ELSA ECOMO 660 User manual

ELSA ECOMO
TM
660
21677_Ecomo660.book Seite 1 Freitag, 14. Juli 2000 12:36 12

© 2000 ELSA AG, Aachen (Germany)
While the information in this manual has been compiled with great care, it may not be deemed an assurance of product
characteristics. ELSA shall be liable only to the degree specified in the terms of sale and delivery.
The reproduction and distribution of the documentation and software supplied with this product and the use of its contents
is subject to written authorization from ELSA. We reserve the right to make any alterations that arise as the result of
technical development.
ELSA is a DIN EN ISO 9001 certified company. With the certificate of June 15, 1998, the authorized certification institute
TÜV-CERT has confirmed the conformity of ELSA AG with the worldwide quality standard DIN EN ISO 9001. The certificate
number of ELSA is 09 100 5069.
You can find all declarations and approvals for the products, as long as they were available at the time of publication, in
the appendix of this documentation.
Trademarks
Windows®, Windows NT®and Microsoft®are registered trademarks of Microsoft, Corp.
Apple®and Macintosh®are registered trademarks of Apple Computer, Inc.
The ELSA logo is a registered trademark of ELSA AG. All other names mentioned may be trademarks or registered
trademarks of their respective owners.
Subject to change without notice. No liability for technical errors or omissions.
ELSA AG
Sonnenweg 11
52070 Aachen
Germany
www.elsa.com
Aachen, July 2000
21677_Ecomo660.book Seite 2 Freitag, 14. Juli 2000 12:36 12

|
|ELSA ECOMO 660 |
EN
Preface
Thank you for placing your trust in this product.
With the ELSA ECOMO 660 you have selected one of ELSA's high-end
monitors. ELSA products are subject to the highest of standards in production
and quality control which are the foundation for consistently high product
quality. This monitor was especially designed to satisfy the ergonomic
requirements of professional users, and distinguishes itself with an
extraordinary degree of reliability.
This documentation was compiled by several members of our staff from a
variety of departments in order to ensure you the best possible support when
using your ELSA product.
Further information on the Internet at 'www.elsa.com'
Our online services 'www.elsa.com' are available to you around the clock
should you have any queries regarding your ELSA ECOMO 660 or require any
further support.
Our KnowledgeBase can be found at 'www.elsa.com/support'. In the
'Support' file section under 'Know-How', you can find answers to frequently
asked questions (FAQs). Current drivers, firmware, tools and manuals can be
downloaded at any time.
The KnowledgeBase can also be found on the CD.
21677_Ecomo660.book Seite 3 Freitag, 14. Juli 2000 12:36 12

|
|ELSA ECOMO 660 |
EN
To switch the monitor on or off,
press and hold the adjuster wheel for
about 5 seconds.
21677_Ecomo660.book Seite 4 Freitag, 14. Juli 2000 12:36 12

|
EN
|ELSA ECOMO 660 |
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.1 Power supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.2 AC adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.3 Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.4 Power cable and extension cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.5 Ambient conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4.6 Servicing and repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Connecting the LCD monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2 Installing the drivers under Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3 Adjusting the screen position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.1 Swiveling, tilting, adjusting the display height . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.2 Rotation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4 The proper care for your monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5 The USB function under Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5.1 What does USB stand for? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5.2 Who can use USB? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.5.3 Checking USB compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 Front control panel and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.1 Aspects of your monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Switching the monitor on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.3 On screen display (OSD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.3.1 Launching the OSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.3.2 Using the OSD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.3.3 Functions of the OSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
21677_Ecomo660.book Seite 5 Freitag, 14. Juli 2000 12:36 12

