1 Introduction
The Rosemount 327T Temperature Transmitter detects media temperature and converts
it into an analog output signal (4 - 20 mA). The temperature transmitter includes an IO-
Link interface for configuring parameter settings or viewing process and diagnostic data.
1.1 Getting started
Follow these steps to configure the temperature transmitter for normal operation.
Procedure
1. Connect the temperature transmitter to a PC to set parameters using IO-Link.
2. Set the standard unit of measurement in °F or °C (Uni). (See Adjustable parameters)
3. Set the analog signal. (See Analog function)
•OU2: I = 4-20 mA or Ineg = 20-4 mA
•ASP and AEP: scaling of the measuring range.
4. Configure Drift Monitoring. (See Setting range for drW and drA)
•drW: drift threshold at which the temperature transmitter signals "warning".
•drA: drift threshold at which the temperature transmitter signals "alarm".
•ddr: Drift Monitoring Diagnostic delay.
5. Set which diagnostic cases the temperature transmitter signals using drEd. (See
Diagnostic cases)
•ON: only failure diagnostic cases
•ONdr: alarm and failure diagnostic cases
•OFF: warning, alarm, and failure diagnostic cases
6. Configure analog signal for diagnostic cases (FOU2). (See Adjustable parameters)
•ON: 21.5 mA
•OFF: 3.5 mA
7. Configure switching signal for diagnostic cases in three-wire operation (dOU1). (See
Diagnostic function (three-wire))
•dOU1: Output opens, closes, or pulsates; according to configuration.
8. Configure output logic for diagnostic output in three-wire operation (P-n). (See
Adjustable parameters)
•pnp
•npn
9. Complete all other necessary parameter settings.
Quick Start Guide Introduction
00825-0100-4329 January 2019
Quick Start Guide 5

Postrequisites
Perform these tasks to complete setting up the transmitter:
•Mounting the transmitter
•Wire the Transmitter
•Operation
1.2 Functions and features
The temperature transmitter detects process temperature and converts it into an analog
output signal.
The temperature transmitter includes an IO-Link interface for configuring parameter
settings or viewing process and diagnostic data.
The transmitter operates in two-wire or three-wire operation modes. The modes produce
these output signals:
Operating mode Output signals
Two-wire Analog signal for temperature measurement and diagnostics
Three-wire •OUT1: switching signal for diagnostics and IO-Link communication
•OUT2: analog signal for temperature measurement and diagnostics
1.2.1 Analog function
The temperature transmitter converts the measured temperature value into an analog
signal proportional to the temperature.
The temperature transmitter also uses the analog output to send diagnostic messages
(see Diagnostic function). Diagnostic messages interrupt the transfer of the measured
temperature value depending on the operating mode and drEd. The transmitter modifies
the analog output to the following values according to NE43: 3.5 mA (FOU2 = On) or 21.5
mA (FOU2 = OFF).
Depending on the OU2 setting, the analog signal is between these measuring ranges in
normal operation:
•I: 4-20 mA
•Ineg: 20-4 mA
The measuring range is scalable using these parameters:
•ASP: the analog start point and the measured temperature when the analog signal is 4
mA (OU2 = I) or 20 mA (OU2 = Ineg)
•AEP: the analog end point and the measured temperature when the analog signal is 20
mA (OU2 = I) or 4 mA (OU2 = Ineg).
Note
The minimum difference between ASP and AEP is 9°F (5°C).
Introduction Quick Start Guide
January 2019 00825-0100-4329
6 Quick Start Guide

If the measured temperature value is outside the scaled measuring range, the analog
signal is 20-20.5 mA or 3.8-4 mA (see Figure 1-1). When the measured temperature value
continues to increase or decrease, diagnostic case 5 occurs. For more information, see
Diagnostic cases.
Figure 1-1: Analog output with factory settings
•1: Setting OU2 = I
•2: Setting OU2 = Ineg
•MAW: initial value of the measuring range
•MEW: final value of the measuring range
•ASP: analog start point
•AEP: analog end point
1.2.2 Diagnostic function
The temperature transmitter uses two different, thermally coupled sensor elements (NTC,
PT 1000) to automatically detect drifts and errors during temperature measurement.
The temperature transmitter forms an average value using the individual NTC and Pt 1000
measured values. That value determines the measured temperature value and is the basis
for Drift Monitoring Diagnostic (see Drift Monitoring).
The temperature transmitter can detect other errors. Use the parameter drEd to set which
diagnostic cases the temperature transmitter signals. For more information, see
Diagnostic cases.
The analog signal provides diagnostic case messages in two-wire operations. In three-wire
operations, the switching signal provides diagnostic case messages in addition to the
analog signal.
Quick Start Guide Introduction
00825-0100-4329 January 2019
Quick Start Guide 7

