Instruction Manual
D104738X012
4400 Transmitter
October 2023
www.Fisher.com
Fisher™FIELDVUE™4400 Digital Position
Transmitter
This manual applies to
Device Type 0x1314
Device Revision 1
Firmware Revision 3
DD Revision 1
Contents
Introduction 2.................................
Scope of Manual 2.............................
Description 2.................................
Specifications 2...............................
Educational Services 2.........................
Security 5.....................................
Installation 6..................................
General Mounting Guidelines 6..................
Mounting on Sliding-Stem Linear Actuators 8......
Bracket Mounted 8........................
Quarter-Turn Rotary Actuators 11................
Electrical Connections 12.......................
Position Transmitter or Discrete Switch 12.....
Calibrate and Configure the Position Transmitter 15..
Calibrate 16..................................
Configuration 17..............................
Alert Setup 25.............................
Maintenance 26................................
Replacing the Magnet Feedback Assembly 26......
Replacing the Instrument 27....................
Product Disposal Guidelines 27..................
Parts Ordering 27...............................
Parts Kits 28..................................
Figure 1. FIELDVUE 4400 Digital Position Transmitter
X1858-1

Scan or click code for
Installation Documents
& Field Support
Instruction Manual
D104738X012
4400 Transmitter
October 2023
2
Introduction
Scope of Manual
This instruction manual includes specifications, installation, basic setup
and configuration, and maintenance and troubleshooting information for
the Fisher FIELDVUE 4400 position transmitter.
This manual describes using the local interface or an Emerson handheld
communicator, such as the AMS Trex Device Communicator, to setup and
calibrate the instrument.
Do not install, operate, or maintain a FIELDVUE 4400 position transmitter without being fully trained
and qualified in valve, actuator, and accessory installation, operation, and maintenance. To avoid
personal injury or property damage, it is important to carefully read, understand, and follow all of the
contents of this manual, including all safety cautions and warnings. If you have any questions about
these instructions, contact your Emerson sales office before proceeding.
Description
The FIELDVUE 4400 transmitter senses the position of rotary or sliding-stem valves, vents, dampers, or other devices.
It provides a precise 4-20 mA feedback signal to indicate equipment position with digital capability via HART®
communication for process variable notifications and alerts/alarms. Position sensing uses a linkageless feedback
design that eliminates direct contact with the measured device (e.g. valve, regulator, level, louver, or other devices).
Specifications
Specifications for the 4400 are shown in table 1.
WARNING
This product is intended for a specific current range, temperature range and other application specifications. Applying
different current, temperature and other service conditions may result in personal injury, property damage or malfunction
of the product.
Educational Services
Emerson Educational Services
Phone: [phone]
E-mail: [email protected]
emerson.com/mytraining

Instruction Manual
D104738X012
4400 Transmitter
October 2023
3
Table 1. Specifications
Input Signal Source
Hall Effect Sensor and magnet array
Transmitter Output Signal
Analog: 4 to 20 mA DC
High saturation: 20.5 mA
Low saturation: 3.8 mA
High alarm(1):> 21.0 mA
Low Alarm(1):< 3.6 mA
Digital - PENDING:
HART 1200 Baud Frequency Shift Keyed (FSK)
HART Version 7
HART impedance requirements must be met to
enable communication. Total shunt impedance
across the master device connections (excluding the
master and transmitter impedance) must be between
230 and 600 ohms.
HART receive impedance:
Rx: 28.06k ohms
Cx: 5.84 nF
Output Current Limit: 30 mA DC maximum
Integral Limit Switch - PENDING
Two isolated solid state limit switches, configurable
throughout the calibrated travel range or actuated
from a device alert
Off State: 0 mA (nominal)
On State: up to 1 A
Supply Voltage: 24 - 30 VDC
Travel Limit Trip Points
Two
Recommended Power Supply
24 to 30 volts DC; 25 mA
Instrument has reverse polarity protection.
