Elite Screens Elite Home 2 Series User manual

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
El
ectr
i
c
S
creen
Elite Home 2 series
Ver.1.6
Users Guide

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
Accessories for Home 2 series
① IR ② RF
③ Wall box
Red
+12V
Green
- 0V
④12V trigge
r
⑤
E
y
e recei
v
er
⑥Battery
Please always point to the eye
receiver when using the IR remote
⑦Bu
b
b
le leve
l

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
Im
p
ortant Safety and
W
arning Precautions
1. Be sure to read this manual
b
efore use and follow the
p
rocedures s
p
ecified:
Please retain this manual for future reference.
To avoid any damage, do not use any accessories not recommended by the
manufacturer. Handle the device carefully during transportation to avoid impact.
Do not put the device on uneven or inclined surfaces.
Do not put heavy objects on the power cord; affix the power cord properly to avoid
someone tripping over it.
Never overload the power cord to prevent electricalshock or fire.
Guard the device from any liquid or foreign object to avoid electrical shock or fire due to
loose contact or shor
t
circuit.
2. If any accessories need to
b
e replaced,
b
e careful to avoid a shor
t
circuit.
3. There are no user serviceable parts in the device. Nobody except authorized technicians can
open this device. To prevent the risk of electrical shock or fire, protect this device against
moisture and rain.
Make sure tha
t
the power source this device is connected to has a continuous power flow.
The rating label on the product indicates the rated voltage.
Do not handle the power plug when your hands are wet or your feet are in contact with water.
4. Do notuse this deviceunder the following circumstances:
Disconnectthe power cord under the condition of heavy wind, rain, thunder or
lightning.
Avoid direct sunshine, rain shower or moisture.
Keep away from fire sources and high temperature to prevent this device from overheating.
Cu
t
off the
p
ower su
p
p
l
y
firs
t
b
efore trans
p
ortation or maintenance.

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
W
arning
W
arning
N
O
T
E
:
The
p
ower outle
t
su
p
p
l
y
in
g
p
ower to the unit should
b
e close to the unit and easil
y
accessi
b
le
Reorient or relocate the receiving antenna
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet using a circuit different from where the receiver is connected
 Consult the dealer or an experienced radio/TV technician for help
Individual modifications to this product are prohibited and will void the warranty. Please contact
our Service Department for any questions.
This equipmen
t
has
b
een tested and found to comply with the limits for a Class B digital device,
p
ursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
To ensure safe and reliable operation, direct connection to a properly grounded power source is advised.

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
Sensor
3. Bubble Level: Included with the installation package is a small bubble level that can be useful in
determining if the screen is perfectly level when installing.
NOTE :
①
Please use the Down sign side as the bottom.
Bu
b
b
le
②
The Bubble should be in the middle position to determine that it is level.
Sensor
3-way manual wall box
switch
Sensor
1. 5/12V Trigger: The built-in 5/12V trigger
input for your new CineTension2 allows your screen
to synchronize its drop and rise with the projector's power
cycle. The screen drops when the projector powers up and
retracts when the projector powers down. The 5/12 volt
adaptor connects to your projectors trigger output via a
separate cable that may or may not be provided by the
projector manufacture. The trigger feature will not work
without an output cable from the projector, but it can be
tested using a 9-volt battery by simply connecting the Red
(+) and Green (-) cable to the 9-volt battery.
2. Wall Box and IR (Infrared) “eye” Receiver: The 3-way Wall Box switch enables the consumer
to manually operate the screen's drop/rise capabilities. The IR “eye” protrudes from the bottom of the casing to present a
low profile line-of-sight control option for your IR remote. It is a low-visibility alternative to using the wall box kit and its
ability to protrude from the bottom of the screen allows line-of-sight control even in a recessed ceiling installation.
3-prong power cable
Red: DC 12 +
Green: 0 V -
RJ-45 input connection for
5/12 volt trigger inside
of case

