Elkay EFRC8C-A Installation manual

PAGE 1 97162C (Rev. L - 05/17)
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
IMPORTANT
Installation/Care/Use Manual
Fully Recessed Refrigerated
Fountain with FLEXI-GUARD®
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
To assure you install this model easily and correctly, PLEASE READ THESE SIMPLE
INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR INSTALLATION
FOR COMPLIANCE WITH PLUMBING, ELECTRICAL AND OTHER APPLICABLE CODES.
After installation, leave these instructions inside the fountain for future reference.
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER
LINES IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY
FROM THE BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN,
CREATING AN ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL
CONTENT OF THE WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS
INDICATED. ANY DRAIN FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO
ELECTRICALLY ISOLATE THE FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.
SEE FIG. 7
SEE FIG. 8
SEE FIG. 9
SEE FIG. 9
SEE FIG. 11
25
20, 21
19, 22
23
24
EFRC8C, EFRC12C EFRC8CDC, EFRC12CDC
Installer
USES HFC-134A REFRIGERANT

PAGE 297162C (Rev. L - 05/17)
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
FIG. 1
FINISHED FLOOR LINE
EFRC8C/EFRC12C ROUGH-IN
LEGEND:
A = RECOMMENDED WATER SUPPLY LOCATION 3/8” O.D. UNPLATED COPPER TUBE CONNECT
STUB 1-1/2” (38mm) OUT FROM WALL, SHUT OFF BY OTHERS (BOTH SIDES).
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4” O.D. DRAIN (BOTH SIDES).
C = ELECTRICAL SUPPLY LOCATION (BOTH SIDES).
NOTES:
1. THERE ARE HOLES AND KNOCKOUTS PROVIDED ON EACH SIDE OF THE MOUNTING BOX THAT
ARE INTENDED TO BE USED TO MOUNT THE BOX. USE SIX SCREWS OR BOLTS (NOT PROVIDED).

PAGE 3 97162C (Rev. L - 05/17)
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
FIG. 2
FINISHED FLOOR LINE
EFRC8CDC/EFRC12CDC ROUGH-IN
LEGEND:
A = RECOMMENDED WATER SUPPLY LOCATION 3/8” O.D. UNPLATED COPPER TUBE CONNECT
STUB 1-1/2” (38mm) OUT FROM WALL, SHUT OFF BY OTHERS (LEFT SIDE ONLY).
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4” O.D. DRAIN (LEFT SIDE ONLY).
C = ELECTRICAL SUPPLY LOCATION (BOTH SIDES).
*WATER AND DRAIN CONNECTIONS MUST BE MADE FROM LEFT SIDE ONLY.
NOTES:
1. THERE ARE HOLES AND KNOCKOUTS PROVIDED ON EACH SIDE OF THE MOUNTING BOX THAT
ARE INTENDED TO BE USED TO MOUNT THE BOX. USE SIX SCREWS OR BOLTS (NOT PROVIDED).

PAGE 497162C (Rev. L - 05/17)
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
INSTALLATION INSTRUCTIONS
1. Remove shipping brace from mounting box and discard.
2. Fasten mounting box into wall cutout using screws or bolts (provided by others) through the holes or knock
outs provided on each side of the mounting box. (See Fig. 1 or 2)
3. Install fountain body to mounting box using #10 x .63” (16mm) PHSM screws and large clips provided.
4. Place refrigeration package into mounting box and connect water lines. (See Page 5 for details)
5. Water inlet is 3/8” O.D. and waste tube is 1-1/4” O.D. Contractor is to supply waste trap and service stop
valve in accordance with local codes.
6. Connecting lines to be unplated copper and thoroughly ushed to remove all foreign matter before
connecting
to refrigeration package. The furnished strainer (Item 18) should be added to the supply line.
7. Connect the refrigeration package to the supply line service stop valve. Connect supplied fountain (internal
plumbing) tubes as shown in gures 3, 4, 5, or 6. Remove any burrs from water tubes before inserting into
ttings. (See Figs. 13 and 14) DO NOT SOLDER TUBES INSERTED INTO THE STRAINER AS DAMAGE
TO THE O-RINGS MAY RESULT.
8. Electrical: Insure power supply is identical in voltage, hertz, and phase to that specied on the refrigeration
package serial plate. Never wire compressor directly to the power supply.
9. Turn water supply on and check thoroughly for leaks.
10. Release air from tank by depressing push button; a steady stream of water assures all air is removed.
11. Re-check for leaks.
12. Stream height is factory set at 35 PSI. If supply pressure varies greatly from this, turn adjustment screw on
regulator (Fig. 8). Clockwise adjustment will raise the stream height and counter-clockwise adjustment
will lower stream height. For best adjustment, stream should hit basin approximately 6-1/2” from the
bubbler.
13. Rotate fan blade on refrigeration package to insure proper clearance and free fan action.
14. Connect power supply.
15. Install grill using #8 x 1.00” (25mm) PH screws and small clips provided.
TROUBLE SHOOTING AND MAINTENANCE
1. Orice Assy: Mineral deposits on orice can cause water ow to spurt or not regulate. Mineral deposits
may be removed from orice with a small round le not over 1/8 diameter or a small diameter wire.
CAUTION: Do not le or cut orice materials.
2. Actuation of Quick Connect Water Fittings: Cooler is provided with lead-free connectors which utilize
an o-ring water seal. To remove tubing from the tting, relieve water pressure, push in on the gray collar
while pulling on the tubing (See Fig. 13). To insert tubing, push tube straight into the tting until it reaches
a positive stop, approximately 3/4”.
Note: Danger! Electric shock hazard. Disconnect power before servicing unit.