A minimum compliance voltage of 17.75 VDC (due to
HART impedance requirement) is required to
guarantee HART communication
Reference Accuracy
$1% of output span. Includes combined effects of
hysteresis, linearity, and deadband
Limit Switch: 2% of travel span
Repeatability
$0.25% of span
Electromagnetic Compatibility
Meets EN61326-1:2013
Performance is shown in table 2 and
EN61326-3-2:2008
Performance is shown in table 3
General Electrical Safety - Environmental
Conditions
Use: Indoor and Outdoor
Altitude: up to 2000 m
Temperature: -40_C to +80_C
Relative Humidity: 9.2 - 90%
Supply Voltage Fluctuations: N/A, not connected to
Mains
Transient Overvoltage: Category I
Pollution Degree: 4
Wet Locations: Yes
Operating Ambient Temperature Limits
-40 to 80_C (-40 to 176_F)
Mounting
The instrument can mount on the actuator of
sliding-stem or rotary valves or it can be used for
other applications. Refer to Bulletin 62.3:4400(S1)
D104740X012 for 4400 position monitor and magnet
array dimensions.
Actuator Compatibility
Stem Travel (Sliding‐Stem Linear)
Linear actuators with rated travel between 6.35 mm
(0.25 inch) and 606 mm (23.375 inches)
Shaft Rotation (Quarter‐Turn Rotary)
Rotary actuators with rated travel between 45
degrees and 180 degrees(2)
Hazardous Area Approvals - PENDING
cCSAus—Intrinsically Safe, Explosion‐proof,
Division 2, Dust Ignition‐proof
ATEX—Intrinsically Safe, Flameproof, Type n,
Dust by intrinsic safety
IECEx—Intrinsically Safe, Flameproof, Type n,
Dust by intrinsic safety or by enclosure
-continued-

Instruction Manual
D104738X012
4400 Transmitter
October 2023
4
Table 1. Specifications (continued)
Electrical Housing - PENDING
cCSAus—Type 4X, IP66
ATEX—IP66
IECEx—IP66
Safety Instrumented System Classification -
PENDING
SIL2 capable
Approximate Weight
Transmitter without mounting bracket: 1.8 kg
(4 pounds)
Note: Specialized instrument terms are defined in ANSI/ISA Standard 51.1 - Process Instrument Terminology.
1. Only one High/Low alarm available in a given configuration. Alarms are NAMUR NE43 compliant.
2. Rotary actuators with 180 degree rated travel require a special mounting kit; contact your Emerson sales office for kit availability.
Table 2. EMC Summary Results—Immunity per EN61326-1
Port Phenomenon Basic Standard Test Level Test Results(1)(2)
Enclosure
Electrostatic
discharge (ESD) IEC 61000-4-2 4 kV contact 8 kV air A
Radiated EM field IEC 61000-4-3 80 to 1000 MHz @ 10V/m with 1 kHz AM at 80%
1400 to 6000 MHz @ 3V/m with 1 kHz AM at 80% A
Radiated power
frequency magnetic
field
IEC 61000-4-8 30 A/m at 50 and 60 Hz A
I/O signal/control
Burst IEC 61000-4-4 1 kV A
Surge IEC 61000-4-5 1kV (line to ground only, each) B
Conducted RF IEC 61000-4-6 150 kHz to 80 MHz at 3 Vrms A
Protective earth
Burst IEC 61000-4-4 2 kV A
Surge IEC 61000-4-5 2 kV (line to ground only) B
Conducted RF IEC 61000-4-6 150 kHz to 80 MHz at 3 Vrms A
1. A = No degradation during testing. B = Temporary degradation during testing, but is self‐recovering. Specification limit = +/- 1% of span.
2. HART communication was considered as “not relevant to the process” and is used primarily for configuration, calibration, and diagnostic purposes.
