Fisher™Large EH Design Supplement
24X20 Class 1500 Design EHT-2 Control Valve
This supplement provides information for serial numbers ME00124272 and ME00124273
Overview
This special instruction manual is a supplement to the Fisher EHD and EHT Sliding-Stem Control Valves (Large EH)
Instruction Manual (D100392X012). Observe all warnings, cautions, and notes provided in the Large EH instruction
manual. Contact your Emerson sales office or Local Business Partner for more information.
Scope
This special instruction sheet provides maintenance information for NPS 24X20 Class 1500 Design EHT-2 control
valves. This information covers valve serial numbers ME00124272 and ME00124273. For other procedures, refer to
the Fisher EHD and EHT Sliding-Stem Control Valve (Large EH) Instruction Manual (D100392X012).
Table 1. Fisher Large EH Specifications
Specifications
Design Pressure 242 Barg (3510 Psig)
Design Temperature 88°C (190°F)
End Connections NPS 24 CL1500 RTJ Flange
Shutoff Classification ANSI Class IV
Flow Characteristic Linear - - See figure 3
Flow Direction Flow Down
Port Diameter 18 1/4 in
Valve Plug Travel 10 7/8 in
Valve Yoke Boss 7 in
Maximum Flowing Pressure Drop 103 bar (1500 psi)
Maximum Shutoff Pressure Drop 258 bar (3750 psi)
Estimated Weight of Valve
and Actuator Assembly 11500 kgf (25,500 lbf )
Large EH
August 2018
Instruction Manual Supplement
D104372X012

Instruction Manual Supplement
D104372X012
Large EH
August 2018
2
Figure 1. Assembly Drawing
PLUG/STEM ASSEMBLY
DETAIL B
RETAINING RING
BACK-UP RING
ANTI-EXTRUTION RING
SEAL RING
SEAL RING
DETAIL A
BONNET
STUD (QTY 16)
GASKET (QTY 16)
STUD SPACER (QTY 16)
HEX NUT (QTY 16)
PLAIN WASHER (QTY 16)
CAGE/SEAT ASSEMBLY
GASKET (QTY 2)
VALVE BODY
FLOW DIRECTION
DETAIL A
DETAIL B
GE98524

Instruction Manual Supplement
D104372X012
Large EH
August 2018
3
Trim Removal
Observe all warnings, cautions, and notes provided in the Large EH Instruction Manual (D100392X012). See figure 1
for assembly drawing.
1. Before removing actuator and disassembling valve, isolate the valve from all pressure and relieve trapped pressure
from body and actuator.
2. Follow the instructions in D100392X012 to remove actuator and packing.
3. Loosen the bonnet bolting hex nuts one-fifth of one nut flat (1/30 of one revolution) to achieve initial breakout of
the nuts while transferring minimal additional loading to the adjacent nuts.
4. When the hex nuts have been loosened one-fifth nut flat, use the bolt loosening sequence (figure 2) and turn the
hex nuts an additional one-half nut flat.
5. Repeat the bolt loosening sequence, turning the hex nuts one-half nut flat each sequence until the hex nuts have
turned a total of two nut flats (after initial breakout). Then loosen the body-to-bonnet joint gasketed joint by either
rocking the bonnet or prying between the bonnet and body. Work the prying tool around the bonnet until the
bonnet loosens. If no fluid leaks from the joint, repeat the bolt loosening sequence to completely remove the hex
nuts.
Figure 2. Bolting Pattern
214
8
3
12
15
9
5
1
13
16
11
4
6
10
7
6. Thread eyebolts, or hoist rings, into the two holes (1-1/4 in X 7 UNB, 2-1/4 in deep) on the top of the bonnet. Attach
rigging equipment capable of lifting 3600 lb to the eyebolts or hoist rings.
7. Carefully lift the bonnet off the body. If the plug/stem assembly starts to lift with the bonnet, use a brass or lead
hammer on the end of the valve stem to move it back down. Set the bonnet on a protective surface to prevent
damage to the cage gasket surface.
8. Carefully lift the valve plug/stem assembly out of the body, taking care not to damage the seal ring on the plug.
Protect the valve plug stem and the valve seating surfaces to prevent damage.
9. Remove and discard the upper cage gasket.