|
|ELSA ECOMO 660 |
EN
4 Advice and help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.1 The monitor does not switch on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2 The monitor does not respond when you start the computer . . . . . . . . . . . . . . . . . 23
4.3 The screen is black. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.4 The display does not properly show individual pixels . . . . . . . . . . . . . . . . . . . . . . . 23
4.5 The picture is too dark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.6 The monitor displays colors incorrectly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.7 Digital or analog connection?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.8 What is DVI, what is DFP? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.9 Two computers on a single monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.10 The picture isn't sharp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.11 The display of circles and squares is distorted . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.12 How can I change the resolution? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.13 How can I change the refresh rate?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.14 Does the monitor also work under Linux and MacOS? . . . . . . . . . . . . . . . . . . . . . 26
5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.1 Performance data and specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.2 The power management function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.3 Adapting the monitor to the graphics board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.4 Monitor inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.4.1 The DVI interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.4.2 The VGA D shell socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.4.3 Contact assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.1 TCO ’99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.2 CE conformity and FCC radiation standard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.3 ELSA-ServiceDirect for ELSA ECOMO monitors. . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.4 Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
21677_Ecomo660.book Seite 6 Freitag, 14. Juli 2000 12:36 12

|Introduction 7
|ELSA ECOMO 660 |
EN
1 Introduction
1.1 General information
With its support for the new DVI (Digital Visual Interface) standard, the ELSA
ECOMO 660 is the state of the art in digital LCD monitor technology. It
features a thin-film transistor (TFT) LCD panel with active matrix control and
a visible diagonal size of 18.1" (46 cm). It is capable of displaying resolutions
of up to 1280 x 1024. The ECOMO 660 can satisfy even the most demanding
user with optimal sharpness and brilliant colors. Its housing can be rotated
by 90°for portrait-mode display.
The ECOMO 660 has a very small footprint and is ideal when you need plenty
of free space on your desk.
1.2 Features
18.1" TFT liquid-crystal panel
Antireflective and protective coating
High contrast and brightness
Extremely wide viewing angle (140°)
Maximum resolution: 1280 x 1024 (SXGA graphic format)
Fully digital signal transmission for perfect picture quality
Compatible to DVI (Digital Visual Interface) standard
Compatible to DFP (Digital Flat Panel) standard with optional adapter
Analog interface
24-bit color depth, 16.7 million colors
Compact design, low weight (9.5kg)
Power management function (VESA-DPMS-compatible)
Plug&play (VESA-DDC2B)
VESA-compatible mount for support arms or wall mounting
USB self-powered hub (1 upstream port and 2 downstream ports)
Provision for Kensington safety lock as theft protection
Rotatable by 90°for portrait-mode display
21677_Ecomo660.book Seite 7 Freitag, 14. Juli 2000 12:36 12

Introduction |
|ELSA ECOMO 660 |
8
EN
1.3 Checklist
Before setting your monitor up for use, please check that all of the parts listed
below have been included in the package:
ELSA ECOMO 660
AC adapter (230 V~)
Power cable (between AC socket and AC adapter)
DVI signal cable
VGA signal cable
USB cable (B type)
Documentation
CD including ELSA drivers, utilities and electronic documentation
1.4 For your safety
1.4.1 Power supply
Use the monitor only with the AC voltage specified on the AC adapter.
1.4.2 AC adapter
Use only the AC adapter designed for this monitor. Using the incorrect
adapter may result in improper function or damage to the monitor and/or
danger for the user.
1.4.3 Plug
Do not modify or replace the AC plug of the monitor under any
circumstances.
Unplug the monitor from the AC socket if you will not be using it for an
extended period.
1.4.4 Power cable and extension cable
Always use the appropriate power cable with the correct plug type. For
an AC voltage of 230 V (Europe), use a power cable with an approved plug
corresponding to the safety regulations of your country. For 120 V AC
(USA), use a UL- and CSA-approved power cable.
21677_Ecomo660.book Seite 8 Freitag, 14. Juli 2000 12:36 12

|Introduction 9
|ELSA ECOMO 660 |
EN
We recommend using the supplied power cable. In the event that you
need a different cable, use a H05VV-F or VW-1, 18AWG x 3G type cable.
Do not overload power cables or sockets. Ensure that the devices
connected to a single AC socket do not exceed a totalpower consumption
of 7.0A.
Also be sure that the total power consumption of the devices connected
to an extension cable do not exceed the rated maximum capacity of the
cable.
If the monitor is to be plugged into the power supply of the PC rather than
an AC socket, ensure that the computer is UL-approved and is capable of
delivering at least 2.0A at 100~240V AC, 50/60Hz.
Do not place heavy objects on the power cable. Do not place the cable
in any location where persons might trip over it.
1.4.5 Ambient conditions
Place the monitor on an even, horizontal surface.
Set the monitor up in a well-ventilated room and ensure that the
ventilation slots remain clear.
Ensure that no foreign objects fall into the housing through the
ventilation slots.
Do not expose the monitor to
rain or water
excessive heat, cold or humidity
direct sunlight
dusty environments
equipment that generates strong magnetic fields
1.4.6 Servicing and repairs
Do not open the housing of the monitor (with the exception of the flaps
and covers that are expressly covered in the manual). If servicing or
repairs should ever become necessary, please contact ELSA's support.
21677_Ecomo660.book Seite 9 Freitag, 14. Juli 2000 12:36 12

