KNX AQS/TH-B-UP
Combined Indoor Sensor

2 Description
Indoor Sensor KNX AQS/TH-B-UP • Status: 07.11.2013 • Technical changes reserved. Errors reserved.
1. Description
The Indoor Sensor KNX AQS/TH-B-UP measures CO2concentration, temperature
and humidity and calculates the dew point. The sensor can receive external measured
values via the bus and process them with the own data to overall vealues (mixed
values, e. g. room average). The KNX AQS/TH-B-UP offers two push buttons that may
be used for changing the ambient temperature (target value), for switching between
day and night mode or as free programmable bus push buttons.
The KNX AQS/TH-B-UP provides eleven switching outputs with adjustable threshold
values. The switching outputs and further communication objects can be linked by
AND and OR logic gates. Additionally, an integrated actuating variable comparator can
compare and output values that are received via communication objects.
Integrated PI controllers allows for control of a ventilation (depending on CO2
concentration and air humidity) and a heating/cooling system (depending on
temperature). The KNX AQS/TH-B-UP can can emit a warning to the bus as soon as
the area of optimum comfort (according to DIN 1946) is left.
The integrated display shows the own values and data received from the bus (e. g.
date, time). The housing is completed with a frame of the switching series installed in
the building and thus merges with the interior.
Functions:
• Measurement of CO2concentration of the air, of temperature and air
humidity (absolute and relative), calculation of the dew point
•Mixed values from own measured values and external values (proportions
can be set in percentage)
•Display 1-3 rows (own values or values received from the bus) or display of
temperature control (see Mode display, page 7)
•2 push buttons. Configuration as bus push button or for changing ambient
temperature and switching between day/night mode (see Change ambient
temperature with the buttons, page 8)
•PI controller for heating (one or two step) and cooling (one or two step)
depending on temperature. Setting of target value for day, night and frost/heat
protection
•PI controller for ventilation depending on humidity and CO2concentration:
dehumidification/humidification (one step) or dehumidification (one or two
step)
•11 switching outputs with adjustable threshold values (Threshold values
can be set by parameter or via communication objects)
•8 AND and 8 OR logic gates with each 4 inputs. Every switching incident as
well as 8 logic inputs in the form of communication objects, may be used as
inputs for the logic gates. The output of each gate may optionally be configured
as 1 bit or 2 x 8 bits
•2 actuating variable comparators for output of minimum, maximum or
avarage values. Each with 5 inputs (for values received via communication
objects)

3 Description
Indoor Sensor KNX AQS/TH-B-UP • Status: 07.11.2013 • Technical changes reserved. Errors reserved.
Configuration is made using the KNX software ETS. The product file, the data sheet
and the manual can be downloaded from the Elsner Elektronik homepage on
www.elsner-elektronik.de in the “Service” menu.
1.0.1. Scope of delivery
• Housing with display, buttons and sensor board
•CO
2sensor unit
• Base plate
You will need in addition (not supplied):
• Socket Ø 60 mm, 42 mm deep
• Frame (for element 55 x 55 mm), suitable for the switching programme used in
the building
1.1. Technical specifications
Housing Plastic material (partly lacquered)
Colours • White glossy (similar to RAL 9016 Traffic White)
• Aluminium matt
• Anthracite matt
• Stainless steel
• Special colours on request
Mounting In-wall (in socket Ø60 mm, 42 mm deep)
Protection category IP 20
Dimensions Housing approx. 55 x 55 (W x H, mm),
mounting depth approx. 15 mm,
base plate approx. 71 x 71 (W x H, mm)
Total weight approx. 72 g
Ambient temperature Operation -10…+50°C, storage -20…+60°C
Ambient air humidity max. 95% R. H., avoid bedewing
Operating voltage KNX bus voltage
Bus current max. 10 mA
Data output KNX +/- bus terminal plug
BCU type Own micro controller
PEI type 0
Group addresses max. 254
Allocations max. 254
Communication objects 253
CO2 measurement range 0...2000 ppm
CO2resolution 1 ppm
CO2accuracy* ± 50 ppm ± 3% of the measuered value
Temperature measurement
range
-10…+50°C