Table 3. EMC Summary Results—Immunity per EN61326-3-2
Port Phenomenon Basic Standard Test Level Test Results(1)(2)
Enclosure
Electrostatic
discharge (ESD) IEC 61000-4-2 6 kV contact 8 kV air A
Radiated EM field IEC 61000-4-3
80 to 1000 MHz @ 10V/m with 1 kHz AM at 80%
1400 to 2000 MHz @ 10V/m with 1 kHz AM at 80%
2000 to 2700 MHz @ 3V/m with 1 kHz AM at 80%
A
Radiated power
frequency magnetic
field
IEC 61000-4-8 100 A/m at 50 and 60 Hz A
I/O signal/control
Burst IEC 61000-4-4 1 kV A
Surge IEC 61000-4-5 1 kV (line to ground only, each) FS
Conducted RF IEC 61000-4-6 10 kHz to 80 MHz at 10 Vrms A
Protective earth
Burst IEC 61000-4-4 2 kV A
Surge IEC 61000-4-5 1 kV (line to ground only) A
Conducted RF IEC 61000-4-6 10 kHz to 80 MHz at 10 Vrms A
1. A = No degradation during testing. B = Temporary degradation during testing, but is self‐recovering. FS = Fail Safe. Specification limit = +/- 2% of span.
2. HART communication was considered as “not relevant to the process” and is used primarily for configuration, calibration, and diagnostic purposes.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
5
Security
NOTICE
Physical security is an important part of any security program and is fundamental to protecting your system.
Unauthorized personnel may potentially cause significant damage to and/or misconfiguration of end users equipment. This
could be intentional or unintentional and must be protected against by restricting access to unauthorized personnel in your
facility.
D The 4400 transmitter has several features to help protect against unintentional configuration changes:
d System stores configuration and log data
d 4400 Signed Firmware
d Configuration lock switch
d Cannot be connected directly to a network and cannot access the worldwide internet
D If unsecured, any device in the field is vulnerable to a physical attack; safety and security procedures must include
mitigation by physical security controls.
D The following are unsecured, unencrypted inputs and outputs used by the 4400 transmitter:
d AO – position feedback
d DO – two solid state position limit switches
d HART - used for digital communication
d Zero pushbutton, Span pushbutton, and LED indicator – used for local calibration
D The configuration lock switch, located under the terminal cover, will prohibit configuration and calibration changes
over all interfaces. Refer to the Calibrate and Configure the Position Transmitter section (page 15) for additional
information on the lock switch.
D The 4400 has optional applications for configuration and data viewing. When such applications are used, they must
run on devices that are configured according to local security policies.
D The device has been developed using secure coding principals and procedures, including threat modeling and
security specific testing. It has several interfaces for configuration, with each of them having an option to disable
write options.
D There are multiple ways to configure the device, including:
d The Zero pushbutton and the Span pushbutton, located under the cover.
d The FDI (Field Device Integration) or DD (Device Description) used with asset manager software such as AMS
Device Manager or a handheld communicator such as Emerson Trex.
D Product Operation Best Practices:
d Ensure that operation personnel are trained both on local security policies and the secure operation of the 4400.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
6
d It is recommended that you set the configuration lock switch in the enabled position after configuration is
complete.
d Operate the device within a controlled and secured physical environment.
d Operate the 4400 and the FDI/DD host within a controlled and secured network environment.
d Configure the FDI/DD host to allow users to have least privilege access to the 4400, providing access to only what
is absolutely required to perform their job function.
d Apply security patches and updates as they are released.
D Report security incidents and potential product vulnerabilities at:
https://go.emersonautomation.com/reportvulnerability_en
D Password Management Best Practices:
d Manage FDI/DD host user passwords per local security policy.
D Product Disposal
d see Product Disposal Guidelines section (page 27) for recommendations on securely disposing an unneeded
device.
Installation
WARNING
Avoid personal injury or property damage from sudden release of process pressure or bursting of parts. Before performing
any installation procedures:
D Always wear protective clothing, gloves, and eyewear.
D Do not remove the actuator from the valve while the valve is still pressurized.
D Disconnect any operating lines providing air pressure, electric power, or a control signal to the actuator. Be sure the
actuator cannot suddenly open or close the valve.
D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure
from both sides of the valve.
D Use lock‐out procedures to be sure that the above measures stay in effect while you work on the equipment.
D Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
D Vent the pneumatic actuator loading pressure and relieve any actuator spring precompression so the actuator is not
applying force to the valve stem; this will allow for the safe removal of the stem connector.