PAGE 5 97162C (Rev. L - 05/17)
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
FIG. 3 FIG. 4
FIG. 5 FIG. 6
17
18
16
18
17
18
17 16
18
EFRC8C EFRC8C W/GLASS FILLER
EFRC12C EFRC12C W/GLASS FILLER
6
6
66
17
17

PAGE 697162C (Rev. L - 05/17)
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
1
3
28
11
13
11
9
15
8
FIG. 8FIG. 7
FIG. 9
NOTE: WHEN INSTALLING REPLACEMENT BUB-
BLER AND PEDESTAL, TIGHEN LOCKNUT ONLY TO
HOLD PARTS SNUG IN POSITION. DO NOT OVER
TIGHTEN.
BASIN
BASIN
2
3
Locknut
10
Adjustment
Screw

PAGE 7 97162C (Rev. L - 05/17)
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
16
14
5
7
DISPENSER/
DISPOSAL
26 12
4
726 27
FIG. 12
FIG. 11
FIG. 10
2
1
2
DESCRIPTION
1
2
3
ITEM NO. PART NO.
51299C
98926C
51469C
Filter Assy-1500 Gal.
Kit-Filter Head Fitting Includes John Guest Fittings
Assy -Filter & Bracket includes Fltr Head/Mtg Bkt/John Guest
Ftgs/Screws
WATERSENTRY® FILTER PARTS LIST
(See Fig. 12)
WATERSENTRY®Filter Detail
3

PAGE 897162C (Rev. L - 05/17)
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
PARTS LIST
ITEM NO. PART NO. DESCRIPTION
98536C
0000000931
40301C
40480C
40561C
40575C
62084C
62088C
56092C
75580C
70151C
70234C
56073C
40299C
40562C
50258C
50967C
61099C
1000001994
1000002162
55996C
110669443890
74070030
74070032
70567C
55001084
EFRCDF
55000881
EG23
31525028
40493C
50074C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Kit - Push Button Assy
Tailpipe - EFRC8, EFRC8F
Tailpipe - EFRC8CD
Precooler - EFRC12, EFRC12F
Precooler - EFRC12CD
Strainer/Ferrule Assy
Tube Assy - GF
Tube Assy - GF
Poly Tubing 48”(Cut to Length)
Locknut
Flat Washer Steel
Washer
Bubbler Assy
Drain - 1/2”
Glass Filler
Flat Washer Rubber
Flow Regulator Assy
Connector Assy
Kit - Tee 1/4 (3 Pack)
Kit - Union 1/4 (3 Pack)
Strainer
Screw - #10 x .63 PHSM
Screw - #8 x 1.00 PH
Speed Nut - #8
Clip - Speed
Fountain
Fountain - GF
Dispenser/Disposal
Grill
O-ring
Glass Filler
Gasket
FIG. 13
FIG. 14
NOTE: REMOVE ANY BURRS FROM WATER TUBES
BEFORE INSERTING INTO FITTINGS.
NOTE: WATER FLOW
DIRECTION
BUILDING WATER
INLET
SERVICE STOP
(NOT FURNISHED)
1/4” O.D. TUBE
WATER INLET
TO COOLER
3/8” O.D. UNPLATED COP-
PER TUBE CONNECT
COLD WATER SUPPLY
B CA
SIMPLY PUSH IN
TUBE TO ATTACH
TUBE IS SECURED
IN POSITION
PUSH IN COLLET
TO RELEASE TUBE
OPERATION OF QUICK CONNECT FITTINGS
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
OPERATION OF QUICK CONNECT FITTINGS
SIMPLY PUSH IN
TUBE TO ATTACH
TUBE IS SECURED
IN POSITION
PUSH IN COLLET
TO RELEASE TUBE
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
A B C
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.834.4816
ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484
PRINTED IN U.S.A. REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640