4 Installation and commissioning
Indoor Sensor KNX AQS/TH-B-UP • Status: 07.11.2013 • Technical changes reserved. Errors reserved.
* Mind the notes on Accuracy of the measurement, page 4
The following standards have been considered for the evaluation of the product in
terms of electro magnetic compatibility:
• EN 50090-2-2: 1996/A2:2007
• EN 61000-6-1: 2007
• EN 61000-6-3: 2007
The product has been tested for the above mentioned standards by an accredited EMV
laboratory.
1.1.1. Accuracy of the measurement
Measurement variations from sources of interference (see chapter Installation
position) must be corrected in the ETS in order to ensure the specified accuracy of the
sensor (offset). To ensure a correct CO2measurement, the device must be installed in
a windproof socket.
The indicated accuracy of the CO2measurement will be achieved after a run-in
period of 24 hours (without interruption of the bus voltage) if the sensor has been in
contact with fresh air (350…450 ppm) at least once in this period.
After this, the CO2sensor will recalibrate every two weeks by defining the lowest
measured value captured during that period (without interruption of the bus voltage)
as a reference for fresh air.
The guarantee the accuracy on a sustained basis, the sensor should be provided with
fresh air at least once in two weeks. This occurs normally during room ventilation.
When measuring temperature, the self-heating of the device is considered by the
electronics. The heating is compensated by reducing the measured temperture by the
self-heating of 1.8°C. The indicated indoor temperature measured value approches the
actual room temperature during a 2 hours heating period.
2. Installation and commissioning
2.1. Installation notes
Installation, testing, operational start-up and troubleshooting should
only be performed by an electrician.
Temperature resolution 0.1°C
Temperature accuracy* ± 0.4°C at 25°C
Humidity measurement
range
0…95%
Feuchtigkeit resolution 0.1%
Feuchtigkeit accuracy ± 5% R. H.

5 Installation and commissioning
Indoor Sensor KNX AQS/TH-B-UP • Status: 07.11.2013 • Technical changes reserved. Errors reserved.
CAUTION!
Live voltage!
There are unprotected live components inside the device.
• National legal regulations are to be followed.
• Ensure that all lines to be assembled are free of voltage and take
precautions against accidental switching on.
• Do not use the device if it is damaged.
• Take the device or system out of service and secure it against
unintentional use, if it can be assumed, that risk-free operation is no
longer guaranteed.
The device is only to be used for its intended purpose. Any improper modification or
failure to follow the operating instructions voids any and all warranty and guarantee
claims.
After unpacking the device, check it immediately for possible mechanical damage. If it
has been damaged in transport, inform the supplier immediately.
The device may only be used as a fixed-site installation; that means only when
assembled and after conclusion of all installation and operational start-up tasks and
only in the surroundings designated for it.
Elsner Elektronik is not liable for any changes in norms and standards which may occur
after publication of these operating instructions.
2.2. Installation position
The Indoor Sensor KNX AQS/TH-B-UP will be installed concealed within a socket
(Ø 60 mm, 42 mm deep).
May be installed and operated in dry interior rooms only.
Avoid condensation.
For monitoring of the CO2content of the room air choose an installation position in
height of head (standing or sitting, according to utilization of room). The CO2
concentration in indoor rooms is highest near the floor and decreases towards the
ceiling.
When selecting an installation location, please ensure that the measurement results
are affected as little as possible by external influences. Possible sources of interference
include:
• Direct sunlight
• Drafts from windows and doors
• Draft from ducts which lead from other rooms or from the outside to the
junction box in which the sensor is mounted
• Warming or cooling of the building structure on which the sensor is mounted,
e.g. due to sunlight, heating or cold water pipes
• Connection lines and ducts which lead from warmer or colder areas to the
sensor

