emerio CH-128215.3 User manual

CH-128215.3
Convector heater (EN)
Konvektor (DE)
Radiateur à convection (FR)
Konvektorelement (SE)
Convectorverwarming (NL)
Grzejnik konwektorowy ( PL )
Convector ( ES )

- 1 -
Content –Inhalt –Teneur - Innehåll –Inhoud –Treść –
Contenido
Instruction manual –English ......................................................................................- 2 -
Bedienungsanleitung –German.................................................................................- 9 -
Mode d‘emploi – French..........................................................................................- 17 -
Bruksanvisning –Swedish ........................................................................................- 25 -
Gebruiksaanwijzing –Dutch.....................................................................................- 32 -
Instrukcja obsługi – Polish........................................................................................- 40 -
Manual de Instrucciones –Spanish ..........................................................................- 48 -

- 2 -
Instruction manual –English
Important: read this instruction fully before using the heater;
retain these instructions for future reference.
This product is only suitable for well insulated spaces or
occasional use.
ASSEMBLY OF THE HEATER
Before using the heater, the feet
(supplied separately in the box) must
be fitted to the unit. These are to be
attached to the base of the heater
using the 4 self-tapping screws
provided, taking care to ensure that
they are located correctly in the bottom ends of the heater
side moldings.
SAFETY INSTRUCTIONS (READ BEFORE OPERATING THE
HEATER)
1. Read and save these instructions. Attention: pictures in
the IM are for reference only.
2. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
3. Children shall not play with the appliance.
4. Cleaning and user maintenance shall not be made by
children without supervision.
5. Children of less than 3 years should be kept away unless
continuously supervised.
6. Children aged from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has been

- 3 -
placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children aged from
3 years and less than 8 years shall not plug in, regulate
and clean the appliance or perform user maintenance.
7. CAUTION —Some parts of this product can become very
hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.
8. Do not use this heater if it has been dropped.
9. Do not use if there are visible signs of damage to the
heater.
10. Use this heater on a horizontal and stable surface.
11. WARNING: Do not use this heater in small rooms when
they are occupied by persons not capable of leaving the
room on their own, unless constant supervision is
provided.
12. WARNING: To reduce the risk of fire, keep textiles,
curtains, or any other flammable material a minimum
distance of 1 m from the air outlet.
13. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
14. This appliance is intended to be used in household and
similar applications.
15. Do not use the heater unless the feet are correctly
attached.
16. Ensure that the power supply is plugged in accordance
with the rating label on the heater; the socket must be
earthed.
17. Keep the mains lead away from the hot body of the
heater.
18. The heater is not intended for use in bathrooms, laundry
areas or similar indoor locations. Never place the heater
where it may fall into a bathtub or any other water
container.

- 4 -
19. Do not use outdoors.
20. Do not cover or obstruct any of the heat outlet grilles or
the air intake openings of the heater.
21. Do not place the heater on carpets with a very deep pile.
22. Always ensure that the heater is placed on a firm level
surface. Ensure that the heater is not positioned close to
curtains or furniture as this could create a fire hazard.
23. The heater must not be located immediately below a
socket outlet.
24. Do not insert any object through the heat outlet or air
intake grilles of the heater.
25. Do not use the heater in areas where flammable liquids
are stored or where flammable fumes may be present.
26. Particular care should be taken when the heater is
situated in areas occupied by children or disabled persons.
27. Always unplug the heater when moving it from one
location to another.
28. Do not use the heater if the power cord is damaged.
29. Do not use this heater in the immediate surroundings of a
bath, a shower or a swimming pool.
30. WARNING: In order to avoid overheating, do not cover the
heater.
31. The appliance should not be operated by means of an
external timer-switch or by means of a separate system
with remote control not originally belonging to this
appliance.
32. This heating device is not suitable for assembling in
vehicles and machines.
33. Means “DO NOT COVER “.

- 5 -
CH-128215.3 EN
PARTS DESCRIPTION
1. Air outlet
2. Power switch (750W; 1250W; 2000W)
3. Thermostat
4. Air inlet
5. Handle
6. Feet
OPERATION OF THE HEATER
Note: When the heater is turned on for the first time, or when it is turned on after a longer period of storage, it
is normal that the heater may emit some smell and fumes. This will disappear when the heater has been on a
short while.
⚫Set the thermostat to the minimal position and insert the plug to the power supply.
⚫Turn on the power switch: 750W, 1250W, 2000W.
⚫Turn the thermostat knob in a clockwise direction to the max position.
⚫Once the room temperature has reached the desired value, turn the thermostat knob slowly in
anti-clockwise direction until you hear a "click" sound; this is the setting temperature.
⚫The appliance will automatically maintain the setting temperature. It will switch on when the room
temperature is below the setting, and switch off if it is above the setting.
PROTECTION AGAINST OVERHEATING
1) An additional fitted safety thermostat protects the heater against overheating and switches it off
automatically. The indicator light then goes out. The heater is ready for service again after a short cooling-off
phase (approx. 15 minutes).
2) If this repeats itself, first check whether the thermostat switch is set correctly or if objects hinder the heating
operation.
CLEANING THE HEATER
Always unplug the heater from the wall socket and allow it to cool down completely before cleaning. Clean the
outside of the heater by wiping with a damp cloth and with a dry cloth. Do not use any detergents or abrasives
and do not allow any water to penetrate the heater.
STORING THE HEATER
When the heater is not used for a long time it should be protected from dust and stored in a clean dry place.
TECHNICAL DATA
Operating voltage: 220-240V ~ 50-60Hz
Power consumption: 1800-2000W
GUARANTEE AND CUSTOMER SERVICE
Before delivery our devices are subjected to rigorous quality control. If, despite all care, damage has occurred
during production or transportation, please return the device to your dealer.
For the purchased device we provide 2 years guarantee, commencing from the day of sale. If you have a
defective product, you can directly go back to the point of purchase.
Defects which arise due to improper handling of the device and malfunctions due to interventions and repairs
by third parties or the fitting of non-original parts are not covered by this guarantee. Always keep your receipt,

