bar x 4
C. End Flange x 2
C. M8x16mmx1.5mm washer x 8
D. M6x13mmx2mm washer x 8
E. M8 nut x 4
F. M6 nut x 4
G. M8x40mm hex screw x 4
H.M6x20mm screw x 4
4.7 Installation Instructions
The Evanesce B allows access for above or below ceiling installation. Please follow the instructions described in
the following steps below for your type of installation.
Power
The Evanesce B Series includes a 3-Prong
Power Cord (2-Prong Power Cord for some
countries) for use in a non-concealed power
outlet. If your installation will be entirely
concealed (including power outlet), Elite
Screens strongly recommends a hardwire
connection. Please refer to the image below for
both 110v & 220v wiring information.
A. Above Ceiling Installation Instructions
Assembly
1. Place the hanging bracket (A) over the left and right side ends of the housing and secure each
one using the M8x40mmhex screw (G), M8x16mmx1.5mm washers (C) and M8 nut (E) as
shown below.

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia 9
2. Place the Suspension Bar (B) over the Hanging Bracket (A) and align with the hole as shown
below according to the height requirement for your installation area. Secure the Suspension Bar
(B) with the M6x20mmScrew (B), M6x13mmx2mmWasher (E) and the M6 Nut (F). Repeat
the process for the other side.
3. Insert the end flange piece (C) on the edge of the housing as shown below to complete the assembly. The
screen is now ready for installation.
Hanging Bracket
G
C
E
H
D
F
Push end flange piece into
housing end until it snaps in
B
A

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
10
B. Below Ceiling Installation Instructions
Please make sure all parts listed below are included before proceeding with the installation.
Hardware Parts List for below ceiling installation
A. End Flange x 2
B. Hanging bracket x 2
C. Threaded rod x 4
D. Socket wrench x 1
E. M8x16mmx1.5mm
washer x 28
F. M8 nut x 20
G.M8 Top expanding bolt x 4
H. M8x40mm hex screw x 4
1. Measure and cut the ceiling installation slot:
The width should not exceed 100mm and not less than the width of the screen’s housing. Measure the
length of your screen to determine the length.
2. Drill 4 holes in the ceiling that correspond with the attachments on the various casing sizes. The
width should be 120mm. The length of (A5) in the diagram below depicts the distance between the
holes located on each ear end of the screen’s case.
70
Ceiling
Ceiling Truss
Screen installation slot
100
The ceiling wall
Install screw holes

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
11
D
H
G
3. The M8expanding bolts (G) mount into thick wood beams, stone or concrete and will support the
screen. Use the Socket wrench (D) to attach the M8x40mm hexagonal screws. The expanding bolts
should be firmly tightened and tested to make sure that they will hold the weight of the screen.
4. Insert the threaded rods (C) through the M8 expanding bolts and then attach the M8x40mm
hexagonal screws with the washer (E). Last put the Hanging Bracket (B) through the threaded rod
equal to the height of the screen’s housing. Once they are firmly in place (as shown below) make sure
that they will hold the weight of the screen.
5. Push the screen up into the space. Use the threaded rods (C) to attach the screen assembly to the
ceiling. The hexagonal screws (E) will connect the screen to the rest of the assembly. Once firmly in
place; use the nuts (F) to ensure a firm connection. Use the socket wrench (D) to make sure that the
bolts are firmly tightened.
C
Ceiling
E and F
C
B

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
12
6. Install end flange cover panel (A) between the gap and the screen to complete the installation.
Section 5: Product Specifications
5.1 Dimensions
5.1.1 Above Ceiling Dimensions
Model Number A A1 A2 Screen
Width A3 A4 A5 B B1 B2 B3 B4 B5 C C1 C2 C3 C4
Unit: mm
EB92HW2-E12 2291 2037 50 2137 2225 2230 2261 2548 1146 305 76 95 1527 80 925 145 180 50
EB100VW2-E12 2290 2032 50 2132 2225 2230 2260 2925 1524 305 76 95 1905 80 925 145 180 50
EB120VW2-E8 2695 2438 50 2538 2630 2635 2665 3128 1829 203 76 95 2108 80 925 145 180 50
EB100HW2-E12 2471 2214 50 2314 2406 2411 2441 2646 1245 305 76 95 1626 80 925 145 180 50
EB110HW2-E12 2695 2435 50 2535 2630 2635 2665 2771 1370 305 76 95 1751 80 925 145 180 50
Ceiling
Socket wrench (H)
Push
Push the screen to
the hole of the
ceiling the screw
across the hole of
the end cap.
Use the Socket wrench
to attach the washer
and the outside hex
screws, and then adjust
the bottom of the
screen to make it
parallel with the
ceiling, and then fasten
the screw.