Instruction Manual Supplement
D104372X012
Large EH
August 2018
4
10. Install two ½”-13 UNC-2A eye bolts or hoist rings with a minimum threaded length of 3/4 inch into the tapped holes
in the top of the cage and carefully lift it out of the valve body. Attach rigging equipment capable of lifting 800 lb to
the eyebolts. The seat ring will be removed with the cage as an assembly due to the seat ring being screwed into the
bottom of the cage and secured with tack welds. If the cage is stuck in the valve, use a rubber mallet to strike the
exposed portion of the cage at several points around its circumference. Set the parts on a protective surface to
prevent damage to gasket or seating surface.
11. Remove and discard the lower cage gasket.
12. Using the below procedure, disassemble the seat ring from the cage:
a. Carefully pry or cut out the seat ring seal ring from its groove in the seat ring. Discard the old seat ring seal ring.
b. Grind or file off the tack welds that prevent the seat ring from unscrewing from the cage.
c. There are 9/16 inch slots cut in the seat ring. Insert a bar through the slots and turn seat ring counter-clockwise
to unscrew it from the cage.
d. Set the seat ring on a protective surface taking care not to damage the seat ring seal ring surface.
13. Inspect all parts for wear and damage that would prevent proper operation of the valve. All gasket surfaces on the
trim parts and in the body must be cleaned of any residue and must be free from nicks and scratches. The seating
surfaces of the valve plug and seat ring need to be free from nicks, scratches, or any other damage for proper shut
off. Replace or repair trim parts as appropriate.
Valve Plug Maintenance
For information concerning the proper repair and maintenance of the valve plug/stem assembly please reference the
section of EHD and EHT valve plug maintenance in the Large EH Instruction Manual (D100392X012).
Trim Replacement
After all trim maintenance has been completed; reassemble the valve by following the numbered steps below. Be
certain that all gasket surfaces have been cleaned well.
1. All gaskets must be new to ensure proper valve operation. This valve assembly requires two flat sheet gaskets.
Observe all warnings and cautions in the Large EH Instruction Manual (D100392X012).
CAUTION
This valve uses special fluorocarbon-coated bolting. The fluorocarbon coating on the bolting must be inspected for damage
each time the body-to-bonnet bolting is loosened. If the fluorocarbon coating is damaged, it is recommended that the
bolting be replaced or contact Emerson for the appropriate bolt torque value. Reassembling the body-to-bonnet bolting
with damaged fluorocarbon-coating will require higher assembly torque to prevent leakage and to ensure proper valve
operation.
2. Orient the cage and seat ring so the threads on each are facing one another for assembly. The bottom of the cage
should be facing the top of the seat ring.
3. Using a bar inserted through the slots on the seat ring, turn the seat ring clockwise into the cage until tight.
4. Tack weld the seat ring to the cage using minimal heat. Two welds, 1/4 inch long and 180 degrees apart are
required.
CAUTION
To avoid damage to the seal ring, slowly and gently stretch it for the following procedure. Avoid pulling sharply on the ring.

Instruction Manual Supplement
D104372X012
Large EH
August 2018
5
5. Install the replacement seat ring seal with the open side facing up (toward the top of the seat ring). The open side of
the seal ring should face down (toward the bottom of the valve body) in flow-up installations and up in flow down
installations.
To Install the seal ring on the seat ring, first lubricate with a general-purpose silicone-base lubricant. Then gently
stretch the seal and work it over the bottom edge of the seat ring. The PTFE material in the seat ring must be
permitted time to cold-flow during the stretching procedure, so avoid pulling sharply on the ring. Stretching the
seal ring over the seat ring may make it seem unduly loose when in the groove, but it will contract to its original size
after insertion in the valve body.
6. Install a new lower cage gasket into the valve body.
7. Make sure the eye bolts that were installed in the cage assembly during the disassembly procedure are still
installed. Then using the eye bolts as lifting points, carefully lower the cage/seat ring assembly into the valve. Using
care to avoid damaging the seat ring seal ring and cage seating surfaces while handling the heavy parts. To help
insert the cage/seat ring assembly into the valve, lubricate the outside diameter of the seat ring seal ring with a
general-purpose silicone-based lubricant.
8. Carefully lower the valve plug/stem assembly into the cage, being careful not to damage any surfaces of the cage,
seat ring or plug. Make sure the seal ring is evenly engaged in the entrance chamfer at the top of the cage assembly
to avoid damage to the ring.
9. Install a new upper cage gasket on top of the cage flange assembly.
10. Mount the bonnet on the valve body.
11. Divide the body-to-bonnet torque value into smaller, equal increments of torque. As the final torque is 6915 N•m
(5100 ft•lb), divide into smaller equal increments of 1152 N•m (850 ft•lb) of torque. Then follow the torquing
sequence (figure 2) and torque the hex nuts to the first increment of torque. When all the hex nuts are at this first
torque valve, follow the bolting torque sequence and torque the hex nuts to the second increment of torque.
Repeat until the hex nuts are all tightened to the specific final torque value of 6915 N•m (5100 ft•lbf). If any of the
hex nut turns at the final torque, tighten all hex nuts to the final torque again.
12. Install the packing and actuator per the instructions in the manual (D100392X012), observe all warnings, cautions
and notes.

Instruction Manual Supplement
D104372X012
Large EH
August 2018
6
Figure 3. Capacity Curve