General Mounting Guidelines
If ordered as part of a control valve assembly, the factory will mount the position transmitter on the actuator and
calibrate the instrument. If you purchased the position transmitter separately, you will need a mounting a kit. The
following procedures are general guidelines. See the instructions that come with the mounting kit for detailed
information on mounting the position transmitter to a specific actuator model. Figure 2 shows the available mounting
variations.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
7
Figure 2. Mounting Variations
ROTARY NAMUR, M6
LINEAR, M8
NOTICE
The magnet assembly material has been specifically chosen to provide a long-term stable magnetic field. However, as with
any magnet, care must be taken care when handling the magnet assembly. Another high powered magnet placed in close
proximity (less than 25 mm) can cause permanent damage. Potential sources of damaging equipment include, but are not
limited to: transformers, DC motors, stacking magnet assemblies.
Use of High Power Magnets with the 4400
D Magnetic Tip Screw Driver - Magnetic tip screw drivers can be used to work on the 4400 position transmitter. However,
they should not be brought in close proximity to the magnet assembly (located at the back of the instrument) during
process operations.
D Calibrator Strap Magnets - These are high power magnets used to hold 4-20 mA calibrators.
Normally, these calibrators would not be used while an instrument is controlling the process.
High power magnets should be kept at least 15 cm (6 inches) from the 4400.
Notes
As a general rule, do not use less than 50% of the magnet assembly travel range for full travel measurement. Performance will
decrease as the assembly is increasingly subranged.
The linear magnet assemblies have a valid travel range indicated by arrows molded into the piece. This means that the hall sensor
(the center point of the channel on the back of the 4400 housing) has to remain within this range throughout the entire valve
travel. The linear magnet assemblies are symmetrical. Either end may be up.
The magnet assembly may be referred to as a magnetic array in user interface tools.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
8
Figure 3. Mounting Parts for Sliding-Stem Actuator with up to 210 mm (8.25 inches) Travel
ACTUATOR
POSITION TRANSMITTER
MOUNTING
BRACKET
FEEDBACK BRACKET
AND MAGNET ASSEMBLY
Mounting on Sliding-Stem Linear Actuators
Bracket Mounted
Up to 210 mm (8.25 inches) Travel (figure 3)
Before mounting, verify that linear travel is greater than one-half and not more than the recommended travel of the
feedback kit.
1. Isolate the control valve from the process line pressure and release pressure from both sides of the valve body. Shut
off all pressure lines to the pneumatic actuator, releasing all pressure from the actuator. Use lock‐out procedures to
be sure that the above measures stay in effect while working on the equipment.
2. Attach to the mounting bracket to the actuator.
3. Loosely attach the feedback pieces and magnet assembly to the valve stem connector. Do not tighten the fasteners
until the magnet assembly is centered and aligned in steps 4 and 5.
Note
Do not install a magnet assembly that is shorter than the physical travel of the actuator. Loss of feedback will result from the
magnet assembly moving outside the range of the index mark in the feedback slot of the position transmitter housing.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
9
Figure 4. Magnet Assembly Alignment, Fail Close
W9718
ALIGNMENT
TEMPLATE
INDEX
MARK
RETAINING
SLOT
Figure 5. Magnet Assembly Alignment, Fail Open
ALIGNMENT
TEMPLATE
W9719
INDEX
MARK
RETAINING
SLOT
4. Center the magnet assembly inside the retaining slot 5.7 mm (0.22 inch) away from the bottom base of the
housing as measured from the center of the assembly bolt holes to the base of the housing (see figure 4).
5. Align the magnet assembly as shown in figure 5.
6. Tighten the fasteners.
Note
Use a flat end hex key to tighten the magnet assembly fasteners to a torque of 2.37 N•m (21 lbf•in) for 4 mm screws, and
5.08 N•m (45 lbf•in) for 5 mm screws. For added security, especially in vibrating services, blue (medium) threadlocker may be
used on the fasteners.
7. Mount the position transmitter to the mounting bracket, using the mounting bolts. Any of the mounting holes may
be used for linear actuators.
8. Once the instrument is mounted, perform the local interface calibration procedure, as described in the Calibrate
and Configure the Position Transmitter section.
9. Verify the magnet assembly position through the entire travel range before putting into service.
Note
Ensure that there is clearance between the magnet assembly and the 4400 housing slot throughout the full range of travel.
