Elkay DSBS130UVPC Manual

Table of Contents
Declaraon of Conformity 2
Associaon 2
Recommendaons for Safeguarding the
Environment 3
Explanaon of Warning/Safety Icons 3
Introducon 4
Components Guide 5
Product Specicaons 6
Before You Begin – Requirements for
Installaon 7
Mounng Dimensions 7
Operang Environment 8
Water 8
Electrical 8
Tools You Will Need 9
Unpacking the Kit 9
What’s in the Kit 10
Installing the Machine 11
Operang the Keypad 16
Roune Maintenance 17
Troubleshoong 20
Replacement Parts 23
NOTICE: Read the instrucons in this manual and retain for future reference.
Installaon and
Maintenance
Manual
ENERGY
SAVING
DSBS130UVPC DSBSH130UVPC

2
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
Declaraon of Conformity
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
Materials compliant for contact with drinking water
This unit is intended for the dispensing of drinking water, and so the materials that enter into direct contact with
water meet the criteria for food-grade components pursuant to the current legislaon. In addion, the unit is
manufactured in compliance with Italian Ministerial Decrees 174 of 04/06/2004 and 25 of 02/07/2012.
Electrical safety
This water cooler is designed, manufactured and marketed in compliance with:
 the safety objecves of the Low Voltage Direcve 2006/95/EC;
 the protecon requirements of the Electromagnec Compability Direcve 2004/108/EC.
The electrical safety of the product is ensured only when it is properly connected to an ecient, legally
compliant grounding circuit.
UL standard for safety of drinking water coolers, ANSI/UL 399, Issued: 2008/08/22, Ed: 7, Rev: 2013/10/18
CSA standard for refrigeraon equipment, CSA C22.2 No. 120, Issued: 2013/03/01, Ed: 4
Associaon
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
Internaonal Awards
2015 - BEST PROMOTION OF HEALTH AND HYDRATION
EUROPEAN AQUA AWARDS 2015, ROME
2015 - BEST ENVIRONMENTAL PRACTICE
EUROPEAN AQUA AWARDS 2015, ROME
2014 – BEST PROMOTION OF HEALTH AND HYDRATION
EUROPEAN AQUA AWARDS 2014, BUDAPEST
2013 – BEST PRODUCT INNOVATION
EUROPEAN AQUA AWARDS 2013, BERLIN
2012 – BEST ENVIRONMENTALLY FRIENDLY PRACTICE
EUROPEAN AQUA AWARDS 2012, ISTANBUL

3
1000003719 (Rev. A - 02/2017)
Recommendaons for Safeguarding the Environment
Packaging materials
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso032 c
The packaging materials are 100% recyclable. Please follow the local guidelines on waste disposal.
For safety reasons keep the packaging material out of the reach and sight of children.
Scrappage
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
The DSBS130UVPC and DSBSH130UVPC water coolers are made using recyclable material.
These units are marked in compliance with European Direcve 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE). By ensuring that the product is scrapped correctly, you will help to
prevent potenal negave consequences for the environment and for health. This symbol indicates
that the product should not be treated as domesc waste but should be taken to a dedicated recycling
center for electrical and electronic equipment. Immediately prior to scrapping, cut o the power cable.
For more informaon on the treatment, recovery and recycling of this product, please contact
the appropriate local oce, the waste disposal service or the reseller from which the product was
purchased.
These products contain no CFCs or HFCs, which contribute to global warming.
They are the rst water coolers on the American market to use natural refrigerant.
The refrigerang system is lled with R134a: a natural gas that does not contribute to global warming
and that allows for substanal Energy Savings.
Explanaon of Warning/Safety Icons
NOTICE: Indicates an instrucon which, if not followed, could result in damage to product or property
or poor product performance.
CAUTION: Indicates an instrucon which, if not followed, could result in minor or moderate injury.
WARNING: Indicates an instrucon which, if not followed, could result in serious injury or death.