Drift Monitoring
For Drift Monitoring Diagnostic, the temperature transmitter compares the temperature
deviation of sensor element 1 (NTC) and sensor element 2 (Pt 1000) to the average
temperature value. The parameters drW (warning threshold) and drA (alarm threshold)
define the permissible temperature deviation.
When values exceed these thresholds, the temperature transmitter triggers drift
monitoring and identifies a fault (see Diagnostic cases).
Figure 1-2: Drift monitoring example
Example: NTC sensor element (1) measures 149 °F and Pt 1000 sensor element (2)
measures 140 °F. The average value (3) is 144.5 °F, i.e. both elements deviate by 4.5 °F.
With setting drW = 4 °F and drA = 9 °F, the temperature transmitter provides a warning
message if drEd = OFF. In this case, the temperature transmitter would not send an alarm
message.
For more information about configuring drW and drA, see Setting range for drW and drA.
Note
Temperature difference of at most 0.18 °F (0.1 °C) can occur with sensor elements
because of standard manufacturing tolerances. This does not affect the drift monitoring
diagnostic.
Note
Large temperature changes in the medium might cause short-term differences between
the measured temperature values of both sensor elements. To avoid short-term drift
warnings, increase the drift warning delay time (ddr).
Sensor backup
If one of the two sensors in the transmitter fails, the temperature transmitter can use the
remaining sensor for temperature measurement.
For more information on operating the temperature transmitter in backup mode, see
Troubleshooting.
Introduction Quick Start Guide
January 2019 00825-0100-4329
8 Quick Start Guide

Note
Drift monitoring is not possible if a sensor fails and sensor backup is active.
Diagnostic cases
The temperature transmitter identifies error scenarios with these diagnostic cases.
For more information on parameters relating to diagnostic cases, see Adjustable
parameters or Drift Monitoring.
Table 1-1: Warnings
Diagnostic number Description
1 The temperature deviation exceeded the drift warning threshold (drW).
2 The temperature of the internal electronics exceeded the limit of 257 °F
(125 °C).
Table 1-2: Alarms
Case number Description
3 The temperature deviation exceeded the drift alarm threshold (drA).
4 One of the two sensor elements failed.
5 The measured temperature value is outside the allowable measuring
range.
6 The supply voltage is outside the operating range.(1)
(1) For 2-wire operation, no diagnostic message is provided in case of low voltage (see Diagnostic
function (two-wire)).
Table 1-3: Failures
Case number Description
7 The temperature deviation exceeded the drift failure threshold (drF).
8 An error occurred while setting parameters using IO-Link.
9 Both sensor elements failed or general electronics problems.
Diagnostic function (two-wire)
In two-wire operation, the temperature transmitter uses the analog output for
temperature measurement and diagnostics.
drEd configures the diagnostic cases that the temperature transmitter signals using the
analog output:
•ON: Limits the diagnostic messages to only failure messages. The temperature
transmitter will signal only diagnostic cases 7-9.
•ONdr: Limits the diagnostic messages to alarm and failure messages. The temperature
transmitter will signal only diagnostic cases 3-9.
Quick Start Guide Introduction
00825-0100-4329 January 2019
Quick Start Guide 9

•OFF: Allows all diagnostic messages. The temperature transmitter will signal all
diagnostic cases.
For more information, see Diagnostic cases.
To signal a diagnostic case, the temperature transmitter interrupts the transfer of
temperature measurements and provides these analog outputs using FOU2:
•ON: 21.5 mA
•OFF: 3.5 mA
Note
In a two-wire operation, the temperature transmitter does not provide diagnostic
messages in the event of low voltage.
Diagnostic function (three-wire)
In three-wire operation, the temperature transmitter uses an analog output for
temperature measurement and a switching output for diagnostics and IO-Link
communication.
drEd configures which diagnostic messages the temperature transmitter uses to indicate
failures.
•ON: Signals only failure diagnostic messages for the analog and switching outputs
(cases 7-9).
•ONdr: Signals only failure diagnostic messages (cases 7-9) for the analog output and
alarm and failure diagnostic messages (cases 3-9) for the switching output.
•OFF: Signals only failure diagnostic messages (cases 7-9) for the analog output and all
diagnostic messages (cases 1-9) for the switching output.
Note
Using the switching output in three-wire operation for diagnostics results in the analog
output being disrupted only if a failure is seen. This ensures maximum use of the analog
output.
dOU1 is used to define how the diagnostic output reacts to diagnostic messages:
dOU1 Normal Warning Alarm and failure
Normally closed (nc) Closed Closed Open
Normally closed,
extended (nc+)
Closed Switching open/closed
at 2 Hz
2 Hz
Open
Introduction Quick Start Guide
January 2019 00825-0100-4329
10 Quick Start Guide

