Emerson MS7609 User manual

OWNER'SMANUAL
MS7609
MICRO AUDIO SYSTEM
withCD PLAYER
Visitourweb siteatwww.emersonradio.com
MS7609_ib040303.p65 4/4/2003, 12:1324

1
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN
BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANTSAFETYINSTRUCTIONS
1.) Read these instructions.
2.) Keep these instructions.
3.) Heed all warnings.
4.) Follow all instructions.
5.) Do not use this apparatus near water.
6.) Clean only with dry cloth.
7.) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8.) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plughastwobladeswithonewiderthantheother.Agroundingtypeplughastwoblades
and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10.) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11.) Only use attachments / accessories specified by the manufacturer.
12.) Unplug this apparatus during lightning storms or when unused for long periods of time.
13.) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
14.) Do not overload wall outlet. Use only power source as indicated.
15.) Use replacement parts as specified by the manufacturer.
16.) The product may be mounted to a wall only if recommended by the manufacturer.
17.) Upon completion of any service or repairs to this product, ask the service technician
to perform safety checks.
CAUTION
!
CAUTION
RISK OFELECTRICSHOCK
DONOTOPEN
The lightning flashwitharrow-
head symbol,withinan equi-
lateraltriangleisintented to
alertthe usertothe presence
ofuninsulated‘dangerousvoltage’
withinthe product’s enclosure
thatmaybe ofsufficient
magnitude toconstitutearisk
ofelectricshock topersons.
The exclamation pointwithin
an equilateraltriangleisin-
tended toalertthe userto
the presenceofimportant
operating and maintenance
(servicing)instructionsin
the literatureaccompany-
ing the appliance.
WARNING:TOREDUCETHE
RISK OFELECTRICSHOCK
DONOTREMOVE COVER
(ORBACK),NOUSER
SERVICEABLEPARTSINSIDE
REFERSERVICINGTO
QUALIFIEDSERVICE
PERSONNEL.
MS7609_ib040303.p65 4/4/2003, 12:131

2
BEFOREWEBEGIN
Thankyou forpurchasing thisEmerson audioproduct.The Emerson brand
isyourassuranceofquality,performanceand value.
Ourengineershaveincluded manyusefuland convenientfeaturesinthis
product. Pleasebe suretoread thisOwner’s Manualcompletelytomake
sureyou aregetting the maximumbenefitfromeachfeature.
Thisproductwasmanufactured using the highestqualitycomponentsand
standardsofworkmanship.It wastested byEmerson inspectorsand found
tobe inperfectworking orderbeforeitleft ourfactory.However,thereis
alwaysthechancethatsomeproblemmayoccurbecauseofroughhandling
during shipmenttothe retail storeortothe finalconsumer.
If,afterreading thisManual,youexperienceanyproblemswiththeoperation
ofthisproduct, pleaserefertothe instructionsforobtaining serviceatthe
end ofthisManual.Emerson and Emerson retailersarecommitted toyour
satisfaction.
Onceagain,thanks forpurchasing thisEmerson audioproduct.
Forfuturereference,recordthe serialnumberinthe spaceprovided.
Model No: MS7609
Serial Number :
18.) Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operation instruction.
19.) Object and Liquid Entry - Never push object of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the product.
20.) Servicing - Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY
WITH SAME TYPE 2.5A, 250V FUSE.
MS7609_ib040303.p65 4/4/2003, 12:132