4
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
Introducon
The DSBS130UVPC and DSBSH130UVPC coolers bring contemporary style and state-of-the-art technology
to commercial water dispensers. DSBS130UVPC and DSBSH130UVPC oer light, compact and powerful
performance made enrely from stainless steel.
 Mulple dispensing opons: cold sll water, cold sparkling water, room temperature sll water and/or hot
water.
 Natural materials throughout: stainless steel, aluminum
 Internal components made enrely of stainless steel
 DRY COOLING technology: a noiseless, low maintenance, and innovave cooling system which allows for great
performance and compact size
 Made enrely of stainless steel
 An-bacterial UV lamp at dispensing point ensures water delivery pure of microbiological contaminants
NOTICE: Due to rigorous tesng, product may reasonably be expected to contain traces of sanizing
soluon.

5
1000003719 (Rev. A - 02/2017)
Components Guide
Keypad
Drip tray
Power buon
Water inlet
CO2inlet
Power cord
Thermostat
Cold sparkling
dispenser
Room
temperature sll
dispenser
Cold sll
dispenser
DSBS130UVPC
DSBSH130UVPC
DSBS130UVPC keypad DSBSH130UVPC keypad
ENERGY
SAVING
ENERGY
SAVING
Keypad
Drip tray
Boiler switch
Power buon
Water inlet
CO2inlet
Power cord
Thermostat
ENERGY
SAVING
Cold sparkling
dispenser
Hot dispensers Cold sll
dispenser

6
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
Product Specicaons
Specicaon DSBS130UVPC DSBSH130UVPC
Cooling capacity gal/h (lt/h) 1.5 (5.7)
32 6 oz. cups/h
1.5 (5.7)
32 6 oz. cups/h
Cold water temperature* 42°F – 50°F
(5.5°C – 10°C)
42°F – 50°F
(5.5°C – 10°C)
Cooling technology Aluminium fusion block heat
exchanger
Aluminium fusion block heat
exchanger
Condensaon Venlated Venlated
Adjustable cooling thermostat Yes Yes
Refrigerant gas HFC R134a HFC R134a
Pump Professional booster pump Professional booster pump
Max hot water temperature - 185°F (85°C)
Hot water tank capacity gal (lt) - 0.265 (1)
Heater waage - 1000W
Inlet water pipe ø 1/4" ø 1/4"
Power 110V - 60Hz 110V - 60Hz
Power consumpon 200W - 2A 1130W - 9.4A
Working room temperature Min 41°F – Max 107.6°F
(Min 5°C – Max 42°C)
Min 41°F – Max 107.6°F
(Min 5°C – Max 42°C)
UNIT WEIGHT lb (kg) 67.5
(30.6)
67.5
(30.6)
SHIPPING WEIGHT lb (kg) 72
(32.6)
72
(32.6)
Dimensions W x D x H in (mm) 10.26 x 19.23 x 16.44
(261 x 488 x 418)
10.26 x 19.23 x 16.44
(261 x 488 x 418)
Dispensing area height in (mm) 10.99 (279) 10.99 (279)
Packaging dimensions
W x D x H in (mm)
14.45 x 23.74 x 27.3
(367 x 603 x 694.4)
14.45 x 23.74 x 27.3
(367 x 603 x 694.4)
Dispensing Supply opon (sparkling, cold
and room temperature water)
Supply opon (sparkling, cold
and hot water)
Push buons Stainless steel push buons Stainless steel push buons
Materials All robust stainless steel parts All robust stainless steel parts
* rated at a room temp. of 77°F and inlet water temp. of 68°F

7
1000003719 (Rev. A - 02/2017)
Before You Begin – Requirements for Installaon
Mounng Dimensions
Width
18.3” (465mm)
Depth
23.2” (589mm)
Height
20.5” (520.7mm)
Height
28" (711mm)
Height
12.75"
(324mm)
Depth
3.88" (99mm)
Diameter
8" (203mm)
Width
3.25" (83mm)
Footprint:
10.3” wide x 19.2” deep
261mm x 488mm
DSBS130UVPC DSBSH130UVPC
Over counter (includes 4" clearance on sides and back)
Under counter
Water lter
CO2 cylinder (typical, 20 pound)
Width
18.3” (465mm)
Depth
23.2” (589mm)
Height
20.5” (520.7mm)
Footprint:
10.3” wide x 19.2” deep
261mm x 488mm