dOU1 Normal Warning Alarm and failure
Normally open,
extended (no+)
Open Switching open/closed
at 2 Hz
2 Hz
Closed
Heartbeat (Hb) Switching open/closed
at 4 Hz
4 Hz
Switching open/closed
at 2 Hz
2 Hz
Open
1.2.3 IO-Link
The IO-Link communication interface enables direct access to process and diagnostic data.
IO-Link can change parameter values without disrupting normal operation. Operating the
temperature transmitter using IO-Link interface requires an IO-Link capable device (IO-
Link master).
Using a PC, suitable IO-link software, and an IO-Link adapter cable enables communication
with the temperature transmitter when not in operation.
The IODDs necessary for configuring the unit, detailed information about process data
structure, diagnostic information, parameter addresses and the necessary information
about the required IO-Link hardware and software are available at Emerson.com.
Quick Start Guide Introduction
00825-0100-4329 January 2019
Quick Start Guide 11

Introduction Quick Start Guide
January 2019 00825-0100-4329
12 Quick Start Guide

2 Installation
This section provides instructions for mounting and connecting the temperature
transmitter.
2.1 Mounting the transmitter
This section provides instructions for mounting the temperature transmitter.
CAUTION
•Before installing or removing the temperature transmitter, ensure no pressure is
applied to the system and there is no medium present.
•Take measures to avoid dangers related to extreme machine and medium
temperatures.
2.1.1 Installing with G1 process connection
These process connection adapters are available.
•Adapter with sealing ring
•G1 flange
Note
The sealing ring on the transmitter acts as the process seal. The upper sealing area on
the process connection must be flush with the tapped hole and have a surface
characteristic of at least 21 Ra (0.81 Ra).
Note
Tighten the temperature transmitter to a torque of 25.81 ft/lb (35 Nm).
Follow these guidelines for adapters with a leakage port:
•Mount the temperature transmitter horizontally or slightly diagonally. Do not mount
the transmitter to the lowest point of the tank or pipe.
•Align the leakage port so that it is located at the lowest possible point.
Note
For more information about available adapters, see the Rosemount™ 327T Product Data
Sheet or visit Emerson.com.
•Follow the instructions included with the adapter.
•Use a suitable and approved lubricating paste for the application.
Quick Start Guide Installation
00825-0100-4329 January 2019
Quick Start Guide 13

2.1.2 Mounting in 3-A® environments
Follow these guidelines when installing the temperature transmitter in a 3-A compliant
environment.
•Use only adapters certified for use in 3-A environments.
•Do not mount the temperature transmitter at the lowest point of the tank or pipe.
Mounting the transmitter to a higher point allows the medium to run off the
transmitter.
2.2 Wire the Transmitter
Follow these steps to wire the transmitter for two-wire or three-wire operations.
CAUTION
•A certified electrician must wire the temperature transmitter.
•Adhere national and international regulations when wiring the temperature
transmitter.
Voltage supply to EN 50178, SELV, PELV / "supply class 2" to cULus.
Procedure
1. Disconnect power from the temperature transmitter.
2. Wire the temperature transmitter according to the diagrams below.
Figure 2-1: For two-wire operation:
•BN: Brown
•WH: White
•Pin 1: L+
•Pin 2: OUT (analog signal for temperature and diagnostics)
Installation Quick Start Guide
January 2019 00825-0100-4329
14 Quick Start Guide

Figure 2-2: For three-wire operation:
•BK: Black
•BN: Brown
•WH: White
•BU: Blue
•Pin 1: L+
•Pin 2: OUT2 (analog signal for temperature and diagnostics)
•Pin 3: L-
•Pin 4: OUT1 (switching signal for diagnostics and IO-Link
communication)
Quick Start Guide Installation
00825-0100-4329 January 2019
Quick Start Guide 15