Actuators over 210 mm (8.25 inches) Travel (figure 6)
1. Isolate the control valve from the process line pressure and release pressure from both sides of the valve body. Shut
off all pressure lines to the pneumatic actuator, releasing all pressure from the actuator. Use lock‐out procedures to
be sure that the above measures stay in effect while working on the equipment.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
10
Figure 6. Mounting on Sliding‐Stem (Linear) Actuators over 210 mm (8.25 Inches) Travel
LONG STROKE MOUNTING KIT
(4400 NOT SHOWN)
MOUNTING ADAPTOR
W9709
ACTUATOR
VALVE STEM
CONNECTOR
CAM
Figure 7. Roller Arm Variation used for Sliding‐Stem (Linear) Actuators over 210 mm (8.25 Inches) Travel
ROLLER
ARM
E1229
CAM
CAM/ROLLER
POSITION MARK
ACTUATOR IS FULLY EXTENDED
ROLLER ARM
E1543
2. Install the cam to the valve stem connector as described in the instructions included with the mounting kit.
3. Install the mounting adaptor to the actuator.
4. Attach the position transmitter and mounting kit assembly to the mounting adaptor. The roller on the position
transmitter feedback arm will contact the actuator cam as it is being attached.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
11
Quarter-Turn Rotary Actuators
The 4400 can be mounted to any quarter-turn rotary shaft actuator, as well as those that comply with the NAMUR
guidelines. A mounting bracket and associated hardware are required. Refer to figure 8.
Before mounting, verify the rotary motion is 45 to 90 degrees of rotation.
1. Isolate the control valve from the process line pressure and release pressure from both sides of the valve body. Shut
off all pressure lines to the pneumatic actuator, releasing all pressure from the actuator. Use lock‐out procedures to
be sure that the above measures stay in effect while working on the equipment.
2. Attach the magnet assembly to the actuator shaft. At mid‐travel, the flats on the magnet assembly should be
approximately parallel to the channel on the back of the 4400 housing, as shown in figure 8.
Note
When the actuator is at its travel limit, the feedback array must always be at a 45 degree angle, regardless of the orientation of the
position transmitter.
NOTES:
1 IF THE ACTUATOR IS STROKED ALL THE WAY TO THE RIGHT OR CLOCKWISE, ATTACH THE
MAGNET ASSEMBLY SO IT POINTS TO THE UPPER RIGHT CORNER OF THE INSTRUMENT.
2 IF THE ACTUATOR IS STROKED ALL THE WAY TO THE LEFT OR COUNTERCLOCKWISE, ATTACH
THE MAGNET ASSEMBLY SO IT POINTS TO THE UPPER LEFT CORNER OF THE INSTRUMENT.
Figure 8. Magnet Assembly Orientation
ORIENTATION AT ONE
TRAVEL EXTREME
ORIENTATION AT MID‐TRAVEL
(FLATS PARALLEL TO 4400
HOUSING CHANNEL)
ORIENTATION AT THE
OTHER TRAVEL EXTREME
W8836‐1A
W8836‐1B
MOUNTING
BRACKET
1
2
ISOLATION VALVE
CONTROL VALVE
MOUNTING
BRACKET

Instruction Manual
D104738X012
4400 Transmitter
October 2023
12
3. Install the mounting bracket on the actuator,
4. Attach the position transmitter to the mounting bracket using the four mounting bolts.
5. Check for clearance between the magnet assembly and the positioner feedback slot.
6. Once the instrument is mounted, perform the local interface calibration procedure, as described in the Calibrating
the LUI section.
7. Verify that the magnet assembly remains centered throughout the entire rotating range.
Electrical Connections
Position Transmitter or Discrete Switch
The position transmitter circuit derives its operating power from the control system input channel in the same manner
as a two-wire system.
The discrete switch is a solid state circuit (1 amp maximum) which opens and closes based on a user configurable trip
point. The trip point can be based on valve travel anywhere within the calibrated travel range. In order for the switch
output to function, the position transmitter must be powered. If power is lost, the switch will always go to the open
state. The output circuit, whether operating as a transmitter or switch, is galvanically isolated from the position
control loop circuit such that different ground references between the two circuits are allowed.
Follow the steps below to connect field wiring to the 4400 transmitter.
