Elo TouchSystems Entuitive ET1724L-7SWB-1-NL User manual

Elo Entuitive Touchmonitor
User Guide
17"LCD Desktop Touchmonitor
1724L Series
Revision A
P/N 008561
Elo TouchSystems, Inc.
1-800-ELOTOUCH
www.elotouch.com

iii
Copyright © 2002 Elo TouchSystems Inc. All Rights Reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or by any means, including, but not
limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written
permission of Elo TouchSystems.
Disclaimer
The information in this document is subject to change without notice. Elo TouchSystems makes no
representations or warranties with respect to the contents hereof, and specifically disclaims any
implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves
the right to revise this publication and to make changes from time to time in the content hereof
without obligation of Elo TouchSystems to notify any person of such revisions or changes.
Trademark Acknowledgments
IntelliTouch, SecureTouch, AccuTouch, Entuitive, and MonitorMouse are trademarks of Elo
TouchSystems, Inc.
Other product names mentioned herein may be trademarks or registered trademarks of their
respective companies. Elo TouchSystems claims no interest in trademarks other than its own.

iv

v
Chapter 1
Introduction 1
Product Description . . . . . . . . . . . . . . . . 1
Precautions . . . . . . . . . . . . . . . . . . . . 1
About the Product . . . . . . . . . . . . . . . . . 1
Chapter 2
Installation and Setup 3
Unpacking Your Touchmonitor. . . . . . . . . . . 3
Rear View . . . . . . . . . . . . . . . . . . . 4
Connecting Your Touchmonitor . . . . . . . . . . 5
Video Cable Connection . . . . . . . . . . . . 5
Touchscreen Cable Connection . . . . . . . . 6
Power Cable Connection. . . . . . . . . . . . 7
Video Input Pin Assignment. . . . . . . . . . . . 8
Installing the Driver Software . . . . . . . . . . . 9
Installing the Serial Touch Driver for Windows
XP, Windows 2000, Me, 95/98 and NT 4.0 . 10
Installing the Serial Touch Driver for MS-DOS
and Windows 3.1 . . . . . . . . . . . . . . 11
Chapter 3
Operation 13
Touchmonitor Controls . . . . . . . . . . . . . 14
Setting the Refresh Rate. . . . . . . . . . . 14
Adjustments . . . . . . . . . . . . . . . . . 15
Screen Adjustments. . . . . . . . . . . . . . . 16
Direct Access Buttons . . . . . . . . . . . . 16
Auto Adjust . . . . . . . . . . . . . . . . 16
OSD Lock/Unlock . . . . . . . . . . . . . . 17
Power Lock/Unlock. . . . . . . . . . . . . . 17
OSD and Power Lock/Unlock . . . . . . . . 18
OSD Adjustments . . . . . . . . . . . . . . . . 19
BRIGHTNESS . . . . . . . . . . . . . . 19
CONTRAST. . . . . . . . . . . . . . . . 19
COLOR CONTROL . . . . . . . . . . . . 19
YUV COLOR . . . . . . . . . . . . . . . 19
HUE . . . . . . . . . . . . . . . . . . . . . 19
FLESH TONE . . . . . . . . . . . . . . . . 19
MISCELLANEOUS . . . . . . . . . . . . 19
RECALL. . . . . . . . . . . . . . . . . . . 19
OSD TIMER. . . . . . . . . . . . . . . . . 19
OSD POSITION . . . . . . . . . . . . . . . 19
AUTO ADJUST . . . . . . . . . . . . . . 20
LANGUAGE. . . . . . . . . . . . . . . . 20
H/VPOSITION . . . . . . . . . . . . . . 20
H-POSITION. . . . . . . . . . . . . . . . . 20
V-POSITION. . . . . . . . . . . . . . . . . 20
CLOCK PHASE . . . . . . . . . . . . . 20
PHASE . . . . . . . . . . . . . . . . . . . 20
CLOCK . . . . . . . . . . . . . . . . . . . 20
Chapter 4
Troubleshooting Tips 21
Appendix A
Native Resolution 23
Appendix B
Touchmonitor Safety 25
Care and Handling of Your Touchmonitor. . . . 27
Appendix C
Technical Specifications 29
Preset Timing Table. . . . . . . . . . . . . . . 29
VESA Mounting. . . . . . . . . . . . . . . . . 30
Touchmonitor Specifications. . . . . . . . . 31
AccuTouch Touchscreen Specifications . . . 32
IntelliTouch Touchscreen Specifications . . . 33
17" LCD Desktop Touchmonitor (ET1724L-XSWB-
1) Dimensions . . . . . . . . . . . . . . . . . 34
Regulatory Information 37
Index 41
Table of Contents

vi
Copyright © 1996, Borland International. All rights reserved. BORLAND CONFIDENTIAL
June 11, 2002 10:05 am (D:\Vera new\8561-17 LCD Econ Hyundai\1724L Econ Hyundai
DesktopTOC.fm)