Introduction |
|ELSA ECOMO 660 |
10
EN
21677_Ecomo660.book Seite 10 Freitag, 14. Juli 2000 12:36 12

|Installation 11
|ELSA ECOMO 660 |
EN
2 Installation
The installation of the ELSA ECOMO 660 is a two-part process:
the connection of the LCD monitor to your PC
the installation of the drivers under Windows
In addition, this chapter covers adjusting the display position, provides
information on the proper care for the display and explains the function of the
USB hub under Windows.
2.1 Connecting the LCD monitor
When removing connector cables from your PC, always pull on the plug rather
than on the cable to prevent damage to the cable.
햲Make sure that your computer is switched off.
햳Open the connector cover 쐃. Push the button on the cover downwards
and move the cover toward the outer edge of the unit to remove it.
햴Connect the display to the computer. The ECOMO 660 features both an
analog and a digital input. Parallel operation is not possible, so a
decision is called for:
if your graphics board has a digital output (DVI or DFP), then use the
DVI cable 쐇to connect that output to the DVI input (DVI-IN) of the


쐃
쐇

21677_Ecomo660.book Seite 11 Freitag, 14. Juli 2000 12:36 12

Installation |
|ELSA ECOMO 660 |
12
EN
ECOMO 660. Connecting to a DFP graphics board requires the
optional DVI-DFP adapter.
Connect a conventional VGA graphics board (analog RGB output) with
the VGA signal cable .
햵USB devices can also be connected to the ECOMO 660.
Connect the square type B plug of the USB cable to the USB upstream
port of the monitor and the other end (flat type A plug, ) to your
computer or to another USB hub.
Connect your USB devices (mouse, keyboard, scanner, etc.) to the
USB downstream ports .
햶A second ECOMO 660 monitor (or DVI-D compatible unit) can be
connected to the DVI-OUT port. This second monitor will display the
Upstream port
Downstream ports
Scanner
Keyboard, mouse
Second monitor
(optional)
AC power connec-
tion, 220V~
PC
VGA connection



DVI (IN)DVI (OUT) VGA
DVI connection
Notebook
21677_Ecomo660.book Seite 12 Freitag, 14. Juli 2000 12:36 12

|Installation 13
|ELSA ECOMO 660 |
EN
same picture as the first. A second monitor can only be connected to the
DVI-OUT port if the first monitor is using the digital DVI-IN port.
햷Replace the connector cover. Place the cover against the three retainer
openings along the outer edge of the unit, press the button downwards
and fit the cover into the unit.
햸Connect the output plug of the AC adapter to the monitor and the
other end to an AC power socket.
햹The power and data cables can be run through the integrated cable duct
in the base of the monitor to ensure that the unit also makes a good
impression when viewed from the back.
Open the cover of the cable duct on the rear of the unit by pulling the
retaining clips behind the cover at the top upwards slightly and remove
the cover. The various cable thicknesses are accommodated by the cable
clips inside the duct. When all cables have been neatly installed, insert
the cover into the two retainer openings at the base and press it against
the duct until the retainer clips snap into place. Ensure that no cables are
pinched by the cover and that no suppressors (iron cores) are preventing
the cover from fitting properly.
햺Switch the computer on.
2.2 Installing the drivers under Windows
The first time you boot your computer with the new display, Windows
(versions 95, 98 or 2000) will recognize the presence of new hardware and
will launch the hardware wizard. The use of the hardware wizard is very
similar in all Windows versions.
Most of the dialog boxes displayed by the hardware wizard can be
acknowledged with OK, Next or Finish.
Be sure, however, to select the ELSA ECOMO 660 on the ECOMOware CD as
the device to be installed. If the hardware wizard doesn't suggest the ELSA
ECOMO 660 as an installation option, help it along by having it search the
'\drivers' folder of the ECOMOware CD for drivers.
Once the hardware wizard has successfully completed the installation,
please restart your PC. Your ELSA ECOMO 660 is now ready!
For further information on using the hardware wizard, please refer to your
Windows manual.
21677_Ecomo660.book Seite 13 Freitag, 14. Juli 2000 12:36 12