WARNING
Select wiring and/or cable glands that are rated for the environment of use (such as hazardous area, ingress protection, and
temperature). Failure to use properly rated wiring and/or cable glands can result in personal injury or property damage
from fire or explosion.
Wiring connections must be in accordance with local, regional, and national codes for any given hazardous area approval.
Failure to follow the local, regional, and national codes could result in personal injury or property damage from fire or
explosion.
To avoid personal injury resulting from electrical shock, do not exceed maximum input voltage specified on the product
nameplate. If the input voltage specified differs, do not exceed the lowest specified maximum input voltage.
Personal injury or property damage caused by fire or explosion may occur if electrical connections are attempted in a
potentially explosive atmosphere or in an area that has been classified as hazardous. Confirm that area classification and
atmosphere conditions permit the safe removal of the terminal box cover before proceeding.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
13
NOTICE
Resistors are required when using limit switches. Failure to correctly install a limit switch resistor when required, as
illustrated in figure 10, could result in permanent damage to the 4400 transmitter.
1. Remove the terminal box cover.
2. Route the field wiring into the terminal box through the conduit connection, see figure 9.
Note
Install conduit using local and national electrical codes relevant to the connection.
3. Connect the control system input channel positive wire to the LOOP + terminal (see figure 10 for wiring diagram.)
4. Connect the control system input channel negative wire to the LOOP -terminal (see figure 10).
5. Install a 250 ohm resistor to provide correct impedance for HART communication on the LOOP - terminal.
6. Replace and hand tighten the cover on the terminal box.
Figure 9. Transmitter without Cover
ZERO PUSHBUTTON
SPAN PUSHBUTTON
CONFIGURATION
LOCK SWITCH
LED INDICATOR
SWITCH TERMINAL
4-20 mA WITH
HART CONNECTION
FAULT HIGH OR LOW SWITCH
CONDUIT
CONNECTION CONDUIT
CONNECTION

Instruction Manual
D104738X012
4400 Transmitter
October 2023
14
Figure 10. Wiring Diagram
2
1
POWER
SUPPLY +
-
DEVICE
RECEIVING
4 TO 20 MA
DC SIGNAL
+
-
TRANSMITTER FIELD WIRING
POSITION SWITCH FIELD WIRING
GROUNDING
TERMINAL
SW2
SW1
EARTH
GROUND
DEVICE
RECEIVING LOW
POSITION
SWITCH OUTPUT
(CONTACT
CLOSURE)
DEVICE
RECEIVING HIGH
POSITION
SWITCH OUTPUT
(CONTACT
CLOSURE)
2
LOOP +
LOOP -
NOTES:
1 RECEIVING DEVICE MAY BE ANALOG CURRENT INPUT TO DISTRIBUTED CONTROL SYSTEM, PROGRAMMABLE LOGIC CONTROLLER OR
INDICATING DEVICE. INDICATING DEVICE CAN BE A VOLTMETER ACROSS A 250 OHM RESISTOR OR A CURRENT METER.
2 CONFIGURABLE SWITCH. DEFAULT SETTING: DURING NORMAL OPERATIONS, SW1 AND SW2 ARE ENERGIZED. SW1 AND SW2 ARE USER
CONFIGURABLE AS TO WHETHER THEY ARE NORMALLY OPEN (NO) OR NORMALLY CLOSED (NC). AS SHIPPED FOR BOTH SWITCHES IS DEFINED AS
NORMALLY OPEN, DISABLED. A TRIPPED (OR ALARM) CONDITION IS WITH THE SWITCH(ES) DE‐ENERGIZED, WHICH CONNECTS THE COMMON (C)
TERMINAL TO THE NORMALLY CLOSED (NC) TERMINAL.
*WHEN THE SWITCH IS DEFINED AS NORMALLY OPEN, THE SWITCH WILL ALLOW THE CURRENT TO FLOW THROUGH ONCE IT IS ACTUATED (HIGH
OR LOW LIMIT BEING TRUE). IN ZERO POWER STATE, NO CURRENT WILL FLOW THROUGH THE SWITCH.