Installation Quick Start Guide
January 2019 00825-0100-4329
16 Quick Start Guide

3 Operation
This section provides information for using the temperature transmitter.
3.1 Setting Parameters
These options are available when setting parameter values using IO-Link.
•Reading current process values.
•Reading, changing and saving current parameter settings and transmitting them to
other units of the same type.
•Read saved diagnostic information (see Troubleshooting).
Note
To configure the temperature transmitter, connect the temperature transmitter to a PC
using the IO-Link interface. For more information, go to Emerson.com.
3.1.1 Adjustable parameters
This table describes parameters that can be modified.
Parameter Description
Uni Sets the standard unit of measurement: °F or °C .
OU2 Configuration of the analog signal: I = 4-20 mA or Ineg = 20-4 mA
ASP Analog start point for measured temperature value
AEP Analog end point for measured temperature value
drW Drift warning threshold. If the temperature measurement exceeds the
deviation value, the temperature transmitter sends a warning diagnostic
message when drEd is set to OFF.
•°F/°C: Maximum permitted temperature deviation of both sensor elements
from the average value.
•OFF: Drift warning deactivated.
drA Drift alarm threshold. If the temperature measurement exceeds the deviation
value, the temperature transmitter sends an alarm diagnostic message when
drEd is set to ONdr or OFF.
•°F/°C: Maximum permitted temperature deviation of both sensor elements
from the average value.
•OFF: Drift alarm deactivated.
Quick Start Guide Operation
00825-0100-4329 January 2019
Quick Start Guide 17

Parameter Description
drF Drift failure threshold drF = drA + 5.4 °F (3 °C) . If the temperature
measurement exceeds the deviation value, the temperature transmitter sends
a failure diagnostic message.
Note
•The drF value is a result of the drA setting. drF cannot be set.
•Setting drA to OFF automatically results in: drF = 14.4 °F (8 °C)
ddr Delay of the drift detection. The time which the drift value must be above the
warning threshold drW or alarm threshold drA before the temperature
transmitter sends a diagnostic signal (0.5 - 300 minutes).
drEd Sets which diagnostic cases the temperature transmitter communicates.
•ON: Limits the diagnostic cases to "failure" cases.
•ONdr: Limits the diagnostic cases to "alarm" and "failure" cases.
•OFF: Limits the diagnostic cases to "warning", "alarm" and "failure" cases.
FOU2 Response of the analog signal when a diagnostic case occurs. Instead of the
measured temperature value, the temperature transmitter provides a defined
current value according to Namur NE43 (On: 21.5 mA; OFF: 3.5 mA).
dOU1 Response of the diagnostic switching output after a diagnostic case occurs.
The output opens, closes, or pulsates depending on the configuration.
P-n The switching logic for the diagnostic output: pnp or npn.
HI Displays the highest recorded temperature measurement.
LO Displays the lowest recorded temperature measurement.
Fnr Shows the fault number. For more information, see Troubleshooting.
rES Restores factory default settings.
Note
Record the current parameter settings before restoring the factory default
settings.
3.2 Operating mode
Eight seconds after applying power, the temperature transmitter is in run mode and is
operating within specifications. In run mode, the transmitter measures and evaluates
temperature and provides output signals according to parameter settings.
Operation Quick Start Guide
January 2019 00825-0100-4329
18 Quick Start Guide

4 Setting range for drW and drA
This table shows the allowable setting ranges for drW and drA depending on process
temperature.
Process temperature range Setting range
14 to 212 °F -10 to 100 °C 0.36 to 9 °F (0.2 to 5 °C)
-13 to 32 °F -25 to 0 °C 0.54 to 9 °F (0.3 to 5 °C)
> 212 °F > 100 °C [A] to 9 °F (5 °C)(1)
(1) See Figure 4-1 for the minimum value for [A].
Figure 4-1: Minimum setting ranges for drW and drA
A. Minimum value for drW and drA
B. Medium temperature
Note
•If the value for drW or drA is lower than the value [A], it changes automatically to the
value [A].
•In case of operation in gaseous media, the value should be greater than 0.6 °F (0.35 °C).
Quick Start Guide Setting range for drW and drA
00825-0100-4329 January 2019
Quick Start Guide 19

Setting range for drW and drA Quick Start Guide
January 2019 00825-0100-4329
20 Quick Start Guide