6 Installation and commissioning
Indoor Sensor KNX AQS/TH-B-UP • Status: 07.11.2013 • Technical changes reserved. Errors reserved.
Measurement variations from such sources of interference must be corrected in the
ETS in order to ensure the specified accuracy of the sensor (offset).
To ensure a correct CO2measurement, the device must be installed in a windproof
socket.
2.3. Composition
2.3.1. Housing
2.3.2. Rear view of sensor board with connections
Fig. 1
1 Base plate
2 Catches
3 Openings for air circulation
4 Push button
5 Programming LED (recessed)
6 Programming button
(recessed) for teaching device
7 Push button
8 Openings for air circulation
(LOWER)
3
24
6
7
5
8
1
Fig. 2
1 KNX terminal BUS +/-
2Notches
3SlotforCO
2sensor unit
4 Plug of CO2 sensor unit
5CO
2sensor unit
Lenght of cable approx. 110 mm
a Hole centre distance approx. 43 mm
b Diameter of diaphragm
approx. 18 mm
2
1
34 5
a
b

7 Display and operation of the device
Indoor Sensor KNX AQS/TH-B-UP • Status: 07.11.2013 • Technical changes reserved. Errors reserved.
2.4. Assembly of the sensor
First of all fit the windproof socket with connection. Also seal inlet pipes to avoid
infiltration.
Screw the base plate onto the socket and position the frame of the switching
programme. Connect the CO2sensor unit and the bus line +/- (black-red plug) to the
terminals provided on the board.
Pin the sensor with the notches on to the metal frame, so that sensor and frame are
fixed.
2.5. Notes on mounting and commissioning
Never expose the device to water (e.g. rain) or dust. This can damage the electronics.
You must not exceed a relative humidity of 95%. Avoid condensation.
After the bus voltage has been applied, the device will enter an initialisation phase
lasting a few seconds. During this phase no information can be received via the bus.
3. Display and operation of the device
3.1. Mode display
The display can show the current mode with the target temperature. The menue
“Display settings“ of the ETS must be set to “Display mode: Temperature control“.
The current target temperature is displayed (not the measured value)!
Day mode.
Target temperature day is used.
Night mode.
Target temperature night is
used.
Heating mode.
System is set to heating the
room.
Cooling mode.
System is set to cool the room.
Window open.
When heating, the lower value for frost protection is used as target value,
when cooling, the higher value for heat protection is used as target value.
Heating and coling are blocked by a communication object.
Place the CO2sensor unit in the socket. The side with the sensor
membrane must face to front.
Fig. 3

8 Display and operation of the device
Indoor Sensor KNX AQS/TH-B-UP • Status: 07.11.2013 • Technical changes reserved. Errors reserved.
3.2. Change ambient temperature with the
buttons
Using the push buttons, the target temperature for the room as well as the day/night
mode can be changed manually. The menue “Push buttons“ of the ETS must be set to
“Use push buttons: for temperature control“.
Decrease target
temperature (-)
briefly press
left button
Ambient temperature in the current
mode is decreased.
The sep-size is defined in the ETS
(0.1°C to 5°C).
Increase target
temperature (+)
briefly press
right button
Ambient temperature in the current
mode is increased.
The sep-size is defined in the ETS
(0.1°C to 5°C).
Switch to
night mode
press
left button
longer than 2 secs.
The set night temperature is the new
target temperature for the room, until
the next switchover to day mode
takes place (with button or via bus).
Switch to
day mode
press
right button
longer than 2 secs.
The set day temperature is the new
target temperature for the room, until
the next switchover to night mode
takes place (with button or via bus).
Extend day mode in night mode:
press both buttons
at the same time
longer than 2 secs.
Switches from night to day mode
again for a certain time (e. g. if the
rooms are used longer in the
evening).
The period is defined in the ETS (up
to 10 hours). The time remaining in
day mode is displayed.
