ELPRO DTS-SOLAR User manual

OPERATING MANUAL
ELPRO CONTROLS, Ahmedabad, Gujarat, INDIA
www.elprocontrols.com
Email: el[email protected] / [e-mail]
SOLAR PANEL TIMER : DTS-SOLAR
FEATURES
 Latest MCU based technology
 RT Accuracy - 2 se ond / day
 ON-OFF Time - 1 per day
 Day selection - 1 to 7
 Lithium Battery Power Reserve - 5 years
 User friendly programming
 BYPASS FUNCTION to override the ON-OFF settings & operate load any time
 Relay Output – 20 AMP resistive
APPLI ATIONS
 Solar panel cleaning system
INSTALLATION GUIDE
 onnect input SUPPLY to input terminal.
 onnect LOAD to output terminal.
 Tight all terminal connection to avoid any loose connections problem.
 Now program the unit as per requirement.

OPERATING MANUAL
ELPRO CONTROLS, Ahmedabad, Gujarat, INDIA
www.elprocontrols.com
Email: el[email protected] / [e-mail]
PROGRAMMING MODE
 Press SET key to enter in programming mode.
 Display TIME for 2 seconds and then ON time and ON indication glow.
 Set ON time by ▲ / ▼ key.
 Press SET key and then display OFF time and OFF indication glow.
 Set OFF time by ▲ / ▼ key.
 Press SET key.
 Display dAY for 2 seconds and then day value (from 1 to 7).
 Set day by ▲ / ▼ key. (1 for every day, 2 for every two day……..,7 for every seven day)
 Repeat the above steps to set Y LE-2,3,4……ON / OFF time.
 Press ENT key to exit from programming mode.
Example : ON/OFF unit 2 minute per day
ON time – 07.00
OFF time – 07.02
DAY – 1
LO K SETTING MODE
 Press ▲ key.
 Display –CLK for 2 seconds and then clock time.
 Set clock time by ▲ / ▼ key.
 Press ENT key to exit from clock setting mode.
RESET FUN TION
 Press ▼ key for 2 seconds.
 Display –rST for 2 seconds and all ON/OFF time, day value and clock value reset to
factory default value.
BYPASS FUN TION
 To enter bypass mode, press ENT key for 2 seconds.
 Display bYPS, override the ON/OFF time settings & unit continuously ON
