Quick-start: For MSP-USTD1/MSP-USTD2
MSP-USTD1/MSP-USTD2
Quick-start booklet
IP2040/QS
January 2006
www.mobrey.com

(IP2040/QS) January 20062
Introduction
What is this Quick-start?
This Quick-Start is for anyone who has to install and commission the MSP-USTD1 or MSP-USTD2 ultrasonic system, and does
not need in-depth information.
For full installation instructions, you must refer to the installation (IM) manuals supplied with the equipment.
What are these MSP-USTD1 and MSP-USTD2 systems?
They are level, contents, or flow measurement and control systems. Suitable applications include wet well level (and pump)
control, tank contents measurement, and open channel flow measurement.
The system comprises mains or DC powered MCU901 control unit, an MSP900SH ultrasonic transmitter with a mounting kit,
and manuals. MSP-USTD1has the wall-mounted version of the MCU901; MSP-USTD2has the panel-mounted MCU901.
Figure 1: MCU901W – wall-mounted Figure 2: MSP900SH Figure 3: MCU901P – panel-mounted
About the MCU901 Control Unit
The MCU901 unit is a member of the MCU900 family of control units. It has:
•Full support for a single MSP900SH ultrasonic transmitter – measuring level by default
•a 4-line LCD display with back light – displays both text and graphical information
•a 6 button keypad
•an LED indicator
•an intuitive menu system – for setting up
•2digital inputs (voltage-free contacts) for triggering various activities (e.g. displaying a message)
•5relay outputs (e.g. for controlling pumps, indicating alarms, etc.)
•a 4-20mA output.
All setting up is achieved from the front panel of the MCU901 control unit.
About the MSP900SH Ultrasonic Transmitter
This is a loop-powered transmitter, factory sealed and fitted with cable ready to install on aqueous applications. The transmitter
is pre-configured to measure liquid level and communicates values to the MCU901.
The other manuals
The following manuals are supplied along with this Quick-start manual:
MCU901:
Installation manual (IP2030/IM)
Safety instructions (IP2030/SI)
MSP900SH:
Installation manual (IP2040/IM)
Safety instructions (IP2040/SI)
Full operation manuals IP2030/OM and IP2040/OM are available on request from Mobrey Measurement and are on the web at
www.mobrey.com.

January 2006 (IP2040/QS)3
Installation
Location of MSP900SH
•Install the transmitter above the liquid surface using the bracket provided.
•Do not mount the MSP900SH on a structure that is subject to vibration, or in a position where damage may be caused by
impact or thermal stress.
•The equipment is not intended for use in areas exposed to dust.
•The equipment must not be installed directly in any process where the enclosure might be charged by the rapid flow of
non-conductive media.
Location of MCU901
•The MCU901 must not be located in a hazardous area. Do not mount the MCU901 where it is subject to vibration, or in a
position where damage may be caused by impact, thermal stress or liquid ingress.
•The MCU901W is housed in a tough IP65 enclosure. If mounted outside, it is recommended that the unit be protected from
direct heavy rain.
•The MCU901P is a standard DIN size designed for direct mounting in a control panel. It is designed for panel mounting in a
weatherproof environment.
Cabling (MCU901W)
1.Cable the MSP900SH to the MCU901 using the gland provided. (Undo 2 screws and lift cover away to reveal terminals).
2. Check the voltage selector switch (230V or 115V) and adjust if necessary. (Mains unit only).
3. Cable the power lead to the MCU901 using the gland provided. Do not apply power yet.
4. Make connections to relay terminals and current output terminals, if required.
5. Seal unused cable entries with the blanking plugs provided.
6. Replace and secure the terminal cover.
Cabling (MCU901P)
1. Cable the MSP900SH transmitter to terminals 1, 2and 3on the rear panel of the MCU901.
(See figure inset, right)
2. Check the voltage selector switch (230V or 115V) and adjust if necessary. (Mains unit only).
3. Cable the AC power supply to terminals 28 (Live) and 29 (Neutral) on the rear panel of the
MCU901. Note that mains Earth is not required. (Mains unit only).
4. Connect terminal 30 to an Intrinsically Safe Earth. This is essential only if the MSP900SH
is in located in a hazardous area.
IMPORTANT - For hazardous area installations
,
y
ou must refer to the installation
(
IM
)
manuals su
pp
lied with the s
y
stem.

