Elkay DSWH160UVPC Manual

Table of Contents
Declaraon of Conformity 2
Associaon 2
Recommendaons for Safeguarding the
Environment 3
Explanaon of Warning/Safety Icons 3
Introducon 4
Components Guide 5
Product Specicaons 6
Before You Begin – Requirements for
Installaon 7
Mounng Dimensions 7
Operang Environment 8
Water 8
Electrical 8
Tools You Will Need 9
Unpacking the Kit 9
What’s in the Kit 10
Installing the Machine 11
Operang the Keypad 17
Roune Maintenance 18
Troubleshoong 21
Replacement Parts 24
NOTICE: Read the instrucons in this manual and retain for future reference.
Installaon and
Maintenance
Manual
ENERGY
SAVING
DSWH160UVPC

2
DSWH160UVPC
Installaon and Maintenance Manual
Declaraon of Conformity
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
Materials compliant for contact with drinking water
This unit is intended for the dispensing of drinking water, and so the materials that enter into direct contact with
water meet the criteria for food-grade components pursuant to the current legislaon. In addion, the unit is
manufactured in compliance with Italian Ministerial Decrees 174 of 04/06/2004 and 25 of 02/07/2012.
Electrical safety
This water cooler is designed, manufactured and marketed in compliance with:
 the safety objecves of the Low Voltage Direcve 2006/95/EC;
 the protecon requirements of the Electromagnec Compability Direcve 2004/108/EC.
The electrical safety of the product is ensured only when it is properly connected to an ecient, legally
compliant grounding circuit.
UL standard for safety of drinking water coolers, ANSI/UL 399, Issued: 2008/08/22, Ed: 7, Rev: 2013/10/18
CSA standard for refrigeraon equipment, CSA C22.2 No. 120, Issued: 2013/03/01, Ed: 4
Associaon
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
Internaonal Awards
2015 - BEST PROMOTION OF HEALTH AND HYDRATION
EUROPEAN AQUA AWARDS 2015, ROME
2015 - BEST ENVIRONMENTAL PRACTICE
EUROPEAN AQUA AWARDS 2015, ROME
2014 – BEST PROMOTION OF HEALTH AND HYDRATION
EUROPEAN AQUA AWARDS 2014, BUDAPEST
2013 – BEST PRODUCT INNOVATION
EUROPEAN AQUA AWARDS 2013, BERLIN
2012 – BEST ENVIRONMENTALLY FRIENDLY PRACTICE
EUROPEAN AQUA AWARDS 2012, ISTANBUL

3
1000003740 (Rev. A - 02/2017)
Recommendaons for Safeguarding the Environment
Packaging materials
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso032 c
The packaging materials are 100% recyclable. Please follow the local guidelines on waste disposal.
For safety reasons keep the packaging material out of the reach and sight of children.
Scrappage
D.M. 174
1
0
0
%
M
A
D
E
I
N
I
T
A
L
Y
C
E
R
T
I
F
I
C
A
T
E
I
T
P
I
rosso 032 c
The DSWH160UVPC water cooler is made using recyclable material.
This unit is marked in compliance with European Direcve 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE). By ensuring that the product is scrapped correctly, you will help to
prevent potenal negave consequences for the environment and for health. This symbol indicates
that the product should not be treated as domesc waste but should be taken to a dedicated recycling
center for electrical and electronic equipment. Immediately prior to scrapping, cut o the power cable.
For more informaon on the treatment, recovery and recycling of this product, please contact
the appropriate local oce, the waste disposal service or the reseller from which the product was
purchased.
This product contains no CFCs or HFCs, which contribute to global warming.
This is the rst water cooler on the American market to use natural refrigerant.
The refrigerang system is lled with R134a: a natural gas that does not contribute to global warming
and that allows for substanal Energy Savings.
Explanaon of Warning/Safety Icons
NOTICE: Indicates an instrucon which, if not followed, could result in damage to product or property
or poor product performance.
CAUTION: Indicates an instrucon which, if not followed, could result in minor or moderate injury.
WARNING: Indicates an instrucon which, if not followed, could result in serious injury or death.