3
FCC INFORMATION
Thisequipmenthasbeen tested and found tocomplywiththe limitsforaClass B
digitaldevice,pursuanttoPart15 ofthe FCC Rules.Theselimitsaredesigned to
provide reasonableprotection againstharmfulinterferenceinaresidential
installation.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergy
and,ifnotinstalledand usedinaccordancewiththeinstructions,maycauseharmful
interferencetoradiocommunications.However,thereisno guarantee that
interferencewill notoccurinaparticularinstallation.If thisequipmentdoescause
harmfulinterferencetoradioortelevision reception,whichcan be determined by
turning the equipmentoff and on,the userisencouraged totrytocorrectthe
interferencebyone ormoreofthe following measures:
•Reorientorrelocatethe receiving antenna.
•Increasethe separation between the equipmentand receiver.
•Connectthe equipmentintoan outleton acircuitdifferentfromthattowhich
the receiverisconnected.
•Consultthe dealeroran experienced radio/TVtechnician forhelp.
ThisdevicecomplieswithPart15 ofthe FCC Rules.Operation issubjecttothe
following twoconditions:
(1)Thisdevicemaynotcauseharmfulinterference,and
(2)Thisdevicemustacceptanyinterferencereceived,including interference
thatmaycauseundesired operation.
•Operatecontrolsand switchesas
described inthe manual.
•Beforeturning on the power,make
certainthatthe connecting cordsand
powercordareproperlyinstalled.
•StoreyourCDsinacoolareatoavoid
damage fromheat.
•When moving the set, be suretofirst
disconnectthe powercordand
removecordsconnected toother
equipment.
•Avoidinstalling thisunitinplaces
exposed todirectsunlightorcloseto
heatradiating appliancessuchas
electricheaters,ontopofotherstereo
equipmentthatradiatesheat, places
lacking ventilation ordustyareas,
placessubjecttoconstantvibration
and/orhumidormoistareas.
•Donotattempttoclean thisunitwith
chemicalsolventsasthismight
damage the finish.Useaclean dry
cloth.
IMPORTANTNOTES
CLASS 1LASERPRODUCT
CLASS 1LASERPRODUCT
APPAREILÁLASERDECLASSE 1
PRODUCTOLASERDECLASE 1
CAUTION
INVISIBLELASERRADIATION
WHENOPENAND INTERLOCKS
DEFEATED.
AVOIDEXPOSURETOBEAM
ThisproductcontainsalowpowerLaserDevice.
MS7609_ib040303.p65 4/4/2003, 12:133

4
UNPACKINGAND SET-UP
•Carefullyremovethe unitfromthe carton and removeall packing material
fromthe unit.
•Removeanylabelsorstickerswhichmaybe on the frontortop ofthe set, but
do notremoveanylabelsfromthe back orbottom.
•Wesuggestthatyou retainthe originalcarton and packing materialsincaseit
everbecomesnecessarytoreturnyourunitforservice.Thisisthe onlysure
waytoprotectthe unitfromdamage intransit.
•If you do disposeofthe carton and packing materials,pleasedo soproperly.
Emerson caresaboutourenvironment.
•Press the CD DOOROPENbutton and removethe dummyCD transit
protection cardfromthe CD mechanism.Discardit.
PREPARATIONFORUSE
SPEAKERCONNECTION
Connecteachspeakertothe corresponding speakerterminalson the back panel
ofthe mainunit. Makesurethatthe left speakerisconnected tothe left (L)pairof
speakerterminalsand the rightspeakertothe right(R)pairofspeakerterminals.
Alsomakesurethatthe speakerwiresarecorrectlyconnected:thatthe red wires
areconnected tothe red terminalsand the black wirestothe black terminals.
Depress the plasticlevertoopen the terminal,insertthe bareend ofthe speaker
wireintothe opening and release.
RL
BLACKRED
RED
Black Wire
Red Wire
MS7609_ib040303.p65 4/4/2003, 12:134

5
PROTECT YOUR FURNITURE !!
Thismodelisequipped withnon-skidrubber'feet'topreventthe productfrom
moving when you operatethe controls.These'feet'aremade fromnon-migrating
rubbermaterialspeciallyformulated toavoidleaving anymarks orstainson your
furniture.Howevercertaintypesofoil based furniturepolishes,wood preservatives,
orcleaning sprays maycausethe rubber'feet'tosoften,and leavemarks ora
rubberresidue on the furniture.Topreventanydamage toyourfurniturewestrongly
recommend thatyou purchasesmall self-adhesivefeltpads,availableathardware
storesand homeimprovementcenterseverywhere,and applythesepadstothe
bottomofthe rubber'feet'beforeyou placethe producton fine wooden furniture.
RIGHTSPEAKERLEFT SPEAKER
BLACK WIRE
RED WIRE RED WIRE
BLACK WIRE
MS7609_ib040303.p65 4/4/2003, 12:135