(IP2040/QS) January 20064
Getting started
After completing the installation of both MCU901 control unit and the MSP900SH transmitter, the next stage is to switch on.
1.Familiarise yourself with the front panel fascia.
Front Panel Fascia of MCU901W
Key to figure:
c4-line LCD with backlight.
dKeypad with 6 function keys.
eStatus LED – flashes once per second if okay.
3. Familiarise yourself with the primary display.
Primary Display
Key to figure:
1. Off-line/on-line status. (Locked padlock = on-line)
(See page 14)
2. Digital input status. (o = de-energised, = energised)
3. Measured variable (P.V.) and units of measurement.
4. Bar graph of 4-20mA output of MCU901.
5. Relay (RL) status. (o = de-energised, = energised)
6. Digital communication in progress. (Absent if idle)
2. Switch on the MCU901 by applying the power. Wait
for the primary display (inset, right) to appear.
During this time, the MCU901 will read parameters
from the MSP900SH transmitter.
If being used for the first time, it will prompt for the
Bottom Reference of the MSP900SH transmitter
and then automatically set-up the 4-20mA output
span over this range. If you do not want to
commission the system now, simply switch off
the power – the same prompt will then re-appear
when switching on the next time.
If you are commissioning the system, edit the
Bottom Reference with the arrow-keys and then
press the yellow key to confirm the value. The
Bottom Reference can be changed at a later stage
but it is better to get it correct now. Should you
press the red (ESC) key, the MCU901 will continue
and the Bottom Reference prompt will re-appear
when switching on the next time.
Once the start-up is completed, the primary display
should appear, showing the measured depth of the
liquid in the tank. The value on the primary display
is the P.V. (Primary Variable).
Note: If a “Find Instrument” screen appears and
remains, power off. Check the cabling and then try
again. If the problem persists, follow the on-screen
prompts until the primary display appears.

January 2006 (IP2040/QS)5
How to display the menu system
4. Press the yellow (ENTER) key to display the top-level of
the menu system.
The primary display re-appears automatically if there is
no keypad activity for several minutes, if on-line. In
addition, it re-appears when pressing the ESC key
whilst at the top level of the menu system.
7. Programming the MCU901 unit is best achieved through easy-to-follow
Wizards. They are simply a sequence of on-screen prompts, allowing you
to easily set-up an individual function or a large application without fuss.
There is a collection of Wizards for most functions and applications. They
are all selected and started through the menu system. On the pages that
follow, examples for several applications show how to use them.
Example of a Wizard
8. Additional features, such as password protection, resetting to factory defaults, etc., can found on pages 14/15.
5. Navigation of the menu system is
achieved by using the ARROW
keys, the ENTER key, and the
ESC key. (See figure, right).
The ESC key will return you to
the
p
revious menu level.
Selecting this will bring up
the “Set-up” menu for
programming the MCU901.
Selecting this will bring up the
“Set-up” menu for optional
MSP900 programming.
The transmitter Bottom
Reference can be changed here.
6. The Main Menu sits above a series of sub-menus. Within the menus, there are
also parameter screens for programming – setting up for an application,
adjusting default settings, etc. – and for displaying information.
Selecting this will allow you
to monitor live readings and
diagnostic information for
the MCU901.
Direct access menu for
advanced users to select
parameter screens.
Toggles operating mode for
MCU901. An open padlock
indicates that the MCU901 is
off-line and parameter values
can be entered or changed.
(See page 14)
Selecting this will allow you to monitor live readings and
diagnostic information from the MSP900 transmitter.