4
DSWH160UVPC
Installaon and Maintenance Manual
Introducon
The DSWH160UVPC cooler brings contemporary style and state-of-the-art technology to commercial water
dispensers. DSWH160UVPC oer the highest level of quality and modern design.
 Mulple dispensing opons: cold sll water, cold sparkling water, and hot water
 Natural materials throughout: stainless steel
 Internal components made enrely of stainless steel
 High-insulaon ice bank ensures a high output of cold water, sll and sparkling
 Self-diagnosis and alarm system responds to lile or no water ow, an accidental water leak or the need for
CO2 cylinder replacement
 Energy Saving command: when selected, this feature enables standby funconality of the unit, with
consumpon reduced by 75% compared to full funconality
NOTICE: Due to rigorous tesng, product may reasonably be expected to contain traces of sanizing
soluon.

5
1000003740 (Rev. A - 02/2017)
Components Guide
ENERGY
SAVING
Removable top cover
Front door
Keypad
Drip tray
Water inlet
CO2inlet
Front Panel lock
LED alarms
Energy Saving
No/low H20/CO2 pressure
Cold sparkling
dispenser
Hot dispensers
Energy Saving
buon
Cold sll
dispenser
DSWH160UVPC
DSWH160UVPC Keypad
ENERGY
SAVING
ENERGY
SAVING
Power cord

6
DSWH160UVPC
Installaon and Maintenance Manual
Product Specicaons
Specicaon DSWH160UVPC
Cooling capacity gal/h (lt/h) 4 (15)
85 6 oz. cups/h
Cold water temperature 42°F – 48°F
(5.5°C – 8.8°C)
Ice bank capacity gal (lt) 2 (7)
Ice bank lb (kg) 6.6 (3.5)
Cooling technology ICE BANK single stainless steel coil
Condensaon Venlated
Adjustable cooling thermostat Yes
Refrigerant gas HFC R134a
Pump Professional booster pump
Max hot water temperature 185°F (85°C)
Hot water tank capacity gal (lt) 0.265 (1)
Heater waage 1000W
Inlet water pipe ø 3/8"
Power 110V - 60Hz
Power consumpon 1350 W - 11 A
Working room temperature Min 41°F – Max 107.6°F
(Min 5°C – Max 42°C)
UNIT WEIGHT lb (kg) 71.65
(32.5)
SHIPPING WEIGHT lb (kg) 80
(36.3)
Dimensions W x D x H in (mm) 13 x 19.48 x 18.41
(330 x 494.9 x 467.5)
Dispensing area height in (mm) 10.67 (271)
Packaging dimensions
W x D x H in (mm)
15.23 x 21.54 x 27.38
(387 x 547 x 695.5)
Dispensing Supply opon (sparkling, cold and hot water)
Push buons Stainless steel push buons
Energy Saving device Included, dedicated push buons
Display Alarms No/low water, No/low CO2
Materials All robust stainless steel parts
* rated at a room temp. of 77°F and inlet water temp. of 68°F

7
1000003740 (Rev. A - 02/2017)
Before You Begin – Requirements for Installaon
Mounng Dimensions
Width
20.9” (531mm)
Depth
23.2” (589mm)
Height
22.4” (569mm)
Height
28" (711mm)
Height
12.75"
(324mm)
Depth
3.88" (99mm)
Diameter
8" (203mm)
Width
3.25" (83mm)
Footprint:
12.9” wide x 19.2” deep
330mm x 489mm
Over counter (includes 4" clearance on sides and back)
Under counter
Water lter
CO2 cylinder (typical, 20 pound)
DSWH160UVPC