*WHEN THE SWITCH IS DEFINED AS NORMALLY CLOSED, THE SWITCH WILL NORMALLY ALLOW CURRENT FLOW. THE SWITCH WILL STOP THE
CURRENT ONCE IT IS ACTUATED (HIGH OR LOW LIMIT BEING TRUE). IN ZERO POWER STATE, NO CURRENT WILL FLOW THROUGH THE SWITCH.
3 RESISTOR REQUIREMENTS: NOMINAL 1K OHM RECOMMENDED.
LED
INDICATO
R
250 OHM
RESISTOR
3
3

Instruction Manual
D104738X012
4400 Transmitter
October 2023
15
Calibrate and Configure the Position Transmitter
1. Install the latest version of the communication software on the user interface tool.
Note
This may include an FDI package or DD. Contact your Emerson sales office to ensure you have the latest software version or for
information on locating the necessary files.
2. If you haven't already done so, perform the Electrical Connections procedure on page 12.
3. Remove the cover to apply electrical power to the position transmitter.
4. Ensure the LED is solid green prior to calibrating the instrument.
Note
If the LED is not green, check the magnet assembly position and adjust as needed. Ensure the instrument is in service. If
performing the calibration procedure after a failed calibration the LED will be blinking red. Cycle instrument power before
attempting another calibration.
5. Proceed to the calibration procedure on the next page.
Note
The TALK terminals are located under the transmitter cover.
Note
In order to perform calibration and/or configuration procedures, the configuration lock switch (shown in figure 9) must be in the
unprotected position ( ) and the instrument must be In Service.
Once calibration and configuration is complete, set the configuration lock switch to the protected position ( ) to prevent
configuration and calibration changes to the instrument.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
16
Calibrate
NOTICE
When accessing the pushbuttons or terminals, proper means of electrostatic discharge protection is required. Failure to
provide appropriate protection can cause the device to malfunction.
The primary function of the local user interface is for calibration. However, an LED on the local user interface can
provide information for checking the status of the device, as well as connected equipment or valve, as follows:
Green Normal, no issues
Green blink Indicates an alert is active
Red solid Failure - replace device, solid red during calibration for 2 seconds only
Red blink Function Check, calibration error, Calibration in Progress, and/or Out of Service.
Note
The cover must be removed for the LED on the local user interface to be visible, as well as to access the zero and span buttons.
Ensure the LED is solid green prior to calibrating the instrument. If the LED is is not solid green, check the magnet assembly
position and adjust as needed to change to solid green. If performing the calibration procedure after a failed calibration the LED
will be blinking red. Cycle instrument power before attempting another calibration.
An Emerson handheld communicator provides access to calibration and setup information, as well as various service
tools.
Note
The valve must move from open to closed, or vice versa, in order for the position transmitter to be calibrated. The Zero and Span
buttons and LED (shown in figure 9) are used during calibration. Press both for 3-8 seconds until the LED flashes red, see
Calibration section below. Attempting to calibrate the device without moving the valve will result in the action being discarded;
the operation of the device will be unchanged. The calibration function of the local user interface can be locked out from the HART
master for security purposes.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
17
Calibrating via the LUI Using an Emerson Handheld Communicator
1. Ensure the instrument is In Service.
2. Verify the actuator or other device is at one end of
travel.
3. Press and hold both the zero button and the span
button for 3 to 8 seconds. The LED will blink red.
4. Move to the zero position and press the zero button.
The red LED will remain solid for 2 seconds then
resume blinking.
5. Move the actuator or other device to the other end of
travel and push the span button. The red LED will
remain solid for 2 seconds then resume blinking.
6. Calibration is complete when the LED turns solid
green.
1. Connect to device using TREX or other handheld
communicator.
2. Open the device and go to Process Variables to take
out of service.
3. Once out of service go to Configure > Guided setup.
4. Start calibration and follow instructions to move to
and select the Zero position. The red LED will remain
solid for 2 seconds then resume blinking.
You will then be instructed to set the Zero again or
press next to set span.
5. Move the actuator or other device to the other end of
travel and select span. The red LED will remain solid
for 2 seconds. The handheld will ask to set again or
continue.
6. Follow the prompts to fill in Calibration details.
7. Calibration is complete when the LED turns solid
green.