8
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
Operang Environment
 Install the machine in a clean, dry, well-venlated room. It is designed to funcon correctly in environments
with a temperature of 16°C to 32°C – Climac Class N, (between 61°F and 90°F).
 Check that the water cooler is level, that it is on a surface that can support its weight and in an environment
suitable for its size and use.
 Do not place the machine near a source of heat.
 To guarantee adequate venlaon, leave at least 4" (100 mm) of space around the unit.
 Take care not to damage the cooling uid circuit. It is essenal to ensure that the tubes of the refrigerant
circuit are not damaged.
 The unit is not intended for use by children.
 Keep the areas surrounding the unit dry to avoid the risk of people slipping.
 The unit must not be cleaned with a water jet.
Water
 Always connect the water cooler to a water main that supplies drinking water only.
 Use of 1/4’’ diameter connecons is recommended.
 Turn o the main water inlet tap if the unit is not to be used for a long period.
Electrical
 Check that the voltage shown on the serial number plate corresponds to the voltage being
supplied at the installaon site.
 Do not use extension cables or mulple-power sockets. The machine must be located
close enough to a standard power socket that the supplied power cable reaches without
stretching.
 Aer installaon, check that the machine is not standing on its power supply cable.
 Ensure that it is possible to disconnect the power supply either by removing the plug or via a two-pole circuit
breaker placed upstream of the plug.
 Before any maintenance or cleaning operaon is carried out, remove the plug from the socket or disconnect
the power supply.
 If the power cable is damaged, it must be replaced by the manufacturer, by its technical support service or by
a qualied technician.
 Do not posion other electrical equipment in the immediate vicinity of the water cooler.

9
1000003719 (Rev. A - 02/2017)
Tools You Will Need
Unpacking the Kit
Remove the front panel (labeled FRONT) and cover of the
wooden packing case.
Remove the cardboard box and the internal protecve
packaging by sliding them up and over the top.
Once you have unpacked the machine, check all components
to ensure that they are not damaged. Contact the carrier
immediately if there has been any damage during shipping.
NOTICE: Ensure that your machine is installed by a
qualied technician in compliance with the
manufacturer’s instrucons and the local safety
guidelines.
NOTICE: Only qualied technicians should access the internal components of your machine.
(2) 8" adjustable wrenches
(1) 10" adjustable pliers
(1) 12" adjustable wrench
(1) universal screwdriver
(1) 12" pipe cuer
(1) wire cung pliers

10
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
What’s in the Kit
NOTICE: CO2 source is not included and must be supplied separately.
(1) DSBS130UVPC or DSBSH130UVPC
water cooler
(1) CO2
regulator
(1) external
water lter
(2) 3/8"–quick
connect connector
(1) supply hose 1/2 ips x 3/8
tube x 12” long
(1) water
shuto valve (1) water
pressure
regulator
(1) 10' coil CO2 tubing (natural)
1/4” OD
(1) 3/8” x 3/8”
quick connect
connector
(1) 10' coil water tubing (blue)
1/4” OD
(1) 10' coil water tubing (blue)
3/8” OD
PLUS

11
1000003719 (Rev. A - 02/2017)
Installing the Machine
CAUTION: Wear safety gloves when handling the machine. Metal edges are sharp, and touching them
could result in minor or moderate injury.
1. Install external water lter and CO2 cylinder.
1. Use (2) Phillips head screws to mount bracket to under-counter wall.
2. Use (4) Phillips head screws to mount lter head to bracket.
3. Remove cap from lter. Insert lter into lter head and turn clockwise (right) unl it stops.
When installing external water ller within the DSCABBSH cabinet, please refer to the following mounng
instrucons:
1. Use 3 Phillips head screws and washers to mount lter bracket to cabinet mounng strip as shown below.
NOTICE: Install CO2 source per manufacturer’s recommendaons.
1. 2. 3.
DSCABBSH