Installation |
|ELSA ECOMO 660 |
14
EN
2.3 Adjusting the screen position
To prevent damage, do not touch the surface of the panel when adjusting the
screen position.
2.3.1 Swiveling, tilting, adjusting the display height
The LCD panel can be tilted forward (up
to 8°) or back (up to 16°), or swiveled on
its base to the right or left (70°in either
direction) in order to set the optimal
viewing angle.
In addition, the height of the LCD panel
can be adjusted by a total of 5 cm.
2.3.2 Rotation
The orientation of the LCD panel (landscape or portrait) can be changed.
From landscape to portrait
Tilt the LCD panel all the way back to
ensure that the housing does not strike
the base when turning 햲. Turn it
clockwise until it locks in the vertical
position 햳.
21677_Ecomo660.book Seite 14 Freitag, 14. Juli 2000 12:36 12

|Installation 15
|ELSA ECOMO 660 |
EN
From portrait to landscape
Tilt the LCD panel all the way back to
ensure that the housing does not strike
the base when turning 햲. Turn it
counterclockwise until it locks in the
horizontal position 햳.
Additional software is required to be able to use the ECOMO 660 in portrait
mode. This software is not included with the ECOMO 660 and must be
ordered separately.
2.4 The proper care for your monitor
The surface of the monitor panel features an antireflective coating. Never
touch the surface of the panel with rough, sharp or pointed objects such as
screwdrivers or ballpoint pens to prevent damage to the coating.
To clean the panel, use a mild detergent such as normal hand soap. Use a
soft cotton cloth to apply the detergent and to wipe the panel dry. Take care
not to apply excessive pressure, as small particles of dust on the panel might
otherwise scratch the surface.
Never use abrasive cleansers, scrubbing sponges, or solvents such as alcohol
or lighter fluid.
2.5 The USB function under Windows
2.5.1 What does USB stand for?
USB stands for “Universal Serial Bus”, a new interface standard offering the
PC user a substantial gain in convenience when connecting and configuring
peripheral devices. Up to 127 devices such as keyboards, mice, modems,
21677_Ecomo660.book Seite 15 Freitag, 14. Juli 2000 12:36 12

Installation |
|ELSA ECOMO 660 |
16
EN
removable drives or digital cameras for videoconferencing can be connected
to a USB system. The configuration of each individual peripheral device is
handled automatically by the USB.
The USB standard involves a standardized plug type and cable that makes
special plugs, cables and additional software superfluous. This eliminates
the old, familiar cabling confusion and the risk of hardware damage through
incorrect connections. A major advantage is that all devices can be
interconnected—in much the same manner as in a network. This also
permits great planning flexibility: Not all peripheral devices need to be
connected centrally to the computer.
2.5.2 Who can use USB?
The USB function is only available if your hardware and operating system
support it. In this case, Windows identifies the hardware, sets up the USB
and controls the connected devices.
USB support is integrated in Windows 98 and Windows 2000. The situation
can be different for earlier versions, however. Not all versions of Windows
95 support the USB function.
2.5.3 Checking USB compatibility
Click on Start Settings Control Panel  System and have Windows
display the existing devices on the 'Device Manager' tab.
For further information on USB, please visit www.usb.org.
The Device Manager will show
whether or not a USB controller
is currently installed.
21677_Ecomo660.book Seite 16 Freitag, 14. Juli 2000 12:36 12

|Front control panel and functions 17
|ELSA ECOMO 660 |
EN
3 Front control panel and functions
Please save the monitor's carton and packing material for future storage or
shipping purposes. Be sure to store the monitor in accordance with the safety
marks on the carton and the ambient conditions described in this manual
(temperature, humidity).
3.1 Aspects of your monitor
The signal light provides information on the monitor's current operating
status:
The lateral adjuster wheel is located behind the signal light 쐃. The
adjuster wheel can be turned upwards and downwards, and can be
pressed into the monitor. All of the monitor's settings and functions can
be controlled using this adjuster wheel.
쐃
쐇
Front view
Side view
green The monitor is switched on and works in the normal mode.
amber The monitor is in the power saver mode.
The monitor will “wake up”and return to normal mode at the next key-
stroke or movement of the mouse.
21677_Ecomo660.book Seite 17 Freitag, 14. Juli 2000 12:36 12

