Elite Screens WhiteBoardScreen Series User manual

Rev. 04/25/17 DR elitescreens.com
W h i t e B o a rd S c re e n™ S e r i e s
Dry-Erase Ambient Light Rejecting Projection Screen
User’s Guide
Thank you for choosing the WhiteBoardScreen™ Series dry-erase whiteboard projection screen! Please
read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a
long product life.
Precautionary Notes:
Before using the dry-erase function of your whiteboard screen, please make note of the following
instructions to properly maintain and clean your dry-erase surface projection screen. (These Whiteboard
cleaning tips are just as relevant with any dry-erase writing surface as they are with our Whiteboard-
Projection Screens.)
1.Only use a high density foam eraser when removing dry-erase markings from the Whiteboard screen.
2. Do not use abrasive erasers as these may scratch the surface of the screen.
3. Never spray the whiteboard cleaner solution onto the surface while marker writing is present and then
attempt to use a high density foam eraser to remove. This will only smear the dry-erase marker ink
making the surface more difficult to clean and will likely ruin the foam eraser.
4. If there are any dry-erase markings left behind even after attempting to remove them using our high
density erasers, spray our whiteboard cleaning solution directly onto the screen surface and use only a
soft microfiber cloth to wipe-down and clean the area.
For a video demonstration, please visit: http://www.elitescreens.com/whiteboardscreen-cleaning
If replacement cleaning accessories are needed, please visit the Whiteboard cleaning accessories section
of our website at http://www.elitescreens.com/clean-whiteboard

Rev. 04/25/17 DR 1 elitescreens.com
Hardware and Parts List
Please make sure all parts listed are included before proceeding with installation.
a b c
d e f
G and H are not
Actual individual
parts included but
configurations only by
combining parts (d)
and (e) with the
butterfly screw.
g h
I j k
Note: The WhiteBoardScreen™
Series
eraser should only be used for
the WhiteBoardScreen™.
Parts List
a. Qty 4–Butterfly screw
b. Qty 12–Wall screw
c. Qty 12–Hollow wall (or drywall) anchor
d. Qty 2–Top hanging wall brackets (to the wall)
e. Qty 2–Top hanging whiteboard brackets (to the whiteboard)
f. Qty 2–Bottom hanging bracket
g. For whiteboard diagonal size 60 (4:3) inches
h. For whiteboard diagonal 80(4:3), 96 (16:9) inches.
i. Qty 2–whiteboard eraser
j. Qty 2–Dry‐erase pens
k. Qty 1–WhiteBoardScreen™ cleaner

Rev. 04/25/17 DR 2 elitescreens.com
X2
2Fig.6
Installation
1. Mark the location the WhiteBoardScreen™ will be installed and drill your holes for all Top Hanging Wall
Brackets (fig.1) and Bottom Frame Hanging Brackets (fig.2).
2. Attach the Top Hanging WhiteBoardScreen™ Brackets (fig.3) to the Top Hanging Wall Brackets (fig.1) with the
Butterfly Screws according to the size of the WhiteBoardScreen™ as specified in fig.4 and 5
below.
3. Next, affix the Top Hanging Wall Brackets (fig.1) and the Bottom Frame Hanging Brackets (fig.2) to the drilled
locations and install the wall screws (fig.6).
4. Lastly, hang the WhiteBoardScreen™ on the brackets (fig.7).
Fig.1 Fig.2 Fig.3
Fig.4 Fig.5
Note:
Fig.4 Bracket configuration for whiteboard 60 inch diagonal (4:3) screens
Fig.5 Recommended Bracket configuration for whiteboard 80 inch (4:3) and 96 inch (16:9)
Cx 12
D
BX1 AX4
Fig.7

Rev. 04/25/17 DR 3 elitescreens.com
Desktop Projector Mode Overhead Projector Mode

Rev. 04/25/17 DR 4 elitescreens.com
Notice to Installer:
Please use the following installation instructions to obtain superior optical performance from the
StarBright 4 Angular Reflective ALR (Ambient Light Rejecting) Screen.
Make sure to follow these instructions in order for the StarBright 4 to perform correctly.
•Angular‐Reflective material is not compatible with ultra/short‐throw projectors
•Minimum lens throw ratio 1.5x image width
•Ambient light must not come from the same direction as the projector
Since angular-reflective means that the projected image will reflect at the mirror-opposite angle, it is
important to position the projector so that the viewer will get the best possible image.
Step 1: Establish the general “eye level” of the viewers
Step 2: Set the appropriate projection level
Step 3: Adjust the screen height level and projection angle
Input Angle (A) = Output Angle (B) aligns with the viewer’s angle