(IP2040/QS) January 20066
Application/Duty: Level Measurement
1. With power on and the MSP900SH transmitter giving a 4-20mA signal to the MCU901 unit (see previous pages), you can
now programme the MCU901 for an application. This application example is for level measurement.
Requirements
Live level measurement in units of metres over a range of 0 to 11.7 metres.
High level alarm.
Input Data
Tank Shape: Linear (e.g. Square)
Bottom Reference: 12 metres
The MSP900SH transmitter is supplying the live level measurements in units of
metres.
4. Work through the “Duty” Wizard prompts (see next page) until completion; this occurs when the menu system re-
appears. Keypad hints, for the illustrated Wizard sequence on the next page, are provided alongside the prompts. If
applicable, adapt the example to suit your application.
5. Circled numbers in the illustrated Wizard sequence relate to these notes:
cSelect “Level” from the multiple-choice list.
dProgramme the 4-20mA output span with a level range (e.g. 0 to 11.7 metres)
eSet-up a high level alarm – the relay RL1 is energised whenever the measured level exceeds a pre-set level and
de-energises below another pre-set level, as defined at these prompts.
fOptional overrides to prevent individual relays from being energised for too little time or too much time.
gOption to set-up further relays.
6. Return to the main menu by holding the ESC key for a few seconds, releasing it when the main menu appears. Next, go
on-line by selecting the “Go on-line” menu option and then pressing the ENTER key once. Finally, press the ESC key
repeatedly until the primary display appears. The level measurement will be live on the primary display.
2. Navigate the menu system to get to the
“Duty Wizard” screen. Keypad hints are
alongside the screens.
3. Start the “Duty” Wizard by pressing the yellow (ENTER) key once.

January 2006 (IP2040/QS)7
Application Example: Level Measurement using Duty Wizard

(IP2040/QS) January 20068
Application/Duty: Wet Well (with Pump Control)
1. With power on and the MSP900SH transmitter giving a 4-20mA signal to the MCU901 unit (see previous pages), you can
now programme the MS901 for an application. This application example is for a Wet Well with pump control.
4. Work through the “Duty” Wizard prompts until completion; this occurs when the menu system re-appears. Keypad
hints, for the illustrated Wizard sequence on the next page, are provided alongside the prompts. If applicable, adapt
the example to suit your application.
5. Circled numbers in the illustrated Wizard sequence relate to these notes:
cSelect “Wet Well” from the multiple-choice list.
dProgramme the 4-20mA output span with a level range (e.g. 0 to 4.7 metres)
eSet-up of On and Off points for Relay 1 (Pump 1) and Relay 2 (Pump 2).
fOptions for switching lead pump according to specified criteria (e.g. number of times used).
gOption to set-up further relays.
6. Return to the main menu by holding the ESC key for a few seconds, releasing it when the main menu appears. Next, go
on-line by selecting the “Go on-line” menu option and then pressing the ENTER key once. Finally, press the ESC key
repeatedly until the primary display appears. The level measurement will be live on the primary display.
2. Navigate the menu system to get to the “Duty Wizard”
screen. Key-press hints are alongside the screens.
3. Start the “Duty” Wizard by pressing the yellow (ENTER) key once.
Requirement
•Live measurement in units of metres.
•Emptying application with 2 pumps
•RL1 On at 2.0m at and Off at 0.5m
•RL2 On at 3.8m and Off at 3.3m
•Additional relay functions: None
Input Data
•Tank Shape: Square
•Bottom Reference: 5 metres
The MSP900SH transmitter is supplying the
live level measurements in units of metres.