8
DSWH160UVPC
Installaon and Maintenance Manual
Operang Environment
 Install the machine in a clean, dry, well-venlated room. It is designed to funcon correctly in environments
with a temperature of 16°C to 32°C – Climac Class N, (between 61°F and 90°F).
 Check that the water cooler is level, that it is on a surface that can support its weight and in an environment
suitable for its size and use.
 Do not place the machine near a source of heat.
 To guarantee adequate venlaon, leave at least 4" (100 mm) of space around the unit.
 Take care not to damage the cooling uid circuit. It is essenal to ensure that the tubes of the refrigerant
circuit are not damaged.
 The unit is not intended for use by children.
 Keep the areas surrounding the unit dry to avoid the risk of people slipping.
 The unit must not be cleaned with a water jet.
Water
 Always connect the water cooler to a water main that supplies drinking water only.
 Use of 3/8" diameter connecons for DSWH160UVPC is recommended.
 Turn o the main water inlet tap if the unit is not to be used for a long period.
Electrical
 Check that the voltage shown on the serial number plate corresponds to the voltage being
supplied at the installaon site.
 Do not use extension cables or mulple-power sockets. The machine must be located
close enough to a standard power socket that the supplied power cable reaches without
stretching.
 Aer installaon, check that the machine is not standing on its power supply cable.
 Ensure that it is possible to disconnect the power supply either by removing the plug or via a two-pole circuit
breaker placed upstream of the plug.
 Before any maintenance or cleaning operaon is carried out, remove the plug from the socket or disconnect
the power supply.
 If the power cable is damaged, it must be replaced by the manufacturer, by its technical support service or by
a qualied technician.
 Do not posion other electrical equipment in the immediate vicinity of the water cooler.

9
1000003740 (Rev. A - 02/2017)
Tools You Will Need
Unpacking the Kit
Remove the front panel (labeled FRONT) and cover of the
wooden packing case.
Remove the cardboard box and the internal protecve
packaging by sliding them up and over the top.
Once you have unpacked the machine, check all components
to ensure that they are not damaged. Contact the carrier
immediately if there has been any damage during shipping.
NOTICE: Ensure that your machine is installed by a
qualied technician in compliance with the
manufacturer’s instrucons and the local safety
guidelines.
NOTICE: Only qualied technicians should access the internal components of your machine, other than
to ll the ice bank.
(2) 8" adjustable wrenches
(1) 10" adjustable pliers
(1) 12" adjustable wrench
(1) universal screwdriver
(1) 12" pipe cuer
(1) wire cung pliers

10
DSWH160UVPC
Installaon and Maintenance Manual
What’s in the Kit
NOTICE: CO2 source is not included and must be supplied separately.
(1) DSWH160UVPC water cooler
(1) CO2
regulator
(1) external
water lter
(2) 3/8"–quick
connect connector
(1) supply hose 1/2 ips x 3/8
tube x 12” long
(1) 3/8” x
3/8” 90° quick
connect elbow
(1) water
pressure
regulator
(1) 10' coil CO2 tubing (natural)
1/4” OD
(1) 3/8” x 1/4”
quick connect
connector
(1) 4” piece of
1/4” OD tubing
(1) 10' coil water 3/8” OD
tubing (blue)
PLUS
Front panel
keys

11
1000003740 (Rev. A - 02/2017)
Installing the Machine
CAUTION: Wear safety gloves when handling the machine. Metal edges are sharp, and touching them
could result in minor or moderate injury.
CAUTION: The unit weighs more than 100 lbs (45 kg) when the ice bank is lled. Liing without proper
support could result in minor or moderate injury.
1. Install external water lter and CO2 cylinder.
1. Use (2) Phillips head screws to mount bracket to under-counter wall or DSCABWH cabinet panel.
2. Use (4) Phillips head screws to mount lter head to bracket.
3. Remove cap from lter. Insert lter into lter head and turn clockwise (right) unl it stops.
When installing external water ller within the DSCABWH cabinet, please refer to the following mounng
instrucons:
1. Use 3 Phillips head screws and washers to mount lter bracket to cabinet mounng strip as shown below.
NOTICE: Install CO2 source per manufacturer’s recommendaons.
1. 2. 3.
DSCABWH