1-1
CHAPTER
1
C HAPTER 1 I NTRODUCTION
Product Description
Congratulations on your purchase of an Elo TouchSystems Entuitive LCD
desktop touchmonitor. Your new high-resolution industrial touchmonitor
combines the reliable performance of Elo’s touch technology with the latest
advances in LCD display design. This combination of features creates a natural
flow of information between you and your touchmonitor.
Precautions
Follow all warnings, precautions and maintenance as recommended in this
user’s manual to maximize the life of your unit. See Appendix B for more
information on touchmonitor safety.
About the Product
Your LCD desktop touchmonitor is a 17" TFT color display with the following
features:
• Direct analog RGB input
• 17.0" diagonal screen size
• 1280 x 1024 resolution
• DOS/ VGA/ SVGA/ XVGA/ SXGA/ EGA/ CGA/ Mac compatible
• Frequency H-sync: 30-80k Hz; V-sync: 50-85kHz
(up to 75khz @ 1280 x 1024)

1-2 Elo Entuitive Touchmonitor User Guide
•Plug&Play
• High quality full screen re-scaling
• VESA DDC 1/2B data communication
• VESA DPMS power saving
• Supports VESA Flat Panel Monitor Physical Mounting Interface
• Worldwide agency approvals that include UL, CUL, TÜV- Bauart, FCC, CE,
C-Tick, VCCI
• IntelliTouch or AccuTouch Technology
For full Product Specifications refer to Appendix C.

2-3
CHAPTER
2
C HAPTER 2 I NSTALLATION AND S ETUP
This chapter discusses how to setup your LCD desktop touchmonitor and how
to install Elo TouchSystems driver software.
Unpacking Your Touchmonitor
AC/DC Power adapter
US power cord
Video cable
Serial touchscreen
cable
CD and Quick
Installation Guide
European power cord

2-4 Elo Entuitive Touchmonitor User Guide
Rear View

2-5
Connecting Your Touchmonitor
Before connecting the cables to your touchmonitor and computer, be sure that the
touchmonitor and computer are off.
Video Cable Connection
1Set the touchmonitor on a solid horizontal surface, such as a table or desk.
2Connect the female end of the video cable connector to the back of the LCD
monitor, and connect the other end to the back of the computer.
3Secure the cable to your touchmonitor and computer by tightening the screws
on the connector clockwise.
Video
cable Video
port
Female 15-pin
video
D-SUB
Connections on underside
Ferrite bead

2-6 Elo Entuitive Touchmonitor User Guide
Touchscreen Cable Connection
1Connect the female end of the 9-pin touchscreen RS-232 cable to the serial
port on the back of your computer.
2Connect the male end of the cable to the serial touchscreen connector on your
touchmonitor.
3Secure the cable to your touchmonitor and computer by tightening the screws
on the connector clockwise.
Connections on underside
Female 9-pin serial
touchscreen
connector
Serial
touchscreen
cable

2-7
Power Cable Connection
1Depending on where you live, you will use either the European or
US/Canadian power cable. Connect the female end of the power cable to the
Brick power supply.
2Connect the Brick power supply into the power port on the touchmonitor.
To protect your equipment against risk of damage from electrical surges in the power
line, plug the Brick supply’s power cord into a surge protector, and then connect the
surge protector to a grounded (three-pronged) AC electrical outlet.
Connections on underside
DC 12V Brick power
cable port
Power
cable
Brick power supply