12
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
2. Cut, size and connect water and CO2 piping to t your installaon.
NOTICE: The water pressure entering the machine must be between 14.5 psi (0.10 MPa) minimum and
51 psi (0.35 MPa) maximum. If the inlet water pressure is higher than 51 psi, the water pressure regulator
supplied must be used.
NOTICE: An incoming ow rate of >1.0 gallon/minute is recommended for opmal quality of sparkling
water.
NOTICE: Check all input piping and connecons for leaks before connecng to the machine.
Water source:
threaded
ng
Water
source: open
3/8" pipe
Water lter
3/8"–quick
connect
adapter
1/4” x 1/4”
Water shuto
valve
Water pressure
regulator
Water
piping cut
to size
1/4” Water
tubing cut to
size
To water
cooler
Short
3/8"– 3/8" pipe
Using the quick connect ngs
To connect:
1. Make clean, 90° cut to
piping end.
2. Push piping straight into
ng unl it stops.
3. Pull back to check that
connecon is secture.
To disconnect:
1. Press in the end tab.
2. Pull piping out.
3. Release tab.
1/4” Gas tubing
cut to size
Regulator
CO2source
1/4” water
tubing cut
to size
Recommended total
length 6 feet
Use one of two
connecon
methods
3/8” x 3/8”
quick connect
adapter
3/8” Tubing cut to
size if addional
length is needed
3/8"–quick
connect
adapter

13
1000003719 (Rev. A - 02/2017)
3. Place the machine in its operang locaon.
NOTICE: Ensure machine remains level while being lied into place.
4. Connect external water and CO2 piping.
5. Plug the machine into the wall socket and turn it on.
1. Connect the power cable to the nearest socket.
2. Flip the power switch at the rear of the machine (A) to the "I" posion.
A
B
Water input Water input
CO2 input CO2 input
DSBS130UVPC
DSBS130UVPC
DSBSH130UVPC
DSBSH130UVPC
A
B
A
B
A
B

14
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
6. Purge the water lines.
1. Place receptacle beneath tap to catch dispensed water. Discard water as necessary.
2. Allow water to run connuously unl ow is clear of air.
3. Repeat for all taps.
7. Turn on the boiler (DSBSH130UVPC only).
NOTICE: Never turn on the boiler unless you have lled the machine with water.
NOTICE: Never turn on the boiler when the inlet water is disconnected.
1. Flip the boiler switch at the rear of the machine to the “I” posion.
2. Aer around 10 minutes, the water reaches the seed temperature.
CAUTION: Hot water reaches 185°F. Keep children away. Hot, boiling water and steam will scald if
spilled on skin. Do not touch the dispensing nozzle to avoid burns.
Press dispensing
buon
Press dispensing
buon
DSBS130UVPC DSBSH130UVPC

15
1000003719 (Rev. A - 02/2017)
8. Open the CO2 valve.
1. Using a screwdriver slowly turn valve screw counterclockwise
(le) to open valve.
2. Connue unl pressure reads 50 to 58 psi max.
9. Re-purge the line for sparkling water.
NOTICE: The water will ow at at rst, then gradually
become more sparkling as the line is purged of sll water.
10. Allow machine to complete inial chilldown.
NOTICE: Complete water heang will require around 10 minutes. The machine should not be used as a
water dispenser unl heang is complete.

16
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
Operang the Keypad
DSBS130UVPC
To dispense your water serving
Hold down the buon for that dispenser.
To stop dispensing your water serving
Release the buon for that dispenser.
Operang the Keypad
DSBSH130UVPC
To dispense your water serving
Hold down the buon for that dispenser.
Note: For safety reason, to dispense hot water you must press and
hold down the 2 hot water buons at the same me.
To stop dispensing your water serving
Release the buon for that dispenser.

17
1000003719 (Rev. A - 02/2017)
Roune Maintenance
Daily
 Clean all external surfaces of the machine, the drip tray and the dispensing nozzles.
NOTICE: It is recommended that all external components of the product be cleaned daily.
It is recommended that you use dish soap, warm water and a clean, so cloth to clean the product.
DO NOT USE THE FOLLOWING PRODUCTS:
Do not use ... chlorine bleach soluons on the product. Chlorides found in most soaps, detergents, bleaches and
cleaners can aack stainless steel. These products can cause surface-ping.
Do not use ... metal bers to clean the product. Metal bers have a tendency to disintegrate and release small
metal parcles that are embedded in the surface. Metal parcles oxidize and give the impression that the
surface of the product is rusng.
Do not use ... abrasive cleaners or abrasive pads, as these will scratch the surface of the product.
Do not use ... a water jet.
 To remove limescale, use a slightly acidic product (e.g. citric acid) that has been heavily diluted – excessive
acidity may damage the surface of the steel.
 To clean the drip tray, use a diluted limescale cleaner such as citric acid. The drip tray may also be washed in
the dishwasher.
 Before cleaning the keypad, turn o the machine to prevent accidentally dispensing water.
Weekly
 Use a vacuum to clean out all vents.