6
AC OPERATION
1.)Unwind the ACPowerCordcompletely.
2.)Insertthe plug intoanyconvenient120V60HzACoutlet.
POWERSOURCE
Thissystemisdesigned tooperateon 120V60HzAChousecurrent.Connecting
thissystemtoanyotherpowersupplycouldresultindamage tothe unitwhichis
notcovered byyourwarranty.You will notethatthissystemisequipped witha
polarized ACpowerplug having one blade widerthan the other.Thisisasafety
feature.If thisplug doesnotfitintoyourexistingACoutlet, do nottrytodefeatthis
safetyfeaturebyfiling the wide blade tomakeitfitintoyouroutlet. If thisplug will
notfitintoyouroutlet, you probablyhavean out-dated non-polarized ACoutlet.
You shouldhaveyouroutletchanged byaqualified licensed electrician.
AC Plug
AC Outlet
MS7609_ib040303.p65 4/4/2003, 12:136

7
LOCATIONOFCONTROLSAND INDICATORS
1.)RemoteControlSENSOR.
2.)ReverseSKIP/SEARCH Button.
3.)PROGRAMButton.
4.)REPEATButton.
5.)POWEROn/Off Button.
7.)PHONES Jack.
6.)STANDBY LEDIndicator.
8.)CD Compartment.
9.)TUNINGControl.
10.)AM/FM/FMST.Selector.
11.)CD/RADIOSelector.
12.)BASS BOOSTON/OFF Selector.
13.)CD DOOROPENButton.
14.)PLAY/PAUSE Button.
15.)VOLUMEUPButton.
16.)VOLUMEDOWNButton.
17.)STOPButton.
18.)MultiFunction LCD Display.
19.)ForwardSKIP/SEARCH Button.
20.)FMWireAntenna.
21.)SpeakerTerminals.
22.)ACPowerCord.
BACK PANEL
TOPPANEL
18
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
19
20 22
21
MS7609_ib040303.p65 4/4/2003, 12:137

8
1.)POWERButton.
2.)PLAY/PAUSE Button.
3.)RANDOMButton.
4.)REPEATButton.
5.)ReverseSKIP/SEARCH Button.
6.)VOLUMEButton.
7.)BatteryCompartment(Back cabinet)
8.)VOLUMEButton.
9.)ForwardSKIP/SEARCH Button.
10.)MUTEButton.
11.)STOPButton.
REMOTECONTROL
BATTERYINSTALLATION
Insert2pcs‘AA’size(Alkaline)batteries(notincluded)intothebatterycompartment
ofthe remotecontroller.Besuretoobservethe polaritymarkingswhichare
engraved inside the batterycompartment, then closethe cover.
BATTERYREPLACEMENT
When the batteriesbecometoo weak,the operating distanceofthe remote
controllerisgreatlyreduced and you will need toreplacethe batteries.
1
2
3
4
5
6
11
10
9
7
8
MS7609_ib040303.p65 4/4/2003, 12:138

9
NOTES:
•Tomaintainthe accuracy and long lifeofthe transmitter,do notpress twoor
morebuttonssimultaneously.
•If the remotecontrolisnottobe used foralong time,removethe batteriesto
preventpossibledamage through leaking batteries.
•Donotmixdifferenttypesofbatteries,oroldbatterieswithnewones.
USINGTHEREMOTECONTROLLERCORRECTLY
•Pointthe remotecontrolleratthe RemoteSensor.
•The functionsofthe buttonson the remotecontrolarethe sameasthe
corresponding controlson the mainunit.
•When thereisastrong ambientlightsource,the performanceofthe infrared
RemoteSensormaybe degraded,causing unreliableoperation.
•The maximumeffectivedistanceforremotecontroloperation isabout15 feet.
BATTERYPRECAUTIONS
Followtheseprecautionswhen using batteriesinthisdevice:
1.Useonlythe sizeand type ofbatteriesspecified.
2.Besuretofollowthe correctpolaritywhen installing the batteriesasindicated inthe battery
compartment. Reversed batteriesmaycausedamage tothe device.
3.Donotmixdifferenttypesofbatteriestogether(e.g.Alkalineand Carbon-Zinc)oroldbatteries
withfreshones.
4. If the deviceisnottobe used foralong period oftime,removethe batteriestoprevent
damage orinjuryfrompossiblebatteryleakage.
5.Donottrytorecharge batteriesnotintendedtobe recharged;theycan overheatand rupture.
(Followbatterymanufacturer’s directions.)
MS7609_ib040303.p65 4/4/2003, 12:139