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
P
lease read this
g
uide prior to installation.
●Make sure the current rating is equal to that of the appliance rating when an extension cord is used.
●Do not use any accessories not provided by the manufacturer with this screen. We will not be responsible for
any risks of fire, electric shock, or injuries resulting from the misuse of this product with accessories not
designed for use with this product.
●Make sure the screen is mounted in a horizontal level position. We suggest consulting with a professional if
you are unsure on how to perform a proper installation.
INSTALLATION
The CineTension 2 series screen is designed for installation on either a wall or ceiling. All hardware is included to
allow either installation method however we do strongly recommend a professional installation for safety purposes.
The extruded hanging brackets are designed to slide anywhere on the back of the screen to accommodate a wall
or ceiling installation and provide an easy alignment with wood studs and trusses.
Please follow the steps below for recommended installation instructions.
Mounting Hardware Kit – Please make sure all of the following items have been supplied before proceeding installation.
Parts identification:
1. Begin by sliding the Bolts (B) thru the left and right slide channel located on the top back of the CineTension 2 screen’s
casing as shown on picture.
D
Qty 2 –Extruded
Hanging Brackets
C
Qty 2 – Masonry screws
Qty 2
–
Masonry anchors
B
Qty 2 - Bolts
A
Qty 2 – Wood Screws
Qty 2 – DrywallAnchors

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
2. Slide the Extruded Hanging Brackets (D) thru the rail located below the slide channel until it meets with the top part
of the bolts (B) and then slightly tighten the lug-nuts located on the top and bottom of the bolt with a wrench to secure the
extruded hanging brackets.
3. Mark the location of where the screen is to be installed and drill your hole. Insert the proper screw into the drilled
hole and finish tightening the bolts to the bracket.
Masonry Anchors and Bolts (C) are used on concrete/masonry wall/ceilings.
Plastic drywall anchors (A) are included for drywall mounting.
Wood screws (A) are to be used for wooden wall/ceiling studs on screen sizes less than or equal to 120” inches
(diagonal).
Masonry anchors (C) should be used for wall/ceiling installations of screen sizes greater than
120 inches (diagonal). We strongly advise to consult with a professional for such installation.
5. Examples of an installed CineTension 2 on a wall, ceiling and enclosed.
A
B
C
D
Top hole for ceiling installation
Back hole for wall installation
Flush mount
to wall Flush mount
to ceiling Enclosed installation
*Allow 2” of spacing
between the front and
back of the screen casing.

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
The IR receiver will be connected from the screen
IR “eye” sensor
11.65 mm. in width
Power Cord
A
pp
rox. 6 ft. len
g
th
Although the IR remote requires a direct line of sight with the IR sensor to
function, the screen’s case can be hidden from sight and operated using the
RF remote. When depressing the directional buttons you should hear a faint
click signifying that the mechanism is working properly.
80mm in width I
R
UP
Stop
Down
RF
This is the IR (Infra-Red) remote with a
range of 15 Ft. Battery size AAA This is the RF (Radio Frequency) remote with a range of 30 Ft. Battery size AAA
** Please remember to always point to the infra-re
d
receiver when using the IR remote. The IR remote can also wor
k
with
a Universal Learning Remote Control usually by programming the Screens IR codes in your Universal Learning Remote.

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
N
ote: For more U
p
date
d
FAQ,
p
lease visit www.elitescreens.co
m
1. Q: Wh
y
does m
y
screen no lon
g
er function?
A: There are a few
p
ossible thin
g
s
y
ou could check:
A.)Make sure your wall plug has power and that the screen is properly plugged in.
B.) Please check the fuse to y our screen. (Call Tech support for location of fuse)
C.) If screen works well with the line switch but not with the remote control, make sure the remote control has goo
d
batteries in it.
D.) Our electric screens with a tubular motor installed are equipped with a Thermal relay. This would
include all Home (2, 3), Tension (1, 2, 3) series, and VMAX screens with a diagonal size above 180". This
feature will automatically shut off screen in the event the motor becomes too hot, preventing overheating of
the motor. To correct this, let screen alone for 10-15 minutes and try again.
2. Q: How is the screen material cleaned?
A: The screen material can be cleaned with mild soap and water.
3. Q: What type of batteries do the remote controls require?
A: The IR and RF remote controls use AAA alkaline batteries
4. Q: Can you manually pull down the screen?
A: No, manually pulling down the screen will damage the electronic motor rolling system.
5. Q: How could I setup my Screens IR receiver to work with my learning remote control system? Do you have any IR
codes I can use to achieve this?
A: Our IR remote controls have been evaluated and entered in to the databases of some Universal remote control
manufacturers. Please contact the manufacturer of your remote to inquire about your remotes ability to function with
ours. If they have not evaluated our remote control then the following list of Binary codes will be used for most remote
setups.
For Spectrum, VMAX2 (Plus), Home2(3) and Tension2(3) Series
Up: 1111 0000 0001
Stop: 1111 0000 0010
Down: 1111 0000 0100
6. Q: What is the gain on the matte white screen material?
A: The matte white material has a gain of 1.1. For detailed specs, info please check our web-site for more detail