Rev. 04/25/17 DR 5 elitescreens.com
Recommended Installation Locations for desktop and overhead projector installations
The StarBright4 material used in this WhiteBoardScreen™ has a special high gain that is
angular reflective.In order to take full advantage of this special material, it is important
that the WhiteBoardScreen™ is installed properly so that the projected image is viewed
within the recommended viewing angle.
It is normal for some viewing areas to be less bright than the center due to the nature
of the screen material. It is not a defect and minor “hot spotting” will occur as a result.
The below charts will assist in determining several factors to consider to help you with your
installation. Please note that these are only recommendations.
Desktop projector installation
Model
Number
Overall
Width
(W)
Overall
Height
(H)
Installation
Height (A)
Suggested
Projection
Distance (B)
Sitting
View
Distance
(C1)
Standing
View
Distance
(C2)
Suggested
Projection
Height
(D)
Viewer
Distance
(E)
Sitting
View
Height
(F1)
Standing
View
Height
(F2)
Sitting
View
Angle
(01)
Standing
View
Angle
(02)
Unit: mm
WB60V 1190.0 930.0 1000‐1200 1950‐2950
160 114 800‐1000 1200 1200 1700 9° 6°
Unit: Inches
WB60V 46.9 36.6 39.4‐47.2 76.8‐116.1
6.3 4.5 31.5‐39.4 47.2 47.2 66.9 9° 6°
Standing
View
Sitting View

Rev. 04/25/17 DR 6 elitescreens.com
Model
Number
Overall
Width
(W)
Overall
Height
(H)
Installation
Height (A)
Suggested
Projection
Distance (B)
Sitting
View
Distance
(C1)
S
tanding
View
Distance
(C2)
Suggested
Projection
Height
(D)
Viewer
Distance
(E)
Sitting
View
Height
(F1)
Standing
View
Height
(F2)
Sitting
View
A
ngle (01)
Standing
View
Angle (02)
Unit: mm
WB80V
1630.0 1230.0 1000‐1200 2750‐3750 228 145 800‐1000 1200 1200 1700 10° 6°
Unit: inches
WB80V
64.2 48.4 39.4‐47.2 108.3‐147.6 9.0 5.7 31.5‐39.4 47.2 47.2 66.9 10° 6°
Standing
View
Sitting View
Desktop Installation explanation:
A= Installation Height (Floor to bracket drilling hole)
B= Suggested Projection Distance (Projector to screen)
C1= Sit View Distance (The brightest view when people are sitting down in relation to the angle setting in
F1) C2= Stand View Distance (The brightest view when people are standing in relation to the angle
setting in F2)
****User selectable average recommendations****
D= Suggested Projection Height (Floor to project center)
E= Viewer Distance (User to
projector) F1= Sit View Height
F2= Stand View Height
****The basis of height is from an average height****
θ1= Sit View Angle (Screen slope angle between screen and wall to achieve brightest view)
θ2= Stand View Angle (Screen slope angle between screen and wall to achieve brightest view)
(*****Relation between C1, F1 and θ1; Relation between C2, F2 and θ2*****)
W= Overall Width
H= Overall Height

Rev. 04/25/17 DR 8 elitescreens.com
Overhead Projector installation
Models
Overall
Width
(W)
Overall
Height
(H)
Installation
Height (A)
Suggested Projection
Distance (B)
Ceiling Height
(C)
Suggested Offset
(D)
Viewer
Distance (E)
Sitting View
Height (F1)
Standing View
Height (F2)
Unit: mm
WB60V 1190.0 930.0
2340 1950‐2950 2500 130 1200 1200 1700
Unit: inches
WB60V 46.9 36.6
92.1 76.8‐116.1 98.4 5.1 47.2 47.2 66.9
Standing
View
Sitting View

Rev. 04/25/17 DR 11 elitescreens.com
Over head installation explanation:
A= Installation Height (Suggested from floor to top of screen)
B= Suggested Projection Distance (Projector
to screen) C= Ceiling Height
D= Suggested Off set (Distance between projection center and top
of screen) E= Viewer Distance (User to projector)
F1= Sit View Height
F2= Stand View Height
****The basis of height is from an average height****
W= Overall Width
H= Overall Height
Note: The data is for reference only. The installer should base the installation
according to the customer and the space provided.
For more information, technical support or your local Elite Screens contact,
please visit www.elitescreens.com
Models
Overall
Width (W)
Overall
Height (H)
Installation
Height (A)
Suggested
Projection Distance
(B)
Ceiling
Height (C)
Suggested
Offset (D)
Viewer
Distance (E)
Sitting View
Height (F1)
Standing View
Height (F2)
Unit: mm
WB80V 1630.0 1230.0 2340 2750‐3750 2500
17
1200 1200 1700
Unit: inches
WB80V 64.2 48.4
92.1 108.3‐147.6 98.4
6.
47.2 47.2 66.9
Sitting View
Standing View
