emerio CBC-122043.1 User manual

CBC-122043.1
Infrared panel heater (EN)
Infrarotheizung (DE)
Radiateur infrarouge (FR)
Pannello radiante a infrarossi (IT)

- 1 -
Content –Inhalt –Teneur –Contenuto
Instruction manual –English......................................................................................- 2 -
Bedienungsanleitung –Deutsch...............................................................................- 16 -
Mode d‘emploi – Français ........................................................................................- 30 -
Manuale d'istruzioni –Italiano.................................................................................- 44 -

- 2 -
Instruction manual –English
SAFETY INSTRUCTIONS
Before use make sure to read all of the below instructions in
order to avoid injury or damage, and to get the best results
from the appliance. Make sure to keep this manual in a safe
place. If you give or transfer this appliance to someone else
make sure to also include this manual.
In case of damage caused by user failing to follow the
instructions in this manual the warranty will be void. The
manufacturer/importer accepts no liability for damages
caused by failure to follow the manual, a negligent use or
use not in accordance with the requirements of this manual.
1. Read and save these instructions. Attention: pictures in
the IM are for reference only.
2. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
3. Children shall not play with the appliance.
4. Cleaning and user maintenance shall not be made by
children without supervision.
5. Children of less than 3 years should be kept away unless
continuously supervised.
6. Children aged from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has been
placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children aged from
3 years and less than 8 years shall not plug in, regulate
and clean the appliance or perform user maintenance.

- 3 -
7. CAUTION —Some parts of this product can become very
hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.
8. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
9. This appliance is intended to be used in household and
similar applications.
10. Do not use outdoors. Do not use to dry clothes or any
fabric.
11. The heater must not be located immediately below a
socket outlet.
12. Do not use the heater if the power cord is damaged.
13. WARNING: In order to avoid overheating, do not cover
the heater.
14. WARNING: The heater must not be used if the panel is
damaged.
15. The heater is to be installed so that switches and other
controls cannot be touched by a person in the bath or
shower.
16. Do not use this heater in the immediate surroundings of a
bath, a shower or a swimming pool.
17. Means “DO NOT COVER“.
18. Keep combustible material such as furniture, cushions,
bedding, paper, clothes, curtains etc. at least 100cm away
from the heater.
19. This heater has hot and arcing or sparking parts inside. Do
not use it in the areas where gasoline, paint, or flammable
liquids are used or stored.
20. Always unplug the appliance when not in use.
21. The appliance is hot when in use. To avoid burned, do not
let bare skin touch hot surfaces.

- 4 -
22. The supply voltage and utility frequency, specified on the
machine, need to match those of the socket that is used.
Only use an undamaged, earthed socket that is secured
with a 30 mA earth leakage circuit breaker. The electrical
socket that you are using must be to hand at all times in
order to be able to remove the plug from the socket in the
event of an emergency.
23. Fully extend the cord before plugging in the heater. Make
sure it does not come into contact with any part of the
heater and prevent it from heating up any other way. Do
not run the cord underneath carpeting; do not cover it
with mats, carpet strips or similar and make sure it is not
placed in any passageways. Make sure the cord cannot be
stepped on and that no furniture is placed on top of it. Do
not lead the cord around sharp corners and do not roll it
up too tightly after use!
24. If possible, do not use an extension cord, as this causes
the risk of overheating and fire. If the use of an extension
cord is unavoidable, then make sure it is an undamaged,
approved extension cord with a minimum diameter of 2 x
1.5 mm²and a minimum permissible power of 1000 Watt.
To prevent overheating, always fully extend the cord!
25. Do not use the heater outdoors and do not use it in
spaces, smaller than 7 m³.
26. Make sure that the air around the heater can circulate
freely. Do not place the heater too close to walls or large
objects and do not place it under shelves, cupboards or
similar: take at all sides at least 30 cm free space and at
least 20 cm from the floor. For hanging installation: don’t
block the space between heater and wall.
27. Carefully supervise when this appliance is used in the
presence of children, incapacitated persons or pets. Let
persons who are not able to leave the room
independently, away from a working heater. The surface
becomes hot (up to 95°C), so keep children and people
with disabilities out of the neighborhood. Keep the
packaging material away from children.

- 5 -
28. Always switch the heater off, unplug it and leave to cool
down before:
-cleaning the heater
-carrying out maintenance on the heater
-touching or moving the heater.
29. Keep the heater clean. Dust, dirt and/or a buildup of
deposits in or behind the heater are a common cause of
overheating. Make sure these deposits are removed
regularly.
30. The appliance (incl. cord and plug) may only be opened
and/or repaired by properly authorized and qualified
persons.
31. Only use this heater for its intended purpose and as
described in this instruction manual.
32. Regarding the information pertaining to the installation,
please refer to the below paragraph of the manual.