Front control panel and functions |
|ELSA ECOMO 660 |
18
EN
3.2 Switching the monitor on and off
To switch the monitor on or off, press the adjuster wheel 쐇and hold it for
approx. 5 seconds.
3.3 On screen display (OSD)
The on screen display (OSD) makes light work of fine tuning the picture on
your monitor. Its adjustment options range from simply changing the bright-
ness to setting the monitor's sharpness and color temperature.
When the monitor is using a digital connection via the DVI-IN port, the display
is automatically set for optimal quality. As a result, a number of settings can
no longer be made manually when using digital control. The functions only
available in analog mode are marked with an asterisk (*) in the following
overviews.
3.3.1 Launching the OSD
To call up the on screen display, briefly press the adjuster wheel into the
monitor. The monitor must be running in normal mode (green signal light).
3.3.2 Using the OSD
The main selection is on the left-hand side of the on screen menu. Select a
menu item by turning the adjuster wheel. Press the adjuster wheel briefly to
confirm your choice.
All of the OSD functions are set in this manner. The displayed values can be
increased by turning the adjuster wheel upwards and reduced by turning it
downwards. Confirm the selected function or setting by briefly pressing the
adjuster wheel.
21677_Ecomo660.book Seite 18 Freitag, 14. Juli 2000 12:36 12

|Front control panel and functions 19
|ELSA ECOMO 660 |
EN
The mouse cursor in the on screen menu is not controlled by the mouse of
your computer. The menu items can only be selected using the adjuster
wheel of the display.
There are two ways to exit the OSD function: Either select Exit in the main
menu, or wait several seconds for the OSD to close automatically. Changes
are saved automatically in both cases.
Display of current picture parameters
The most important picture parameters can be found in the main menu below
the ELSA logo:
Digital/analog control: 'Analog RGB'
Screen resolution: '1280 x 1024'
Horizontal frequency: 'Fh: 64.0kHz'
Refresh rate: 'Fv: 60Hz'
3.3.3 Functions of the OSD
The OSD has one main menu and six submenus. All of the functions of these
menus are covered in the following function reference. The functions have
been sorted according to submenus. Functions that are not available under
digital control have been marked with an asterisk (*).
Video
21677_Ecomo660.book Seite 19 Freitag, 14. Juli 2000 12:36 12

Front control panel and functions |
|ELSA ECOMO 660 |
20
EN
Position *
Scaling
The scaling menu lets you adjust the output of your graphics board to suit the
aspect ratio of your display. Changing the scaling parameters permits you to
project partial contents of the display, such as PowerPoint presentations,
onto the full display area. The scaling function can also prove useful when
using multiple displays.
The default value is 'Full Screen'.
Please note that changing the scaling values may lead to a distortion of the
picture. If circles no longer display as round, for example, change the value
to 'Maintain aspect ratio'.
Symbol Function Description
Brightness Increase or decrease the brightness
Contrast * Increase or decrease the contrast
Auto-
adjustment *
Automatic adjustment of picture width and height,
horizontal and vertical picture position
Frequency * Sets the refresh rate to the output values of the graphics board
Phase * Adjusts the analog/digital signal conversion; affects the clarity
and sharpness of the picture
Sharpness * Adjusts the sharpness of the picture
Color
temperature *
4 color temperatures may be selected: 5000 K, 6500 K, 8000 K
and 9500 K
Return to
main menu
Return to main menu
Symbol Function Description
Horizonal
position *
Horizontal picture position (left/right)
Vertical
position *
Vertical picture position (up/down)
Return to
main menu
Return to main menu
21677_Ecomo660.book Seite 20 Freitag, 14. Juli 2000 12:36 12