12
DSWH160UVPC
Installaon and Maintenance Manual
2. Cut, size and connect water and CO2 piping to t your installaon.
NOTICE: The water pressure entering the machine must be between 14.5 psi (0.10 MPa) minimum and
51 psi (0.35 MPa) maximum. If the inlet water pressure is higher than 51 psi, the water pressure regulator
supplied must be used.
NOTICE: An incoming ow rate of >1.0 gallon/minute is recommended for opmal quality of sparkling
water.
NOTICE: Check all input piping and connecons for leaks before connecng to the machine.
Water source:
threaded
ng
Water
source:
open 3/8"
pipe
Water lter 3/8"–quick
connect
adapter
3/8"–quick
connect
adapter
Water
pressure
regulator
Water
piping cut
to size
3/8”
water
tubing cut
to size
Water piping
cut to size
To water
cooler
Short
3/8"– 3/8" pipe
Using the quick connect ngs
To connect:
1. Make clean, 90° cut to
piping end.
2. Push piping straight into
ng unl it stops.
3. Pull back to check that
connecon is secture.
To disconnect:
1. Press in the end tab.
2. Pull piping out.
3. Release tab.
1/4” Gas tubing
cut to size
Regulator
CO2source
3/8” 90° quick
connect elbow -
Needed when unit
is on a countertop
3/8” x 1/4”
quick connect
connector
1/4” tubing
4” long
Recommended total
lenght 6 feet
Use one of two
connecon
methods

13
1000003740 (Rev. A - 02/2017)
3. Fill the ice bank in your machine.
DSWH160UVPC
1. Unlock and open the side door using the supplied key (A).
2. Look for the bright yellow label with the arrow (B), which points to the ice bank inlet hole (C).
3. Insert piping from water supply directly into the ice bank inlet.
4. Fill slowly unl water starts to come out of the ice bank drainage pipe (D).
5. If you have to move the unit, remember to empty the ice bank rst.
6. Turn o water supply and remove piping from ice bank inlet.
4. Place the machine in its operang locaon.
NOTICE: Ensure machine remains level while being lied into place to prevent spillage from ice bank.
ENERGY
SAVING
A
B
C
D

14
DSWH160UVPC
Installaon and Maintenance Manual
5. Connect external water and CO2 piping.
6. Plug the machine into the wall socket and turn it on.
1. Connect the power cable to the nearest socket.
2. Open the front panel with the supplied key and press the power buon at the top le of machine (B).
NOTICE: Chilling of the ice bank begins immediately when unit is turned on. Complete chilling of ice
bank will require around 30 minutes - 1 hour. The machine should not be used as a water dispenser unl
chilling is complete.
DSWH160UVPC
DSWH160UVPC
A
B
A
B
Water input
CO2 input

15
1000003740 (Rev. A - 02/2017)
7. Purge the water lines.
1. Place receptacle beneath tap to catch dispensed water. Discard water as necessary.
2. Allow water to run connuously unl ow is clear of air.
3. Repeat for all taps.
NOTICE: The "No/low CO2" error LED will ash when dispensing begins. This is correct, as the CO2
connecon has not been acvated yet. This alarm can be ignored during this step .
8. Turn on the boiler
NOTICE: Never turn on the boiler unless you have lled the machine with water.
NOTICE: Never turn on the boiler when the inlet water is disconnected.
1. Open the front panel with the supplied key and press the boiler buon at the top center of machine.
2. Aer around 10 minutes, the water reaches the seed temperature.
CAUTION: Hot water reaches 185°F. Keep children away. Hot, boiling water and steam will scald if
spilled on skin. Do not touch the dispensing nozzle to avoid burns.
Press dispensing
buon
DSWH160UVPC

16
DSWH160UVPC
Installaon and Maintenance Manual
9. Open the CO2 valve.
1. Using a screwdriver slowly turn valve screw counterclockwise (le)
to open valve.
2. Connue unl pressure reads 50 to 58 psi max.
10. Re-purge the line for sparkling water.
NOTICE: The water will ow at at rst, then gradually
become more sparkling as the line is purged of sll water.
NOTICE: If the "No/low CO2" error LED ashes during this step, there is a problem with the connecon
to the CO2 source. Check all components in the gas system before proceeding.
11. Allow machine to complete inial chilldown.
NOTICE: Complete chilling of ice bank will require around 30 minutes - 1 hour. The machine should not
be used as a water dispenser unl chilling is complete.
NOTICE: Complete water heang will require around 10 minutes. The machine should not be used as a
water dispenser unl heang is complete.