2-8 Elo Entuitive Touchmonitor User Guide
Video Input Pin Assignment
This section describes the pin assignment of the LCD’s 15 Pin Mini D-sub
(video cable) connector.
Pin No. Signal Connector
1 Red Video Signal
2 Green Video Signal
3 Blue Video Signal
4 N.C.
5 Ground
6 Ground for red video signal
7 Ground for green video signal
8 Ground for blue video signal
9 N.C.
10 Ground
11 N.C.
12 DDC data
13 Horizontal sync signal
14 Vertical sync signal
15 DDC clock

2-9
Installing the Driver Software
The driver software allows your touchmonitor to work with your computer.
Drivers are located on the enclosed CD-ROM for the following operating
systems:
• Windows XP
• Windows 2000
• Windows Me
• Windows 98
• Windows 95
• Windows NT 4.0
Your touchmonitor is plug-and-play compliant. Information on the video
capabilities of your touchmonitor is sent to your video display adapter when
Windows starts. If Windows detects your touchmonitor, follow the instructions
on the screen to install a generic plug-and-play monitor.
Refer to the appropriate following section for driver installation instructions.

2-10 Elo Entuitive Touchmonitor User Guide
Installing the Serial Touch Driver for Windows XP,
Windows 2000
1
, Me, 95/98 and NT 4.0
N OTE : For Windows 2000 and NT 4.0 you must have administrator access rights to install the
driver.
1Insert the Elo CD-ROM in your computer’s CD-ROM drive.
If the AutoStart feature for your CD-ROM drive is active, the system
automatically detects the CD and starts the setup program.
2Follow the directions on the screen to complete the driver setup for your
version of Windows.
If the AutoStart feature is not active:
1Click Start > Run.
2Click the Browse button to locate the EloCd.exe program on the CD-ROM.
3Click Open, then OK to run EloCd.exe.
4Follow the directions on the screen to complete the driver setup for your
version of Windows.
1. To install Windows 2000 and Windows XP, you must use the "update driver" method; you will not
find a setup.exe file within the download.

2-11
Installing the Serial Touch Driver for MS-DOS and
Windows 3.1
You must have a DOS mouse driver (MOUSE.COM) installed for your mouse
if you wish to continue using your mouse along with your touchmonitor in
DOS.
To install Windows 3.xand MS-DOS from Windows 95/98, follow the
directions below:
1Insert the CD-ROM in your computer’s CD-ROM drive.
2From DOS, type d:\EloDos_W31 to change to the correct directory on the
CD-ROM (your CD-ROM drive may be mapped to a different drive letter).
3Type install and press Enter to start the installation.
4Align the touchscreen.
You must have already completed Steps 1 and 2 before proceeding.
To run the INSTALL program:
1Type INSTALL at the DOS prompt in the directory containing the driver
install files.
2INSTALL asks you to select the software to install. Then choose
d:\EloDos_W31 from the displayed list.
3INSTALL also asks you for the paths to use during installation, or you may
use its defaults. INSTALL creates directories as necessary, and warns you if
they exist.
If you are updating your software, you may wish to specify the paths containing
the earlier versions, and overwrite the obsolete files. All executable programs
are upward compatible. For a list of differences from each previous version of
the drivers, be sure to select "Differences from Previous Versions" during the
installation process.
INSTALL updates your AUTOEXEC.BAT file with the drivers you select.
INSTALL makes a copy of your original AUTOEXEC.BAT file, called
AUTOEXEC.OLD. If you already have Elo driver commands in your
AUTOEXEC.BAT file, they will be commented out.
When INSTALL is finished, it leaves a file called GO.BAT in the subdirectory
you specified. GO loads the touchscreen driver, runs the calibration program
ELOCALIB, and gives you some final instructions.
If you are using Windows 3.1, you will also calibrate the touchscreen within
Windows 3.1 with the Touchscreen Control Panel.

2-12 Elo Entuitive Touchmonitor User Guide

3-13
CHAPTER
3
C HAPTER 3 O PERATION
Variations in video output and application will likely require you to adjust your
touchmonitor to optimize the quality of the display.
For best performance, your monitor should be operating in native resolution;
that is, 1280 x 1024 at 60 Hz. Use the Display control panel in Windows to
choose 1280 x 1024 resolution.
Operating in other resolutions will degrade video performance. For further
information, please refer to Appendix A.
All adjustments you make to the controls are automatically memorized. This
feature saves you from having to reset your choices every time you unplug or
power your touchmonitor off and on. If there is a power failure, your
touchmonitor settings will not default to the factory specifications.