- 6 -
CBC-122043.1 EN
PARTS DESCRIPTION
1. Heating panel
2. Temperature sensor
3. Power switch
4. Control panel
5. Remote control
a) LED display
b) On/off button
c) Time set button
d) Value increase button
e) Value decrease buttons
LED display
a) Temperature / Data
b) Heating symbol
c) Open-window detection symbol
d) Power indicator light

- 7 -
Remote control
1. On/off button
2. Cancel button
3. Open-window detection button
4. Set button
5. Ok button
6. Edit button
7. ECO button
8. Temperature button
9. Time on button
10. Time off button
11. Value increase button
12. Value decrease button
13. Week button
WALL MOUNTING
The fixing materials supplied are intended for a brick wall. If you are using a different type of surface, you
should supply appropriate fixing materialsyourself.
This heater has been designed to hang securely from the wall. Do not use it until it has been properly
installed, as described in these instructions for use and never, for example, in a standing position or when
leaning against something!
Please take below minimum distance picture (fig.1) for reference.
(fig.1) (fig.2)
Please pay attention to fig.2: The wall-mounting system (A & B) on the rear side of the appliance should be
pre-mounted in order to hang it vertically. Viewed from the front, thepower switch is at the bottom side and
the control panel is at the right-hand side.
A. Wall mounting bracket & knobs
B. Wall spacer (Bracket for keeping space from the appliance to the wall)
Note: The knobs and wall spacer have already been installed on the rear side by the factory.
A
B

- 8 -
Please install the wall mounting bracket by following steps.
1. Choose a firm, even, vertical wall made of heat-resistant material on which to hang the appliance.
2. Define the position of the wall mounting bracket: the bracket should be mounted horizontal to the wall.
Position the bracket in such a manner that the minimum distances stated in fig.1 are guaranteed after the
appliance is mounted to the wall. Mount the bracket with the correct side upwards (see the mark “This
side up”on the bracket).
3. Mark the positions of the four holes to be drilled on the wall.
4. Drill 10mm holes in the marked places.
5. Insert the bolts (A&B) into the holes with a hammer. Put on the wall bracket. Secure the wall bracket
immovably against the wall by using the washer (C), gasket (D) and nut (E).
6. Hang the panel by letting the knobs through the eyes in the wall mounting bracket. Slide the panel as far as
possible to the right side and lower it as far as possible. Now the panel is mounted securely.
7. To remove the panel from the wall, you must lift and slide in the opposite direction, until the knobs are in
front of the eyes again. Now you can take the panel off.
Note: Guide the electric cable immediately downwards and make sure that it does not come into contact with
the panel. Donot conceal the cable behind theheater!
Holes
Bolts
Wall mounting bracket

- 9 -
OPERATION
Plug the appliance into an appropriate electrical outlet. Turn on the appliance by pressing the power switch to
position “I”. The power indicator light will be illuminated on the LED display. The appliance is standby.
You can use the control panel on the appliance or the separate remote control to operate your appliance.
Please note the control panel can only operate the basic functions. The remote control can operate the basic
functions as well as the advanced functions.
The remote control should be directed towards the LED display while using.
Basic functions:
1. Press the on/off button to turn on the appliance. Press the button again to turn the appliance off.
2. Set the temperature.
1) Press the button “+” or “-” to set your desired temperature. You can choose from 0-37℃. Long
pressing for rapid adjustment.
2) The LED display will flash the set temperature approx. 10 seconds and then turn back to show the
current temperature. It means the temperature has been set.
3) If the set temperature is higher than the current temperature, the appliance will start to heat and the
heating symbol will be illuminated on the LED display. If the set temperature is reached, the appliance
will automatically switch off and then switch on again when the room cools down. The heating symbol
will be off and illuminated again accordingly.
Note: If no button is pressed in approx. two minutes, the current temperature will disappear from the LED
display. Pressing any button will make the current temperature re-appear.
3. Set the current day and time (so that you can set the weekly timer function later.)
1) Let the appliance be on but not heat. Therefore, no heating symbol is illuminated on the LED display.
(Do this by setting the temperature lower than the current temperature, for example.)
2) Follow below steps in the table to set the current day and time. When using the control panel, please
press the button “M”. When using the remote control, please press the button “SET”.
Step
Press button
The LED display shows
Note
1
M / SET (3 sec.)
HH flashes
It means to set the day of today.
2
+ or –
01 to 07
01 = Monday, 02 = Tuesday, 03 = Wednesday, 04 =
Thursday, 05 = Friday, 06 = Saturday, 07 = Sunday.
3
M / SET
H1 flashes
It means to set the current hour.
4
+ or –
00 to 23
Choose the correct hour.
5
M / SET
H2 flashes
It means to set the current minute.
6
+ or –
00 to 59
Choose the correct minute.
7
M / SET
Current temperature
It means the day and time are set.
4. Check the current day and time.
1) Let the appliance be on and heat. Therefore, the heating symbol is illuminated on the LED display. (Do
this by setting the temperature higher than the current temperature, for example.)
2) Consecutively press the button “M” (on the control panel) / “SET” (on the remote control) to check the
current day and time:
HH: day of the week;
H1: hour;
H2: minute.