17
1000003740 (Rev. A - 02/2017)
Operang the Keypad
To dispense your water serving
Hold down the buon for that dispenser.
Note: For safety reason, to dispense hot water you must hold down the upper hot water
buon rst and then the lower hot water/Energy Saving buon at the same me.
To stop dispensing your water serving
Release the buon for that dispenser.
To turn on Energy Saving mode
Press and release for less than 4 seconds the Energy Saving buon.
Note: The green LED on the right turns on.
NOTICE: E nergy Saving mode slows down the acvaon me of the
compression. This mode should only be used when the machine will not be
operated, such as when the business has closed for the day.
To turn o Energy Saving mode
Press the Energy Saving buon or any of the dispensing buons.
Alarms
The blue LED on the le is ashing if an alarm is acve:
 Quick ashing - Lile or no water at the inlet
 Slow ashing - Lile or no CO2 remaining
To reset an alarm
Turn the machine o, then on again.
NOTICE: Alarms indicate a problem with the water, CO2, or electrical system of the machine. Do not operate
the machine unl the problem has been located and xed.
ENERGY
SAVING
ENERGY
SAVING
ENERGY
SAVING

18
DSWH160UVPC
Installaon and Maintenance Manual
Roune Maintenance
Daily
 Clean all external surfaces of the machine, the drip tray and the dispensing nozzles.
NOTICE: It is recommended that all external components of the product be cleaned daily.
It is recommended that you use dish soap, warm water and a clean, so cloth to clean the product.
DO NOT USE THE FOLLOWING PRODUCTS:
Do not use ... chlorine bleach soluons on the product. Chlorides found in most soaps, detergents, bleaches and
cleaners can aack stainless steel. These products can cause surface-ping.
Do not use ... metal bers to clean the product. Metal bers have a tendency to disintegrate and release small
metal parcles that are embedded in the surface. Metal parcles oxidize and give the impression that the
surface of the product is rusng.
Do not use ... abrasive cleaners or abrasive pads, as these will scratch the surface of the product.
Do not use ... a water jet.
 To remove limescale, use a slightly acidic product (e.g. citric acid) that has been heavily diluted – excessive
acidity may damage the surface of the steel.
 To clean the drip tray, use a diluted limescale cleaner such as citric acid. The drip tray may also be washed in
the dishwasher.
 Before cleaning the keypad, turn o the machine to prevent accidentally dispensing water.
Weekly
 Use a vacuum to clean out all vents.

19
1000003740 (Rev. A - 02/2017)
Annually
 Replace the water lter aer 6000 gallons or a maximum of 1 year, or earlier depending on water quality.
NOTICE: The lter head has an internal shuto valve that stops the ow of water when the lter is
removed. It is not necessary to shut o the water supply.
1. Turn used lter counterclockwise (to the le) 1/4 turn to remove from lter head. Pull lter away from head
and remove.
2. Remove the cap from the new lter. Place the cap on the used lter to seal it.
3. Insert the new lter into the lter head and turn the lter clockwise (to the right) unl it stops.
4. Place a receptacle under the sll water dispenser and dispense connuously for a minimum of two gallons to
purge air and ne carbon parcles from lter.
 Sanize the machine
NOTICE: This operaon must be carried out by your ELKAY reseller or by a qualied technician.
When required
 Replace the UV lamp
CAUTION: The light emied by the ultra-violet lamp may cause serious burns to the eyes and skin.
Disconnect the electrical source of supply of the UV radiaon before opening the machine.
NOTICE: The UV OUT lamp can not be installed on the hot water nozzle.
1. Disconnect the unit from its electrical source.
2. Once the unit is shut down, open the side panel with the key provided in the kit.
3. Disconnect the electrical connector of the UV OUT lamp. Pull the lamp removing it from its ng holder —
handling it carefully.
4. Insert the new lamp and reconnect the connector — handling it carefully.
5. Repeat the procedure for all the dispensing valves.
6. The used UV lamps can be disposed at your local waste management site.
NOTICE: This operaon must be carried out by your ELKAY reseller or by a qualied technician.
NOTICE: For the replacement of UV OUT pipe is not necessary to turn water o.

20
DSWH160UVPC
Installaon and Maintenance Manual
 Set the thermostat
1. Set the thermostat between 5 and 6 to control the temperature of the cold
water.
2. If you want to avoid the formaon of ice in the bank, turn the thermostat
screw located on the back side of the machine at least 1/4 an-clockwise.
COLDER
OFF
1
2
3
4
5
6
7