January 2006 (IP2040/QS)9
App
lication Exam
p
le: Wet Well usin
g
Dut
y
Wizard

(IP2040/QS) January 200610
Application/Duty: Contents Measurement
1. With power on and the MSP900SH transmitter giving a 4-20mA signal to the MCU901 unit (see previous pages), you can
now programme the MCU901 for an application. This application example is for contents measurement.
Requirement
Live contents measurement in units of litres.
Low level alarm at 2000 litres.
Input Data
Tank Shape: horizontal cylinder with flat ends.
Tank Diameter: 2.5 metres.
Tank Length: 5 metres.
The MSP900SH transmitter is supplying live level measurements in units of
metres.
4. Work through the “Duty” Wizard prompts until completion; this occurs when the menu system re-appears. Keypad
hints, for the illustrated Wizard sequence on the next page, are provided alongside the prompts. If applicable, adapt
the example to suit your application.
5. Circled numbers in the illustrated Wizard sequence relate to these notes:
cSelect “Contents” from the multiple-choice list.
dThe required tank shape is a pre-programmed shape from the MCU901 library.
eMaximum contents as calculated by MCU901 unit. It can be edited here if required.
fProgramme the 4-20mA output span with a content range (e.g. 0 to 24,543.5 litres)
gSet-up a low level alarm – the relay RL1 is energised whenever the measured level falls below a pre-set level and
de-energises on rising above another pre-set level, as defined at these prompts.
hOptional overrides to prevent individual relays from being energised for too little time or too much time.
iOption to set-up further relays.
6. Return to the main menu by holding the ESC key for a few seconds, releasing it when the main menu appears. Next, go
on-line by selecting the “Go on-line” menu option and then pressing the ENTER key once. Finally, press the ESC key
repeatedly until the primary display appears. The content measurement will be live on the primary display.
2. Navigate the menu system to get to the “Duty Wizard”
screen. Key-press hints are alongside the screens.
3. Start the “Duty” Wizard by pressing the yellow (ENTER) key once.

January 2006 (IP2040/QS)11
Application Example:
Contents measurement
using the Duty Wizard

(IP2040/QS) January 200612
Application/Duty: Flow Measurement
1. With power on and the MSP900SH transmitter giving a 4-20mA signal to the MCU901 unit (see previous pages), you can
now programme the MCU901 for an application. This application example is for flow measurements.
Requirement
Live flow measurements in units of cubic metres per second.
Totalised flow in cubic metres per second.
Input Data
Channel Shape: Flume
Maximum depth: 1 metre
Maximum rate: 1 cubic metre per second
The MSP900SH transmitter is supplying live level measurements in units of
metres.
Output Data
The MCU901 will be calculating the flow rate.
4. Work through the “Duty” Wizard prompts until completion; this occurs when the menu system re-appears. Keypad
hints, for the illustrated Wizard sequence on the next page, are provided alongside the prompts. If applicable, adapt
the example to suit your application.
5. Circled numbers in the illustrated Wizard sequence relate to these notes:
cSelect “Flow” from the multiple-choice list.
dEnter the maximum rate of flow.
eEnter the present height of maximum flow in the Flume.
fOption of registering flow as 0 m3/s on the MCU901 while the measured flow rate is below a programmed cut off.
gProgramme the 4-20mA output span with a flow rate range (e.g. 0 m3/s to 1 m3/s)
hOption to set-up a relay to output (100ms) pulses representing the totalised flow.
6. Return to the main menu by holding the ESC key for a few seconds, releasing it when the main menu appears. Next, go
on-line by selecting the “Go on-line” menu option and then pressing the ENTER key once. Finally, press the ESC key
repeatedly until the primary display appears. The flow measurement will be live on the primary display.
2. Navigate the menu system to get to the “Duty Wizard”
screen. Key-press hints are alongside the screens.
3. Start the “Duty” Wizard by pressing the yellow (ENTER) key once.