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
Two (2) year warranty parts and labor from purchase date as follows (except for refurbished units
as specified below):
Refurbished units carry a 90-day parts and labor warranty.
Demo units or open box items are AS IS items and do not carry a warranty.
Each party will be responsible for one way shipping during the warranty period.
DOA (Defective On Arrival): Must be reported within 7 business days of receipt. An RMA
(Return Merchandise Authorization) number must be issued in order to process a replacement.
Elite Screens will replace the DOA (Defective On Arrival) unit with a brand new replacement
*(see exceptions below) after the DOA unit is received and/or confirmed defective. Once the
p
roduct is received, Elite Screens will send out a new* unit to the customer by ground service
(based on stock availability). Should a problem be reported after the 7-day grace period, the item
must be shipped to us for warranty repair.
Missing Parts must be reported within the 7-day (DOA) grace period. If reported after 7 days,
customer will be only responsible for shipping and handling fees. If reported after 30 days of
receipt, customer is responsible for cost of the parts and shipping & handling fees.
*A new or refurbished replacement will be sent out to the customer depending on the type of purchase (new or
refurbished) or based on stock availability.
Please do not return any unauthorized items to Elite Screens, as they will be refused.
The RMA number must be included on the outside label of your shipping box and shipping documents. Our
warehouse is not authorized to accept returns without an RMA number on the shipping label. RMA numbers are
valid for 45 days from the date of issue.
●All shipping damages must be reported within 7 business days upon receipt of the Product. After 7 days Customer is
responsible for all incurred costs
●Inspect all shipments upon arrival. If damage or loss is apparent upon delivery do not accept the shipment until you
make a notation of the damage on all copies of the carrier's delivery receipt and have the driver sign all copies to
acknowledge the damage. Do not sign a clear receipt for damaged or missing items or there will be no basis for a
claim. Ask the carrier to make a detailed inspection of the damage. File a claim with the carrier. Cooperate and
follow up as necessary to secure final settlement
●Immediately advise Elite Screens of all damages or problems. Do not return merchandise to Elite Screens. File your
claim with the carrier enclosing copies of the bill of lading (signed by the driver) and inspection report as support. Keep
all packing materials and boxes with the damaged product. DO NOT throw any thing away. Although Elite Screens will
provide any assistance possible we can not be responsible for the actual filing of claims on the carrier or accept liability
for non-collectable freight claims
For Warranty and Service requests please fill out a RMA /Service Form at:
http://www.elitescreens.com/service_form.htm.
Please Visit this link for full Warranty information:
http://www.elitescreens.com/service.htm
For Customer Service and Technical questions, please contact Elite Screens at:
Telephone: [phone] Fax: [phone]

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
Two wa
y
s to re
g
ister
y
our warrant
y
with Elite Screens Inc.
A. On Line (Faster and Easier) www.elitescreens.com/re
g
ister.htm
B. Fill out & Fax to
(
562
)
483-8498, Attn: Customer Service De
p
t.
*YourName:
__
Address:
___
_
_
_
_
____
_
_
__
Cit
y
/State/Zi
p
:
_
___
_
____
_
_
_
_
____
_
_
_
*Email Address:
____
_
____
_
_
_
_
____
_
_
_
__
*Phone:
_
_
____
_
_
_
_
____
_
_
_
_
___
*Screen Model:
_
_
_
____
_
_
_
_
____
_
_
__
*Serial Number:
_
_
_
_
_
_
____
_
_
_
_
____
*Date of Purchase:
_
__
____
_
_
_
_
____
_
_
_
_
__
*Dealer/Reseller Purchased from (name of the reseller):
____
_
____
_
___
What is
y
our Pro
j
ector Model:
_
_
_
_
_
_
____
_
_
_
___
A
pp
lication:
___
Home
__
_
Education
__
_
_
Cor
p
oration
___
_
_
Government
__
_
Others
How would
y
ou rate this screen?
_
_
_
Excellent
___
Good
_
_
Ok
__
_
Im
p
rovement needed
Comments:
If
y
ou have pictures of
y
our screen
y
ou'd like to share with us, please email
y
our pictures to:
[e-mail]
Or call us at 877-511-1211 Sales and
Marketing Div.
For any technical inquiries, please email to:
[e-mail] or 877-511-1211 Customer Service Div.
For any warranty claim inquires, please email to:
[e-mail] or 877-511-1211 Customer Service Div.

www.elitescreens.co
m
/ eliteinfo
@
elitescreens.com