8. Return the instrument to in service.
Note
The LED will blink red if calibration is not successful. If unsuccessful, check mounting and verify that at least 50% of the magnet
assembly travel range is used.
In the event of an unsuccessful calibration the device reverts back to the prior calibration.
Note
The limit switches do not require an independent calibration; they are calibrated as part of the Zero and Span calibration.
Configuration
Smart Instruments are considered universal; they can be used with any final control element from any manufacturer.
The default factory configuration of universal instruments may not fit or suit the application, therefore the ability to
change or alter the device configuration is necessary.
This section describes the 4400 transmitters advanced features and parameters that can be accessed with a handheld
communicator. See figure 11, 12, 13, and 14 for the menu structure.
Note
Various menu items/parameters within the menu structure are defined alphabetically on the following pages.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
18
Figure 11. Overview
Overview
Status
Device
Mode
Primary Purpose Variables
PV: Percent of Span
Temperature: Instrument Temperature
Limit Switch Status: Switch State
Loop Current
Short Cuts
Device Information
Calibration
Primary Purpose Variables
Overview
Calibrate Time Delay
The 4400 captures the first end point and stores it indefinitely until the second end point is captured. This is used to
provide baseline time for open/closed diagnostics/alerts.
Close State Dwell Time is the length of time, in seconds, the position remained in the closed state.
Cycle Counter
The capability of the instrument to record the number of times the travel changes direction. The change in direction
must occur after the deadband has been exceeded before it can be counted as a cycle.
Deadband (Limit Switch): The difference between the trip and reset points of a relay, set in percent (%).
Descriptor
Enter a descriptor for the application with up to 16 characters. The descriptor provides a longer user-defined electronic
label to assist with more specific instrument identification than is available with the Tag.
Device includes Important information regarding the connected instrument such as device type, firmware and
hardware revisions, functional options, and the HART ID identifier.

Instruction Manual
D104738X012
4400 Transmitter
October 2023
19
Mapping
Dynamic Variables
Primary Variable
Secondary Variable
Tertiary Variable
Quaternary Variable
HART
Communication Settings
Polling Address
Loop Current Mode
Figure 12. Configure
Instrument
Instrument Clock
Instrument Date
Instrument Time
Device Information
Tag
Long Tag
Descriptor
Date
Message
Instrument Serial Number
Sensor Serial Number
Instrument Temperature
Units
Instrument
Temperature
Instrument Temperature Lower Limit
Instrument Temperature Upper Limit
Limit Switch
Limit Switch Setup
Limit Switch One
Limit Switch Two
Normal Position
Action
Trigger Point
Deadband
Limit Switch Status: Switch State
PV
PV High and Low Points for
Open/Close States
Direct or Reverse Action
PV Lower Alert Point
PV High Alert Point
PV Damping
Input Filter
Initial Setup
Calibrate
Calibrate Time Delay
Guided Setup Manual Setup
Location
Calibration Status
Calibration Date
Hours
Minutes
Person
Alert Setup
See figure 13
Configure

Instruction Manual
D104738X012
4400 Transmitter
October 2023
20
Temperature
Instrument Temperature Low
Instrument Temperature High
Instrument Temperature Sensor Alert
Sensors
Hall Sensor Alert
Hall Diagnostic
Reference Voltage Alert
Loop Readback Alert
Loop Readback Time
Analog Output Fixed
Analog Output Saturated
Memory
Program Memory Alert
RAM Error
Noncritical NVM Error
Critical NVM Error
Instrument
Watchdog Reset
Program Flow Error
Out Service
Electronics Error
Device Malfunction
Configuration Changed
Figure 13. Configure: Alert Setup
Calibration
Calibration Progress
Calibration Failed
Cycle Counter
Cycle Counter Alert
Alert Trigger
Travel Accumulator Alert
Alert Trigger
PV
Opening Stroking Time Deviation
Time Open Threshold
Closing Stroke Time Deviation
Time Close Threshold
PV Low Alert
PV Low Alert Point
PV High Alert
PV High Alert Point
Non-PV Out Limit
PV Out Limit
Logs
Event Log Full
Stroke Time Log Full
Alert Record Full
Alert Record Not Empty
Alert Setup
See Alert Setup Section, page 25