January 2006 (IP2040/QS)13
Application Example: Flow Measurements using Duty Wizard

(IP2040/QS) January 200614
Other Features
Restoring factory defaults (Erases all user entered data)
To re-set the MCU901 unit back to the factory defaults, navigate to the “Load Defaults” screen and press the ENTER key twice.
Navigating to the LOAD DEFAULTS Screen
PIN Security
Personal Identification Number (PIN) security prevents unauthorised people from programming the MCU901 control unit.
Typically, this is set-up when all the other programming has been completed. As with Bankcards, there is one PIN number.
The factory default is for PIN security to be inactive. To activate, navigate the menu system to the PIN screen and edit a 4-digit
personal identification number (PIN) that you want. The PIN is edited with the arrow keys and confirmed with the ENTER key;
the 4-digit PIN will then be replaced by “- - - -“ to indicate that PIN security is active. (By default, PIN is a 0 if inactive).
Once PIN security is activated, a prompt for the PIN will appear when needed for an activity, such as starting a Wizard. If
correctly entered, no further PIN requests are made unless the “Cancel Password” option is selected from the MAIN MENU
screen. This menu option appears only after correctly entering the PIN; the option disappears when selected, therefore making
the MCU901 secure and prompt for the PIN when needed.
Navigating to the PIN set-up screen
Modes of operation
There are two operating modes for the MCU901. They are on-line and off-line.
An open padlock icon indicates the MCU901 is presently in the off-line mode. In this mode, the unit can be
programmed providing that you know the security PIN (if set-up). Additionally, the 4-20mA output and all relays
are frozen.
A closed padlock icon indicates that the MCU901 is presently in the on-line mode. In this mode, most of the unit
cannot be programmed. However, you will be prompted to go off-line if you attempt to programme whilst in this
mode and providing that you know the security PIN (if set-up). Additionally, the 4-20mA output and all relays are
not frozen.

January 2006 (IP2040/QS)15
Relays
Relay outputs 1 to 4 are normally On Point/Off Point relays which may be used to start/stop pumps or open/close valves at
different levels. They normally energise at one level and de-energise at a different level.
Alternatively, they may be programmed as out-of-limits alarms such that they are energised between defined points and will de-
energise outside the defined limits. They may also be programmed to perform a variety of auto-sequences and auxiliary
functions, such as pump-down operations, pump rotations to equalise wear, and desludge/cleaning.
Relay output 5 is normally a fail safe fault relay but may be re-allocated to another duty.
Relays can be set-up easily using the Relay Wizard, accessible by navigating to the RELAYS menu screen.
Navigating to the RELAY Screen
Relay (RL) Status
The relay status icons on the primary display have the following meanings:
= energised Relay is presently energised.
0 = de-energised Relay is presently de-energised.
A = Alarm All active alarms can be viewed by parameter D831.
S = Sampler Relay is allocated to sampling duty.
T = Totalising Relay is allocated to totalising duty.
Comfort (System) Settings
The SETTINGS menu allows adjusting of the time and date, switching off the keyboard sound and changing language.
Navigating to the SETTINGS Menu

MSP-USTD1/MSP-USTD2 Quick-start booklet
IP2040/QS
January 2006
Mobrey Measurement Mobrey Inc
158 Edinburgh Avenue, 19408 Park Row, Suite 320,
Slough, Berks, UK, SL1 4UE Houston, TX 77084 USA
T [phone] T [phone]
F [phone] F [phone]
[email protected] [email protected]
www.mobrey.com www.mobrey.com
Mobrey SA-NV Belgium tel: [phone]
Mobrey Ltd China tel: [phone]
Mobrey GmbH Deutschland tel: [phone]
Mobrey SA France tel: [phone]
Mobrey sp z o o Polska tel: [phone]
Mobrey AB Sverige tel: [phone]
© 2006, Mobrey. The right is reserved to amend details given in this publication without notice.
ABCDEF
Trademarks
Mobrey, Mobrey Measurement, and the Mobrey logotype are
registered trademarks of Mobrey Limited.
The Emerson logo is a trade mark and service mark of
Emerson Electric Co. “Brand mark listing” are marks of one of
the Emerson Process Management family of companies.
A
ll other marks are property of their respective owners.