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
13
Model Number A A1 A2 Screen
Width A3 A4 A5 B B1 B2 B3 B4 B5 C C1 C2 C3 C4
EB120HW2-E8 2913 2436 50 2535 2850 2855 2883 2794 1494 203 76 95 1773 80 925 145 180 50
EB100HW2-E8 2471 2214 50 2314 2406 2411 2441 2544 1245 203 76 95 1524 80 925 145 180 50
Unit: Inch
EB92HW2-E12 90.2 80.2 2.0 84.1 87.6 87.8 89.0 100.3 45.1 12.0 3.0 3.7 60.1 3.1 36.4 5.7 7.1 2.0
EB100VW2-E12 90.2 80.0 2.0 83.9 87.6 87.8 89.0 115.2 60.0 12.0 3.0 3.7 75.0 3.1 36.4 5.7 7.1 2.0
EB120VW2-E8 106.1 96.0 2.0 99.9 103.5 103.7 104.9 123.1 72.0 8.0 3.0 3.7 83.0 3.1 36.4 5.7 7.1 2.0
EB100HW2-E12 97.3 87.2 2.0 91.1 94.7 94.9 96.1 104.2 49.0 12.0 3.0 3.7 64.0 3.1 36.4 5.7 7.1 2.0
EB110HW2-E12 106.1 95.9 2.0 99.8 103.5 103.7 104.9 109.1 53.9 12.0 3.0 3.7 68.9 3.1 36.4 5.7 7.1 2.0
EB120HW2-E8 114.7 95.9 2.0 99.8 112.2 112.4 113.5 110.0 58.8 8.0 3.0 3.7 69.8 3.1 36.4 5.7 7.1 2.0
EB100HW2-E8 97.3 87.2 2.0 91.1 94.7 94.9 96.1 100.2 49.0 8.0 3.0 3.7 60.0 3.1 36.4 5.7 7.1 2.0
5.1.2 Below Ceiling Dimensions
Model Number A A1 A2 Screen
Width A3 A4 A5 B B1 B2 B3 B4 B5 C C1 C2 C3
Unit: mm
EB92HW2-E12 90.2 80.2 2.0 84.2 87.6 87.8 89.0 63.9 45.1 12.0 3.0 3.7 60.1 4.3 3.1 4.7 89.8
EB100VW2-E12 90.2 80.0 2.0 83.9 87.6 87.8 89.0 78.7 60.0 12.0 3.0 3.7 75.0 4.3 3.1 4.7 89.8
EB120VW2-E8 106.1 96.0 2.0 99.9 103.5 103.7 104.9 86.7 72.0 8.0 3.0 3.7 83.0 4.3 3.1 4.7 105.7
EB100HW2-E12 97.3 87.2 2.0 91.1 94.8 95.0 96.1 67.8 49.0 12.0 3.0 3.7 64.0 4.3 3.1 4.7 96.9
EB110HW2-E12 106.1 95.9 2.0 99.8 103.5 103.8 105.0 72.7 54.0 12.0 3.0 3.7 69.0 4.3 3.1 4.7 105.7
EB120HW2-E8 114.7 104.6 2.0 108.5 112.2 112.4 113.5 73.5 58.8 8.0 3.0 3.7 69.8 4.3 3.1 4.7 114.3
EB100HW2-E8 97.3 87.2 2.0 91.1 94.7 94.9 96.1 63.7 49.0 8.0 3.0 3.7 60.0 4.3 3.1 4.7 96.9
Unit: Inch
EB92HW2-E12 2291 2037 51 2139 2225 2230 2261 1623 1146 305 76 94 1527 110 80 120 2281
EB100VW2-E12 2290 2032 50 2132 2225 2230 2260 2000 1524 305 76 95 1905 110 80 120 2280
EB120VW2-E8 2695 2438 50 2538 2630 2635 2665 2203 1829 203 76 95 2108 110 80 120 2685
EB100HW2-E12 2472 2214 50 2314 2407 2412 2442 1721 1245 305 76 95 1626 110 80 120 2462
EB110HW2-E12 2695 2435 50 2535 2630 2636 2666 1847 1371 305 76 95 1752 110 80 120 2685
EB120HW2-E8 2914 2657 50 2757 2849 2854 2884 1868 1494 203 76 95 1773 110 80 120 2904
EB100HW2-E8 2471 2214 50 2314 2406 2411 2441 1619 1245 203 76 95 1524 110 80 120 2461

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
14
5.2 Drawings
5.2.1 Above Ceiling Drawing
5.2.2 Below Ceiling Drawing

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
15
5.3 Pictures
Evanesce B Series – Front View
Housing and Weight Bar Detail

PRODUCT WHITE PAPER
www.elitescreens.com
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India | Elite Screens China Ltd.
Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
16
Evanesce B Series – Housing
Section 6: About Elite Screens .
6.1 Company Description
Elite Screens Inc. is a California based company that specializes in making quality commercial and home-
theater projection screens for the retail and custom install sales channels. Our company began as an innovative
venture into the projection market by manufacturing veterans from the AV/IT industry. Elite Screens quickly
established itself as an entry level commercial and home theater screen manufacturer. This was accomplished by
making a quality product cost effective with a focus on mass-producing screen material, sizes and aspect ratios
that were most commonly preferred by AV customers in general. We focused on uniformity with what would
match the mainstream demographic while including extra features that are not usually included by other
manufacturers. In time, we progressed from just retail sales into the realm of custom installer/integrator
manufacture as our numerous reviews and awards will attest. We stand behind our product and are so certain of
customer satisfaction with the quality of our product that we offer a 2-year manufacturer's warranty which is
twice the industry standard. In our continued devotion to excellence in products and service, we are committed
to implementing green practices with our production. We have adopted manufacturing methods that promote
conservative regulation of our energy needs. Our simple product designs combined with the expertise of our
permanent staff ensures that our entire line of products are made by experienced hands devoted to the high
standards of today’s audio-video consumer.
###