18
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
Annually
 Replace the water lter aer 6000 gallons or a maximum of 1 year, or earlier depending on water quality.
NOTICE: The lter head has an internal shuto valve that stops the ow of water when the lter is
removed. It is not necessary to shut o the water supply.
1. Turn used lter counterclockwise (to the le) 1/4 turn to remove from lter head. Pull lter away from head
and remove.
2. Remove the cap from the new lter. Place the cap on the used lter to seal it.
3. Insert the new lter into the lter head and turn the lter clockwise (to the right) unl it stops.
4. Place a receptacle under the sll water dispenser and dispense connuously for a minimum of two gallons to
purge air and ne carbon parcles from lter.
 Sanize the machine
NOTICE: This operaon must be carried out by your ELKAY reseller or by a qualied technician.
When required
 Replace the UV lamp
CAUTION: The light emied by the ultra-violet lamp may cause serious burns to the eyes and skin.
Disconnect the electrical source of supply of the UV radiaon before opening the machine.
1. Disconnect the unit from its electrical source.
2. Once the unit is shut down, rotate and remove the nozzle and remove
the top cover unscrewing the two screws on the sides of the nozzle
(A).
3. Disconnect the electrical connector of the UV OUT lamp. Pull the lamp
removing it from its ng holder —handling it carefully.
4. Insert the new lamp and reconnect the connector — handling it carefully.
5. Repeat the procedure for all the dispensing valves.
6. The used UV lamps can be disposed at your local waste management site.
NOTICE: This operaon must be carried out by your ELKAY reseller or by a qualied technician.
NOTICE: For the replacement of UV OUT pipe is not necessary to turn water o.
AA

19
1000003719 (Rev. A - 02/2017)
 Set the thermostat
1. Set the thermostat between 5 and 6 to control the temperature of the cold
water.
COLDER
OFF
1
2
3
4
5
6
7

20
DSBS130UVPC and DSBSH130UVPC
Installaon and Maintenance Manual
Troubleshoong
Problem Possible Cause Acon To Take
No water dispense The main water valve is closed Open the valve
The power switch is set to OFF Set the power switch to ON
Malfuncon in the ribbon cable connecon/
spade connectors
Repair connecon to main circuit board
The water inlet solenoid is not working Bypass the solenoid and replace it
The aluminium fusion block is frozen Defrost the aluminium fusion block
Reduce the thermostat seng
The low voltage transformer is not working Replace the transformer
Problem Possible Cause Acon To Take
Low ow dispense The lter is clogged Replace the lter
The main water valve is not fully opened Open the valve
The ow control valve is not fully opened
(sparkling water only)
Open the valve
The CO2 cylinder is empty (sparkling water
only)
Replace the cylinder
Problem Possible Cause Acon To Take
Sparkling water doesn’t
come out
The CO2 cylinder is empty Replace the cylinder
The pump is not working Force the pump to start
Replace the pump if broken
The solenoid is not working Repair or replace the solenoid
The ow control valve is too ght Open the valve
Problem Possible Cause Acon To Take
Water is not cold enough The thermostat is not adjusted properly Adjust the thermostat
The condenser is dirty Clean the condenser
The fan is not working Replace the fan
Cold or not warm enough air is blowing
through the condenser
Check for faulty compressor or gas leak on
the refrigerant circuit and repair
Malfuncon in the over temperature switch/
relay
Switch the machine o and wait 5 minute for
restart
Replace if broken
The compressor is not working Replace the compressor
Leak in the refrigeraon system Refrigeraon system requires repair or
replacement
Problem Possible Cause Acon To Take
Hot water is not hot The power switch is o Switch on the boiler
The safety therm-o-disk has tripped Reset the therm-o-disk
Disconnected wires to the boiler Connect the wires