- 6 -
without the receipt you can’t claim any form of warranty. Damage caused by not following the instruction
manual, will lead to a void of warranty, if this results in consequential damages then we will not be liable.
Neither can we hold responsible for material damage or personal injury caused by improper use or if the
instruction manual are not properly executed. Damage to accessories does not mean free replacement of the
whole appliance. In such case please contact our service department. Broken glass or breakage of plastic parts
is always subject to a charge. Defects to consumables or parts subjected to wearing, as well as cleaning,
maintenance or the replacement of said parts are not covered by the warranty and are to be paid.
ENVIRONMENT FRIENDLY DISPOSAL
Recycling –European Directive 2012/19/EU
This marking indicates that this product should not be disposed with other household wastes. To
prevent possible harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
Emerio B.V. Customer service: Kundeninformation: Klantenservice:
Oudeweg 115 T: [phone] T: [phone] T: [phone]
2031 CC Haarlem www.emerio.eu/service www.emerio.eu/service www.emerio.eu/service
The Netherlands
Looking for spare parts? Have a look at https://spareparts.emerio.eu
Sie brauchen Ersatzteile? Besuchen Sie https://ersatzteile.emerio.eu
Onderdelen nodig? Kijk op https://onderdelen.emerio.eu

- 7 -
ERP information (EN)
Supplier: Emerio B.V.
Oudeweg 115
2031 CC Haarlem
The Netherlands
Declare that the product detailed below:
Information requirements for electric local space heaters
Model identifier(s):
Item
Symbol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat
output
Pnom
1.8-2.0
kW
manual heat charge control, with
integrated thermostat
No
Minimum heat
output
(indicative)
Pmin
0.75
kW
manual heat charge control with room
and/or outdoor temperature feedback
No
Maximum
continuous heat
output
Pmax,c
2.00
kW
electronic heat charge control with
room and/or outdoor temperature
feedback
No
Auxiliary
electricity
consumption
fan assisted heat output
No
At nominal heat
output
elmax
0.000
kW
Type of heat output/room temperature
control (select one)
At minimum heat
output
elmin
0.000
kW
single stage heat output and no room
temperature control
No
In standby mode
elSB
0.000
kW
Two or more manual stages, no room
temperature control
No
with mechanic thermostat room
temperature control
Yes
with electronic room temperature
control
No
electronic room temperature control
plus day timer
No
electronic room temperature control
plus week timer
No
Other control options (multiple selections
possible)
room temperature control, with
presence detection
No
room temperature control, with open
window detection
No
with distance control option
No
with adaptive start control
No

- 8 -
with working time limitation
No
with black bulb sensor
No
Contact details
Emerio B.V.
Oudeweg 115
2031 CC Haarlem
The Netherlands
Satisfies the requirement of the Council Directives:
COMMISSION REGULATION (EU) No 2015/1188 of 28 April 2015 and Amending COMMISSION
REGULATION (EU) 2016/2282 implementing Directive 2009/125/EC of the European Parliament and
of the Council with regard to ecodesign requirements for local space heaters
Regarding information for consumers on how to install, use and maintain the product, WEEE
information, please check the instruction manual provided with packaging.

- 9 -
Bedienungsanleitung –German
Wichtig: Lesen Sie vor Verwendung dieses Heizgerätes diese
Anweisungen sorgfältig durch und bewahren Sie sie für
spätere Zwecke gut auf.
Dieses Produkt ist nur für gut isolierte Räume oder für den
gelegentlichen Gebrauch geeignet.
ZUSAMMENBAU DES HEIZGERÄTES
Vor Verwendung des Heizgerätes müssen
die Standfüße (separat in der Verpackung)
am Gerät befestigt werden. Die
Standfüße müssen mit den vier
mitgelieferten selbstschneidenden
Schrauben an die Grundplatte des Heizgerätes montiert
werden; sie müssen sich ordnungsgemäß unten in den
Enden der Seitenteile des Heizgerätes befinden.
SICHERHEITSHINWEISE (VOR BETRIEB DES HEIZGERÄTS
DURCHLESEN)
1. Lesen und bewahren Sie diese Anleitungen auf. Achtung:
Die Bilder in der Bedienungsanleitung dienen nur zur
Veranschaulichung.
2. Dieses Gerät kann von Kindern ab 8 Jahren und von
Personen mit eingeschränkten physischen, sensorischen
oder geistigen Fähigkeiten oder ohne Erfahrung und/oder
Wissen benutzt werden, wenn diese durch eine für ihre
Sicherheit zuständige Person beaufsichtigt werden oder
von ihr Anweisungen erhielten, wie das Gerät sicher zu
benutzen ist und sie auf die Risiken aufmerksam gemacht
wurden.
3. Kinder dürfen nicht mit dem Gerät spielen.
4. Kinder sollten dieses Gerät nicht unbeaufsichtigt reinigen
oder warten.
5. Kinder unter 3 Jahre sollten ferngehalten werden, außer
sie werden ständig beaufsichtigt.
