Part No. F40BP72060000 Form No. BP7206 Printed in U.S.A. 4/97
Model No.
SW95
WHITE/IVORY
QUIETSET FAN CONTROL
SINGLE-POLE, 4-SPEED FAN MOTOR CONTROL
MAXIMUM 1.25 AMP, 120VAC, 60HZ
CAUTION: Read all instructions carefully before installation.
Save this Owner's Manual for future reference.
Form No. BP7206 Printed in U.S.A.
EMERSON
Air Comfort Products
DIVISION OF EMERSON COMPANY
8100 W. Florissant, St. Louis, MO 63136
SW95 Quietset Fan
Control Owner's Manual
®
LIMITED WARRANTY
What The Warranty Covers:
All products covered by this Owner’s Manual are warranted against all defects in workmanship and materials. You must be the
original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
All components are covered by this warranty for one year from the date you purchased your fan control. ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES
IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Company Do To Correct Problems:
Emerson Company will replace a defective Emerson Fan Control at no charge to you. We will ship the repaired product or replacement
to you at no charge, but you are responsible for all costs or removal, reinstallation and shipping of the product to Emerson.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE FAN CONTROL TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR
RECEIPT OR OTHER PROOF OF PURCHASE. You can return the product to our factory or to your nearest authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort Products,
Division of Emerson Company, 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown on the product
with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your
Emerson Fan Control should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
What Is Not Covered:
This warranty also does not cover any defects, malfunctions or failures caused by:
• Repairs by persons not authorized by Emerson Company,
• Use of parts or accessories not authorized by Emerson Company,
• Mishandling, improper installation, modifications or damage to your wall control while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• The original purchaser or user ceases to own the product, or
• The ceiling fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral warranties
apply, and no employee, agent, dealer or other person is authorized to give any warranties on behalf of Emerson Company.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND EMERSON IS
NOT RESPONSIBLE FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGES. Incidental damages
include but are not limited to such damages as loss of time and loss of use. Consequential damages include but are not limited to the
cost of repairing or replacing other property which was damaged if this product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may
not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
OPERATION
NOTE: Fan control knob turns fan
on at maximum speed to assist
motor start-up. Fan speed
decreases with clockwise
rotation.
Set the fan on its HIGH speed pull
chain setting. Then use your speed
control to select any of the
4-speeds, plus OFF.
NOTE: Fully counter-clockwise is
OFF. The four fan speeds are
selected by rotating the knob one
position at a time clockwise.
IMPORTANT
Always have the fan switch set to
HIGH speed before using the wall
control. To avoid accidental pull
chain use, shorten chain by
cutting it 1” below switch body.
The SW95 Quietset Fan Control
turns all Emerson CF Series Ceiling
Fans into four-speed fans.
32
General
This control is designed to operate
only one ceiling fan, and not an
accessory light kit. This SW95
speed control is rated for 1.25 amps
at 120 volts. To avoid erratic speeds
and possible damage to your ceiling
fan, use this control only with the fan
pull chain switch set to its high
speed setting.
Installation
1. Before disconnecting power,
ensure that the fan is set at the
highest speed.
NOTE: Electric connections
should be in accordance with the
National Electrical Codes and all
Local Codes. Before starting,
disconnect power to the circuit at
the fuse box or circuit breaker
panel.
2. Remove the faceplate and
screws from the existing wall
switch. Pull switch out from wall
outlet box.
3. Disconnect wire from existing fan
wall switch (Figure 1).
4. Set the SW95 Quietset Fan
Control in the off position (full
counter-clockwise), and pull off
the knob.
Safety Instructions
WARNING: To avoid fire, shock, and serious personal injury,
follow all instructions carefully.
1.Read your Owner's Manual carefully. Retain Owner’s Manual for
future reference.
2.To avoid possible electrical shock, be sure electricity is turned off
at the main fuse or circuit breaker box before wiring.
3.Make certain no bare wires are exposed outside the wire
connectors.
4.Do not mount speed control near heat producing equipment.
5.All wiring must conform to National and Local Electrical Codes. If
you do not have enough electrical knowledge, have a licensed
electrician install the control.
WARNING: Use of this control with some ceiling fans could result
in fire, shock and serious personal injury. Use this speed control
only with Emerson CF series ceiling fans.
7. Position the faceplate (not
provided) onto the speed control.
Using the two 6-32 screws
supplied with the faceplate, screw
the faceplate and speed control
to the wall outlet box (Figure 3).
8. Press knob onto the shaft and
rotate counter-clockwise to the
full-OFF position.
9. Restore power at the main fuse
box or circuit breaker panel.
CAUTION
For fans equipped with built-in
variable speed devices: These
devices must be set at their
MAXIMUM SPEED for proper
operation. Adjustments to their
setting must only be made with
Quietset in the OFF position.
Changing or switching these
settings while the fan control is in
operation could damage the
control.
FACEPLATE SWITCH WALL
OUTLET
BOX
Figure 1
5. Connect the BLACK wire from
the Quietset to the fan/motor lead
with a wire connector (provided).
(Figure 2.)
6. Connect the BLACK wire from
the Quietset to the 120VAC hot
wire with a wire connector
(provided).
NOTE: Use wire connectors
(supplied) to secure electrical
connections.
TM
TO NEUTRAL TO FAN MOTOR LOAD
MOTOR LOAD
1.25 AMP MAXIMUM
TO 120VAC
SOURCE HOT
BLACK
BLACK
Figure 2
FACEPLATE
QUIETSET SPEED
CONTROL
WALL OUTLET
BOX
6-32 SCREWS (2)
Figure 3
